Sheffield PL618 User manual

ELECTRONIC
DEHUMIDIFIER

AFTER SALES SUPPORT
Email: [email protected]
Phone: [phone] - Mon-Fri 8:30am –4.30pm Page 1
CONTENTS
02 Welcome
03 Package Contents
03 Technical Specifications
04 Important Safety instructions
09 Assembly and parts
11 Instructions
14 Cleaning and Maintenance
16 Troubleshooting

AFTER SALES SUPPORT
Email: [email protected]
Phone: [phone] - Mon-Fri 8:30am –4.30pm Page 2
WELCOME
Congratulations on choosing to buy a Sheffield product.
All products brought to you by Sheffield are manufactured
to the highest standards of performance and safety, and, as
part of our philosophy of customer service and satisfaction,
are backed by our comprehensive 24 Month warranty.
We hope you will enjoy using your purchase for many years
to come.

AFTER SALES SUPPORT
Email: [email protected]
Phone: [phone] - Mon-Fri 8:30am –4.30pm Page 3
PACKAGE CONTENTS
1 x Dehumidifier
1 x Instruction Manual
1 x Warranty Card
Confirm all parts before disposing of the carton. Safely
dispose of all plastic bags and other packaging components.
They may be potentially dangerous to children.
TECHNICAL SPECIFICATION
Model: PL618
Rated voltage: 220-240V~50Hz
Rated Power max.: 185W
Protection class: I
Refrigerant: R290a / 55g
Moisture Removal: 12L/D (30oC 80%RH)
7L/D (26.7oC 60%RH)
Water Tank: 2L
Size (W x H x D): xxx*xxx*xxxmm
Weight: 11kg
Operating Temperature: 5oC - 35oC
Sound Pressure Level: ≤36dB(A)

AFTER SALES SUPPORT
Email: [email protected]
Phone: [phone] - Mon-Fri 8:30am –4.30pm Page 4
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
Carefully read this manual before using this appliance.
Ensure that you know how the appliance functions and how to operate it.
Maintain the appliance in accordance with the instructions to ensure that
it functions properly.
Keep this manual with the appliance. If the appliance is to be used by a
third party, this instruction manual must be supplied with it.
The safety instructions do not by themselves eliminate any danger
completely and proper accident prevention measures must always be
used.
No liability can be accepted for any damage caused by non-compliance
with these instructions or any other improper use or mishandling.
Do not use this appliance if it has been dropped or damaged in any way, or if
the supply cord is damaged.
warning
This unit uses a flammable refrigerant.
If refrigerant leaks and comes in contact with fire or heating
part, it will create harmful gas and there is risk of fire.
Read the USER MANUAL carefully before operation.
Further information is available in the USER MANUAL,
SERVICE MANUAL, and the like.
Service personnel are required to carefully read the USER
MANUAL and SERVICE MANUAL before operation.

AFTER SALES SUPPORT
Email: [email protected]
Phone: [phone] - Mon-Fri 8:30am –4.30pm Page 5
Intended Use
Indoor domestic use only: this appliance is intended for indoor domestic
use only. Do not use it outdoors. Do not use it in moving vehicles or
boats.
Do not use it for commercial or industrial use.
Intended Purpose: Do not use the appliance for anything other than its
intended purpose, and only use it as described in this manual
This appliance is intended to be used in household and similar applications
such as
Staff kitchen areas in shops, offices and other working environments.
Farm houses.
By clients in hotels, motels and other residential type environments.
Bed and breakfast type environments.
When using electric appliances always observe safety regulations where
applicable to reduce the risk of fire, electric shock and personal injury.
Always check that the power supply corresponds to the voltage on the rating
plate.
WARNING: Any person who is involved with working on or
breaking into a refrigerant circuit should hold a currently valid
certificate from an industry-accredited assessment authority, which
authorises their competence to handle refrigerants safely in
accordance with industry, recognized assessment specifications.
Warning: This unit uses a flammable refrigerant. R290 (propane)
If refrigerant leaks and comes in contact with fire or heating part, it will create
harmful gas and there is a risk of fire.
Read the USER MANUAL carefully before operation.
Service personnel are required to carefully read the USER MANUAL before
operation.
Servicing shall only be performed as recommended by the
equipment manufacturer. Maintenance and repair requiring the
assistance of other skilled personnel shall be carried out under the
supervision of the person competent in the use of flammable
refrigerants.
If you don't understand something or need help, please contact the
after sales support.

