SHENGYA CV-1HD User manual

使用说明书 / User's Manual
CV-1HD
电子管全平衡前置放大器
Tube Balanced Preamplifier
中山市声雅音响电器有限公司
地址:广东省中山市小榄镇民安南路广进横街8号
电话:[phone]
传真:[phone]
邮箱:[email protected]om
www.shengya-audio.com
ZHONGSHAN SHENGYA AUDIO ELECTRONIC CO.,LTD
Address:No.8,Guangjin Heng Street,Min'an South Road,
Xiaolan Town,Zhongshan City,Guangdong Province
Tel:[phone]
Fax:[phone]
E-mail:[email protected]om
因产品改进，规格及外观如有小许变化，恕不另行通知，最终解释权归声雅音响电器有限公司所有。
声雅微信公众号
ShengYa WeChat
Official Accounts
声雅微信客服号
ShengYa WeChat
Customer service
VER: S2.0

中文
目录
CONTENTS 感谢
感谢您购买声雅音响的 Hi-Fi 产品 !
我们相信，对高品位音响产品的不懈追求，是我们的责任，也是您的理想。
为使 CV-1HD 电子管全平衡前置放大器更好地发挥它的性能，给你带来更大的乐趣，我
们建议您在连接及操作本系统之前，认真阅读本说明书。
安全警告
警告:为防止起火或触电事故,请不要让机器暴露在雨中或潮湿环境里。机内有危
险的高电压配件,因而不要打开机盖维修时只可委托给合资格的维修人员。
危险电压:为减少电击危险,请勿擅自拆卸盖子(或后板)。
请注意:装置内部并无用户自行检修的零部件,需要检修时,请委托经销商或合资
格的人员。
设备仅适用于热带气候条件下安全使用，最高操作温度为45°C；
设备仅适用于海拔5000m及以下地区安全使用；
设备使用器具耦合器作为断接装置。
01
02
03
04
05
07
08
09
性能特点························································
前面板功能····················································
后面板功能····················································
系统连接························································
遥控器····························································
注意事项························································
故障指导························································
技术参数························································
中文
CHARACTERISTICS ·······································
FRONT PANEL FUNCTION ····························
BACK PANEL FUNCTION ·······························
REMOTE CONTROL ·······································
SYSTEM CONNECTION ··································
PRECAUTIONS ···············································
FAULT GUIDANCE ·········································
PARAMETERS ················································
11
13
14
15
17
18
19
20
EN

0201
前面板功能性能特点
等响度指示灯
当等响度开关按下时，指示灯点亮；复位时，指示灯熄灭
1
遥控接收器
接收遥控器发出的红外线遥控指令信号。
3
信号输入选择旋钮
此旋钮是对六组不同的音频信号进行输入选择。被选中的音频信
号指示灯相应点亮。
2
电源开关按钮
此开关用于接通或切断整机交流电源。
8
信号输入指示灯（S4、S5、S6）
9
等响度开关按钮
在小音量聆听时，按下此按钮来补偿高低音的响度，但音量
拧至过半后，作用逐步减少。
4
音量旋钮
此旋钮用作音量控制；向右旋时增大，向左旋时减少。
旋钮上有一红色指示灯，开机时闪动，大约15秒钟后熄灭，表示机
器进入工作状态；在遥控音量控制时，此灯跟随点亮；在静音模式
时，此灯闪动。
5
输入增益指示灯
用户可根据音源的输出电平高低通过遥控器上的GAIN键来选0dB
或-8dB档位；当指示灯点亮时表示增益档位为-8dB，当指示灯熄灭
时，表示增益为0dB档。(此功能只适合信源输出电平高于2.5V以上
使用,当信源输出电平在2.5V以内应选择0dB档 位 。)
6
信号输入指示灯（S1/USB、S2/OPTICAL、S3/COAXIAL）
7
放大部分的核心为积累多年经验而开发研制的电子管全平衡放大电路，令你体会到电子管放大器特有
的优美音色。
采用双单声道全平衡放大电路高级设计，两声道完全独立；为了减小动态串音干扰，每声道各用一只电
源变压器，而且特制了变压器屏蔽盒消除电源噪声干扰。
使用ECC83(12AX7)和ECC82(12AU7)及5814(12AU7)音响专用电子管及配套镀金管座，音色表现甜美自
然，动态庞大。
高达30V不失真输出电压的电子管甲类输出缓冲器，轻易匹配众多后级功率放大器。
音量控制器为日本制造ALPS品牌大型四联高精度电位器，声道误差小，寿命长，而且确保音质和音色
表现优美。加入了遥控音量和音频信号输入选择系统，令使用者倍感方便。
机内大量使用音响专用高级元件，如使用德国WIMA品牌MKP音响专用薄膜无极电容，德国Mcap品牌
音响专用油浸金银箔及铝箔无极电容，高精度低噪声电阻，场效应晶体管伺服式高压精密稳压电源，令音质
和音色表现达到相当高的水准。
不平衡信号输入和输出端子均为镀金高级品，2个平衡信号输入及4个平衡信号输出端子均采用瑞士
NEUTRIK品牌产品,使音频信号得到更理想的传输。
本机具有光纤，同轴，USB数码输入端子。USB使用美国“XMOS”方案，解码芯片采用ES9038Q2M芯片。
电源输入插座采用日本FURUTECH(古河)品牌镀金产品，保险管采用进口发烧级产品。
7 8 9
5
23 4 6 1

