Shenzhen HD320 User manual

HD VIDEO CONFERENCE CAMERA
User Manual

2 3
1. Precaution ................................................................................................... 3
2. Product Introduction .................................................................................. 4
2.1 Camera Technical Parameters ................................................................... 4
2.2 Product Feature ........................................................................................ 5
3. Using Instructions........................................................................................ 6
3.1 Camera Interface....................................................................................... 6
3.2 RS232 Interface Specification .................................................................... 7
3.3 Camera Dimension .................................................................................... 8
3.4 Remote Controller Specification................................................................ 9
4. Operation Instruction ................................................................................. 10
4.1 Camera ID Select ..................................................................................... 10
4.2 Pan/Tilt Control ........................................................................................ 10
4.3 Focus ........................................................................................................ 11
4.4 Preset Setting ........................................................................................... 12
4.5 Function of Touch Button ........................................................................ 12
5. Camera Setting ........................................................................................... 13
5.1 EXPOSURE................................................................................................. 13
5.2 COLOR....................................................................................................... 14
5.3 PICTURE.................................................................................................... 14
5.4 P/T/Z ........................................................................................................ 15
5.5 Noice Reduction ....................................................................................... 15
5.6 Video Format............................................................................................ 16
5.7 System Setting.......................................................................................... 16
5.8 Restore Default......................................................................................... 16
6. Network Connecting................................................................................... 17
6.1 Mode of Connecting ................................................................................ 17
6.2 CGI /APK login .......................................................................................... 19
7. Installation Instruction ............................................................................... 29
8. Maintenance Service Terms ....................................................................... 30
8.1 Warranty Policy ....................................................................................... 30
8.2 Warranty range ........................................................................................ 30
8.3 Warranty Condition ................................................................................ 30
8.4 Shipping cost of RMA or replaced .......................................................... 30
8.5 Warranty ................................................................................................. 31
Content
Electrical Safety
Confirm country and local electrical safety standard when using or installing the
product. The product itself has no power switch. Please stop power supply or
plug out power socket when it is not in good working. Video wire and control wire
should be insulated and individual connected, can’t mix-up with other wires.
Transportation with Care
Product should be protected against extremes of stress, vibration and moisture in
transport, storage and installation. It is transported by integrated packing style.
Power Supply
Product supplies 12V DC power.
Installation with Care
Don’t turn camera head manually. Doing so may result in mechanical damage.
Product should be put on stable horizontal table, and does not be installed at a tilt,
or else, which may cause tilted image.
Don’t apply corrosive liquid, gas or solid, to avoid damaging the cover which is
made up of plastic material.
Make sure there is no obstacle with the camera’s rotational range when installing.
Never power on before installation has been completed.
Prohibited unauthorized disassemble
There is no part for users to disassemble voluntarily. PUAS is not responsible for any
unauthorized modification or dismantling.
1. Precaution

