Operator’s
Manual
66006
Shaft
Hedge Trimmer
Attachment
For models: M262, M235
The engine exhaust from this product contains chemicals known
to the State of California to cause cancer, birth defects, or other
reproductive harm.
Read and understand all provided literature before use.
Failure to do so could result in serious injury.

TABLE OF CONTENTS 66006
2 X7712093401
© 08/2021 ECHO Incorporated
TABLE OF CONTENTS
Introduction................................................................................................. 3
Servicing Information.................................................................................. 3
Parts and Serial Number ..................................................................... 3
Service ................................................................................................ 4
Consumer Product Support................................................................. 4
Product Registration ............................................................................ 4
Additional Literature ............................................................................ 4
Safety ......................................................................................................... 5
Manual Safety Symbols and Important Information............................. 5
International Symbols.......................................................................... 6
Equipment ......................................................................................... 12
Description................................................................................................ 14
Contents ................................................................................................... 15
Assembly .................................................................................................. 15
Power Head Shaft to Lower Shaft Assembly..................................... 15
Operation.................................................................................................. 16
Hedge Trimming ................................................................................ 17
Maintenance ............................................................................................. 18
Skill Levels ........................................................................................ 18
Maintenance Intervals ....................................................................... 19
Lubrication......................................................................................... 19
Blades ............................................................................................... 21
Storage ..................................................................................................... 22
Storage Hook Installation .................................................................. 23
Specifications ........................................................................................... 23
Product Registration ................................................................................. 24

66006 INTRODUCTION
X7712093401 3
© 08/2021 ECHO Incorporated
INTRODUCTION
Specifications, descriptions and illustrative material in this literature are as
accurate as known at the time of publication, but are subject to change
without notice. Illustrations may include optional equipment and
accessories, and may not include all standard equipment.
Read and understand all provided literature.
Literature contains specifications and
information for safety, operation,
maintenance, storage and assembly specific
to this product. Scan QR codes for more
information.
For additional literature, including safety manuals where applicable, or
questions regarding terms used in this manual, visit:
https://www.echo-usa.com/manuals
OR
https://www.shindaiwa-usa.com/manuals
SERVICING INFORMATION
Parts and Serial Number
Genuine SHINDAIWA Parts and
Assemblies for your SHINDAIWA
products are available only from an
Authorized SHINDAIWA Dealer.
When you do need to buy parts
always have the Model Number and
Serial Number of the unit with you.
You can find these numbers on the
engine housing. For future reference,
write them in the space provided
below.
Model No. _____________________ Serial No. _____________________

SERVICING INFORMATION 66006
4 X7712093401
© 08/2021 ECHO Incorporated
Service
Service of this product during the warranty period must be performed by an
Authorized SHINDAIWA Service Dealer. For the name and address of the
Authorized SHINDAIWA Service Dealer nearest you, ask your retailer or
call: 1-877-986-7783. Dealer information is also available on
WWW.SHINDAIWA-USA.COM. When presenting your unit for Warranty
service/repairs, proof of purchase is required.
Consumer Product Support
If you require assistance or have questions concerning the application,
operation or maintenance of this product you may call the SHINDAIWA
Consumer Product Support Department at1-877-986-7783 from 8:00 am to
5:00 pm (Central Standard Time) Monday through Friday. Before calling,
please know the model and serial number of your unit.
Product Registration
Toensure trouble free warranty coverage it isimportant that you register
your SHINDAIWA equipment on-line at WWW.SHINDAIWA-USA.COM or
by filling out the product registration sheet included in this manual.
Registering your product confirms your warranty coverage and provides a
direct link between you and ECHO if we findit necessary to contact you.
Additional Literature
In addition to finding information online, information is available from your
Authorized Shindaiwa Service Dealer, or by contacting ECHO
Incorporated, 400 Oakwood Road, Lake Zurich, IL 60047 (800-673-1558).

