Show Tec Star Sky Pro II User manual

Star Sky Pro II V1
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Ordercode: 40372
MANUAL
ENGLISH

1
Ordercode: 40372
Star Sky Pro II
Table of contents
Warning ...............................................................................................................................................................................3
Safety Instructions .........................................................................................................................................................3
Operating Determinations ..........................................................................................................................................5
Rigging ............................................................................................................................................................................5
Connection with the mains.........................................................................................................................................7
Return Procedure..........................................................................................................................................................8
Claims..............................................................................................................................................................................8
Description of the device.................................................................................................................................................9
Overview ......................................................................................................................................................................10
Controller - Frontside ..................................................................................................................................................10
Controller - Backside ..................................................................................................................................................11
Installation.........................................................................................................................................................................11
Set Up and Operation .....................................................................................................................................................11
Control Modes.............................................................................................................................................................12
One Star Sky (Built-in programs, Manual mode and Macro mode)..............................................................12
One Star Sky (Sound-controlled) ..........................................................................................................................12
Multiple Star Sky devices (Master/Slave control)...............................................................................................12
Multiple Star Sky devices (DMX Control) .............................................................................................................13
Fixture Linking...............................................................................................................................................................14
Data Cabling...............................................................................................................................................................14
Control Panel ...............................................................................................................................................................15
Control Mode ..............................................................................................................................................................15
DMX Addressing ..........................................................................................................................................................15
Menu Overview...........................................................................................................................................................16
Main Menu Options....................................................................................................................................................17
1. Main Settings ........................................................................................................................................................17
1.1. Language settings............................................................................................................................................17
1.2. Reset settings.....................................................................................................................................................17
1.3. Master/Stand-alone mode.............................................................................................................................17
1.4. Auto/Sound-controlled mode .......................................................................................................................17
1.5. Display settings..................................................................................................................................................18
1.6. Display lock........................................................................................................................................................18
1.7. System information...........................................................................................................................................18
1.8. Timer....................................................................................................................................................................18
2. DMX settings .........................................................................................................................................................19
2.1. DMX starting address .......................................................................................................................................19
2.2. Channel mode selection ................................................................................................................................19
2.3. DMX failure mode ............................................................................................................................................19
3. Dimmer menu.......................................................................................................................................................20
3.1. Dimmer intensity ...............................................................................................................................................20
3.2. Strobe frequency..............................................................................................................................................20
3.3. Red, Green, Blue intensity...............................................................................................................................20
3.4. Dimmer mode ...................................................................................................................................................21
4. Program menu .....................................................................................................................................................22
4.1. Dimmer intensity ...............................................................................................................................................22
4.2. Strobe frequency..............................................................................................................................................22
4.3. Program speed .................................................................................................................................................22
5. Macro menu.........................................................................................................................................................23
5.1. Macro steps.......................................................................................................................................................23
5.2. Edit steps ............................................................................................................................................................23
DMX Channels .............................................................................................................................................................24
7 channels .................................................................................................................................................................24
28 channels...............................................................................................................................................................25

2
Ordercode: 40372
Star Sky Pro II
Maintenance....................................................................................................................................................................27
Replacing the Fuse.....................................................................................................................................................27
Troubleshooting ...............................................................................................................................................................27
No Light.........................................................................................................................................................................27
No Response to DMX..................................................................................................................................................27
Product Specifications....................................................................................................................................................29

3
Ordercode: 40372
Star Sky Pro II
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
Showtec Star Sky Pro II controller
Blue/White power cable (1,5 m)
User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason, when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving the lifespan is of higher priority, place care in providing for lower
operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity.
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
be qualified
follow the instructions of this manual