0403
系统连接后面板功能
1 2
63 5
4
模拟音频输入端子
此端子用作连接模拟音源输出端子(共设三组输入端子，其中
“S4~S5”为不平衡RCA输 入 ，“ S6”为平衡XLR输入)。
1
3同轴数码输入端子
此端子用作连接数字设备的同轴接口。(电脑/数字游戏机/高清电
视机顶盒)。
音频输出端子
此输出端子连接后级放大器的输入端子(共设五组输出端子,其中
两组为不平衡RCA输出, 两组为平衡XLR输出)。
2
光纤数码输入端子
此端子用作连接数字设备的光纤接口。(电脑/数字游戏机/DVD播
放机/高清电视机顶盒)。
4
USB数码输入端子
此端子用作连接数字设备的USB接口。(电脑/数播等)
注意:苹果系统，数码播放器免装驱动，window系统需要到声雅官网下载中心下载驱动并
安 装 。( http://www.shengya-audio.com/downloads.html)
5
带交流电源保险丝的电源插座
此电源插座用作连接交流电源, 保险丝在电源插座下部, 更换保险
丝时一定要将电源线拔下方可更换。
6
ANALOG OUTPUT
BALANCED BALANCED
RCA
DIGITAL OUTPUT
COAXIAL OPTICAL
CD唱机
音源CS-3.8前级功放
ANALOG INPUT
OUTPUT
BALANCED
DIGITAL INPUT
12
346
5
7
电脑主机 DVD播放机 高清机顶盒
1信号源(CD唱机)的音频输出端子XLR(平衡)与前级音
频输入端子XLR对应对接。
2信号源(CD唱机)的音频输出端子RCA(不平衡)与前级音
频输入端子RCA对应对接。(前级提供两组不平衡信号输入端子)
3信号源(CD唱机)的数码音频同轴输出端子与前级数
码音频同轴输入端子对应连接。
4信号源(CD唱机)的数码音频光纤输出端子与前级数
码音频光纤输入端子对应连接。
5数码设备(电脑/DVD播放机/高清机顶盒)的USB输出
端子与前级的USB输入端子对应连接。
6前级音频输出端子RCA与后级(两台单声道)的音频输
入端子RCA对应连接。(前级有两组不平衡输出端子)
7前级音频输出端子XLR与后级(两台单声道)的音频输
入端子XLR对应连接。(前级有三组平衡输出端子)

