Sharp ESX156 User manual

Thank you for purchasing our product.
承蒙购买本公司产品
深表谢意。
Please read this manual carefully before use.
Please read “Safety Precautions” carefully
before use.
Please keep this manual in a safe place.
Our product is intended for household use only.
使用前请务必阅读本说明书。
使用前请务必阅读“安全注意事项”。
使用后请保存好本说明书。
本公司产品专为家庭用户设计。
Operation manual
of full-automatic
washing machine
自动洗衣机使用说明书
20
9
22
11
24
12
25
13
26
14
27
C Panel F
How to Use Different Washing Programs
洗涤程序指南
Additional Functions
附加功能操作说明
Cleaning and Maintenance
清洁与维护操作指南
Troubleshooting
异常 故障确认与处理方法
Specifications
规格
Table of contents
目录
Page
页次
Safety Precautions
安全注意事项
Component Parts
各部分名称
How to Install
安装与调整指南
Things to Check Before Wash
洗衣前须知
Instructions Before Wash
洗衣前操作指南
ontrol unctions
操作面板说明
2
15
4
17
5
18
6
19
6
19
7
ESX156

Safety Precautions
WARNING
Do not allow children to play
with or look around the
washing • dehydration tub,
in case they fall into the tub,
they will get injured.
Clothing stained with harmful
diluting agents such as gasoline,
kerosene and so on must not be
put into the washing •
dehydration tub.
Do not use power supply other
than AC240V, 50Hz, so as to
avoid malfunction, damage and
fire.
Do not modify the machine (except
for professional repairmen). Please
do not disassemble and repair the
machine without permission, so as
to avoid fire, electric shock, getting
hurt or machine malfunctions.
To prevent electric shocks, fires,
malfunctions and distortions, do not
place the machine in a place with
high-humidity (such as
bathrooms), or where wind and
rain may get in.
Use a plug seat above 13A
separately. A loose plug seat or
the action of sharing a plug seat
with other apparatus may start a
fire due to heat.
While cleaning the machine body,
the plug should be pulled out first.
Do not plug or pull the plug with
wet hand or wet cloth, so as to
avoid electric shock.
Before the dehydration tub
completely stops, do not touch
the clothing being washed.
Even if the tub is running at
low speed, your hand may get
wrapped up and injured.
Special attention should be
paid to children.
Do not change the original
state of power cable. Any
artificial damage to the power
cable could cause electric
shock, electric leakage or
other malfunctions.
Do not use damaged power
cable, plug and loose plug
seat, so as to avoid short
circuit, electric shock, fires and
other accidents.
Do not wash components of
the machine, so as to avoid
short fires and electric shock.
Do not approach any fire source
near to a plastic component,
which has the risk of starting
a fire.
Clean the dust on the plug and
plug seat to avoid fire.
This machine is equipped with an
earthing plug. Changing the plug is
not allowed. If an earthing-type
receptacle is not available, customer
is obligated to have it installed by
qualified electrician.
To move the machine, carry
only by the its handle to avoid
any harm and damage.
If gas leak, do not plug or
unplug the machine. Do not
use any inflammable object
close to the machine.
2
FORBIDDEN
FORBIDDEN
FORBIDDEN TO TOUCH
PLUG OR PULL
THE PLUG
FORBIDDEN
FORBIDDEN
FORBIDDEN
FORBIDDEN
FORBIDDEN
FORBIDDEN TO
WASH WITH WATER
FORBIDDEN
FORBIDDEN TO
DISASSEMBLE
FORBIDDEN TO USE
AT HIGH-HUMUDITY
LOCATIONS.
MANDATORY
MANDATORY
MANDATORY
27
ESX156
15.0kg
650x670x1040
50

