Thank you for purchasing this Marantz product.
To ensure proper operation, please read this owner’s manual carefully before using the product.
After reading this manual, be sure to keep it for future reference.
Accessories
Check that the following parts are supplied with the product.
.
.
.
Quick Start Guide CD-ROM (Owner’s Manual) Safety Instructions
.
.
.
Power cord Remote control unit (RC002PMCD) R03/AAA batteries
Contents Connections Playback Settings Tips Appendix
4
Front panel Rear panel
Remote control
unit
Index
Downloaded from www.vandenborre.be

Inserting the batteries
1Remove the rear lid in the direction of the arrow and
remove it.
.
2Insert two batteries correctly into the battery
compartment as indicated.
.
R03/AAA batteries
3Put the rear cover back on.
NOTE
0To prevent damage or leakage of battery fluid:
0Do not use a new battery together with an old one.
0Do not use two different types of batteries.
0Remove the batteries from the remote control unit if it will not be in use for long
periods.
0If the battery fluid should leak, carefully wipe the fluid off the inside of the battery
compartment and insert new batteries.
Operating range of the remote control
unit
Point the remote control unit at the remote sensor when operating it.
.
30°
Approx. 7 m
30°
Contents Connections Playback
Settings Tips Appendix
5
Front panel Rear panel
Remote control
unit
Index
Downloaded from www.vandenborre.be

Features
High quality sound
0All-discrete current feedback amplifier
This unit uses a high-speed current feedback amplifier circuit for its
preamplifier and power amplifier so that signals from the Super Audio
CD player can be amplified with high fidelity. The high-speed current
feedback amplifier reproduces a natural sound space.
0High-power output
This unit features a slimline body, but comes with a large power supply
unit for dynamic music reproduction with high power.
0High quality audio design
This unit has a high quality audio design such as minimized signal path,
use of high sound quality parts, and large power circuit, which is
possible only in discrete audio components.
0Phono input connectors for connecting turntables
This unit is provided with a phono amplifier so that you can directly
connect a turntable and play records (Only the MM cartridge can be
used). (v p. 20)
0Two-sets of speaker output terminals
In addition to using two sets of speakers (Speakers A and Speakers B),
you can connect to bi-wiring speakers with separate input terminals for
high range and low range. (v p. 19)
The unit adopts screw terminals that can connect thick audio cables.
High performance
0Tone control function
This unit has a tone control function for adjustment of bass (low
frequency) and treble (high frequency) sound to produce your preferred
tone. (v p. 27)
0LOUDNESS function
This unit is provided with a LOUDNESS function that makes it easier to
hear music played back at a low volume level. (v p. 27)
Contents Connections Playback Settings Tips Appendix
6
Front panel Rear panel
Remote control
unit
Index
Downloaded from www.vandenborre.be

Easy operation
0Remote control compatible with CD players and network audio
players
The remote control provided with this unit can control Marantz CD
players and network audio players in addition to this unit. (v p. 12)
This unit can also switch between three remote control codes. When
using three units in the same area, you can set a different remote
control code for each unit to control them independently. (v p. 33)
Contents Connections Playback Settings Tips Appendix
7
Front panel Rear panel
Remote control
unit
Index
Downloaded from www.vandenborre.be

Part names and functions
Front panel
.
iQ
3
Q
4
Q
0
Q
1
Q
2
ou
rteqw y
APower operation button (X)
This turns the power on/off. (v p. 25)
BPower indicator
This is lit as follows according to the power status:
0Power on : Off
0Standby : Red
0Power off : Off
0When the protection circuit is activated : Red (blinking)
Contents Connections Playback
Settings Tips Appendix
8
Front panel Rear panel
Remote control
unit
Index
Downloaded from www.vandenborre.be

.
r t ye
iuQ
3
Q
4
Q
0
Q
1
Q
2
o
CInput source select knob (INPUT SELECTOR)
This selects the input source. (v p. 26)
DInput indicators (v p. 26)
EMUTE indicator
This lights while the sound is muted. (v p. 26)
FVOLUME knob
These adjust the volume level. (v p. 26)
GHeadphones jack (PHONES)
Used to connect headphones.
Turn off speaker output when using headphones. (v p. 26)
NOTE
To prevent hearing loss, do not raise the volume level excessively when using
headphones.
HBASS control knob
This setting adjusts the volume level for the bass. (v p. 26)
ISOURCE DIRECT button/indicator
This turns SOURCE DIRECT mode on/off.
(v p. 27)
JTREBLE control knob
This setting adjusts the volume level for the treble. (v p. 26)
KSpeaker switching buttons/indicators (SPEAKERS A/B)
These select the speaker for audio output. (v p. 26)
LLOUDNESS button/indicator
This turns the LOUDNESS mode on/off.
(v p. 27)
MBALANCE control knob
This adjusts the balance of the volume output from the left and right
speakers. (v p. 26)
NRemote control sensor
This receives signals from the remote control unit. (v p. 5)
8, 0, b and c can be adjusted when 9 is off (SOURCE DIRECT mode is off).
Contents Connections Playback Settings Tips Appendix
9
Front panel Rear panel
Remote control
unit
Index
Downloaded from www.vandenborre.be

