ShorePower WU-120 User manual
Level One Electric Vehicle Charging Station
Wall Mount
Product Guide
Model # WU-120
ShorePower Technologies
2351 NW York St.
Portland, OR 98664
503-892-7345
www.shorepower.com
2
3
Warnings
Installation & Mounting
Usage
Maintenance & Cleaning
Troubleshooting
Features & Specifications
Accessories
Warranty
Other ShorePower Products
Table of Contents
P.2
P.4
P.9
P.10
P.11
P.12
P.13
P.14
P.15
4
Installation & Mounting
1. Using Diagram 1, mark
the mounting bolt pattern
on your mounting surface
2. Drill Pilot holes into the
mounting surface (Follow
the fastener recommen-
dations as to the depth
and diameter of the pilot
hole. Different materials
will require different fas-
teners and pilot holes. I.e.
Steel, Concrete, Wood.
3. Install appropriate fasten-
ers through each of the
four corners of the station
from inside the station.
See picture.
5
4. Locate the wiring conduit
knockout at the base of
the charging station. Se-
lect which knockout to
punch by sizing against
your conduit diameter.
5. Remove the selected
knockout.
6. Insert the conduit pass
through hardware into
the knockout hole
6
7. Attach the conduit hard-
ware nut to the protrud-
ing conduit.
8. Tighten to the recom-
mended specifications
7
9. Run the 4 conductor ser-
vice cable through con-
duit into the charging sta-
tion
10.Connect each of the 4
leads to the appropriate
distribution lugs as shown
11.Torque the allen head lug
screws to the recom-
mended specifications
G L1 N L2
8
Mounting Bolt Pattern is a 18.5” x 14.5” Rectangle
as seen Below
Diagram 1
9
Usage
Shorepower Level 1 Charging Stations
work like any standard 120 volt oulet with
one exception. We recommend that the
circuit breaker for the specific outlet you
intend to use, be shut off prior to plugging
in. Once plugged in, you can then switch
the circuit breaker back on and commence
charging.
1. Switch Circuit
Breaker to the “Off”
Position
2. Plug extension cord
into Charging Station
Outlet
3. Switch Circuit
Breaker to the “On”
Position
Reverse the process for
disconnecting from charg-
ing station.
1
2
3
10
Maintenance & Cleaning
Regular maintenance is not generally required on ShorePower Charging Stations. However you may find the need
to replace the illumination bulb within the Unit. To do so, follow these simple steps:
1. Shut off main power service to Charging Station
2. Open Station Access Panel by inserting the latch key supplied with station and turning counter clockwise
3. Grasp Bulb with soft cloth and turning counter clockwise until the bulb becomes free
4. Replace bulb with same compact fluorescent or equivalent incandescent
Cleaning:
Use a soft damp cloth with a mild detergent to wipe exterior of unit with main power service off
Standard Stainless Steel polish can be used on the exterior as needed
User
Serviceable
Light Bulb
11
Troubleshooting
Problem: Charging Station Does not Light Up
Shut power to station off
Open charging station with the included door key
Verify that the lighting circuit breaker mounted on the back panel is switched to the on
position
Remove the light bulb and test it a known good standard light fixture such as a table
lamp
Problem: Charging Station does not charge Vehicle (No Power Output)
Verify all Circuit Breakers are in the on position
Verify no circuit breakers have been tripped by switching them to the full off position
Then back to the on position
If there is still no power, verify that the main power to the station is on. WARNING,
SHOCK DANGER! Open charging station door and measure voltages at L1 and L2 of the
Charging stations main input buss. You should read 110v—120v between L1 and N and
L2 and N. If no power is found, you have a main supply issue.
Problem: Circuit Breaker will not stay “On”
If the circuit breaker will not stay in the on position, please disconnect any cords you
May have connected. If the problem no longer exists, check your cords and vehicle for
Circuits.
If the problem still exists, replace the circuit breaker in question
12
Features & Specifications
Input Power Recommended 240 Volt or 208 Volt, 100 amp
(min. 50 amp) 4 Wire Circuit
Output Power 4 Level 1 GFCI 120 Volt 20 Amp Outlets (NEMA 5-
20R) One Station Serves up to 4 Vehicles
Material Stainless Steel
Outdoor Rating NEMA
Dimensions H20” x W16” x D9”
Weight 40 Pnds apx.
Visibility Backlit Outlets and ShorePower Logo for Nighttime
Visibility
Upgradability Fully Upgradable to future Level 2, SAE J1772 Stan-
dards, with corded Connector
Warranty Full 10 Year Warranty against Defects in workman-
ship and materials. (Excluding Outlets)
Safety Hi Visibility
Ground Fault Circuit Interrupt equipped Outlets
13
Accessories
Payment and Monitoring Control System
ShorePower Accessory payment and monitoring
control system allows owners to:
Optionally charge customers for use of the
charging station
Switch Power ports on and off via our web
interface
Meter power usage per individual power out-
let and access Statistical data via our web in-
terface
Call ShorePower Technologies for Pricing and
detailed information 503-892-7345
14
Warranty
Limited Warranty
ShorePower Technologies warrants its factory-installed wall mount charging station, free standing charging sta-
tion, and TSE Pedestals to be free from failure due to defects in material and workmanship under normal care
and proper usage in a residential installation which fully complies with all National Electrical Code requirements
for a period of 1 years from the date of installation.
In the event the product fails to comply with this warranty, ShorePower Technologies will, at its option, either
repair or replace the product at without charge. To obtain warranty service the purchaser should return the prod-
uct to the place of purchase or deliver the product prepaid to ShorePower Technologies at the address set forth
below. Proof of purchase in the form of a receipt or invoice, which is evidence that the unit is within the warranty
period, must be presented to obtain warranty service.
ShorePower Charging Stations Additional Information
These warranties do not cover failure or damage due to improper storage, installation, operation, maintenance,
accident, misuse, abuse or negligence. These warranties do not cover reimbursement for labor, transportation,
gaining access, removal, installation, temporary power, or any other expenses that may be incurred in connection
with repair or replacement of the ShorePower Technologies products.
The remedies as provided under these warranties are the exclusive remedy of the purchaser and the limit
of the liability of ShorePower Technologies with respect to these products, whether in contract, in tort
(including negligence or strict liability) or otherwise. ShorePower Technologies disclaims all other war-
ranties, including without limitation any implied warranty of merchantability or of fitness for a particular
purpose, and shall not be liable for any incidental or consequential damages.
With respect to products purchased by consumers of the United States for personal use, the implied warranties,
including but not limited to the warranties of merchantability and of fitness for a particular purpose, are not ex-
cluded but are limited to the duration of the warranty period. Some states do not allow the exclusion or limitation
of incidental or consequential damages or implied warranties, so the above limitations or exclusions may not
apply to you. This warranty gives you specific legal rights, and you may also have other rights which vary from
state to state.
All product warranties are rendered null and void if a breaker other than those specifically listed by UL
for use in the type BR product is installed.
SHOREPOWER TECHNOLOGIES
WARRANTY DEPARTMENT
2351 NW York St.
Portland, OR 97210
15
Other ShorePower Products
Level 1 & 2 Free Standing EV
Charging Stations
Truck Stop Electrification Pedestals
