Show Tec LED Strip Set 4x 40cm RGB V1 User manual

LED Strip Set 4x 40cm RGB V1
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Ordercode: 42772
MANUAL
ENGLISH

1
Ordercode: 42772
LED Strip Set 4x 40cm RGB
Table of contents
Warning ...............................................................................................................................................................................2
Safety Instructions .........................................................................................................................................................2
Operating Determinations ..........................................................................................................................................4
Connection with the mains.........................................................................................................................................4
Return Procedure..........................................................................................................................................................5
Claims..............................................................................................................................................................................5
Description of the device.................................................................................................................................................6
Overview ........................................................................................................................................................................6
Installation...........................................................................................................................................................................7
Connecting LED Strip Set 4x 40cm RGB ....................................................................................................................7
Set Up and Operation .......................................................................................................................................................8
Remote control .............................................................................................................................................................8
Maintenance....................................................................................................................................................................10
Troubleshooting ...............................................................................................................................................................10
No Light.........................................................................................................................................................................10
Product Specifications....................................................................................................................................................11
Notes ..................................................................................................................................................................................12

2
Ordercode: 42772
LED Strip Set 4x 40cm RGB
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear to be damaged from shipping or the carton
itself shows signs of mishandling. Save the carton and all packing materials. In the event that the fixture
must be returned to the factory, it is important that the fixture be returned in the original factory box and
packing.
Your shipment includes:
●Showtec 4x LED Strip RGB 40cm
●Power adapter
●RGB controller
●Remote control
●3x Extension cables 50cm
●8x Mounting clips
●User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving the lifespan is of higher priority, place care in providing for lower
operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
●be qualified
●follow the instructions of this manual

3
Ordercode: 42772
LED Strip Set 4x 40cm RGB
Before your initial start-up, please make sure that there is no damage caused by transportation. Should
there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
•Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
•Never remove warning or informative labels from the unit.
•Never use anything to cover the ground contact.
•Never place any material over the LEDs.
•Never look directly into the light source.
•Never leave any cables lying around.
•Never use the LED strip in sealed or hot places.
•Do not connect this device to a dimmerpack.
•Do not switch the device on and off in short intervals, as this will reduce the device’s life.
•Do not shake the device. Avoid brute force when installing or operating the device.
•Only use the device indoors, avoid contact with water or other liquids.
•Only operate the device after having familiarized with its functions.
•Avoid flames and do not put close to flammable liquids or gases.
•Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord holding it by the plug. Never pull out the plug by tugging the power cord.
•Make sure that the device is not exposed to extreme heat, moisture or dust.
•Make sure that the available voltage is not higher than stated on the rear panel.
•Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
•If the LEDs are obviously damaged, it has to be replaced.
•If device was dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
•If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
•If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
•The user is responsible for correct positioning and operating of the LED strips. The manufacturer will
not accept liability for damages caused by the misuse or incorrect installation of this device.
•This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
•Repairs, servicing and electric connection must be carried out by a qualified technician.
•WARRANTY: Till one year after date of purchase.

4
Ordercode: 42772
LED Strip Set 4x 40cm RGB
Operating Determinations
●This device is not designed for permanent operation. Regular operation breaks will ensure that the
device will serve you for a long time without defects.
●The minimum distance between light-output and the illuminated surface must be bigger than 0,5
meter.
●The maximum ambient temperature ta = 40°C must never be exceeded.
●The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
●If this device is operated in any other way than the one described in this manual, the product may
suffer damages and the warranty becomes void.
●Any other operation may lead to dangers like short-circuit, burns, electric shock, crash etc.
You endanger your own safety and the safety of others!
Improper installation can cause serious injuries and/or damage of property!
Connection with the mains
Connect the device to the mains with the power plug.
Always check if the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE GROUND
Make sure that the device is always connected properly to the earth!
Improper installation can cause serious damage to people and property!

5
Ordercode: 42772
LED Strip Set 4x 40cm RGB
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause of the
return. Be sure to properly pack fixture as any shipping damage resulting from inadequate packaging is
the customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name.
02) Your address.
03) Your phone number.
04) A brief description of the symptoms.
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to notify and submit claims with the shipper in the event that the fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
agreed otherwise in writing.
Complaints against us must be made known in writing or by fax within 10 working days after receipt of the
invoice. After this period, complaints will not be handled anymore.
Complaints will only be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement of which the obligation is resulting.

