Galaxy G8 User manual

1
®
®
®
®
®
POPCORN
POPPERS
MODELS
G8, G8-AT
G12, G12-AT
G14, G14-AT
G18, G18-AT
Installation and
Operation
Instructions
2M-Y8351 Rev. O 12/12/2011
G14-AT

2
2
These symbols are intended to alert the user to the presence of
important operating and maintenance instructions in the manual
accompanying the appliance.
RETAIN THIS MANUAL FOR FUTURE REFERENCE
NOTICE
Using any part other than genuine Star factory supplied parts relieves the
manufacturer of all liability.
Star reserves the right to change specications and product design without
notice. Such revisions do not entitle the buyer to corresponding changes,
improvements, additions or replacements for previously purchased
equipment.
Due to periodic changes in designs, methods, procedures, policies and
regulations, the specications contained in this sheet are subject to change
without notice. While Star International Holdings Inc., Company exercises
good faith efforts to provide information that is accurate, we are not
responsible for errors or omissions in information provided or conclusions
reached as a result of using the specications. By using the information
provided, the user assumes all risks in connection with such use.
MAINTENANCE AND REPAIRS
Contact your local authorized service agent for service or required maintenance.
Please record the model number, serial number, voltage and purchase date in the area below and have it ready when
you call to ensure a faster service.
SAFETY SYMBOL
Model No.
Serial No.
Voltage
Purchase Date
Business 8:00 am to 4:30 p.m. Central Standard Time
Hours:
Telephone: [phone]
Fax: [phone]
E-mail [email protected]
[email protected]
W[email protected]
Website: www.star-mfg.com
Service Help Desk
Authorized Service Agent Listing
Reference the listing provided with the unit
or
for an updated listing go to:
Website: www.star-mfg.com
E-mail [email protected]
Mailing Address: Star International Holdings Inc., Company
10 Sunnen Drive
St. Louis, MO 63143
U.S.A

3
PRODUCT IDENTIFICATION
Star Manufacturing International Popcorn Machines
Galaxy Models: G8, G8-AT, G12, G12-AT, G14, G14-AT, G18 and G18-AT
SPECIFICATIONS
MODEL G8 8 oz. Electric Model
Capacity: 8 oz. (230g) All Steel Kettle, 170 one ounce (28g) servings per hour
Electrical: 120 volt, 60 hertz, single phase, 1736 watts, 14.4 amps
230 volt, 50 hertz, single phase, 1595 watts, 6.93 amps
Dimensions: 21-1/8"D x 21-1/8"W x 35-1/2" H (53.66cm D x 53.66cm W x 90.17cm H)
Net Weight: 87 lbs. (39.5 Kilograms)
MODEL G8-AT 8 oz. Antique Electric Counter Model
Capacity: 8 oz. (230g) All Steel Kettle, 170 one ounce (28g) servings per hour
Electrical: 120 volt, 60 hertz, single phase, 1736 watts, 14.4 amps
230 volt, 50 hertz, single phase, 1595 watts, 6.93 amps
Dimensions: 23-3/16"D x 23-3/16"W x 40-5/8"H (58.90cm D x 58.90cm W x 103.19cm H)
Net Weight: 94 lbs. (42.7 Kilograms)
MODEL G12 12 oz. Electric Model
Capacity: 12 oz.(340g) All Steel Kettle, 240 one ounce (28g) servings per hour
Electrical: 120 volt, 60 hertz, single phase, 2136 watts, 17.8 amps
240 volt, 50/60 hertz, single phase, 2136 watts, 8.9 amps
230 volt, 50 hertz, single phase, 1962 watts, 8.53 amps
Dimensions: 21-1/8"D x 21-1/8"W x 35-1/2"H (53.66cm D x 53.66cm W x 90.17cm H)
Net Weight: 87 lbs. (39.5 Kilograms)
MODEL G12-AT 12 oz. Antique Electric Counter Model
Capacity: 12 oz.(340g) All Steel Kettle, 240 one ounce (28g) servings per hour
Electrical: 120 volt, 60 hertz, single phase, 2136 watts, 17.8 amps
240 volt, 50/60 hertz, single phase, 2136 watts, 8.9 amps
230 volt, 50 hertz, single phase, 1962 watts, 8.53 amps
Dimensions: 23-3/16"D x 23-3/16"W x 40-5/8"H (58.90cm D x 58.90cm W x 103.19cm H)
Net Weight: 94 lbs. (42.7 Kilograms)
MODEL G14 14 oz. Electric Model
Capacity: 14 oz. (400g) All Steel Kettle, 280 one ounce (28g) servings per hour
Electrical: 120 volt, 60 hertz, single phase, 2416 watts, 20.13 amps
240 volt, 50/60 hertz, single phase, 2416 watts, 10.0 amps
230 volt, 50 hertz, single phase, 2219 watts, 9.65 amps
Dimensions: 24-1/8"D x 28-1/8"W x 35-1/2"H (61.28cm D x 71.44cm W x 90.17cm H)
Net Weight: 107 lbs. (48.6 Kilograms)
MODEL G14-AT 14 oz. Antique Electric Counter Model
Capacity: 14 oz. (400g) All Steel Kettle, 280 one ounce (28g) servings per hour
Electrical: 120 volt, 60 hertz, single phase, 2416 watts, 20.13 amps
240 volt, 50/60 hertz, single phase, 2416 watts, 10.0 amps
230 volt, 50 hertz, single phase, 2219 watts, 9.65 amps
Dimensions: 26-3/16"D x 30-3/16"W x 40-5/8"H (66.52cm D x 76.68cm W x 103.19cm H)
Net Weight: 114 lbs. (51.8 Kilograms)