0605
遥控器遥控器
遥控器
遥控感应器
使用操作
遥控器有效距离大约7米之内。
遥控器的接收角度为30度之内。
不可将机器的遥控感应器置于阳光或强光直射之
下;因这会导致遥控器无法操作。
注意:
1.遥控器不应靠近过热或过潮之处, 更不应受阳光直射或强光照射。
2.遥控器请勿受到强烈碰撞或从高处跌下, 否则会损坏遥控器使其不能
正常工作。
3.请使用CR2032扭扣电池；勿混用新旧或不同型号的扭扣电池。
4.当遥控器长期不用时, 请将电池取出, 请勿将电池投入火中。
5.如果电池爆裂, 请清洗并擦干电池舱, 然后再装入新的电池。
6.正常使用情况下, 每6个月更换电池一次。
GAIN(前级):(输入增益按键)
用户可根据音源的输出电平高低来选择0dB或-8dB档位；当音源
输出电平过高时，请选择-8dB档位(相应面板上GAIN灯点亮)。
1
MUTE:(静音按键)
按一下此键,机器停止信号输出;再按一下此键则恢复信号输出。
2
S1、S2、S3、S4、S5、S6:(信号输入选择按键)
分别对应面板S1/USB(数码)、S2/OPTICAL(数码)、S3/COAXIAL(数
码)、S4、S5、S6(平衡)档位。
3
▲VOLUME▼:(音量控制按键)
按此键可控制音量的大小；“▼”为减小音量，“▲”为增加音量。
4
按键说明
4
3
21
推出电池盒
装入电池盒
将纽扣电池插入电池
盒， (正)极向上 (负)
极向下
1
2
3
使用准备

0807
故障指导注意事项
原因 解决方法
1.电源线没接好
2.交流保险管熔断
3.音量旋钮在最小位置
4.输入信号线没有接好
5.音源未工作或音源不良
6.音箱连线未接好
7.机器严重过载
8.机内直流保险管熔断
7.关机并检查音箱线是否短接
8.请合格维修人员更换保险管
3.前级音量调整到适当的位置
4.接好输入信号线
5.开启音源或更换其他音源
6.接好音箱线
1.接好电源线
2.请合格维修人员更换保险管
1.一边信号线未接好
2.一边音箱线未接好
1.接好信号线
2.接好音箱线
1.信号线接触不良或插得不够深入
2.信号线不良
1.插紧信号线或用力把插头插入
2.更换信号线
异常现象
有一边
声道无声
无声
声音伴有很大
交流声(嗡嗡声)
遥控器失灵
1.遥控器没有对准功放机遥控接收器
2.遥控器距离功放机太远
3.有物体阻挡在遥控器与功放机之间
4.遥控器中的电池耗尽
1.将遥控器指向功放机
2.在7米之内使用遥控器
3.将阻挡物体拿走
4.换上新电池
当您一段长时间不使用本机时请将
电源线从插座拔下。
不要随便拆开机壳拔弄内部器件,这
样会有触电危险。
清洁机壳时,请勿使用具有强烈挥发
性有机溶剂(如汽油,苯等)洗擦机面
机壳,应用柔软干净的布轻擦。
请将本机放置于通风良好以及干燥
的地方工作，不要放置在阳光直接照
射或靠近热源地方；并注意支承机器
的柜台四周要有一定空间，10cm内
无任何障碍物；以便机器通风散热。
机器上不能放置带液体的容器(如花
瓶、水杯、油瓶等)，更不可将任何类
型的液体洒入机器内，这会造成短路
或漏电事故。
使用电源时请手执插头绝缘部分插
入或拔下电源插座,不要直接扯电源
线。

1009
EN
技术参数
本公司产品保养维修委托当地经销商负责联络接洽。
我公司产品奉行不断改进与更新,产品规格及指标如有变更，恕不另行通知。
如有对本说明书不解之处，请向零售商咨询，或直接向本公司查询。
本产品的执行标准 :GB8898、Q/SHYA01-1997
Thank you for purchasing Hi-Fi products of Shengya Audio!
We believe that the unremitting pursuit of high-quality audio products is our responsibility
and your ideal.
In order to make CV-1HD (Tube balanced preamplifier)better performance and bring you
greater pleasure, we recommend that you read this manual carefully before connecting and
operating the system.
GRATITUDE
Warning: In order to prevent fire or electric shock, please do not expose the
machine to rain or humid environment. There are dangerous high-voltage accesso-
ries in the machine, so do not open the machine cover and only entrust it to qualified
maintenance personnel.
Dangerous voltage: In order to reduce the risk of electric shock, please do not
remove the cover (or rear panel)without authorization.
Note: There are no user-overhauled parts inside the device. When overhauling is
required, please entrust the dealer or qualified personnel.
The equipment is only suitable for safe use in tropical climates, with a maximum operating temperature of 45°C;
The equipment is only suitable for safe use in areas with an altitude of 5000m and below;
The equipment uses an appliance coupler as a disconnect device.
SAFETY WARNING
9.输入灵敏度 ···························· : 400 mV(不平衡)
8.信噪比 ···································· : 105 dB(平衡)
100 dB(不平衡)
10.输入阻抗 ······························ : 47 kΩ
11.体积(W×H×D) ······················· : 446×142×415(mm)
12.重量 ······································ : 13 kg
7.谐波失真 ································ : ≤0.01%(1kHz 2V)
6.最大输出电压 ························· : 30 V(不平衡)
5.额定输出电压 ························· : 2V(不平衡)
4.频率响应 ································ : 20Hz-20kHz ± 0.5dB
2.USB支持 ································· : PCM:16-32Bit,44.1-384kHz,
DSD64,DSD128,DSD256,
DSD512
3.USB支持系统 ························· : 苹果、window、数码播
放器等系统
1.光纤、同轴数码数字支持 ············ : 16-24Bit,44.1-192kHz,
DOP64