66006 SAFETY
X7712093401 5
© 08/2021 ECHO Incorporated
SAFETY
Manual Safety Symbols and Important Information
Throughout this manual and on the product itself, you will find safety alerts
and helpful, informational messages preceded by symbols or key words.
The following is an explanation of those symbols and key words and what
they mean to you.
The safety alert symbol accompanied by the word “DANGER”
calls attention to an act or condition which WILL lead to serious
personal injury or death if not avoided.
The safety alert symbol accompanied by the word “WARNING”
calls attention to an act or condition which CAN lead to serious
personal injury or death if not avoided.
The safety alert symbol accompanied by the word “CAUTION”
calls attention to an act or condition which may lead to minor or
moderate personal injury if not avoided.
The enclosed message provides information necessary for the
protection of the unit.
Note: This enclosed message provides tips for use, care and
maintenance of the unit.
CIRCLE AND SLASH SYMBOL
This symbol means the specific action shown is prohibited.
Ignoring these prohibitions can result in serious or fatal injury.

SAFETY 66006
6 X7712093401
© 08/2021 ECHO Incorporated
International Symbols
Symbol Description Symbol Description
Warning, see
Operator’s
Manual.
Safety / Alert
Wear eye, ear
and head
protection.
Finger severing
Wear hand and
foot protection.
Rotating cutting
attachment
Wear face
shield.
Wear slip-
resistant
footwear.
Keep feet away
from blade.
Do not operate
closer than
15 m (50 ft.)
from electrical
hazards. Keep
bystanders at
least 15 m
(50 ft.) away.
DO NOT USE
BLADES - line
head only.
Beware of
thrown objects.
15 M - 50 FT

66006 SAFETY
X7712093401 7
© 08/2021 ECHO Incorporated
Hot surface
Plan retreat path
from falling
objects.
DO NOT USE
LINE HEAD -
blades only.
Keep bystanders and helpers
away 15 m (50 ft.).
Beware thrown objects.
Wear eye protection.
Keep bystanders and helpers
away 15 m (50 ft.).
Do not cut branches overhead.
Symbol Description Symbol Description

SAFETY 66006
8 X7712093401
© 08/2021 ECHO Incorporated
Personal Condition and Safety Equipment
Cancer and Reproductive Harm
www.P65Warnings.ca.gov
The muffler or catalytic muffler and surrounding cover
may become extremely hot. Always keep clear of
exhaust and muffler area, otherwise serious personal
injury might occur.
Users of this product risk injury to themselves and others if the
unit is used improperly and/or safety precautions are not
followed. Proper clothing and safety gear must be worn when
operating unit.
Physical Condition
Your judgment and physical dexterity may not be good:
• If you are tired or sick
• If you are taking medication
• If you have taken alcohol or drugs
Operate unit only if you are physically and mentally well.
Eye Protection
◆Eye protection that meets ANSI Z87.1 or CE requirements
must be worn whenever you operate the unit.
◆For additional safety, a full-face shield can be worn over
safety glasses or goggles to provide protection from sharp
branches or flying debris.

66006 SAFETY
X7712093401 9
© 08/2021 ECHO Incorporated
Hand Protection
Wear sturdy, no-slip, rubber work gloves to improve your grip on the
handles. Gloves also provide protection against cuts and scratches, cold
environments, and reduce the transmission of machine vibration to your
hands.
Hearing and Ear Protection
ECHO recommends wearing personal protective equipment whenever unit
is used.
Breathing Protection
Operators who are sensitive to dust or other common airborne allergens
may need to wear a dust mask to prevent inhaling these materials while
operating unit. Dust masks can provide protection against dust, plant debris,
and other plant matter such as pollen. Make sure the mask does not impair
your vision, and replace the mask as needed to prevent air restrictions.
Proper Clothing
Wear snug-fitting, durable clothing:
• Pants should have long legs, shirts should have long sleeves.
• DO NOT WEAR SHORTS.
• DO NOT WEAR TIES, SCARVES, JEWELRY, or clothing with loose or
hanging items that could become entangled in moving parts or
surrounding growth.
• Keep clothing buttoned or zipped, and keep shirt tails tucked in.
• Wear sturdy work shoes with nonskid rubber soles.
• DO NOT WEAR OPEN TOED SHOES.
• DO NOT OPERATE UNIT WITH BARE FEET.
Keep long hair away from engine and air intake. Retain hair with cap or net.
Heavy protective clothing can increase operator fatigue, which may lead to
heat stroke. Schedule heavy work for early morning or late afternoon hours
when temperatures are cooler.