4
Ordercode: 40372
Star Sky Pro II
Before the initial start-up, please make sure that there is no damage caused by transportation.
Should there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes contained in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
•Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
•Never remove warning or informative labels from the unit.
•Never use anything to cover the ground contact.
•Never place any material over the LEDs.
•Never look directly into the light source.
•Never leave any cables lying around.
•Do not connect this device to a dimmerpack.
•Do not switch the device on and off in short intervals, as this will reduce the device’s life.
•Do not touch the device’s housing bare-handed during its operation (housing becomes very hot).
Allow the fixture to cool for at least 5 minutes before handling.
•Do not shake the device. Avoid brute force when installing or operating the device.
•Only use the device indoors, avoid contact with water or other liquids.
•Only operate the fixture after having checked if the housing is firmly closed and all screws are tightly
fastened.
•Only operate the device after having familiarized with its functions.
•Avoid flames and do not put close to flammable liquids or gases.
•Always keep the case closed while operating.
•Always allow a free air space of at least 50 cm around the unit for ventilation.
•Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord holding it by the plug. Never pull out the plug by tugging the power cord.
•Make sure that the device is not exposed to extreme heat, moisture or dust.
•Make sure that the available voltage is not higher than stated on the rear panel.
•Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
•If the LEDs are obviously damaged, they need to be replaced.
•If device was dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
•If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
•If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
•For adult use only. The fixture must be installed beyond the reach of children. Never leave the unit
running unattended.
•Never attempt to bypass the thermostatic switch or fuses.
•For replacement use fuses of same type and rating only.
•The user is responsible for correct positioning and operating of the Star Sky. The manufacturer will not
accept liability for damages caused by the misuse or incorrect installation of this device.
•This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
•Repairs, servicing and electric connection must be carried out by a qualified technician.
•WARRANTY: Till one year after date of purchase.

5
Ordercode: 40372
Star Sky Pro II
Operating Determinations
•This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
•The minimum distance between light output and the illuminated surface must be bigger than 1
meter.
•The maximum ambient temperature ta= 40°C must never be exceeded.
•The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
•If this device is operated in any other way than the one described in this manual, the product may
suffer damages and the warranty becomes void.
•Any other operation may lead to dangers like short-circuit, burns, electric shock, crash, etc.
You endanger your own safety and the safety of others!
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer !
Procedure:
•If the Star Sky is lowered from the ceiling or high joists, professional trussing systems have to be used.
•Use the textile hook and loop fastener strips (Velcro) or tie-wraps/shock cords to install the Star Sky.
•The controller must never be fixed swinging freely in the room.
•The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety cable.
•When rigging, derigging or servicing the Star Sky, always make sure, that the area below the
installation site is secured and that there are not any unauthorized people around.

6
Ordercode: 40372
Star Sky Pro II
One Star Sky Pro –Wentex
Multiple Star Sky Pros –Horizontal Installation

7
Ordercode: 40372
Star Sky Pro II
Multiple Star Sky Pros –Vertical Installation
The Star Sky can be mounted to any kind of truss with hook and loop fasteners (Velcro) and/or tie-
wraps/shock cords.
Improper installation can cause serious injuries and/or damage of property!
Connection with the mains
Connect the device to the mains with the power-plug.
Always check if the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE GROUND
Make sure that the device is always properly connected to the earth!
Improper installation can cause serious injuries and/or damage of property!

8
Ordercode: 40372
Star Sky Pro II
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to report and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
agreed otherwise in writing.
Complaints against us must be prepared in writing or sent by fax within 10 working days after receipt of
the invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement from which the obligation is resulting.

9
Ordercode: 40372
Star Sky Pro II
Description of the device
Features
The Star Sky Pro II is a star curtain controller.
Input voltage: 175-240V AC 60/50Hz
Power consumption: 70W
Control: Built-in programs, Manual mode, Macro mode, Sound-controlled mode, Master/Slave, DMX
Built-in programs: 10 patterns with speed, strobe and dimmer control
DMX channels: 7, 28 channels
DMX connector: 3-pin/5-pin XLR IN/OUT
Curtain connector: 5-pin XLR OUT
Power connector: Blue/White power connector IN
Color: Black
Main fuse: F2AL/250V
Curtain fuse: 2 x F10AL/250V
Dimensions: 315 x 178 x 65 mm (LxWxH)
Weight: 1,9 kg
Optional accessories:
89300 –2 x Baseplate
89310 –2 x Baseplate pin
89330 –2 x Telescopic upright –2-way
89342 –1 x Telescopic drape support
40373 –LED curtain, black, 4 x 6 m
40374 –LED curtain, white, 4 x 6 m

10
Ordercode: 40372
Star Sky Pro II
Overview
Fig. 01
Controller - Frontside
Fig. 02
01) Power switch ON/OFF
02) 5-pin XLR curtain # 1 connector OUT
03) 5-pin XLR curtain # 2 connector OUT
04) LCD display + menu buttons
05) Curtain # 2 fuse: F10AL/250V
06) Curtain # 1 fuse: F10AL/250V
07) Main fuse: F2AL/250V
08) Blue/White power connector 175-240V IN

11
Ordercode: 40372
Star Sky Pro II
Controller - Backside
Fig. 03
09) Built-in microphone
10) 3-pin DMX signal connector IN
11) 3-pin DMX signal connector OUT
12) 5-pin DMX signal connector IN
13) 5-pin DMX signal connector OUT
Installation
Remove all packing materials from the Star Sky Pro II. Check if all foam and plastic padding is removed.
Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Connect the device to the main power supply.