1211
CHARACTERISTICS CHARACTERISTICS
The core of the amplificationpart is a fully balanced tube amplifier circuit
developed for years of experience. Let you experience the better sound quality and
timbre charm of the tube balance preamplifier.
The advanced design of dual mono full-balanced amplifier circuit is adopted, and
the two channels are completely independent; in order to reduce the dynamic
crosstalk interference, each channel uses a power transformer to operate
independently, and a special transformer shield box is used to eliminate power noise
interference.
Using ECC83 (12AX7), ECC82 (12AU7) and 5814 (12AU7) audio-specific tubes and
matching gold-plated tube sockets, the sound performance is sweet and natural, and
the dynamics are huge.
The class-A tubeoutput buffer with up to 30V undistorted output voltage can easily
match many power amplifier.
The volume controller is a large-scale quadruple high-precision potentiometer
made in Japan ALPS, with small channel error, long life, and ensure beautiful sound
performance. The remote control volume and audio signal input selection system are
added to make users feel more convenient.
A large number of high-end audio components are used in the machine, such as
WIMA MKP audio specific film infinite capacitors, German Mcap brand oil-immersed
capacitors, high-precision low-noise resistors, field effect transistor servo-type
high-voltage precision regulated power supply, make the sound quality and timbre
performance reach a very high level.
The unbalanced signal input and output terminals are gold-plated high-grade
products, and the 2 balanced signal input and 4 balanced signal output terminals are
made of Swiss NEUTRIK brand products, so that the audio signal can be transmitted
more ideally.
This machine has optical , coaxial, USB digital input terminal. The USB uses the
American "XMOS" solution, and the decoding chip uses the ES9038Q2M.
The power input socket adopts Japanese FURUTECH Furutechgold-plated , and
the fuse adopts imported fever-grade products.

