Sheng Jay Automation Technologies SJ-AK49 Instruction manual

SJ-AK49
High Definition and touch Camcorder
High definition 2CH Car DVR/Speed Camera
/Radar Detector/Security-Tracker-Photo
Quick user guide

Content
Product Feature .......................................................... 2
Caution ....................................................................... 5
Apearance................................................................... 6
Learning the remote control .................................... 8
Reset the default settings ........................................... 9
Install Car Holder ...................................................... 11
Screen function information - Video recording mode
.................................................................................. 12
Screen capabilities information - file playback mode
.................................................................................. 14
Playback - Delete ............................................. 15
Main Menu ............................................................... 17
System setup......................................................... 18
(1) Video set................................................ 18
(2) General setup ........................................ 19
An emergency force to protect.......................... 20
Link TV output video audio....................................... 21
Installation Steps ...................................................... 21
Multimedia Message Setting .................................... 31

Authorized Number .................................................. 33
SOS –Send MMS Message ....................................... 35
GPS real-time position tracking via server ............... 36
Security Alarm .......................................................... 39
Security Alarm sensitivity ......................................... 40
Time Zone ................................................................ 40
Geo-Fence................................................................. 41
Cellular Positioning................................................... 44
Low-voltage alert ...................................................... 44
Photo shot ................................................................ 45
SMS Configuration .................................................... 46

Warranty Service and Responsibility
The information contained in this document is proprietary and
confidential information of Sheng Jay Automation Technologies Co.,
Ltd. Any unauthorized reproduction, use or distribution is strictly
prohibited.
This document and information is intended solely for authorized hang
Jay Automation Technologies Co., Ltd. customers as permitted by
Sheng Jay Automation Technologies Co., Ltd. and for the limited
purposes set forth herein.
The incorrect installation or utilization could cause damageto device
or user. We shall not be liable for result, incidental damages or other
losses that incurred by user inrelation with user's mistake to obey the
information andinstructions contained herein.The product is designed
to record, store, play and analyzesvideos caused by impacts but we
do not guarantee theproduct records every event without missing.
Furthermore, if the impact is too weak, the vibration sensor may not
beable to detect the impact, which induces that the systemwill be
unable to automatically start recording the video file.The information
within this manual may change withoutnotice due to technical
changes or upgrades.

Product Feature
140 super degree wide angle, the visual range is wider 15% than
the other similar products in the electronic community.
Humanity operation interface uses all-touch-control, you can
operate video, photograph, mute switch, emergency protection
enforcement files by fingers immediately; 2.4 Inches super wide
screen, frame shade design, and good sharpness make all
information and functions are just at a glance.
Screen sleep mode function allows no interference from screen
brightness.
Equipped with 1/4"HD CMOS High quality PC components, it not
only has the 1080P Full HD and 720P HD high resolution levels,
but detects lighting changes between day and night, adjusting the
ISO automatically, strengthen the quality of shooting.
Using 5 Multi-layer glass lens, capturing images hyper-realistic;
Exclusive glare hood design, improve photo quality.
Equipped with function of digital zoom (zoom), supporting the
operation of 4x optical zoom support for video and photos Model
All operations.
Built-in 3G-SENSOR Gravity sensor, detecting XShaft, Y Axis and Z
Axis 3Stereo spatial variation of gravity automatically, providing
emergency video automatic protection; when being hardly hit,

G-Sensor detect and switch on film protection automatically,
recording key files by full guarantee.
Supporting optional outer type GPS locating speed camera
detector, it can display locations, on the screen and voice release
speed camera, maximum speed limit, speed and coordinate the
information, strengthening vehicle detection protection capacity, and
reducing speeding fines.
Function of automatic loop recording, can overwrite old files
automatically.
Function of seamless video recording, ensures that records images
complete and no leaks seconds.
Function of delaying start can prevent electropulsing would
damage the product at the moment while car starting, improve
service life.
Starting recording is with car starting automatically, and delaying
turning off automatically to ensure the completeness emergency
record.
Providing video mode and playback mode synchronized the image
output, it can be used with car audio equipment.
Supporting maximum 32GB Micro SD Card. (Please choose grade
over 4GB Class 6)
Built-in microphone and speaker can record clear audio quality.
The product uses RoHS unleaded manufacturing process and
passed Taiwan BSMI, CE,FCC International safety certificates.