12
Ordercode: 40372
Star Sky Pro II
Control Modes
There are 6 modes:
•Built-in programs
•Manual mode (RGB, Group mode)
•Macro mode
•Sound-controlled mode
•Master/Slave
•DMX-512 (7CH, 28CH)
One Star Sky (Built-in programs, Manual mode and Macro mode)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Plug the end of the electric mains power cord into a proper electric power supply socket.
03) When the Star Sky is not connected with a DMX cable, it functions as a stand-alone device.
Please read for more information about the Built-in programs (page 22), Manual mode (pages 20-
21) and Macro mode (page 23).
One Star Sky (Sound-controlled)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Plug the end of the electric mains power cord into a proper electric power supply socket.
03) Turn on the music. If the device is set to sound-control, then the Star Sky will react to the beat of the
music. Please see pages 17 (Sound-controlled mode) and 19 (DMX failure) for more information.
Multiple Star Sky devices (Master/Slave control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Use a 3-pin XLR cable to connect the Star Sky.
The pins:
01) Earth
02) Signal -
03) Signal +
03) Link the units as shown in fig. 04. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX-signal cable. Repeat this process to link the second, third, and fourth units.
You can use the same functions on the master device as described on pages 17-23 (Built-in
programs, Manual mode, Macro mode or Sound-controlled mode). This means that you can set
your desired operation mode on the master device and all slave devices will react the same as the
master device. However, the DMX address of the slave devices must be the same as the one of the
master device.
Multiple Star Sky devices (Master/Slave control)
Fig. 04

13
Ordercode: 40372
Star Sky Pro II
Multiple Star Sky devices (DMX Control)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Use a 3-pin/5-pin XLR cable to connect the Star Sky fixtures and other devices.
04) Link the units as shown in fig. 05. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX-signal cable. Repeat this process to link the second, third, and fourth units.
05) Supply electric power: Plug electric mains power cords into each unit's Blue/White socket, then plug
the other end of the mains power cord into proper electric power supply sockets, starting with the
first unit. Do not supply power before the whole system is set up and connected properly.
Multiple Star Sky devices DMX Set Up
Fig. 05
Note : Link all cables before connecting electric power

14
Ordercode: 40372
Star Sky Pro II
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important:
Fixtures on a serial data link must be daisy-chained in a single line. To comply with the
EIA-485 standard, no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX optically
isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of fixtures on a DMX data link: 30 fixtures
Data Cabling
To link fixtures together, you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable,
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
•DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin.
Ordercode FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
•DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
•DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).

15
Ordercode: 40372
Star Sky Pro II
The Star Sky Pro II can be operated with a controller in control mode or without the controller in
stand-alone mode.
Control Panel
A) LCD display
B) SET/ESC button
C) UP button
D) DOWN button
E) ENTER button
Fig. 06
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address, next time.)
DMX Addressing
The control panel on the front side of the base allows you to assign DMX fixture addresses, which is the first
channel with which the Star Sky will respond to the controller.
Please note, when you use the controller, the unit has 28 channels.
When using multiple Star Sky devices, make sure you set the DMX addresses right.
Therefore, the DMX address of the first Star Sky should be 1(001); the DMX address of the second Star Sky
should be 1+28=29 (029); the DMX address of the third Star Sky should be 29+28=57 (057), etc. Please, be
sure that you do not have any overlapping channels in order to control each Star Sky correctly. If two or
more Star Sky devices are addressed similarly, they will work similarly.
Controlling:
After having addressed all Star Sky fixtures, you may now start operating these via your lighting controller.
Note: After switching on, the Star Sky will automatically detect whether DMX 512 data is received or not.
If there is no data received at the DMX-input, the “LED “ on the control panel will not flash.
If not, the problem may be:
•The XLR cable from the controller is not connected with the input of the Star Sky Pro II.
•The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It is necessary to insert an XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.
Display Off after 30 seconds
When no button is pressed for 30 seconds, the display will turn off.
To light up the display, you have to press the SET/ESC, UP, DOWN or ENTER button.
Once you have pressed the button, the display will light up.