AFTER SALES SUPPORT
Email: [email protected]
Phone: [phone] - Mon-Fri 8:30am –4.30pm Page 6
Supply Cord and Plug
Always unplug from mains supply when not in use. Do not abuse or damage
the power cord. If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified person in order to
avoid a hazard.
Do not turn this appliance on or off by inserting or removing the plug from a
switched-on power outlet and always pull out the plug from the socket (pull
on the plug, not the cable)
Ensure hands are dry before handling the plug or the main unit.
Earth Safety
This appliance must be earthed. Only connect to a suitably earthed 220-240V
~ 50Hz supply socket.
Use and Environment
Operate the appliance on a flat and stable surface. The appliance must be
operated the right way up. Do not tip over. Do not use outdoors.
Do not unplug while the unit is operating.
Never place the appliance close to a radiant heat source.
Avoid contact with the moving parts. Keep hands, hair, and clothing, away
from the blade of the fan during operation to reduce the risk of injury to
person and/or damage to the unit.
Never insert or allow foreign objects to enter any ventilation or exhaust
opening, as this may cause an electric shock, fire or damage to the
appliance.
Never operate in areas where petrol, paint or other flammable liquids are
used or stored.
Never place the unit in wardrobes or other enclosed spaces as this may
cause fire hazards.
Do not use any means to accelerate the defrosting process or to clean,
other than those recommended by the manufacturer.
Do not run cord under carpeting and do not cover cord with throw rugs,
runners or the like. Arrange the cord away from traffic areas and where it will
not be tripped over. Avoid the use of an extension cord as this may overheat
and cause a risk of fire.
Pipe-work shall be protected from physical damage and shall not be installed
in an unventilated space if that space is smaller than 7m².

AFTER SALES SUPPORT
Email: [email protected]
Phone: [phone] - Mon-Fri 8:30am –4.30pm Page 7
Supervision
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge unless they have been given supervision or instruction concerning
the use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
appliance.
Cleaning and user maintenance shall not be made by children without
supervision.
Damaged or Dropped
Always inspect your appliance before use. Check parts are correctly attached.
Do not use this appliance if it has been damaged, dropped, left outdoors or
dropped in water. Return it to an authorised service dealer for examination
and repair.
Water
Do not immerse the appliance or its supply cord in water. Do not use with wet
hands and prevent water from spilling onto the unit.
Do not immerse or expose the unit to rain, moisture or any other liquid.
Never use this appliance in the immediate surroundings of a bath, a shower,
or a swimming pool or other liquids. The appliance must not be immersed in
any liquids.
Cleaning
Turn off and unplug the appliance when not in use and before cleaning or
maintenance.
Do not try to clean the inner part of the air inlet or outlet with a sharp object.
Never use abrasive cleaning products on this appliance. Clean with a damp
cloth (not wet) rinsed in hot soapy water only. Always remove the plug from
the mains supply before cleaning. Do not pierce or burn, even when disposing
of.
The A-weighted sound pressure level is below 36 dB.

