Shiro SD8201 User manual

•User Manual •
SD8201
Digital Enhanced Cordless Communication

U
Us se er r M Ma an nu ua al l
1
Contents
WHAT THE SYMBOLS MEAN............................................................ 1
KEYPAD DESCRIPTION (HANDSET + BASE UNIT ..................................... 2
SETTING UP YOUR TELEPHONE....................................................... 3
INSTALLATION........................................................................... 4
IMPORTANT SAFETY INFORMATION .................................................. 5
WARRANTY INFORMATION............................................................. 5
MAKING AND ANSWERING CALLS ..................................................... 6
PHONEBOOK............................................................................. 6
CALL LOGS............................................................................... 7
BASE SETTINGS.......................................................................... 9
HANDSET REGISTRATION ............................................................. 11
INTERCOM AND TRANSFER ........................................................... 11
TROUBLESHOOTING ................................................................... 12
TECHNICAL DETAILS................................................................... 13
DECLARATION OF CONFORMITY ..................................................... 13
WHAT THE SYMBOLS MEAN
Battery charge level Whenever this shows ‘nearly empty’ ( ), put the
handset on the base unit to charge the batteries. While the
battery is being charged, the level shown will keep
changing.
Outside call You are connected to an outside call.
Intercom call You are connected to an intercom call.
Phone book Show the names and numbers of stored record.
Mute Your handset's microphone is muted.
Up and down arrows To browse through the programming menu for more
options.
Signal level Shows the strength of the signal between the handset and
base unit, and flashes when you are out of range of the
base unit, when the level is low, or the symbol is flashing,
move closer to base unit.
Speakerphone Your handset’s loudspeaker is on.
Messages You have missed call.

U
Us se er r M Ma an nu ua al l
2
KEYPAD DESCRIPTION (HANDSET + BASE UNIT) AS
CHARGE li
g
ht
The CHARGE light comes on
when the handset's batteries are
being charged.
Before you can use the handset to make
calls for the first time, you will need to
fit and fully charge the battery for 15
hours.
MENU Button
Press to enter menu mode and
enter sub-menu. With the key
“*” to lock or unlock the
keyboard
CALL Button
Press to begin, answer and
end a telephone call.
UP and DOWN Button
In standby mode, press to show
phonebook list
Press during programming to
move through the menu.
Press during a call to change the
volume in the earpiece.
Clear button
Press and hold (2-3seconds)
to switch the handset on and
off.
Press during programming to
go back to the previous
option, or to clear digits one
by one from the display.
Press during a call to mute
the microphone.
Phonebook Button
INT Button
Press to make an intercom
call (if you have more than
one handset)
SPEAKERPHONE Button
Press to turn the
speakerphone ON/OFF
IN USE light
The IN USE light
comes on when you
have a connection to
the telephone line.
HANDSET LOCATOR button
Press this to make the
handset ring,
if you cannot remember
where you put it.
Press it again to stop the
handset ringing.
In standby mode, press to enter
phonebook menu.
Press to confirm selection.
You need the button if your phone is
connected to a PABX

U
Us se er r M Ma an nu ua al l
3
SETTING UP YOUR TELEPHONE
Connection and conditions for use
You can connect your SD8201 to a direct exchange line (DEL), a line connected to a local
exchange, with its own phone number; to an extension socket connected to a DEL; or to an
extension on an approved compatible PBX. Do not connect the SD8201 as an extension to a
payphone.
How many phones can you connect?
The ringer equivalence numbers (RENs) of all instruments (phones, fax machines, etc.)
connected to an exchange line must not add up to more than 4, otherwise, one or more of
them may not ring and/or answer calls correctly. The SD8201 has a REN of 1, and most
other telephones have a REN of 1 unless marked otherwise.
Radio signals between handset and base unit
To use your handset and base unit together, you must be able to establish a radio link
between them. Be aware that:
• Sitting the base unit as high as possible will give better results, in a two-storey
house, the best position may be on the first-floor landing.
• Any large metal object, like a fridge, a mirror or a filing cabinet, between the
handset and base unit may block the radio signal.
• Other solid structures, like walls, may reduce the signal strength.
Choosing a site for the base unit
The base unit should be placed on a level surface, in a position where:
• The mains adapter plug will reach a 230-V AC switched mains supply socket; never
try to lengthen the mains power cable.
• The telephone cable will reach your telephone line socket or extension socket.
• It is not close to another telephone, this can cause radio interference.
• It is not close to a sink, bath or shower, or anywhere else where it might get wet.
• It is not close to other electrical equipment, fridges, washing machines, microwave
ovens, TVs, fluorescent lights, etc.
What's in this pack
Please check the box contents for completeness.
If any parts are missing, return complete box to
your supplier.
• The cordless handset
• The base unit
• 2x rechargeable battery
• A telephone line cable (different from country to country)
• A mains power lead and adaptor (different from country to
country)
• Charger pods (not available for single handset)
• User manual
Note: Keep your proof of purchase to support any warranty claim.