Safety Precautions
CAUTION
Do not wash clothing treated for water
resistance. Do not wash sleeping bags,
bath curtains, raincoats, rain ponchos, rain
covers, ski jackets, ski pants, automobile
covers and other water-resistant clothing,
so as to avoid abnormal vibration and
other unexpected accidents.
During dehydration, the washing
machine is rotating at high speed.
Because water in water-resistant
clothing could not be discharged
instantaneously, the machine will be out
of balance, causing abnormal vibration
and other unexpected accidents.
Do not wash objects other than
clothing, such as cabbage, sweet
potato, kelp, shoes and so on, so
as to avoid abnormal vibration
and causing damage to the machine.
Water temperature must
not exceed 60 C, so as to avoid
accidents of electric leakage and
electric shock due to distortion or
damage of plastic.
While pulling out or plugging the
plug, do not touch the metal part
of the plug, so as to avoid electric
shock or short circuit.
After using the washing machine,
please pull out the plug, so as to
avoid electric leakage, electric
shock or fire due to loose
connection of plug.
Please use the provided water
inlet hose and drain hose, do
not reuse old hose.
Before using, check carefully if
the connection of water inlet
hose or drain hose is reliable,
so as to avoid water leakage.
While the machine is running,
do not touch the bottom with
hand or foot, where there’s a
rotating mechanism, so as to
avoid getting hurt.
Before using, check the bottom
of the product. Make sure there is
no packaging material such as
plastic holder still attached on the
visible parts. Then only install the
bottom cover.
Do not place heavy things on the
machine, so as to avoid distortion
and damage.
After using, please turn off the
tap to avoid water leakage.
The base opening must not be
obstructed by carpeting when
the washing machine is
installed on a carpeted floor.
When connected to water tap,
follow the instructions stated to
connect the water inlet hose.
Make sure inlet hose and water
tap connect properly. Do not
frequently remove inlet hose.
Do not pull or twist drain hose.
CAUTION
• To avoid danger, if the soft power cable is damaged, it must be replaced by the manufacturer, its
maintenance department or a qualified personnel.
• If powder detergent or liquid detergent adheres to a plastic component such as the top cover, wipe
it away immediately; otherwise it may damage the plastic component.
• Please wash the filter frequently to keep the washing efficiency.
3
MANDATORY
MANDATORY
MANDATORY
MANDATORY
MANDATORY
MANDATORY
MANDATORY
FORBIDDEN
FORBIDDEN
FORBIDDEN
FORBIDDEN TO TOUCH
FORBIDDEN
CAUTION
DO NOT PUT
WATER-RESISTANT
CLOTHING INTO
THE BARREL
26
异常表示
常见非故障现象

2.将过滤网袋取出并往反方
向拉出清洗干净后归位。
Component Parts
List of accessories
Item Quantity
Water inlet hose assembly
1 set
Drain hose assembly
1 set
Screw 1 pc
Bottom cover 1 pc
Operation manual 1 pc
Warranty card
1 pc
Unit
4
Lint Filter
Control Panel
Top Lid
Water Inlet Valve
Detergent Box
Power Cord
Drainage hose
Pulsator
Cabinet
Adjustable
Feet
注意
25
日常保养
注意 注 意
每周最少清洗一次
Liquid Detergent
Dispenser
Liquid Detergent
Dispenser
Powder
Detergent
Dispenser
Powder
Detergent
Dispenser
Softener
Dispenser
Softener
Dispenser

1.Slowly lean the unit facing up/down on soft object.
2.Push the bottom cover into the base slot.
3.Use the screw to fix the bottom cover onto the base
of body (a small hole in the middle of the
bottom cover), then slowly lift up the unit.
How to Install
Installing the bottom cover
1.Install the washer, adjust the Adjustable Feet if
surface is not level. The distance between the
tub and cabinet should be the same (left & right,
front & back).
2.Distance between washer and wall should be at
least 5cm.
Placing the washer
Connect the drain hose to drain outlet, then secure
it with the metal clamp.
1. Do not seal the drain hose in the sewer pipe
to avoid poor drainage or no drainage.
2. In case of extending the drain hose, do not
exceed 3m to avoid long drainage time.
3. The height of the drain hose should not be
more than 10cm.
Installing the drain hose
Installing the water inlet hose
1. The joint of water inlet hose consists
of 2 parts, adapter and collar.
2. Pull down the collar of the inlet hose
to remove the adapter.
3. Loosen connectors A and B.
1.Length of the faucet need to be at least 10mm, outer diameter need to be 24mm and below.
2.If a suitable faucet is installed, an adapter is not necessary to be installed.
3.Spout of faucet should be smooth and round.
4.If spout of faucet is not flat, scrape it with rasp until it is flat.
5.Remove liner if outer diameter of faucet is too big.
5
Note
Note Do not place washer on stage to avoid overturn. When placing washer on carpet, make sure
carpet does not block air vents.
front/back
back/front
soft object
bottom cover
Distance between
dehydration tub and
cabinet should be same
adjustable
feet
metal clamp
adapter
adapter
adapter
collar
collar loop
nut
screw
about 5mm
liner
dehydration tub
cabinet
24
注意
桶洗净操作方式
按压“电源”键接通电源后，按压“附加”键直至桶
洗净灯点亮，按压“启动/暂停”键洗衣机开始工作。
TUB
CLEAN