AFTER SALES SUPPORT
Email: [email protected]
Phone: [phone] - Mon-Fri 8:30am –4.30pm Page 8
THE FOLLOWING SHOULD ALWAYS BE OBSERVED FOR SAFETY
The environmentally friendly R290 is used as the refrigerant. R290 has no
damaging influence on the ozone layer (ODP), a negligible greenhouse
effect (GWP) and is available worldwide. Because of its efficient energy
properties, R290 is highly suitable as a coolant for this application. Special
precautions must be taken into consideration due to the coolant's high
flammability.
The unit is designed only for use with R-290(propane) gas as the
designated refrigerant
The refrigerant loop is sealed.
Only a qualified technician should attempt to service!
Do not discharge the refrigerant into the atmosphere.
R-290 (propane) is flammable and heavier than air. It collects first in low
areas but can be circulated by the fans.
If propane gas is present or even suspected, do not allow untrained
personnel to attempt to find the cause.
The propane gas used in the unit has no odour. The lack of smell does
not indicate a lack of escaped gas.
If a leak is detected, immediately evacuate all persons from the store,
ventilate the room and contact the local fire department to advise them
that a propane leak has occurred.
Do not let any persons back into the room until the qualified service
technician has arrived and that technician advises that it is safe to return
to the room.
No open flames, cigarettes or other possible sources of ignition should be
used inside or in the vicinity of the units.
Component parts are designed for propane and non-incentive and non-
sparking. Component parts shall only be replaced with identical repair
parts.
Be aware that refrigerants do not have any odour.
FAILURE TO ABIDE BY THIS WARNING COULD RESULT IN AN EXPLOSION,
DEATH, INJURY AND PROPERTY DAMAGE.
Do not use the appliance in any other orientation other than upright
as shown in this manual.

AFTER SALES SUPPORT
Email: [email protected]
Phone: [phone] - Mon-Fri 8:30am –4.30pm Page 9
ASSEMBLY AND PARTS

AFTER SALES SUPPORT
Email: [email protected]
Phone: [phone] - Mon-Fri 8:30am –4.30pm Page 10
Before First Use
1. Remove all packaging materials.
2. Remove any stickers or labels from the appliance. (Except the rating label!).
3. Wipe the outside of the appliance with a moist cloth and dry with a towel.
Clearance
Maintain the minimum clearance around the dehumidifier when the unit is operating as
shown below.
WARNING
Install the unit in rooms that exceed 4 m².
Do not install the unit in a place where inflammable gas may leak.
NOTE
The manufacture may provide other suitable examples or may provide
additional information about the refrigerant odour.
Only operate this unit in ambient temperature from 5°C to 35°C.
Do not use in the outdoors. This dehumidifier is intended for indoor residential
applications only.
Do not operate close to walls, curtains, or other objects that may block the inlet
and outlet.
Keep the air inlet and outlet free of obstacles.
Adjust the wind deflector in the upward position before start-up.
If tipped more than 45°, allow the unit to sit upright for at least 4 hours before
start-up.
Keep doors and windows closed for better energy efficiency.
Do not operate or store the unit in direct sunlight or rain.
It is normal for the air outlet to feel warm to touch after continuous operation on
warm days.
Empty the water tank before moving the device.

AFTER SALES SUPPORT
Email: [email protected]
Phone: [phone] - Mon-Fri 8:30am –4.30pm Page 11
Make sure the Water tank is correctly fitted otherwise the unit will not operate.
The dehumidifier will start in the mode selected when the unit was last used.
The dehumidifier starts dehumidifying if the room humidity is 3% higher than the
selected humidity.
There is a protective 3-minutes time delay of the compressor. If turned off wait 3
minutes before turning it back on.
INSTRUCTIONS
Using Your Dehumidifier
POWER
In the standby state, press the power button to turn on, the operation indicator lights
up and the default fan speed is high, and the default humidity is 50%. In the power-on
state, press the power button to turn off, the running indicator light goes off and the
compressor stops immediately, and then the fan shut down after 30 seconds delay.
MODE
Auto mode - continuous drying mode-sleep mode
Press to cycle the mode from one to another, the corresponding indicator will light up.
 Auto mode: when the environmental humidity ≥ set humidity (+3%), the fan
starts working and the compressor starts working after 3 seconds. When
environmental humidity ≤ set humidity (-3%), the compressor stops working and
the fan stops working after 30 seconds’ delay.
Both fan speed and humidity can be adjusted under auto mode.
 Continuous drying mode: The machine will run, but the humidity cannot be
adjusted.
 Sleep mode: Press the sleep button, the button lights up and starts the sleep
function. After no operation in 10 seconds, all indicators gradually turn dark and
the fan speed is automatically switched from high to low. Press any button to
wake up the indicator. Press the sleep button again to exit the sleep mode.
When the environmental humidity ≤ 57%，the compressor will stop
working and the fan shuts down after 30 seconds’ delay.
When the environmental humidity ≥ 63%，the fan starts to work and
the compressor will start working after 3 seconds.
The fan speed and humidity cannot be adjusted under sleeping mode.