U
Us se er r M Ma an nu ua al l
4
INSTALLATION
1. Choose a suitable site for the base unit
Make sure it is not near to another telephone, nor to other electrical equipment.
2. Plug the mains power
lead and the telephone
line cord into the rear of
the base unit
3. Plug the mains adapter
into a 230 V AC, 50 Hz
mains socket, with the
switch on the socket set to OFF
Note: The illustration of adaptor
may vary from country to country.
4. Switch on mains power at the socket
5. Fit the battery in the handset(s)
Insert the battery pack as shown. Fit the battery compartment cover,
Sliding it until it clicks firmly into position.
6. Connect the base unit to the telephone line
Switch off power at the mains socket.
Insert the telephone line plug into the socket.
Switch mains power back on
Make sure the mains socket is
switched on if you want to use
the phone---it will not work
without electrical power.
Use the plug to raise the shutter
before pushing it into the socket
Note:
1. The charge pod does not have a connection
to the
telephone line.
2. When Handset is placed onto the charge pod, a
red light lights up to indicate it is charging.
3. The illustration of telephone's socket may vary
from country to country.
Please note the battery cell polarity
during insert.

U
Us se er r M Ma an nu ua al l
5
IMPORTANT SAFETY INFORMATION
This equipment is not designed for making emergency calls in the event of a power failure.
Alternative arrangements should be made for access to emergency services.
(This means that you should also have a basic phone that does not need mains power,
connected to your line so that you can make calls during a power failure)
People with a heart pacemaker should consult their doctor before using the telephone.
If you wear a hearing aid, you should note SD8201 works by transmitting radio waves
between base and handset that may cause a humming noise.
1. DO NOT clean any part of your phone with benzene, thinner or other solvent chemicals,
which may cause permanent damage to your phone. This damage is not covered by the
Guarantee. When necessary, clean it with a damp cloth.
Cleaning it with a wet cloth may give you an electric shock.
2. DO NOT use this equipment in places where volatile or explosive materials may be
present.
3. DO NOT let the base unit get wet. Electrical equipment can cause serious injury if used
while you are wet or standing in water. NEVER use your phone during a thunderstorm.
Unplug the base unit from the telephone line and the mains socket when there are storms
in your area. Damage caused by lightning is not covered by the Guarantee.
4. The SD8201 will produce a certain amount of heat during operation. For this reason it is
recommended that this equipment is NOT placed in direct contact with antique, veneered
or delicate furniture surfaces.
5. DO NOT dispose batteries with normal household waste.
6. The SD8201 DECT phone emits radio signals which could interfere with other electronic
equipment, computers, radio, TV set, clock radio alarms, etc.
A distance of at least one meter should be maintained between SD8201 base station and
other equipment. This will minimize the risk of such interference.
7. When you do not need to carry your handsets around, leave them on the base unit or
charger pod, to keep the batteries charged.
8. If you hear a warning tone as move around during a call, and/ or the sound in the
earpiece becomes faint or distorted; you may be going out of range of the base unit.
Move nearer to the base unit within 20 seconds, until the tone stops. Otherwise your call
may be cut off.
WARRANTY INFORMATION
Your phone is covered by a 12-month warranty from the date of purchase shown on your
sales receipt. The warranty does not cover the batteries, misuse or damage caused by a
storm or excessive voltages.
If you have any problems using the phone, check the Troubleshooting section at the back of
this manual. If you need to return your SD8201 to our Repair Center while it is under
guarantee, there will be some handling charge.