Speed Camera Detector
Italerts you kinds of speed cameras. Radar Detector and database
are built-in L869. GPS system starts to work after being turned on.
The front panel displays your direction and GPS time.
Vehicle monitoring system
Highly sensitive GPS chip andlocalization sensors can trace your
position and send the location where you are to the cellphone or IP
address.
Anti-theft system
Ultrasonic wave and G-sensor detect unusual invasion, break of car
window and tow. Front lens take pictures and store in Micro SD Card
which is built-in, after warning mode being started. L869 is different
from the other speed camera detector, it can provide you a more
detailed situation in your car.

Caution
●Please set up all the function options before you start to drive the car,
in order to assure drive safety, please avoid operating while driving.
●Please keep the lens clean, do not touch the lens by something contains
oil or water, that would cause the lens become dirty and blurred, so the
quality of recording will be lower. We recommend that you clean the lens
by wiping clothe to keep the high quality of recording don’t clean the le
ns by tissue or paper, so you can protect your product from scratch.
●Please keep the camera lens clean substances such as grease or moisture d
o not use finger sticking the lens, which can result in dirt and produce a haz
y fog lens or a halo effect, resulting in shooting quality; we recommend that
you periodically wipe the lens with a lens cloth, to maintain the quality of sh
ooting high definition clarity and do not wipe with toilet paper or paper the l
ens in order to avoid scratching the lens glass.
●Please use the Micro SD Card (at least more than 4GB, recommended u
sing above Class6). For the first time using the Micro SD card, please
format it, make sure that the memory card would be used properly on the
product.
●In order to assist the recording sharpness of the video, please maintain it
and always wipe the interior sheathing paper.
●If your vehicle is not usually used, and long-term exposure at outdoor, it
is recommended that you remove this product back in the indoor and insta
lled again in car to extend product life.

Apearance
1
2.4 Inches Touch screen
6
Cradle slot
2
USB
7
Second shot Jack
3
Power on/off
8
Micro SD card slot
4
AV OUT
9
GPS
5
LED pilot lamp

Hardware
1. Use tool to take out SIM card socket
2. Insert the SIM card, with the chip side on the top. Please remember to remove
the PIN code in your SIM card before setting.
3. Set Micro SD card in your SJ-L869. The Micro SD card supports up to 2G.

Learning the remote control
1. Hold the LK key on the interface of SJ-L869 for 5 seconds until L/K being
light on.
2. Press any key of the remote controller.
3. The device buzz four times, when it has learnt the controller.Up to 4 remote
controllers supported.
security
mode off
security mode on
security mode off
Undefined
SOS urgent
button

Remote Controller buzz table
Type
Beep frequency
The device can receive no more remote
control(Received over four pieces)
1 time
The remote control received successfully
4 times
The remote control have already been set
1 time
Reset the default settings
When the device was shut down, press the reset key on the device until hearing beep
for 3times. It will be reset the default settings.

Cradle
Motor power c
ord
Rear lens
Lens extension
cable
RFremote-co
ntrol
Car Charger
USB extension
cable
User CD

Begin using the product
Once the packaging is opened, insert SD Card, the product can be directly c
onnected to get in to start with using the power cord.
Please choose the appropriate SD Card (recommended to use 4GB, access spe
ed above Class6). Following the indicated direction, insert the SD Card to th
e card slot until you hear a loud "click" sound, complete installation. If you
would like to remove a card, just push the SD Card inside to the card slot li
ght, it will automatically eject to remove. (Video, photo and playback file duri
ng playback, please do not removed SD card, that may cause files be corrupte
d, it also may cause the host not work normally)
Install Car Holder
Attached car holder can be adsorbed on the front windshield, to fix the produ
ct, please follow the following steps for fixing car holder and the product.

A. Insert the buckle of the car holder into the back fixed slot. (As shown in
the picture below)
B. After completing the foregoing step, it is recommended that adsorbed on th
e front windshield behind the rearview mirror.
C. After you confirm the location, press the fixed frame of the sucker down,
and check that all components and sucker are firm again.
Screen function information - Video recording mode

Tap the center of the screen for stop or start the recording function
Video
recording mode
Enter the main
menu
Recording
indicator
(blinking)
Single / dual
screen
The current file
properties
(protection,
write-protected,
or General)
Recording sound
function
Recoding Time
File lock

Focal Distance
Current filing
date and time
GPS
Motion
Detection
Manual
Digital Zoom
Zoom in / Zoom out
Screen capabilities information - file playback mode

Playback - Delete

File playback
mode
Previous/Rew
ind
Current file
number
Next/ Fast
Forward
File Locked
Play / stop
Enter main menu
Play/Pause
Current archive
video resolution
Delete options
Current filing date