AFTER SALES SUPPORT
Email: [email protected]
Phone: [phone] - Mon-Fri 8:30am –4.30pm Page 12
TIMER
Use the timer to turn on and off the appliance automatically.
When the Dehumidifier is turned on, press the timer button to program the time
you wish the unit to turn off. Each press of the button will change the timer by 1
hour. The unit will automatically switch off after the pre-selected time.
If you want to cancel the timer programming, press the timer button to
adjust the time at 00.
When the dehumidifier is turned off, press the timer button to set the time you
wish the unit to turn on. Each press of the button will change the timer by 1 hour.
The unit will automatically switch on after the pre-selected time.
If you want to cancel the timer programming, press the timer button to
adjust the time to 00.
The programmed time remains unchanged if the machine stops working due to water
full or during defrost mode.
HUMIDITY
Press the humidity button to check the current environmental humidity, press this
button again to set the humidity.
The range of target humidity is 30%- 80%. In 5% increments.
If no button is pressed after 3 seconds, the system confirms the input value and
then returns to the current humidity. In the continuous drying mode, the target
humidity cannot be changed.
Long Press the humidity button for 3 seconds to display the current ambient
temperature.
FAN
High speed - low speed, press the button once to cycle fan speed, the corresponding
indicator lights up.
In continuous drying mode, sleep mode and during defrost, the wind speed cannot be
changed.
CHILD-LOCK
Press and hold 3 seconds to turn on/off the child lock function.
DRAINAGE
There are two ways of removal collected water produced by the unit.
a) Manual draining: Emptying the water tank manually.
b) Continuous draining: connect a drain hose allowing captured water to flow
out.

AFTER SALES SUPPORT
Email: [email protected]
Phone: [phone] - Mon-Fri 8:30am –4.30pm Page 13
EMPTYING THE WATER TANK
The built-in water tank will fill up and shut the unit down once it is full. It will run again
once you empty the water tank and is installed correctly.
When the tank is full, The unit will make a buzzing sound, and the “Water Full”
light will turn on.
1. Press the POWER button to turn off the unit. Pull out the water tank by sliding out
of the body of the dehumidifier.
2. Empty the water into an area with a drain or outside.
3. Clean the inside of the tank as well as the outside with a damp cloth.
4. Replace the empty tank into the unit.
5. Press the POWER button to resume operation.
6. If the Water Full light does not turn off, check that the float on the water tank is
correctly in place.
CONTINUOUS DRAINING
For continuous operation or unattended dehumidification, please connect the attached
drain hose to the unit. Condensate water can automatically flow into a bucket or a
drain using gravity.
Set the unit in a horizontal surface and stable position.
Switch off the unit before operating.
Remove the plug of the water outlet opening, and keep it in a safe area.

AFTER SALES SUPPORT
Email: [email protected]
Phone: [phone] - Mon-Fri 8:30am –4.30pm Page 14
Securely connect the drain hose and make sure it is not kinked and free of
obstruction.
Place the outlet of the hose over a drain or bucket and ensure that water could
freely flow out of the unit.
Do not submerge the end of the hose into water; otherwise, it can cause an
airlock in the hose.
As the negative pressure of the condensate drain pan is large, tilt the drain hose
down toward the floor. The degree of inclination should not be less than 20
degrees.
Straighten the hose to avoid a trap existing in the hose.
FUNCTIONING TEMP
5°C ≤ Ambient Temp. ≤ 35°C
When the ambient temp is lower or higher than the functioning temperature, the
dehumidifier will stop working.
When 5°C ≤ Ambient temp. ≤ 16°C, the compressor will automatically defrost at
intervals; during defrosting, the compressor stops and the fan keeps running.
CLEANING and MAINTENANCE
This appliance requires little maintenance. It contains no user-serviceable parts. Any
servicing requiring disassembly other than cleaning must be performed by a qualified
appliance repair technician.
Before Cleaning
Before unplugging the unit ensure all controls are set off.
When not in use or before cleaning, always disconnect the appliance from the
mains supply.
Care and Cleaning
Accumulated dust may be removed from dehumidifier surfaces with a soft cloth.
For more thorough cleaning, use a cloth that has been moistened with a solution
of mild detergent and water.
Dry the dehumidifier casing thoroughly with a soft, dry cloth before operating the
unit again.
To Clean the Air Filter
Dust collects on the filter and restricts the airflow. The restricted airflow reduces the
efficiency of the system and if it becomes blocked it can cause damage to the unit.
The air filter requires regular cleaning. The air filter is removable for easy cleaning. Do
not operate the unit without an air filter, or the evaporator may be contaminated.