4 5
Model
Specifications HD320
Camera Parameters
CMOS Sensor 1/2.8”Exmor CMOS
Effective Pixels 2.38 Megapixels
Video Format 1080P60/59.94/50/30/29.97/25;1080i60/59.94/50;720P60/59.94/50/30/25
Optical Zoom 20x Optical
Focus f=4.7~94.0mm
Horizontal Field of View 3.2°(T) ~ 55.2°(W)
F-number F1.6 ~ F2.8
Min. Illumination 0.05Lux(F1.8,AGC:ON)
Digital Noise Reduction 2D&3D
White Balance Auto/Manual/Indoor/outdoor/White Balance/3000K/4000K/5000K/6500K
Focus Auto/Manual
Iris Auto/Manual
Backlight Compensation 1-7/Off
Control Panel Brightness, Hue, Saturation, Contrast, Sharpness
Interface Parameters
Video Output Interface HDMI,3G-SDI,RJ45
Video Network Coding H.264,H.265,MJPEG
Communication 1X RS232 IN, 1X RS232 Out, 1X RJ45, RS485
Control Protocol VISCA/PELCO-D/PELCO-P/Visca Over IP/ONVIF
Baud Rate 2400/4800/9600/115200
Audio Input Double Channel 3.5mm Linear Input
Audio Compression Format ACC,G711A,G711U
Network Interface 100M internet access(10/100BASE-TX), supply network with
VISCA/PELCO-D/PELCO-P control protocol,ONVIF
Network Protocol RTSP, RTMP, ONVIF, GB/T28181
Power Interface DC-038 outlet(DC12V)
Mechanical Parameters
Pan RotationAngle -178°~ +178°
Vertical Angle of View -30°~ +90°
Pan Speed Range
(per second) 0.1~180°/s
Tilt Speed Range
(per second) 0.1~120°/s
Presets 255
Other Parameters
Power Adapter AC100V~AC240V in, DC12V/2A out
Input Voltage DC 12V
Power Consumption 12W
Storage Environment -10°C ~ +60°C / 20% ~ 95%
Working Environment -10°C ~ +50°C / 20% ~ 80%
Standard Accessory Power adapter, RS232 pallet, 2-bit RS485terminal, Remote
controller, Instruction book, Guarantee card
Optional Accessory Installing Bracket
2. Product Introduction
2.1 Camera Technical Parameters
2.2 Product Feature
1080P Full High-denition
1/2.8 inch high quality CMOS sensor, can reach maximum 1920 x 1080 resolutions and
output frame rate up to 60fps.
20X Optical Zoom with wide horizontal of view 55.2°
The camera with advanced video image processing technology & full HD 1/2.8" CMOS
Sensor, 20X Optical Zoom,Max resolution up to 3840*2160P@30fps.
Low Noise
High SNR of CMOS sensor, combined with 2D and 3D noise reduction algorithm, effectively
reduces the noise, even under low illumination conditions, to ensure that the picture can still
remain clean and clear.
Rich and Perfect Interface
Support to output High-definition HDMI, 3G-SDI and high-definition wired LAN. And could
simultaneously output three ways video with.
Quiet Pan and Tilt Movement
Using high-precision stepping motor and advance motor driven chip to make sure it rotates
stably under different speed and without any noise and howling.
Remote Control
Can remote control camera by using RS232, RS485 or internet. Support VISCA, PELCO-D and
PELCO-P protocol.
Presets Image Freezing
Support the function with only freezing preset images when transferring presets, which
could shield the image during transferring.
Multi-preset
Support as many as 255 presets. (Remote control can only set 9 presets.)
Multi-application Scenario
Education recorded, Remote conference, Remote medical treatment, Remote training, Trial
system, Command system, Webcast, etc.
Multiple Network Protocol
Support ONVIF, GB/T28181, RTSP, RTMP protocol, and also can be extended according to
users’ requirement.

6 7
3. Using Instructions
3.1 Camera Interface
1, Lens 6, Touch Panel 11, Storage Interface
2, IR Receiver 7, 3G-SDI Output 12, RS485 Interface
3, Power Led 8, HDMI Output 13, RS232 IN
4, OLED 9, LAN Interface 14, RS232 OUT
5, Standby Led 10, Audio Interface 15, DC12V Input
3.2 RS232 Interface Speci cation
Connect Ways Between Computers Or
Control Keyboard and Camera
CAMETA WINDOWS DB-9
1.DTR 1. DCD
2.DSR 2. RXD
3.TXD 3. TXD
4.GND 4. DTR
5.RXD 5. GND
6.GND 6. DSR
7.IR OUT 7. RTS
8.NC 8. CTS
9. RI
CAMERA Mini DIN
1.DTR 1. DTR
2.DSR 2. DSR
3.TXD 3. TXD
4.GND 4. GND
5.RXD 5. RXD
6.GND 6. GND
7.IR OUT 7. NC
8.NC 8. NC
RS232INPUT
NO. Function Defi nition-
specifi cation
1 DTR Data Set Ready
2 DSR Data Set Ready
3 TXD Transmit Data
4 GND Ground
5 RXD Receive Data
6 GND Ground
7 IR OUT IR Signal Output
8 NC No Connec

8 9
3.3 Camera Dimension
The Size for HD video conference camera is as below:
3.4 Remote Controller Specication
1.Standby Button
2.[MENU]: Enter/Exit the OSD menu
3.[CAMERA SELECT]: Camera ID select, select
the target camera you need.
4.[FAST T]: Swiftly adjust the lens to focus the
nearby object
5.[SLOW T]: Slightly adjust the lens to focus
the nearby object
6.[FAST W]: Swiftly adjust the lens to focus
the distant object
7.[SLOW W]: Slightly adjust the lens to focus
the distant object
8.PTZ Controller, PTZ turn according to the
arrow
Up Down
Left Right
[HOME]: Face the camera back to front
9.[Number Key]: Set or call the Presets of No.1-9
10.[PRESET]: PPRESET + Numeric button(1-9), set the presets you want
11.[RESET]: RESET + Number(1-9), reset the presets you want
12.[BRIGHT]: + increase, - decrease
13.[FOCUS]: Camera focus select
[AUTO]: Automatic focus
[MANNUAL]: Manual focus
[FAR]: Manual focus, make the far object clearer
[NEAR]: Manual focus, make the near object clearer
Note:
1.If the remote control does not work properly, please replace the
battery.
2.If there is object occlusion between the remote controller and the
remote control special sensor on the camera, the camera will not work
properly, so when using the remote controller, the remote controller will
directly towards the remote sensor of the front part of the camera.