6
Ordercode: 42772
LED Strip Set 4x 40cm RGB
Description of the device
Features
The Showtec LED Strip Set 4x40 cm RGB is a set of 4x 40cm RGB LED-strips which are easy to install. It can
be controlled by the included IR remote control.
●Plug and Play
●Built-in Programs
●Easy to operate
●LED: 5050 RGB, 15 LEDs per strip.
●Power consumption: 18W
●Power supply: 12V, 1,5A
●PCB color: White
●Beam angle: 120 degrees
●IP rating: IP20
●Included: Controller, IR remote, Power adapter, Mounting clips and extension cables
●Dimensions: 400 x 10 x 8 mm (LxWxH) per strip
●Weight: 0,40 kg (complete set)
Overview
Fig. 01
01) DC 12V 1,5A power adapter
02) 4x 40cm LED strip 15 LEDs 5050 RGB
03) 3x 50cm Extension cables
04) RGB Controller
05) IR remote control

7
Ordercode: 42772
LED Strip Set 4x 40cm RGB
Installation
Remove all packing materials from the LED Strip Set 4x 40 cm RGB. Check that all foam and plastic
padding is removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Connecting LED Strip Set 4x 40cm RGB
First you have to mount the LED strips on a flat surface. Use the included mounting clips to attach the LED
strips on the surface. After mounting the LED strips follow the next steps to connect the LED strips in order
to operate the LED strips with the IR remote control.
Fig. 02
01) Connect the RGB controller to the first LED strip or Extension cable.
02) Connect the power adapter to the RGB controller.
03) Plug the power adapter into a proper electric power supply socket. Do not supply power before the
whole system is set up and connected properly.

8
Ordercode: 42772
LED Strip Set 4x 40cm RGB
Set Up and Operation
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Remote control
The remote control will sent a signal to the IR-sensor cable from the RGB controller, see figure 03.
Fig. 03

9
Ordercode: 42772
LED Strip Set 4x 40cm RGB
Button
Function
Description
Increase
Increase the intensity of the LEDs
Decrease
Decrease the intensity of the LEDs
Off
Switch the LED strips off
On
Switch the LED strips on
Red
Activate the Red color
Green
Activate the Green color
Blue
Activate the Blue color
White
Activate the White color
Flash
Activate the flash mode
Strobe
Activate the strobe mode
Fade
Activate the fade mode
Smooth
Activate the smooth mode
Colors
Activate one of the 12 pre-programmed colors

10
Ordercode: 42772
LED Strip Set 4x 40cm RGB
Maintenance
The operator has to make sure that safety-related and machine-technical installations are to be
inspected by an expert after every year in the course of an acceptance test.
The operator has to make sure that safety-related and machine-technical installations are to be
inspected by a skilled person once a year.
The following points have to be considered during the inspection:
01) All screws used for installing the device or parts of the device have to be tightly connected and
must not be corroded.
02) There may not be any deformations on housings, fixations and installation spots.
03) Mechanically moving parts like axles, eyes and others may not show any traces of wearing.
04) The electric power supply cables must not show any damages or material fatigue.
The LED Strip Set 4x 40cm RGB requires almost no maintenance. However, you should keep the unit clean.
Otherwise, the fixture’s light-output will be significantly reduced. Keep connections clean. Disconnect
electric power, and then wipe the LED Strip with a cloth. Do not use alcohol or solvents.
Troubleshooting
No Light
This troubleshooting guide is meant to help solve simple problems.
If a problem occurs, follow the steps below in sequence until a solution is found. Once the unit operates
properly, do not carry out the following steps.
If the light effect does not operate properly, refer servicing to a technician.
Response: Suspect two potential problem areas: power supply and the LEDs.
01) Power supply. Check that the unit is plugged into an appropriate power supply.
02) The LEDs. Return the LED Strip Set 4x 40cm RGB to your Showtec dealer.
03) If all of the above appears to be in order, switch the unit on again.
04) If you are unable to determine the cause of the problem, do not open the LED Strip Set 4x 40cm
RGB, as this may damage the unit and the warranty will become void.
05) Return the device to your Showtec dealer.
Problem
Probable cause(s)
Solution
The device does
not function at all
No power to the device
•Check if power is switched on and
cables are plugged in
LEDs damaged
•Disconnect the device and return
it to your dealer
The power supply settings do not
match local AC voltage and
frequency
•Disconnect the device. Check
settings and correct if necessary
The device works
correctly but
responds
erratically or not
at all to the
remote control
The remote control battery is flat
•Replace the battery of the remote
control
No light or lamp
cuts out
intermittently
Device is too hot
•Allow the device to cool down
•Turn up the air conditioning
LEDs damaged
•Disconnect the device and return
it to your dealer

11
Ordercode: 42772
LED Strip Set 4x 40cm RGB
Product Specifications
Design and product specifications are subject to change without prior notice.
Website: www.Showtec.info
Email: [e-mail]
Model:
Showtec LED Strip Set 4x 40 cm RGB
Power supply:
12V, 1,5A
Power consumption:
18W
Protection rate:
IP20
Dimensions:
400 x 10 x 8 mm (LxWxH) per strip
Weight:
0,40 kg (complete set)
Operating and Programming:
Control Protocol:
IR
Electro-mechanical effects:
LED Quantity:
15 LEDs per strip
LED Type:
5050 RGB
PCB color:
White
Beam angle:
120 degrees
Plug and Play
Built-in programs
Max. ambient temperature ta:
40°C
Minimum distance:
Minimum distance from flammable surfaces:
0,5 m
Minimum distance to lighted object:
1 m

12
Ordercode: 42772
LED Strip Set 4x 40cm RGB
Notes

13
Ordercode: 42772
LED Strip Set 4x 40cm RGB

14
Ordercode: 42772
LED Strip Set 4x 40cm RGB

©2016 Showtec