1413
FRONT PANEL FUNCTION BACK PANEL FUNCTION
LOUD INDICATOR LIGHT
When the loud button is pressed, the indicator light is on;
when reset, the indicator light is off
1
REMOTE CONTROL RECEIVER
Receive the infrared remote control command signal sent by the
remote control.
3
INPUT
This knob is for input selection of six different audio signals. The
selected audio signal indicator lights up accordingly.
2
LOUD
When listening at a low volume, press this button to compensate
for the loudness of high and low sounds, but when the volume is
turned to more than half, the effect gradually decreases.
4
SIGNAL INPUT INDICATOR
S1/USB、S2/OPTICAL、S3/COAXIAL
7
POWER
This button is used to turn on or off the AC power supply of the
whole machine.
8
SIGNAL INPUT INDICATOR
S4、S5、S6
9
VOLUME
This knob is used as a volume control; it increases when turned
to the right, and decreases when turned to the left.
There is a red indicator light on the knob, which flashes when it is
turned on, and goes out after about 15 seconds, indicating that
the machine enters the working state; in the remote control
volume control, the light follows; in the silent mode, the light
flashes.
5
INPUT GAIN INDICATOR LIGHT
The user can select the 0dB or -8dB gear according to the output
level of the audio source through the GAIN button on the remote
control; when the indicator light is on, it means the gain gear is
-8dB, when the indicator light is off, it means the gain is 0dB gear.
(This function is only suitable for the use of the signal source
output level higher than 2.5V. When the signal source output level
is within 2.5V, the 0dB gear should be selected.)
6
7 8 9
5
23 4 6 1
ANALOG AUDIO INPUT TERMINAL
This terminal is used to connect the analog audio signal source output
terminal.(a total of three input terminals are provided,among which "S4 ~
S5" are RCA inputs, and"S6"are XLR inputs).
1
AUDIO OUTPUT TERMINAL
This output terminal is connected to the input terminal of the power
amplifier
(a total of four output terminals are provided, two of which are RCA
outputs and two are XLR outputs).
2
6POWER SOCKET WITH AC POWER FUSE
This power socket is used to connect to AC power. The fuse is at
the bottom of the power socket. When replacing the fuse, be sure
to unplug the power cord to replace it.
5USB DIGITAL INPUT TERMINAL
This terminal is used as a USB interface for connecting digital
devices. (Computer/Digital player, etc.)
Note: Apple system and the digital player is free of driver installation, and the window
system needs to go to the download center of Shengya official website to download the
driver and install it.(http://www.shengya-audio.com/downloads.html)
4OPTICAL DIGITAL INPUT TERMINAL
This terminal is used as an optical interface for connecting digital
equipment.(Computer/digital game console/DVD player/HD TV set-top box)
3COAXIAL DIGITAL INPUT TERMINAL
This terminal is used as an optical interface for connecting digital
equipment.(Computer/digital game console/HD TV set-top box)
1 2
63 5
4

1615
REMOTE CONTROL REMOTE CONTROL
Function Description
NOTE:
1. The remote control should not be near overheated or humid places,and should not be exposed to direct
sunlight or strong light.
2. Do not subject the remote control to strong collisions or fall from a high place, otherwise it will damage
the remote control and make it impossible normal work.
3. Please use CR2032 button batteries; do not mix new and old button batteries or different types of button
batteries.
4. When the remote control is not used for a long time, please take out the battery and do not throw the
battery into the fire.
5. If the battery bursts, please clean and wipe the battery compartment dry, and then install a new battery.
6. Under normal use, replace the battery every 6 months.
GAIN
The user can choose the 0dB or -8dB gear according to the output level of the audio source;
when the output level of the audio source is too high, please select the -8dB gear (the GAIN light on
the corresponding panel is on).
1
MUTE
Press this key once to stop the signal output; press this key again to resume signal output.
2
XLR 1、XLR 2、RCA 3、RCA 4、RCA 5、RCA 6
Signal input selection button:
Corresponding to the panel S1/USB,S2/OPTICAL,S3/COAXIAL,S4,S5,S6 gears.
3
▲VOLUME▼
Press this key to control the volume; "▲" to increase the volume, and "▼" to decrease the volume.
4
Introducing the battery box
Insert the battery box
Insert the coin cell battery into
the battery box, (positive)pole
up; (negative)pole down
1
2
3
Preparation
Remote
Control
Remote Control
Receiving
Use Operation
The effective distance of the remote control is about
7 meters.
The receiving angle of the remote control is within 30
degrees.
Do not place the remote control sensor of the machine
under direct sunlight or strong light; this will cause the
remote control to fail to operate.
4
3
21