10 11
4. Operation Instructions
4.1 Camera ID Select
Select the target camera ID (from No.1 to
No.3) When the camera ID is over 3, select
No.1
will enable you to operate the camera.
4.2 Pan/Tilt Control
Turn up Press
Turn down Press
Turn left Press
Turn right Press
Reposition Press: [HOME] button
Press the corresponding buttons to adjust the angle of the lens. Tip: Click on the direction
button will enable the camera rotating in a slow speed, while keep pressing the direction
button in a period of time will enable the camera rotating in a fast speed.
4.3 Focus
[AUTO]Enable camera automatically focus
[MANUAL] Switch to manually control mode
[FAR] Manually focus the distant object
[NEAR] Manually focus the nearby object
Backlight imaging
Strong background ray can make back-lighting objects engender shadow press [BRIGHT+] to
activate the back light mode. Quit the back light mode press [BRIGHT-]
Zoom
Press the four [ZOOM] buttons to zoom the target object

12 13
4.4 Preset Setting
1, Save the preset press [PRESET] button first, then press any of the numbers you need (from1-
9) to save the preset.
Note: You can save at most 9 presets through the remote controller.
2, Call the preset press the saved preset number from1-9 will activate the
corresponding preset position.
Note: Call a preset number has not been saved will be invalid.
3, Reset the preset Press [RESET] button firstly, then press the number (from1-9) will clear the
corresponding preset.
4.5 Function of Touch Button
1, Double click the breathing light on the camera touch panel, and wake
up the touch button, the breathing light will keep lighting.
2, Click [ ◎]on the camera touch panel, select the parameters to modify, including: output
format, protocol, baud rate, address code
3, Click [ ]to modify parameters, and click [ ◎] to confi rm the change, at last restart the
camera to make settings take effect.
5. Menu Setting
1, Operate remote controller, press the [MENU] button to
display the OSD menu.
2, Press the arrow keys to select the menu, press left and
right button to set the camera.
MAIN MENU
EXPOSURE
COLOR
P/T/Z
NOISE REDUCE
VIDEO OUT
SYSTEM SETUP
SEFAULT SETUP
EXIT
5.1 EXPOSURE
Press the [MENU] button to display the OSD menu, press
arrow keys to move to EXPOSURE and then press right
button to enter sub menu, as the right picture.
EXPOSURE
AE MODE: AUTO
AE LEVEL: N/A
EXPCOMP: OFF
BACKLIGHT: OFF
FLICKER: 50HZ
GAMMA: 5
BACK
EXIT
[AE MODE]: AUTO/SHUTTER/IRIS
[EXPOSURE SETTING]: Press right,button, for optional
as Follows
[AUTO]:N/A
[SHUTTER]: shutter priority mode:
1/1-1/10000
[IRIS]: iris priority mode: F1.6-F24
[EXPCOMP]: -3.5DB - 3.5DB, OFF
[BACKLIGHT]: 1-7/OFF
[FLICKER]: 50HZ, 60HZ, OFF
[GAMMA]:0-9

14 15
5.2 COLOR
Press the [MENU] button to display the OSD menu, press
arrow keys to move to COLOR and then press right button
to enter sub menu, as the right picture.
COLOR
WB MODE: AUTO
SATURATION 100%
COLOR HUE: 7
BACK
EXIT
[WB MODE]: AUTO/INDOOR/OUTDOOR/ONE-SHOT/
ATW/MUNUAL/3000K/4000K/5000K/6500K
[SATURATION]: 60%-200%
[COLOR HUE]: 0-14
[RED GAIN]: 0-255(only under MANUAL)
[BLUE GAIN]: 0-255(only under MANUAL)
5.3 PICTURE
[BRIGHT] : 0-14
[CONTRAST] : 0-14
[SHARPNESS] : 0-15
[ICR] : COLOR/BLACK
[STYLE]: STANDARD/CLEAR/BRIGHT/RTSP/GENTAL
Press the [MENU] button to display the OSD menu, press
arrow keys to move to [PICTURE] and then press right
button to enter sub menu, as the right picture.
BRIGHT: 8
CONTRAST: 7
SHARPNESS: 5
ICR: COLOR
STYLE: STANDARD
BACK
EXIT
5.4 P/T/Z
Press the [MENU] button to display the OSD
menu, press the arrow keys to move to [P/T/
Z], press right button to the sub menu, as the
right picture shown.
P / T / Z
FLIP: OFF
L/R DIRECTION: OFF
AF MODE: AUTO
AF SENS: NORMAL
PRESET FREEZE: OFF
D ZOOM: ON
P/T: NORMAL
PRESET SPEED: 24
BACK
EXIT
[FILP]: ON/OFF
[L/R DIRECTION]: ON/OF
[AF MODE]: AUTO/MANUAL/ZOOM
[AF SENS]: NORMAL/LOW
[PRESET FREEZE]: ON/OFF
[D ZOOM]: ON/OFF
[P/T]:NORMAL/TRACING
[PRESET SPEED]:1-24
5.5 Noise Reduction
Press the [MENU] button to display the OSD
menu, press the arrow keys to move to [NOISE
REDUCTION], press right button to the sub
menu, as the right picture shown.
[2D NR]: 0-5 / OFF
[3D NR]: 0-5 / OFF
[DYN HOT PIXEL]: ON/OFF
NOISE REDUCE
2D NR: 2
3D NR: 3
DYN HOT PIXEL: OFF
BACK
EXIT