U
Us se er r M Ma an nu ua al l
6
MAKING AND ANSWERING CALLS
To switch the handset ON or OFF
• Press the CLEAR button briefly to switch the handset ON,
• Press and hold the CLEAR button for 1 second to switch the handset OFF.
To make a call
1. Key in the telephone number (If you make a mistake, press CLEAR button to clear
digits from the display. To clear all digits, press and hold CLEAR button.)
2. Press the CALL button.
Or you also can dial the stored number through PHONEBOOK button.
Note: You can dial the number after you press the CALL button if you need, but you won't
be able to correct any mistakes if you do it in this way.
When you dial the outside line access digit (e.g. 9) then the telephone number, press and
hold the "#" button about 2 seconds for a pause.
To answer a call
When the handset and base unit ring, press the CALL button to answer a call, and the
symbol or appears in the display.
When the AUTO TALK is turned on, you can simply answer the call by lifting the handset
from the base unit (see AUTO TALK).
To end a call
Press the CALL button to end a call.
To save a call
After you dial or receive a call, you can press MENU button to save it.
Earpiece volume
During a call, to adjust the volume of the earpiece:
Press the UP or DOWN button to change the volume (1 to 10).
Muting the mouthpiece
To put a call "on hold", so that the person on the other hand end cannot hear you:
Press the CLEAR button once
While the mouthpiece is muted, you cannot press any number key to send digits down the
line.
To get back to the call:
Press the CLEAR button again.
PHONEBOOK
Up to 30 records could be stored in each handset's Phone Book. Each record can store up to
20 digits, and names of up to eight characters could be stored with the number. In standby
mode, press UP/DOWN button to show phonebook list. There are two ways to enter
phonebook.
In standby mode, press PHONEBOOK button to enter phonebook; or through MENU and
UP/DOWN button to enter phonebook.
To store new number into phonebook
1. Press the PHONEBOOK button, the display shows ADD
2. Press the PHONEBOOK button again, then key in the name and the number
3. Press the PHONEBOOK button to confirm
4. Press the CLEAR button twice to return to standby mode, or you can continue to
store number.

U
Us se er r M Ma an nu ua al l
7
To clear a number from phonebook
1. Press the PHONEBOOK button, the display shows ADD
2. Press UP/DOWN button to the location DELETE
3. Press PHONEBOOK button to confirm, then press UP/DOWN button to select the
number you want to delete
4. Press the PHONEBOOK to delete the name and number, the display shows DELETE
5. Press the PHONEBOOK to confirm, then Press the CLEAR button twice to return to
standby mode
To modify (change) a number in phonebook
1. Press the PHONEBOOK button, the display shows ADD
2. Press UP/DOWN button to the location EDIT, then press PHONEBOOK to confirm,
the display shows the first stored number
3. Press UP/DOWN button to select the number you want to modify, then press
PHONEBOOK to confirm
4. Press CLEAR button to clear the old name, then key in the new name;
5. Press PHONEBOOK to save the edit, press CLEAR button to clear the old number
and key in the new number.
6. Press PHONEBOOK to save the change, then Press the CLEAR button to return to
standby mode
To clear all numbers from phonebook
1. Press the PHONEBOOK button, the display shows ADD
2. Press UP/DOWN button to the location DEL ALL
3. Press the PHONEBOOK button to delete all numbers
CALL LOGS
You must subscribe to Caller ID service from your service provider to use this feature.
Call Logs store information related to received calls, missed calls and dialed calls. The
SD8201 can store up to a maximum of 30 calls, consisting of 10 received, missed and dialed
calls respectively.
To check call records
1. Press the MENU button
The display shows CALL LOGS
2. Press the PHONEBOOK button, then press UP/DOWN button to the locations
MISSED, RECEIVED, or DIALED calls.
3. Press the PHONEBOOK button, then press UP/DOWN button to scroll the records
4. If you receive or dial a new number that you have not stored in phonebook, the
display shows NO NAME. Press the PHONEBOOK button to show the number,
To save a number in call logs
When you received a new number, you want to store in phonebook. The following is for
your reference.
1. Repeat step 1 to 4 above, until the display shows the new number.
2. Press the CLEAR button, the displays shows NO NAME
3. Press the MENU button, the displays shows SAVE
4. Press the MENU button, the displays shows NAME?
5. Key in the name, Press the MENU button to save.
To dial a number from call logs
1. Ensure the required name/number is visible on the display
2. Press CALL button to DIAL