Things to Check Before Wash
Installing the water inlet hose
1.The capacity of Wash and Spin program refers to the maximum weight of dry
clothes that Wash and Spin program can take on.
2.Different types of fabric and size will affect the washing performance, put an
adequate amount of clothes to ensure a good rotation for a more effective wash.
3.Remove coins, keys, and other hard objects, ensure zippers are fastened and buttons
are buckled to avoid scratching the interior of washing machine.
4.To wash wool and delicate clothing, use washing mesh bag.
5.
6. The amount of softener and liquid detergent shall not exceed the top of siphon cap.
Sort out colorfast items and heavily soiled items to wash them separately.
Instructions Before Wash
1.Connect water inlet hose properly, turn on water tap, put down the drain hose.
2.Before plugging in the power cord, make sure the socket is earthed.
3.Check the care label to see whether the clothes is suitable to wash by a washer.
4.Load washing machine properly, add measured detergent and softener.
5.Close the lid.
4. Loosen the four screws on connector A, fit it into the water
tap. Push up the adapter so that the rubber seal can attach
to the water tap tightly, then screw evenly.
5. Screw connector B tightly so that rubber seal can attach to
water tap tightly, to avoid leaking.
6. To attach: Pull the collar down until you see four metal
balls, fit it into the adapter, let go the collar after it is fixed.
To detach: Turn off the water tap, pull down the collar and
remove the adapter.
7. Tighten the other end of the inlet hose to the water inlet of
washer.
Caution: Tighten the nut by fastening evenly. Do not twist
the hose to avoid hose cracking.
8. Turn on water faucet. If collar part is leaking, please check: (a) Is the nut of connector B screwed properly? (b) Is distance
between connector A and B less than 5mm, causing rubber seal in adapter not to seal with water faucet? (c) Is head of water
tap flat? (d) Is adapter A screwed properly? (e) Is adapter slant causing rubber seal not to seal properly on water faucet?
6
nut
Water inlet
hose
23
注意 1.可 选水 位极 低-中段 。适用于洗涤少量比较干净的衣物。
2.使 用过 量洗 涤剂将导致洗涤剂残留在衣物上。
3.建 议根 据衣 物量来调节洗涤剂的用量。

POWER:
CAUTION:
START/PAUSE:
*STANDARD:
HEAVY:
GENTLE:
QUICK WASH:
SOAK:
WASH:
RINSE:
SPIN:
SAFETY LOCK:
Plug the power cord, press this buon, the power will be connected. Press this
buon again to shut the power off.
1. Press POWER buon to acvate power, it will turn off automacally aer 5
minutes of inacvity.
2. Press START/PAUSE buon when machine operates, it will turn off
automacally aer 10 minutes of inacvity.
Connect power and press this buon, the chosen program will start running.
Press again, chosen program will pause.
Default program, suitable for daily soiled clothing like shirt and pants.
Strong washing flow, suitable for towel and other heavy clothing.
Suitable for silk or other delicate clothing.
Low water level, suitable for less dirty or light clothing.
An addional washing program, only suitable for STANDARD and HEAVY mode.
Aer selecng, SOAK will light up together with the chosen program. Display
shows “JP”. When soaking, tub rotates disconnually. Soaking me sets
automacally according to water level, manual seng is not available. Soaking
me for water level LOW and E.LOW:20 minutes; water level HIGH and MID:30
minutes.
Select for wash program.
Select for rinse program.
Select for spin program.
All buons will not funcon under safety lock mode, except to unlock. Alarm
beeps when lid is open under safety lock mode. For safety purpose, washer will
drain the water if lid opens for too long.
This funcon is to wash the inner tub, do not put any clothes when you
acvate this funcon. For beer cleaning result, you may add detergent
for cleaning tub.
Control Panel Functions
Control Panel
722
WATER LEVEL:
PRESET:
Choose the suitable water level according to load size. (E.LOW~HIGH)
Select suitable preset me (1~24 hours).
Preset me is to decide when to start washing. If the schedule me is set 1 hour,
program will start washing aer 1 hour. PRESET is an addional funcon on top
of other features.
TUB
CLEAN
TUB CLEAN:
1.无水位调节功能。
2.自动设置为高水位。
注意
*Power on, press PROGRAM buon for 3 seconds (there will be a sound of “beep”, water level will be in HIGH).
Then press START to enter Water Efficiency mode. This nominated mode is recommended for normally soiled load equal
to the rated capacity in the product literature.
・Fuzzy program starts display with “- -“
・When program is running, display shows remaining me (Rem) in “minute”
・When PRESET mode operang, display shows preset me (Preset) in “hour”
・When SOAK mode operang, display shows “JP”
・When error occurs, display shows error code, see page 13