AFTER SALES SUPPORT
Email: [email protected]
Phone: [phone] - Mon-Fri 8:30am –4.30pm Page 15
1. Remove the filter frame and take off the filter.
2. Use a vacuum cleaner to gently vacuum the dust on the surface.
If the filter is very dirty, wash it with water and a soft detergent and dry it
thoroughly afterwards.
3. Replace the filter by reversing the above instructions.
NOTE: Never use rough scouring pads or abrasive cleansers on any plastic or metal
parts as the surface may be damaged.
Storing the Dehumidifier
When not in use store your appliance and all its accessories and instruction manual in
a safe and dry place.
1. Empty any water left in the drainage tank.
2. Fold up the power supply cord and put it in the water tank.
3. Clean the air filter.
4. Store in a cool and dry place.
NOTE: The unit must be kept in an upright position when in storage.
NOTE: The evaporator inside the machine has to be dried out before the unit is packed
to avoid component damage and mould. Unplug the unit and place it in a dry open
area for a few days to dry it out. Another way to dry the unit is to set the humidity
point more than 5% higher than the ambient humidity to force the fan to dry the
evaporator for a couple of hours.

AFTER SALES SUPPORT
Email: [email protected]
Phone: [phone] - Mon-Fri 8:30am –4.30pm Page 16
TROUBLESHOOTING
If a condition listed below occurs, please check the following items before calling
customer service.
Problem
Possible Cause
Solution
Not working
No power supply
Connect to a functioning outlet
and switch on
Water-Full Indication Flashes
Drain water tank and reset it, or
re-position the water tank to the
right place
Room temperature ˂ 5°C, or ˃
35 °C
Self-Protection is designed to
protect the unit. Cannot work at
such a temperature
incorrect
function
Is the air filter clogged?
Clean the air filter as instructed
Is the intake duct or discharge
duct obstructed?
Remove the obstruction from the
discharge duct or intake duct.
No air
intake
Is the filter clogged?
Wash the filter
Loud noise
when
running
Is the machine put on a flat
surface?
Put the machine on the flat even
surface
Is the filter clogged?
Wash the filter
E2
Humidity sensor problem
Contact service support
LO
Environmental humidity is
below 20%
The dehumidifier shuts down for
self-protection. Unplug the
appliance for ten minutes and then
plug it back in and turn it on. If
still not functioning contact service
support
HI
Environmental humidity is
above 90%
CL
Low-temperature protection,
the environmental temperature
＜5℃
CH
High-temperature protection,
the environmental temperature
＞35℃

AFTER SALES SUPPORT
Email: [email protected]
Phone: [phone] - Mon-Fri 8:30am –4.30pm Page 17
SAFETY PRECAUTIONS ON SERVICING
Please follow these warnings when to undertake the following when servicing an
appliance with R290.
Checks to the area
Before beginning work on systems containing flammable refrigerants, safety checks
are necessary to ensure that the risk of ignition is minimized. For repair to the
refrigerating system, the following precautions shall be complied with before
conducting work on the system.
Work procedure
Work shall be undertaken under a controlled procedure to minimize the risk of
flammable gas or vapour being present while the work is being performed.
General work area
All maintenance staff and others working in the local area shall be instructed on the
nature of the work being carried out. Work in confined spaces shall be avoided. The
area around the workspace shall be sectioned off. Ensure that the conditions within the
area have been made safe by control of flammable material.
Checking for presence of refrigerant
The area shall be checked with an appropriate refrigerant detector before and during
work, to ensure the technician is aware of potentially flammable atmospheres. Ensure
that the leak detection equipment being used is suitable for use with flammable
refrigerants, i.e. no sparking, adequately sealed or intrinsically safe.
Presence of fire extinguisher
If any hot work is to be conducted on the refrigeration equipment or any associated
parts, appropriate fire extinguishing equipment shall be available to hand. Have a dry
powder or CO2fire extinguisher adjacent to the charging area.
No ignition sources
No person carrying out work in relation to a refrigeration system that involves exposing
any pipework that contains or has contained flammable refrigerant shall use any
sources of ignition in such a manner that it may lead to the risk of fire or explosion. All
possible ignition sources, including cigarette smoking, should be kept sufficiently far
away from the site of installation, repairing, removing and disposal, during which
flammable refrigerant can be released to the surrounding space. Before work taking
place, the area around the equipment is to be surveyed to make sure that there are no
flammable hazards or ignition risks. “No Smoking” signs shall be displayed.