4
SPECIFICATIONS CONT
MODEL G18 18 oz. Electric Model
Capacity: 18 oz. (510g) All Steel Kettle, 360 one ounce (28g) servings per hour
Electrical: 240 volt, 50/60 hertz, single phase, 2816 watts, 11.73 amps
230 volt, 50 hertz, single phase, 2587 watts, 11.25 amps
Dimensions: 24-1/8"D x 28-1/8"W x 35-1/2"H (61.28cm D x 71.44cm W x 90.17cm H)
Net Weight: 107 lbs. (48.6 Kilograms)
MODEL G18-AT 18 oz. Antique Electric Counter Model
Capacity: 18 oz.(510g) All Steel Kettle, 360 one ounce (28g) servings per hour
Electrical: 240 volt, 50/60 hertz, single phase, 2816 watts, 11.73 amps
230 volt, 50 hertz, single phase, 2587 watts, 11.25 amps
Dimensions: 26-3/16"D x 30-3/16"W x 40-5/8"H (66.52cm D x 76.68cm W x 103.19cm H)
Net Weight: 114 lbs. (51.8 Kilograms)
OPERATING CONTROLS
The operating controls are located above the serving doors.
Kettle heat switch - turns on heat in the kettle and the corn agitator motor.
Corn freshener heat lamp - turns on the heat lamp and heating element under the corn pan.

5
GENERAL INSTALLATION DATA
CAUTION
This equipment is designed and sold for commercial use only by personnel trained and experienced
in its operation and is not sold for consumer use in and around the home nor for use directly by the
general public in food service locations.
Before using your new equipment, read and understand all the instructions & labels associated with
the unit prior to putting it into operation. Make sure all people associated with its use understand the
units operation & safety before they use the unit.
All shipping containers should be checked for freight damage both visible and concealed. This
unit has been tested and carefully packaged to insure delivery of your unit in perfect condition. If
equipment is received in damaged condition, either apparent or concealed, a claim must be made
with the delivering carrier.
Concealed damage or loss - if damage or loss is not apparent until after equipment is
unpacked, a request for inspection of concealed damage must be made with carrier within
15 days. Be certain to retain all contents plus external and internal packaging materials for
inspection. The carrier will make an inspection and will supply necessary claim forms.
INSTALLATION
Each machine has been properly wired and inspected at the factory for operation on the voltage and
type of current specied on the nameplate.
CAUTION
DO NOT CONNECT TOANY OTHER TYPE OF CURRENT OR THE MACHINE WILL
BE SERIOUSLY DAMAGED.
A receptacle is furnished with the G12 120 volt and G14 120 volt popcorn machines.
We strongly recommend installation by a licensed electrician. The guarantee of this machine as
covered by the warranty does not apply if an improper installation has been made.
120 VOLT MACHINES
Machines with a nameplate stamped 120V, are equipped for operation on 120 volt 60 hertz AC single
phase service and must be connected to a separate 20 amp circuit with a 3 wire grounded, polarized
receptacle. NOTE: The G14 120V machine uses a 30 amp circuit.
240/230 VOLT MACHINES
Machines with a nameplate stamped 240V, are equipped for operation on 240 volt 50/60 hertz AC
single phase service. Machines with a nameplate stamped 230V, are equipped for operation on 230
volt 50 hertz AC single phase service. All must be connected to a separate 15 amp circuit with a 3
wire grounded, polarized receptacle.