Things to Check Before Operating Your Washing Machine
•When selecting a washing program, choose the water level according to load size.
May choose different water levels for different programs.
•Once START/PAUSE button pressed (washing program running), the selected
program cannot be changed. To change washing program, turn the power off then
turn on again.
•The indicator light blink while program is running. Indicator light will light up when
program is selected.
•
•
•
•
•
Guide for operation buttons:
1.Other than POWER button, the rest of the button do not work when the
washer is beeping; PRESET is working; or wash course ends.
2.When washer is paused, PRESET button will not function.
•To avoid washer overheat which could cause thermostat to operate, please do not
continuously run the washer more than
At the beginning of washing, if desired, you may add fabric softener to the softener
inlet.
During the rinsing process, do not open the tub cover. On the contrary, softener will
be put in ahead of time, and it will affect the result.
If the concentrated softener is used, dilute it with water one third of its original
concentration before pouring it into the softener inlet.
Do not leave softener in the softener inlet for long periods, it may agglomerated.
Do not mix softener with other detergent, it may cause chemical reaction.
3 cycles.
CAUTION: While thermostat is operating, washer will stop functioning. Washer will resume
to normal when its temperature decreases.
8 21
Min
Hour
13
注意
操作部 显示部
This appliance is not intended for use by persons(including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety. Children should be supervised
to ensure that they do not play with the appliance.
如未在他人陪同或指导下，身体，感官或精神有缺陷者，儿童，经验缺乏者，都不得使用洗衣
机。且需确保儿童不将洗衣机作为玩物进行玩耍。
若洗衣时，您需要添加柔顺剂，可在洗衣前，将适量柔顺剂倒入柔顺剂
注入 口内 。
在脱 水过 程中 ，请 不要打开上盖。反之，柔顺剂会提前流入桶内，影响其效果。
使用 柔顺 剂若 为浓 缩型，请用3倍的水稀释后使用。
请不要让柔顺剂在柔顺剂注入口的放置时间过长，以避免柔顺剂结块。
柔顺剂不可与洗涤剂混合后使用，会发生化学反应。
Usage of Softener
•Fuzzy program starts display with“- - ”
•When program is running, display shows remaining time (Rem) in “minute”
•When PRESET mode operating, display shows preset time (Preset) in “hour”
•When SOAK mode operating, display shows “JP”
•When error occurs, display shows error code, see page 13