AFTER SALES SUPPORT
Email: [email protected]
Phone: [phone] - Mon-Fri 8:30am –4.30pm Page 18
Ventilated area
Ensure that the area is in the open or that it is adequately ventilated before breaking
into the system or conducting any hot work. A degree of ventilation shall continue
during the period that the work is carried out. The ventilation should safely disperse
any released refrigerant and preferably expel it externally into the atmosphere.
Checks to the refrigeration equipment
Where electrical components are being changed, they shall be fit for the purpose and
to the correct specification. At all times the manufacturer’s maintenance and service
guidelines shall be followed. If in doubt consult the manufacturer’s technical
department for assistance.
The following checks shall be applied to installations using flammable refrigerants:
The charge size is in accordance with the room size within which the refrigerant
containing parts are installed;
The ventilation machinery and outlets are operating adequately and are not
obstructed;
If an indirect refrigerating circuit is being used, the secondary circuit shall be
checked for the presence of refrigerant;
Marking the equipment continues to be visible and legible. Markings and signs that
are illegible shall be corrected;
refrigeration pipe or components are installed in a position where they are unlikely
to be exposed to any substance which may corrode refrigerant containing
components unless the components are constructed of materials that are
inherently resistant to being corroded or are suitably protected against being so
corroded.
Checks to electrical devices
Repair and maintenance of electrical components shall include initial safety checks and
component inspection procedures. If a fault exists that could compromise the safety,
then no electrical supply shall be connected to the circuit until it is satisfactorily dealt
with. If the fault cannot be corrected immediately but it is necessary to continue
operation, an adequate temporary solution shall be used. This shall be reported to the
owner of the equipment so all parties are advised.
Initial safety checks shall include:
those capacitors are discharged: this shall be done in a safe manner to avoid the
possibility of sparking;
that there no live electrical components and wiring are exposed while charging,
recovering or purging the system;
there is continuity of earth bonding.
WARNING! Install the unit in rooms that exceed 10 m².
WARNING! Do not install the unit in a place where inflammable gas may leak.

AFTER SALES SUPPORT
Email: [email protected]
Phone: [phone] - Mon-Fri 8:30am –4.30pm Page 19
Cleaning up refrigerant
General Measures:
1. Gas/vapour is heavier than air and may accumulate in confined spaces,
particularly at or below ground level.
2. Eliminate every possible source of ignition.
3. Use appropriate personal protection equipment (PPE).
4. Evacuate unnecessary personnel, isolate, and ventilate the area.
5. Do not get in eyes, on the skin, or on clothing. Do not breathe vapours or gas.
6. Prevent entry to sewers and public waters.
7. Stop the source of the release, if safe to do so. Consider the use of water spray to
disperse vapours.
8. Isolate the area until gas has dispersed. Ventilate and gas test area before
entering. Contact competent authorities after a spill.
Disposal
WARNING!!! Releasing refrigerant into the atmosphere is strictly forbidden!
Do not dispose of electrical appliances as unsorted municipal waste, use separate
collection facilities. Contact your local government for information regarding the
collection systems available. If electrical appliances are disposed of in landfills or
dumps, hazardous substances can leak into the groundwater and get into the food
chain, damaging your health and well-being.