16 17
5.6 Video Format
Press the [MENU] button to display the
OSD menu, press the arrow keys to move to
[VIDEOOUT], press right button to the sub
menu, as the right picture shown.
[VIDEO OUT] : 720P25,720P30,720P50,720P59,
720P60,1080I50,1080I59,1080I60,1080P25,1080
P29,1080P30,1080P50,1080P59,1080P60
VIDEO OUT
VIDEO OUT: 108030
RESTART
BACK
EXIT
5.7 System Setting
Press the [MENU] button to display the OSD
menu, press the arrow keys to move to
[SYSTEM SETTING], press right button to the
sub menu, as the right picture shown.
[SYSTEM INFO]: press right button to the sub
menu, as the right picture shown
[LANGUAGE]: CHINESE/ENGLISH
[ZOOM LEVEL]: ON/OFF
[PROTOCOL]: VISCA/PELCO-D/PELCO-P
[ADDRESS]: 1-255
[BAUDRATE]:2400/4800/9600/19200/38400
SYSTEM SETUP
SYSTEM INFO
LANGUAGE: CHINESE
ZOOM LEVEL: ON
PROTOCOL: VISCA
ADDRESS: AUTO
IP: 192.168.1.162
BAUDRATE: 9600
BACK
EXIT
5.8 Restore Default
Press the [MENU] button to display the OSD
menu, press the arrow keys to move to
[DEFAULT], press right button to make the OSD
parameter return to the default.
DEFAULT SETUP
FACTORY DEFAULT
BACK
6. Network Connecting
6.1 Mode of Connecting
Direct Mode: Connect camera with computer through network cable directly.
LAN Connecting Mode: Camera could connect to the Internet by router or interchanger then
users could log in through browser.
Note: Don’t put the wires and cables at somewhere easily touched by people for
fear that the quality of imaging is affected by unstable signaltransmission which
is caused by line contact problem.
There must be IP net segment for camera in the computer. It will be a phenomenon that
couldn’t log in if without net segment. For example, camera’s default IP is 192.168.1.162 then
the computer should add Network of 1.
Specific process as below: First, open [Properties] at computer’s local network, then select
“Internet Protocol Version 4(TCP/IPv4)” and double click or click its [Properties] and enter. And
then click [Advanced] to enter into Advanced TCP/IP Settings. Input IP to the [WINS server]
and click [Add] to finish. Users could change the camera IP address with relevant net segment.
Note: Don’t clash the IP with other computers or IP equipment when adding IP
address. Please make sure whether the IP you need is available or not before
adding.
Verify if the net segment works. Open [Start] on the computer and input cmd to “operation”
and click “enter” then input ping 192.168.1.245 to DOS commend window and press enter.
Then it comes up with the information as below picture that means the net segment works.

18 19
After products finished self-checking, it could follow the steps as above to check if the network
works. For example, open DOS commend window and input ping 192.168.1.176 and press the
ENTER button. If it comes up with information as below picture, it means network working.
6.2 CGI /APK login
6.2.1 CGI /APK Login
Open the client software (before turning on the client software, first turn off the anti-virus
software such as 360, avoid being mistaken for viruses and be prohibited from running by
360). By default, admin login with user name and password can preview, record, screenshot,
PTZ control, audio and video. Operations such as encoding configuration. At present, this
version can be run on Windows7/32/64bits & windows 8 or higher. Multiple cameras are
supported in the LAN for simultaneous display (up to 9 devices at the same time).
The Menu language can supports Chinese and English.
6.2.2. CGI /APK Overviews
6.2.2.0 Interface Preview
6.2.2.1 Language
6.2.2.2 Multi-Image Channel Display
After the login is successful, the system will be automatically searches for devices connected
to the LAN, and enters the management interface as shown in the following pictures.
Chooses the drop-down menu to switch the language to Chinese/English.
This version of the software supports 1*CH, 4*CH, 6*CH, 9*CH, click on the interface software
icon , it also can support selection it by Click” Right” Button of Mouse.