SAFETY 66006
10 X7712093401
© 08/2021 ECHO Incorporated
The components of this machine generate an electromagnetic
field during operation, which can interfere with some
pacemakers. Reduce the risk of serious or fatal injury, persons
with pacemakers should consult with their physician and the
pacemaker manufacturer before operating this machine. In the
absence of such information, ECHO does not recommend the
use of this machine by anyone who has a pacemaker.
Extended Operation and Extreme Conditions
Prolonged exposure to cold and/or vibration can result in injury.
Read and follow all safety and operation instructions to
minimize risk of injury. Failure to follow instructions can result
in painful wrist/hand/arm injuries.
It is believed that a condition called Raynaud’s Phenomenon, which affects
the fingers of certain individuals, may be brought about by exposure to
vibration and cold. Exposure to vibration and cold may cause tingling and
burning sensations, followed by loss of color and numbness in the fingers.
The following precautions are strongly recommended, because the
minimum exposure, which might trigger the ailment, is unknown.
• Keep your body warm, especially the head, neck, feet, ankles, hands, and
wrists.
• Maintain good blood circulation by performing vigorous arm exercises
during frequent work breaks, and also by not smoking.
• Limit the hours of operation. Try to fill each day with jobs where operating
the unit or other hand-held power equipment is not required.
• If you experience discomfort, redness, and swelling of the fingers
followed by whitening and loss of feeling, consult your physician before
further exposing yourself to cold and vibration.

66006 SAFETY
X7712093401 11
© 08/2021 ECHO Incorporated
Repetitive Stress Injuries (RSI)
It is believed that overusing the muscles and tendons of the fingers, hands,
arms, and shoulders may cause soreness, swelling, numbness, weakness,
and extreme pain in those areas. Certain repetitive hand activities may put
you at a high risk for developing a Repetitive Stress Injury (RSI). An
extreme RSI condition is Carpal Tunnel Syndrome (CTS), which could occur
when your wrist swells and squeezes a vital nerve that runs through the
area. Some believe that prolonged exposure to vibration may contribute to
CTS. CTS can cause severe pain for months or even years.
To reduce the risk of RSI/CTS, do
the following
• Avoid using your wrist in a bent,
extended, or twisted position.
Instead try to maintain a straight
wrist position. Also, when
grasping, use your whole hand,
not just the thumb and index
finger.
• Take periodic breaks to minimize
repetition and rest your hands.
• Reduce the speed and force with
which you do the repetitive
movement.
• Do exercises to strengthen the
hand and arm muscles.
• Immediately stop using all power equipment and consult a doctor if you
feel tingling, numbness, or pain in the fingers, hands, wrists, or arms. The
sooner RSI/CTS is diagnosed, the more likely permanent nerve and
muscle damage can be prevented.
All over head electrical conductors and communications wires
can have electricity flow with high voltages. This unit is not
insulated against electrical current. Never touch wires directly
or indirectly, otherwise serious injury or death can result.
Do not operate this product indoors or in inadequately
ventilated areas. Engine exhaust contains poisonous emissions
and can cause serious injury or death.

SAFETY 66006
12 X7712093401
© 08/2021 ECHO Incorporated
Read the Manuals
• Provide all users of this equipment with the Operator’s Manual for instruc-
tions on safe operation.
Clear the Work Area
• Spectators and fellow workers must be warned, and children and animals
prevented from coming nearer than 15 m (50 ft.) while the unit is in use.
Keep a Firm Grip
• Always hold throttle handle and support handle with thumbs and fingers
tightly encircling the handles.
Keep a Solid Stance
• Maintain footing and balance at all times. Do not stand on slippery,
uneven or unstable surfaces. Do not work in odd positions or on ladders.
Do not over reach.
Avoid Hot Surfaces
• During operation, the drive shaft housing and
attachment bearing housing may become very hot,
too hot to touch. Avoid contact during and
immediately after operation.
Equipment
Use only SHINDAIWA attachments. Serious injury may result
from the use of a non-approved attachment combination. ECHO,
Incorporated will not be responsible for the failure of cutting
devices, attachments or accessories which have not been
tested and approved by ECHO. Read and comply with all safety
instructions listed in this manual and safety manual.
◆Check unit for loose/missing nuts, bolts, and screws.
Tighten and/or replace as needed.
◆Inspect guards and shields for damage and to ensure that
they are securely in place. Replace if damaged or missing.
◆Check that the attachment is firmly attached and in safe
operating condition.
◆Check that handle and harness (if included) are adjusted
for safe, comfortable operation. See Assembly Section for
proper adjustment.