How To Use Different Washing Programs
Standard Program
1. Switch power on. 2. Select Standard course by
pressing Program button. (For
soak, select Standard + Soak)
3. Select water level by
pressing Water Level
button
4. Press Start /Pause
button.
5. Washing course ends with beeping sound. Power shuts off after 30s.
Gentle Program
1. Switch power on. 2. Select Gentle course by
pressing Program button.
3. Select water level by
pressing Water Level
button
4. Press Start /Pause
button.
5. Washing course ends with beeping sound. Power shuts off after 30s.
Select water level from E.Low~High, suitable for soiled items like shirt and pant.
Select water level from Low~High, suitable for silk and other delicate clothing.
9 20
注意
操作部 显示部
此功能为了清洁内桶，使用桶洗净程序时，不得放入任何衣物，放入
适量清洗剂，效果更佳。
桶洗净：
TUB
CLEAN
Heavy Program
1. Switch power on. 2. Select Heavy course by pressing
Program button. (For soak, select Heavy +
Soak)
3. Press Start /Pause button.
4. Washing course ends with beeping sound. Power shuts off after 30s.
Suitable for blankets and other big and heavy clothing.
Note:
1. Water Level setting is not available for this program.
2. Automatically set to High water level.

How To Use Different Washing Programs
Quick Wash Program
1. Switch power on. 2. Select Quick Wash course
by pressing Program button.
3. Select water level by
pressing Water Level
button
4. Press Start /Pause
button.
5. Washing course ends with beeping sound. Power shuts off after 30s.
Wash/Spin Program
5. Washing course ends with beeping sound. Power shuts off after 30s.
Rinse Program
1. Switch power on. 2. Select Rinse, Spin course by
pressing Program button.
3. Select water level by
pressing Water Level
button
4. Press Start /Pause
button.
5. Washing course ends with beeping sound. Power shuts off after 30s.
1. Switch power on. 2. Select Wash/Spin course
by pressing Program
button.
3. Select water level by
pressing Water Level button.
(Water Level selection is not
available for Spin mode.)
4. Press Start /Pause
button.
10 19
1.Select water level from E.Low-Mid. This program is suitable for small load size and cleaner clothing.
2.Too much of detergent will result in residual left on clothes.
3.It is advisable to adjust dosage of detergent according to load size.
Note
柔顺剂和洗涤剂注入量不得超过虹吸帽顶部

10
Additional Functions
Preset Function
1. Switch
power on.
2. Select washing
course by pressing
Program button.
3. Select water level
by pressing Water
Level button
5. Press Start /Pause
button.
6. Preset start.
7. When display showing remaining time, preset is end. (Preset lights off, Rem lights on)
8. Washing course end with beeping sound, power shut off after 30s.
Safety Lock Function
Tub Clean Function
While washing course is operating , press Preset and Add. button
Switch power on, press "Add" button to select Tub Clean.
Press START/PAUSE button to activate tub clean function.
together until the Safety Lock lights up to activate safety lock
function. To deactivate, repeat the same step until the light goes
off.
Fuzzy Function
1. Switch power on. 2. Select Standard course by pressing
Program button.
3. Press Start/Pause button.
4. Washing course ends with beeping sound. Power shuts off after 30s.
Caution: Pressing Water Level button while washing course is operating will cancel Fuzzy Function.
4. Select preset time by
pressing Preset button
(display showing preset
time)
Sensor device detects load size and optimizes the washing condition such as water level, washing course, and
washing time. Pressing the water level button or selecting other washing course before starting a wash will cancel
Fuzzy Function. To use Fuzzy Function, please ensure there is no water or very less water in the tub.
Suitable for Standard program only. Switch on power and press Start/Pause button.
11 18
注意
注意
注意
TUB
CLEAN

Cleaning and Maintenance
1.After wash course ends, turn off the water tap, shut the power off. Remove water
inlet hose if necessary.
2.Please drain the tub completely. Make sure the tub is dry and there is no water
residue.
3.Unplug the washer before maintenance.
4.Hang the hose and power cord properly.
5.Use a soft cloth to wipe away the water and stain inside the tub, open the lid for 1
hour then close the lid back.
6.Use a soft cloth to clean the water and stain on the washer body. To avoid damage
to the body, do not use detergents, solvents , etc.
Maintenance
Cleaning Lint Filter
Cleaning Water Inlet
1. Shut off the
water faucet,
lift the hose
up.
2. Switch power on,
press Water Level
button.
3. Press Start/Pause
button.
Caution: Switch
power off after few
seconds.
5. Clean the inlet
valve filter.
Caution: The filter
can be removed and
washed.
4. Remove water inlet
hose.
Caution: Do not twist
the hose.
After long usage time, water inlet filter may be blocked by dirt. Please follow instructions below to clean the filter:
1. Detach the filter from the
washing machine.
2. Remove the net from the filter and
turn it inside out. Clean the net with
clean water and restore it to the filter.
3. Attach the filter back into
the washing machine.
Proper care of your washer can extend its life.
12
Clean it at least once a week.
water inlet valve
本机
附件清单
17
洗涤剂盒
螺钉
洗涤液
投放盒
洗衣粉
投放盒
柔顺剂
投放盒