Rear panel
.
oitre Q
0
q w
y u
ASIGNAL GND jacks
Used to connect a turntable. (v p. 20)
BAC inlet (AC IN)
Used to connect the power cord. (v p. 23)
CTurntable input connectors (PHONO)
Used to connect a turntable. (v p. 20)
DTuner input connectors (TUNER)
Used to connect a tuner. (v p. 20)
ECD input connectors
Used to connect a CD player. (v p. 20)
FNetwork audio player input connectors (NETWORK)
Used to connect a network audio player.
(v p. 20)
GRecorder input/output connectors (RECORDER 1)
Used to connect the input/output connector of a recorder. (v p. 21)
HRecorder input/output connectors (RECORDER 2)
Used to connect the input/output connector of a recorder. (v p. 21)
ISpeaker terminals (SPEAKERS)
Used to connect speakers. (v p. 17)
JRemote control input/output connectors (REMOTE CONTROL)
Used to connect to a Marantz audio device that is compatible with the
remote control function. (v p. 22)
Contents Connections Playback Settings Tips Appendix
10
Front panel Rear panel
Remote control
unit
Index
Downloaded from www.vandenborre.be

Remote control unit
.
r
t
e
w
q
oAmplifier operations
AInput source select buttons
This selects the input source. (v p. 26)
BSOURCE DIRECT button
This turns SOURCE DIRECT mode on/off.
(v p. 27)
CMUTE button (:)
This mutes the output audio. (v p. 26)
DAMP POWER button (X)
This turns the power on/off (standby).
(v p. 25)
EVOLUME buttons (df)
These adjust the volume level. (v p. 26)
Contents Connections Playback Settings Tips Appendix
11
Front panel Rear panel
Remote control
unit
Index
Downloaded from www.vandenborre.be

.
o
Q0
i
u
w
q
e
r
y
t
Q3
Q1
Q2
oCD player operations
The supplied remote control can be used to control a Marantz CD player in
addition to this unit. To operate a Marantz CD player, press the REMOTE
MODE CD button to switch the remote control to the CD player operation
mode.
0REMOTE MODE CD button lights for approximately two seconds.
APOWER button (X)
BRemote mode select button (REMOTE MODE CD)
CSkip buttons (8, 9)
DStop button (n)
EInput source select button (INPUT)
FInformation button (INFO)
GTIME button
HCursor buttons (uio p)
IProgram button (PROG)
JNumber buttons (0 – 9)
KDIMMER button
LRANDOM button (P)
MSOUND MODE button
Contents Connections Playback
Settings Tips Appendix
12
Front panel Rear panel
Remote control
unit
Index
Downloaded from www.vandenborre.be

.
Q5
Q9
W0
W1
Q4
Q6
Q8
Q7
NPause button (3)
OPlay button (1)
PPlayback mode switching button (MODE)
QENTER button
RSETUP button
SCLEAR button
TREPEAT A-B button
UREPEAT button (L)
The amplifier can be operated with the amplifier operation buttons even when the
remote control operation mode is set to CD.
Contents Connections Playback Settings Tips Appendix
13
Front panel Rear panel
Remote control
unit
Index
Downloaded from www.vandenborre.be

.
w
e
q
r
y
i
u
t
Q0
Q1
Q2
o
oNetwork audio player operations
The remote control provided with this unit can control a network audio
player in addition to this unit. To operate a Marantz network audio player,
press the REMOTE MODE NET button to switch the remote control to the
network audio player operation mode.
0REMOTE MODE NET button lights for approximately two seconds.
APOWER button (X)
BRemote mode select button (REMOTE MODE NET)
CSkip buttons (8, 9)
DStop button (n)
EInput source select button (INPUT)
FInformation button (INFO)
GTOP MENU button
HCursor buttons (uio p)
IFAVORITES button
JNumber buttons (0 – 9, +10)
KDIMMER button
LRANDOM button (P)
Contents Connections Playback
Settings Tips Appendix
14
Front panel Rear panel
Remote control
unit
Index
Downloaded from www.vandenborre.be