66006 SAFETY
X7712093401 13
© 08/2021 ECHO Incorporated
Moving parts can amputate fingers or cause severe injuries.
Keep hands, clothing and loose objects away from all openings.
◆ALWAYS stop engine, disconnect spark plug, and make
sure all moving parts have come to a complete stop before
removing obstructions, clearing debris, or servicing unit.
◆DO NOT start or operate unit unless all guards and
protective covers are properly assembled to unit.
◆NEVER reach into any opening while the engine is running.
Moving parts may not be visible through openings.

DESCRIPTION 66006
14 X7712093401
© 08/2021 ECHO Incorporated
DESCRIPTION
Locate the safety decal(s) on your unit. Make sure the decal(s) is legible
and that you understand and follow the instructions on it. If a decal cannot
be read, a new one can be ordered from your SHINDAIWA dealer. Safety
label is for example only. Your label may appear slightly different.
1. Tip Guard
2. Blades
3. Gear Case
4. Lower Driveshaft Assembly
5. Flexible Driveshaft
6. Hanger Attachment
7. Handle Grip
8. Shoulder Harness
9. Scabbard
15 m
50 ft
1
2
3
4
5
6
7
8
9

66006 CONTENTS
X7712093401 15
© 08/2021 ECHO Incorporated
CONTENTS
The SHINDAIWA product you purchased has been factory pre-assembled
for your convenience. Due to packaging restrictions, some assembly may
be necessary.
After opening the carton, check for damage. Immediately notify your retailer
or SHINDAIWA Dealer of damaged or missing parts. Use the contents list to
check for missing parts.
ASSEMBLY
Power Head Shaft to Lower Shaft Assembly
Do not perform maintenance or assembly procedures with
engine running.
1. Set Power Head/Shaft Assembly on a level surface.
2. Pull locater pin (A) out, and turn counterclockwise one-quarter turn to
lock-out position.
3. Remove storage hook and cap from attachment drive shaft.
Note: Your coupler may appear different than coupler shown.
Earlier model power heads may have shorter couplings.
1Multi-Tool Shaft Hedge Trimmer Attachment
1Shoulder Harness
1Operator's Manual
1Warranty Sheet
1Blade Cover
1Storage Hook Assembly
Parts Required: Multi-Tool Power Head Shaft and Coupling

OPERATION 66006
16 X7712093401
© 08/2021 ECHO Incorporated
4. Carefully fit attachment drive
shaft assembly into coupler (B).
Rotate the shaft (C) to make
sure the inner lower drive shaft
engages the square upper drive
shaft socket.
Note: Lower bearing housing
and head assembly must
be in line with the engine.
Some models have an
assembly line decal to
assist in assembly.
5. Rotate locater pin (A) one-
quarter turn clockwise to
engage lower shaft hole. Make
sure locater pin is fully engaged
by rotating the lower drive shaft.
Locater pin should snap flush in
coupler. Full engagement will
prevent further shaft rotation.
6. Secure lower shaft assembly to
coupler by tightening clamping
knob (D).
OPERATION
Moving parts can amputate fingers or cause severe injuries.
Keep hands, clothing and loose objects away from all openings.
Always stop engine, disconnect spark plug, and make sure all
moving parts have come to a complete stop before removing
obstructions, clearing debris, or servicing unit. Allow unit to
cool before performing service.
Note: Refer to your Multi-Tool power source Operator's Manuals for
correct engine fueling, starting and stopping instructions.
B
A
C
D
A