U
Us se er r M Ma an nu ua al l
8
HANDSET SETTINGS
Key tone on and off
Each time you press a key on your handset, you hear a tone. You can turn this off if
needed.
1. Press the MENU button, then press UP/DOWN button to the location HANDSET
2. Press the PHONEBOOK button
The display shows KEYTONE
3. Press the PHONEBOOK, then UP/DOWN button
The display shows ON? or OFF?
4. Press the PHONEBOOK button to confirm
Ringer Volume (EXT)
You have a choice of five volume levels (1 to 5).
1. Press the MENU button, then press UP/DOWN button to the location HANDSET
2. Press the PHONEBOOK button, then press UP/DOWN button to the location EXT VOL
3. Press the PHONEBOOK button. The display shows the current volume level
4. Press UP/DOWN button to change the volume
5. Press the PHONEBOOK button to confirm the volume level you want
Ringer Volume (INT)
You have a choice of five volume levels (1to 5).
1. Press the MENU button, then press UP/DOWN button to the location HANDSET
2. Press the PHONEBOOK button, then press UP/DOWN button to the location INT VOL
3. Press the PHONEBOOK button. The display shows the current volume level
4. Press UP/DOWN button to change the volume
5. Press the PHONEBOOK button to confirm the volume level you want
Ringer Melody (EXT)
You have a choice of 9 ringing melodies
1. Press the MENU button, then press UP/DOWN button to the location HANDSET
2. Press the PHONEBOOK button, press UP/DOWN button to the location EXT RING
3. Press the PHONEBOOK button. The display shows the current melody
4. Press UP/DOWN button to change the melody
5. Press the PHONEBOOK button to confirm the melody you want
Ringer Melody (INT)
You have a choice of 9 ringing melodies
1. Press the MENU button, then press UP/DOWN button to the location HANDSET
2. Press the PHONEBOOK button, press UP/DOWN button to the location INT RING
3. Press the PHONEBOOK button. The display shows the current melody
4. Press UP/DOWN button to change the melody
5. Press the PHONEBOOK button to confirm the melody you want
Our handset name
1. Press the MENU button, then press UP/DOWN button to the location HANDSET
2. Press the PHONEBOOK button, press UP/DOWN button to the location SET NAME
3. Press the PHONEBOOK button. The display shows the current name
4. Press the CLEAR button repeatedly to clear the display, key in your chosen name
5. Press the PHONEBOOK button to confirm
Display language
You can change the default language to any language you prefer.
1. Press the MENU button then press UP/DOWN button to the location HANDSET
2. Press the PHONEBOOK button. Press UP/DOWN button again to location LANGUAGE
3. Press the PHONEBOOK button. The display shows the current language
4. Press UP/DOWN button to the language you prefer

U
Us se er r M Ma an nu ua al l
9
Auto Talk
Normally, you need to press the CALL button to answer an incoming call. But with
AUTOTALK turned on, when your handset is resting on the base unit and it rings for an
incoming call, you can answer the call by simply lifting the handset. To turn auto-talk
ON/OFF:
1. Press the MENU button then UP/DOWN button to HANDSET
2. Press the PHONEBOOK button then UP/DOWN button to AUTOTALK
3. Press the PHONEBOOK button again, the display shows ON? / OFF?
4. Press the PHONEBOOK button to confirm
!If you have turned auto-talk on, do not press the CALL button after you've answered a
call by lifting the handset, otherwise, you'll disconnect the call.
To Lock /Unlock the keypad
Press MENU button and “ “ button consecutively to lock or unlock the keypad.
BASE SETTINGS
Call Barring Function
Call barring enables you to restrict or bar certain types of calls from your phone.
To set call barring number
1. Press MENU button then UP/DOWN button until the display shows BASE SET
2. Press the PHONEBOOK button, the display shows PIN?
3. Key in your PIN number and press the PHONEBOOK button, then press UP/DOWN
button to the location BARRING
4. Press the PHONEBOOK button, then UP/DOWN button
The display shows one of the numbers from 1 to 5 (The maximum call barring
numbers you can set), key in the telephone number you want to set call Barring
5. Press PHONEBOOK button, then the display shows HS?
Key in the handset number that you want to set call barring
6. Press PHONEBOOK button to confirm
To delete call barring number
1. Press MENU button then UP/DOWN button until the display shows BASE SET
2. Press the PHONEBOOK button, the display shows PIN? Key in your PIN number
3. Press the PHONEBOOK button, then UP/DOWN button to the location BARRING
4. Press the PHONEBOOK button, the display shows the call barring number you set.
5. Press the CLEAR button to delete the number
6. Press PHONEBOOK button to confirm
Base Melody
You have a choice of nine ringing melodies for the base unit
1. Press MENU button then UP/DOWN button to the location BASE SET
2. Press PHONEBOOK button and Key in the PIN number
3. Press PHONEBOOK button then UP/DOWN button to the location B RING
4. Press UP/DOWN button to change the melody
5. Press the PHONEBOOK button to confirm the melody you chosen
Base Volume
You have a choice of five volume levels (1-5)
1. Press MENU button then UP/DOWN button to the location BASESET
2. Press PHONEBOOK button and Key in the PIN number
3. Press PHONEBOOK button then UP/DOWN button to the location B VOLUME
4. Press UP/DOWN button to change the volume
5. Press the PHONEBOOK button to confirm the volume level you chosen