.
Q4
Q5
Q3
Q7
Q8
Q6
Q9
W0
MPause button (3)
NPlay button (1)
OPlayback mode switching button (MODE)
PENTER button
QSETUP button
RCLEAR button
SSearch button (SEARCH)
TREPEAT button (L)
The amplifier can be operated with the amplifier operation buttons even when the
remote control mode is NET.
Contents Connections Playback Settings Tips Appendix
15
Front panel Rear panel
Remote control
unit
Index
Downloaded from www.vandenborre.be

oContents
Connecting speakers 17
Connecting a playback device 20
Connecting a recording device 21
Connecting devices with remote control connectors 22
Connecting the power cord 23
NOTE
0Do not plug in the power cord until all connections have been completed.
0Do not bundle power cords together with connection cables. Doing so can result in
humming or noise.
oCables used for connections
Provide necessary cables according to the devices you want to
connect.
Speaker cable
.
Audio cable
.
R
L
R
L
Remote connector cable
.
Contents Connections Playback Settings Tips Appendix
Connections
16
Front panel Rear panel
Remote control
unit
Index
Downloaded from www.vandenborre.be

Connecting speakers
NOTE
0Disconnect this unit’s power plug from the power outlet before connecting the
speakers.
0Connect so that the speaker cable core wires do not protrude from the speaker
terminal. The protection circuit may be activated if the core wires touch the rear
panel or if the + and - sides touch each other. (“Protection circuit” (v p. 40))
0Never touch the speaker terminals while the power cord is connected. Doing so
could result in electric shock.
0Use speakers with impedances within the ranges shown below to suit how they
are used.
Speaker terminals used
on this unit
No. of connected
speakers
Speaker
Impedance
SPEAKERS A
(Standard connection) 2 (one set) 4 – 16 Ω/ohms
SPEAKERS B 2 (one set) 4 – 16 Ω/ohms
SPEAKERS A and
SPEAKERS B 4 (two sets) 8 – 16 Ω/ohms
SPEAKERS A and
SPEAKERS B
(Bi-wiring connection) 2 (one set) 4 – 16 Ω/ohms
oConnecting the speaker cables
Carefully check the left (L) and right (R) channels and + (red) and – (black)
polarities on the speakers being connected to this unit, and be sure to
connect the channels and polarities correctly.
1
Peel off about 10 mm of sheathing from the tip of the speaker
cable, then either twist the core wire tightly or terminate it.
.
2
Turn the speaker terminal counterclockwise to loosen it.
.
3Insert the speaker cable’s core wire to the hilt into the
speaker terminal.
.
4Turn the speaker terminal clockwise to tighten it.
.
Contents Connections Playback
Settings Tips Appendix
17
Front panel Rear panel
Remote control
unit
Index
Downloaded from www.vandenborre.be

Speaker A/B connection
This unit is equipped with two sets of speaker terminals (SPEAKER A and SPEAKER B). One set of speakers can be connected to each set of terminals,
and a total of two sets of speakers can be connected.
The same signal is output from the SPEAKERS A and SPEAKERS B terminals.
When only one set of speakers is to be connected, use either the SPEAKERS A or SPEAKERS B terminals.
.
wqwq
(R)(L)
wqwq
(R)(L)
SPEAKERS A SPEAKERS B
Contents Connections Playback
Settings Tips Appendix
18
Front panel Rear panel
Remote control
unit
Index
Downloaded from www.vandenborre.be

Bi-wiring connection
This connection limits the effects of signal interference between the high range speakers (tweeters) and low range speakers (woofers), allowing you to
enjoy high quality playback.
When bi-wiring with bi-wireable speakers, connect the mid and high range terminals to SPEAKERS A (or SPEAKERS B), the low range terminals to
SPEAKERS B (or SPEAKERS A).
.
wq
wq
HIGH
LOW
wq
wq
HIGH
LOW
Speaker
(R)
Speaker
(L)
Remove shorting bar Remove shorting bar Remove shorting bar Remove shorting bar
Contents Connections Playback
Settings Tips Appendix
19
Front panel Rear panel
Remote control
unit
Index
Downloaded from www.vandenborre.be

Connecting a playback device
You can connect turntables, tuners, CD players and network audio players to this unit.
This unit is compatible with turntables equipped with a moving magnet (MM) phono cartridge. When you connect to a turntable with a low output moving
coil (MC) cartridge, use a commercially available MC head amp or a step-up transformer.
If you set this unit’s input source to “PHONO” and you accidentally increase the volume without having a turntable connected, you may hear a hum noise
from the speakers.
NOTE
The earth terminal (SIGNAL GND) of this unit is not for safety grounding purposes.
If this terminal is connected when there is a lot of noise, the noise can be reduced.
Note that depending on the turntable, connecting the ground line may have the
reverse effect of increasing noise. In this case, it is not necessary to connect the
ground line.
GND
AUDIO
OUT
L
R
AUDIO
OUT
LR
AUDIO
OUT
LR
AUDIO
OUT
LR
L
L
R
R
L
L
R
R
L
L
R
R
Network audio
player
Tu n e r
Turntable
CD player
Contents Connections Playback
Settings Tips Appendix
20
Front panel Rear panel
Remote control
unit
Index
Downloaded from www.vandenborre.be