66006 OPERATION
X7712093401 17
© 08/2021 ECHO Incorporated
Hedge Trimming
Do not cut branches overhead. They might fall on operator.
Shoulder Harness (if included)
1. Loosen harness clamp screw
(A).
2. Put harness on and attach it to
harness clamp ring (B).
3. Adjust harness for comfortable
operation.
4. Tighten harness clamp screw
(A).
Hedge Trimmer blades are very sharp. Touching them may lead
to severe personal injury. Avoid touching blades whenever
possible, and always wear gloves to protect hands.
Never remove hands from unit when blades are moving. The
engine continues running even when the blades have stopped
due to an obstruction. If this occurs, stop the engine,
disconnect ignition cable and remove the obstruction.
1. Always grip throttle handle with right hand and support handle with left
hand.
2. Hold trimmer firmly and squeeze throttle trigger to accelerate engine.
3. Tilt trimmer so cutting teeth are angled slightly toward the hedge or
shrub and proceed to cut.
Gear case becomes extremely hot during use. Wear gloves to
protect hands whenever handling gear case. Otherwise serious
personal injury may result.
A
B

MAINTENANCE 66006
18 X7712093401
© 08/2021 ECHO Incorporated
MAINTENANCE
Moving parts can amputate fingers or cause severe injuries.
Keep hands, clothing and loose objects away from all openings.
Always stop engine, disconnect spark plug, and make sure all
moving parts have come to a complete stop before removing
obstructions, clearing debris, or servicing unit. Allow unit to
cool before performing service. Wear gloves to protect hands
from sharp edges and hot surfaces.
Operating a poorly maintained unit can result in serious injuries
to operator or bystanders. Always follow all maintenance
instructions as written, otherwise serious personal injury may
result.
Your unit is designed to provide many hours of trouble free service. Regular
scheduled maintenance will help your unit achieve that goal. If you are
unsure or are not equipped with the necessary tools, we recommend that
you take your unit to a Servicing Dealer for maintenance. To help you
decide whether you want to DO-IT-YOURSELF or have the Dealer do it,
each maintenance task has been graded. If the task is not listed, see your
Dealer for repairs.
Skill Levels
Level 1 = Easy to do. Common tools may be required.
Level 2 = Moderate difficulty. Some specialized tools may be required.
Level 3 = See your dealer.
Click HERE or go to http://www.echo-usa.com/products/maintenance-kit
or
HERE https://www.shindaiwa-usa.com/you-can.aspx
For information about maintenance kits.

66006 MAINTENANCE
X7712093401 19
© 08/2021 ECHO Incorporated
Maintenance Intervals
Lubrication
Blades
Level 1.
Hedge Trimmer blades are very sharp. Touching them may lead
to severe personal injury. Avoid touching blades whenever
possible, and always wear gloves to protect hands.
1. Brush loose debris from blade
and coat both sides of blade
with the 50-50 cleaning mixture.
2. Allow cleaning mixture to soften
the remaining gummy residue
then wipe it from the blade.
3. Apply clean oil to the entire length of the blade. Be certain the blade
bolts are lubricated.
4. Wipe excess oil from the blade before putting the unit back in service.
Component Maintenance
Procedure
Skill
Level Interval
Drive Shaft Apply lithium
based
grease. 1
Every 25 hours of use.
Gear Housing
Every 15 - 25 hours of use.
Blades Lubrication
Sharpen 2As needed.
Adjust Every 40 hours of use.
Screws/Nuts/Bolts Inspect/
Tighten/
Replace
1Before each use.
IMPORTANT - Time intervals shown are maximum. Actual use and your
experience will determine the frequency of required maintenance.
Parts Required: 20W Engine Oil (blade lubrication), 50-50 mixture of
kerosene and 20W oil (blade cleaning)

MAINTENANCE 66006
20 X7712093401
© 08/2021 ECHO Incorporated
Gear Case
Level 1.
1. Clean dirt from the grease
fitting (A).
2. Carefully pump grease into
fitting (A). DO NOT force
grease. Too much pressure will
force grease past seals and
cause damage. Apply 1 - 2
pumps of grease every 15 - 25
hours of operation.
3. Wipe excess grease from
around grease fitting.
Drive Shaft Assembly
Level 1.
Hedge Trimmer blades are very sharp. Touching them may lead
to severe personal injury. Avoid touching blades whenever
possible, and always wear gloves to protect hands.
1. Remove gear housing locating
screw (A) and loosen clamping
screw (B). Remove the gear
housing assembly from the
drive shaft housing.
Parts Required: A grease gun with lithium based grease.
Parts Required: Lithium based grease.
A
A
A
FH
AH
AHS
A
B
A
B
AH
AHS
FH