Phenomenon Possible reason and solution
Program stops during WASH/RINSE mode Water detector is working, it is normal.
Water inlet during WASH/RINSE mode Water detector detects low water level, inlet water automatically.
Program stop after WASH/RINSE mode Spin mode delay, it is normal.
When spinning, tub rotates discontinuously Program designated to be intermittently paused.
During SPIN mode, tub knocking and water start supply and
enter RINSE mode
Unbalance spinning causes program to autocorrect and resume, it is
normal.
Sounds of water flowing after SPIN mode end It is the sound of the fluid inside balance ring, it is normal.
Control panel heating up The memory part of PWB heating up, it is normal.
Operation button not working Pressing too soft.
SAFETY LOCK mode is on, deselect it.
Troubleshooting
Some of the circumstances may not be a
please contact our service department, do not try to disassemble the washer or repair the washer
by yourself.
fault, please check before sending for repairs. If it is a fault,
Display Problem Solution Reason Summary of
Reason
•Water supply is too low.
•Water faucet is shut off.
•Filter net of water Inlet valve
jammed.
•Increase water supply.
•Turn on the water faucet.
•Wash the filter net, remove blockage,
press the START/PAUSE button.
①②
③④
⑤⑥
① Pipe leaking
②PWB
breakdown
③Inlet valve
breakdown
④Circuit board
breakdown
⑤Connection of
control panel
loosen off
⑥Water level
sensor breakdown
⑦Safety lock
breakdown
⑧Drainage system
breakdown
⑨Retractor
breakdown
⑩Connection of
retractor loosen off
•Water level exceeded the highest
limit of the tub.
•Abnormal water level.
•Program will automatically adjust the
water level and resume function.
②④
⑤⑥
•Lid open when running PRESET
mode.
•Lid is not close when Spin mode is
operating.
•Close the lid. ②④
⑤⑦
•Washing machine incline.
•Clothes is collected on one side,
causing unbalanced spin.
•Adjust the adjustable leg.
•Open the lid and distribute the clothes
evenly.
④⑤
⑦
•Draining position is relatively high.
•Drainage hose is frozen or blocked.
•Drainage hose is bent, squeezed,
tangled.
•Lower down the drain hose, press
START/PAUSE button.
•Defreeze/unblock drainage hose, press
START/PAUSE button.
•Smooth out drainage hose, press
START/PAUSE button.
②④
⑤⑥
⑧
⑩
⑨
• Lid is not close when safety lock is
on.
•Close the lid in 10s and program will
resume itself; if lid is still open after 10s,
machine will start draining. To resume,
deselect SAFETY LOCK mode.
②④
⑤⑦
Common non-fault phenomenon
13
E1
E2
E3
E4
E5
E7
55
16
注意
注 意
CAUTION:

Specifications
Inspecting a washing machine that has been used for many years.
Are there
situations
like these?
•Doesn't run sometimes.
•When spinning, lid cannot be locked.
•Water leak (water hose, spinning tub, tap connection).
•There s a burning smell.'
•There s an abnormal sound or vibration during running.'
•Your hand feels numb while touching the machine.
•Power cable or plug is unusually hot.
Check
To avoid a fault or an accident, please pull out the plug from
the plug seat.
Be sure to entrust the maintenance department to check it,
and consult the maintenance department for check and repair
fees.
Stop using
the machine
To consistently improve quality of our products, we reserve the right to modify product
specifications without prior notice. We appreciate your kind understanding and continuously
strive to exceed customers' expectations.
14 15
240V
13A
13A
警 告
Model Name
≤62dB(sound power level)
≤72dB(sound power level)
Capacity
Wash Noise
Spin Noise
Operating Water Pressure
Net Weight(kg)
Dimension (WxDxH)
ESX156
15.0kg
650x670x1040
50