1817
SYSTEM CONNECTION PRECAUTIONS
Please unplug the power cord from
the socket when you are not using
the machine for a long time.
Do not disassemble the casing and
try to get the internal components,
otherwise there will be a risk of
electric shock.
When cleaning the cabinet, do not
use strong volatile organic solvents
(such as gasoline,benzene,etc.)to
clean the cabinet on the surface of
the machine.Use a soft,clean cloth
to wipe gently.
Please place the machine in a
well-ventilated and dry place for
work.Do not place it in direct sun-
light or close to a heat source;and
pay attention to a certain space
around the counter supporting the
machine,without any obstacles
within 10cm;to allow the machine
to ventilate and dissipate heat.
Do not place containers with liquids
(such as vases,water cups, oil bot-
tles,etc.)on the machine, and do
not spill any type of liquid into the
machine,which may cause short
circuits or electric leakage acci-
dents.
When using the power supply, insert
or unplug the power socket by
holding the insulated part of the
plug,and do not pull the power cord
directly.
The XLR audio output terminal of the signal source
(CD player)is connected to a preamplifier XLR input
terminal correspondingly.
1
The RCA audio output terminal of the signal source
(CD player)is connected to a preamplifier RCA input
terminal correspondingly.
(The preamplifier provides two sets of unbalanced signal input terminals)
2
The digital audio coaxial output terminal of the signal
source(CD player)is connected to a preamplifier audio
coaxial input terminal correspondingly.
3
The digital audio optical output terminal of the signal
source(CD player)is connected to a preamplifier audio
optical input terminal correspondingly.
4
The USB output terminal of digital equipment(computer
/DVD player/HD set-top box)is connected to a preampli-
fier USB input terminal correspondingly.
5
The RCA audio output terminal of the preamplifier is
correspondingly connected to the RCA audio input
terminal of the power amplifier (two channels).
(The preamplifier has two sets of unbalanced output terminals)
6
The XLR audio output terminal of the preamplifier is
correspondingly connected to the XLR audio input
terminal of the power amplifier (two channels).
(The preamplifier has three sets of balanced output terminals)
7
ANALOG OUTPUT
BALANCED BALANCED
RCA
DIGITAL OUTPUT
COAXIAL OPTICAL
CD PLAYER
ANALOG INPUT
OUTPUT
BALANCED
DIGITAL INPUT
12
346
5
7
Computer
Host DVD Player HD TV set-top box
SIGNAL SOURCEAMPLIFIER CS3.8 PREAMPLIFIER

2019
FAULT GUIDANCE PARAMETERS
3.The volume knob is in the minimum position
4.The input signal line is not connected properly
5.The sound source is not working or the sound source is bad
6.Speaker connection is not connected
7.The machine is overloaded
8.Internal DC fuse breaker
7.Replace speakers with 4-8Ω impedance
8.Ask qualified maintenance personnel to replace the fuse
3.Adjust the volume to the appropriate position
4.Connect the input signal line
5.Turn on the audio source or change to another audio source
6.Connect the speaker cable
1.Connect the power cord
2.Ask qualified maintenance personnel to replace the fuse
1.The power cord is not connected properly
2.AC fuse blown
1.One side of the signal line is not connected
2.One speaker cable is not connected properly
1.Connect the signal line
2.Connect the speaker cable
1.The signal line is in poor contact or not inserted deep enough
2.Bad signal line
1.Tighten the signal cable or force the plug into
2.Replace the signal line
ABNORMAL REASON SOLUTION
mute
One side channel
is voiceless
The sound is
accompanied by a
loud humming
Remote control
malfunction
1.The remote control is not pointed at the remote control
receiver of the amplifier
2.The remote control is too far away from the amplifier
3.There is an object blocking between the remote control and
the amplifier
4.The battery in the remote control is exhausted
1.Point the remote control at the amplifier
2.Use the remote control within 7 meters
3.Remove obstructing objects
4.Replace with new batteries
The company's product maintenance and repair entrust the local distributor to be responsible for contacting and contacting.
Our company's products pursue continuous improvement and update, product specifications and indicators are subject to change without notice.
If you have any questions about this manual, please consult the retailer or directly contact our company.
Implementation standards of this product:GB8898、Q/SHYA01-1997
8.Signal to noise ratio ··················· : 105 dB(balance)
100 dB(unbalance)
10.Input Impedance ····················· : 47 KΩ
11.Dimensions(W×H×D)·············· : 446×142×415(mm)
12.Weight ··································· : 13 kg
9.Input sensitivity ························· : 400 mV(unbalance)
6.Max Output Voltage ··················· : 30 V(unbalance)
7.Harmonic distortion ·················· : ≤0.01%(1kHz 2V)
5.Rated Output Voltage················· : 2 V(unbalance)
2.USB Support ···························· : PCM:16-32Bit,44.1-384kHz,
DSD64,DSD128,DSD256,
DSD512
3.USB Support System ················ : Apple,Window,Digital player
and other systems
1.Optical,coaxial digital support ···· : 16-24Bit,44.1-192kHz,
DOP64
4.Frequency Response ················ : 20Hz-20kHz±0.5 dB