16
Ordercode: 40372
Star Sky Pro II
Menu Overview

17
Ordercode: 40372
Star Sky Pro II
Main Menu Options
1. Main Settings
01) Switch power to the device. The display will show one of the 20 following options:
02) Press the SET/ESC button to enter the settings menu. The display shows .
03) Press the ENTER button to enter the device’s settings.
04) Press the UP/DOWN buttons to toggle between the following submenus:
1.1. Language settings
01) When the display shows , press the ENTER button to open the language settings.
02) Press the UP/DOWN buttons to choose one of the 3 languages: English, French or German.
03) Press the ENTER button to confirm your choice.
1.2. Reset settings
01) When the display shows , press the ENTER button to open the menu.
02) Press the UP/DOWN buttons to choose between ON and OFF.
03) If you choose ON, and press the ENTER button, the device will perform reset.
04) If you choose OFF and press the ENTER button, the device will return to the previous menu.
1.3. Master/Stand-alone mode
01) When the display shows , press the ENTER button to open the menu.
02) Press the UP/DOWN buttons to toggle between the 2 options:
The device will send DMX signal to the other connected devices.
The device will not send any DMX signals.
03) Press the ENTER button to confirm your choice.
1.4. Auto/Sound-controlled mode
01) When the display shows , press the ENTER button to open the menu.
02) Press the UP/DOWN buttons to toggle between the 2 options:
Auto mode
Sound-controlled mode
03) Press the ENTER button to confirm your choice.

18
Ordercode: 40372
Star Sky Pro II
1.5. Display settings
01) When the display shows , press the ENTER button to open the menu.
02) Press the UP/DOWN buttons to choose between the 2 options:
The display remains continuously ON.
The display turns OFF after remaining idle for 30 seconds.
03) Press the ENTER button to confirm your choice.
1.6. Display lock
01) When the display shows , press the ENTER button to open the menu.
02) Press the UP/DOWN buttons to choose between the 2 options:
After remaining idle for 30 seconds, the display will turn OFF and you will have to
insert a special key combination to unlock it.
Display lock is inactive.
03) Press the ENTER button to confirm your choice.
04) To unlock the display, press the following buttons in this very order: SET/ESC,DOWN,UP,ENTER.
1.7. System information
01) When the display shows , press the ENTER button to open the menu.
02) Press the UP/DOWN buttons to toggle between the following pieces of information:
The name of the device
The e-mail address in case of any questions.
Software version
Software production time
1.8. Timer
01) When the display shows , press the ENTER button to open the menu.
02) Press the UP/DOWN buttons to toggle between the following options:
The time which passed since last power up.
The total time amount of time for which the device was used.
Timer reset
03) Once you have chosen the desired option, press the ENTER button to see more details.
04) If you have chosen , press the ENTER button to open the submenu.
05) Press the UP/DOWN buttons to select 088 and press the ENTER button to open the menu.
06) Press the UP/DOWN buttons to choose between ClearTotal: OK (timer reset) and ClearTotal: NO (the
device will return to the previous menu.)
07) Press the ENTER button to confirm your choice.

19
Ordercode: 40372
Star Sky Pro II
2. DMX settings
01) If you are in the main settings menu (see page 17), press the UP/DOWN buttons until the display
shows .
02) Press the ENTER button to open the menu. The display shows .
03) Press the ENTER button to open the submenu.
04) Press the UP/DOWN buttons to toggle between the 3 options:
DMX starting address selection
Channel mode selection
DMX failure mode
2.1. DMX starting address
01) When the display shows , press the ENTER button to open the menu.
02) Press the UP/DOWN buttons to choose the desired DMX starting address. The adjustment range is
betwen .
03) Press the ENTER button to confirm your choice.
2.2. Channel mode selection
01) When the display shows , press the ENTER button to open the menu.
02) Press the UP/DOWN buttons to toggle between the 2 options:
7-channel mode
28-channel mode
03) Press the ENTER button to confirm your choice.
2.3. DMX failure mode
01) When the display shows , press the ENTER button to open the menu.
02) Press the UP/DOWN buttons to toggle between the 4 options:
When a DMX signal is terminated, the device will black out.
When a DMX signal is terminated, the device will keep operating in the
previously active mode.
When a DMX signal is terminated, the device will activate Auto run mode.
When a DMX signal is terminated, the device will activate Sound-controlled
mode and the device will react to the beat of the background music. Choose
this option, every time you want to operate the device in Sound-controlled
mode.
