Show Tec Accent Spot SW User manual

Accent Spot SW
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Product code: 42542
USER MANUAL
ENGLISH
V1

1
Accent Spot SW
Product code: 42542
Preface
Thank you for purchasing this Showtec product.
The purpose of this user manual is to provide instructions for the correct and safe use of this product.
Keep the user manual for future reference as it is an integral part of the product. The user manual shall be
stored at an easily accessible location.
This user manual contains information concerning:
●Safety instructions
●Intended and non-intended use of the device
●Installation and operation of the device
●Maintenance procedures
●Troubleshooting
●Transport, storage and disposal of the device
Non-observance of the instructions in this user manual may result in serious injuries and damage of
property.
©2022 Showtec. All rights reserved.
No part of this document may be copied, published or otherwise reproduced without the prior written
consent of Highlite International.
Design and product specifications are subject to change without prior notice.
For the latest version of this document or other language versions, please visit our website
www.highlite.com or contact us at [e-mail].
Highlite International and its authorized service providers are not liable for any injury, damage, direct or
indirect loss, consequential or economic loss or any other loss arising from the use of, or inability to use or
reliance on the information contained in this document.

2
Accent Spot SW
Product code: 42542
Table of contents
1. Introduction..........................................................................................................................................................4
Before Using the Product ..................................................................................................................................4
Intended Use .......................................................................................................................................................4
Product Lifespan.................................................................................................................................................4
LEDs Lifespan .......................................................................................................................................................4
Text Conventions ................................................................................................................................................4
Symbols and Signal Words................................................................................................................................5
Symbols on the Information Label ..................................................................................................................5
2. Safety ....................................................................................................................................................................6
Warnings and Safety Instructions ....................................................................................................................6
Requirements for the User.................................................................................................................................8
3. Description of the Device ...................................................................................................................................9
Front View ............................................................................................................................................................9
Back View ............................................................................................................................................................9
Product Specifications ....................................................................................................................................10
Optional Accessories.......................................................................................................................................11
Dimensions.........................................................................................................................................................11
4. Installation ..........................................................................................................................................................11
Safety Instructions for Installation ..................................................................................................................11
Personal Protective Equipment .....................................................................................................................11
Installation Site Requirements ........................................................................................................................11
Rigging ...............................................................................................................................................................12
Angle Adjustment ............................................................................................................................................13
Beamshaper Installation .................................................................................................................................13
Connecting to Power Supply.........................................................................................................................14
Power Linking of Multiple Devices.................................................................................................................14
5. Setup ...................................................................................................................................................................15
Warnings and Precautions .............................................................................................................................15
Stand-alone Setup ...........................................................................................................................................15
DMX Connection..............................................................................................................................................15
DMX-512 Protocol .......................................................................................................................................15
DMX Cables .................................................................................................................................................16
Master/Slave Setup ....................................................................................................................................16
DMX Linking..................................................................................................................................................17
DMX Addressing..........................................................................................................................................17
6. Operation ...........................................................................................................................................................18
Safety Instructions for Operation...................................................................................................................18
Control Modes ..................................................................................................................................................18
Control Panel ....................................................................................................................................................19
Start-up...............................................................................................................................................................20
Menu Overview ................................................................................................................................................21
Main Menu Options .........................................................................................................................................23
DMX Settings ................................................................................................................................................23
DMX Address .......................................................................................................................................23
DMX Channel Mode..........................................................................................................................24
Manual Mode .............................................................................................................................................24
Auto Mode...................................................................................................................................................24
Program Mode............................................................................................................................................25
Program 1 ............................................................................................................................................25
Program 2–7 ........................................................................................................................................26
Slave Mode..................................................................................................................................................26
Sound-controlled Mode ............................................................................................................................26
Settings..........................................................................................................................................................27

3
Accent Spot SW
Product code: 42542
Selecting Dimming Curves ...............................................................................................................27
Setting Dimmer Speed ......................................................................................................................28
Setting PWM Frequency....................................................................................................................28
DMX Failure Settings...........................................................................................................................28
DMX Synchronization.........................................................................................................................29
Display Lock.........................................................................................................................................29
Restoring Factory Settings.................................................................................................................29
Device Information.....................................................................................................................................30
DMX Channels ..................................................................................................................................................30
RDM Information...............................................................................................................................................31
RDM Details..................................................................................................................................................31
Supported RDM PIDs for the Device .......................................................................................................31
7. Troubleshooting .................................................................................................................................................32
8. Maintenance .....................................................................................................................................................32
Safety Instructions for Maintenance.............................................................................................................32
Preventive Maintenance................................................................................................................................33
Basic Cleaning Instructions .......................................................................................................................33
Corrective Maintenance................................................................................................................................33
9. Deinstallation, Transportation and Storage ....................................................................................................34
Instructions for Deinstallation..........................................................................................................................34
Instructions for Transportation ........................................................................................................................34
Storage...............................................................................................................................................................34
10. Disposal ..............................................................................................................................................................34
11. Approval.............................................................................................................................................................34

4
Accent Spot SW
Product code: 42542
1. Introduction
Before Using the Product
Important
Read and follow the instructions in this user manual before installing, operating or
servicing this product.
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual.
After unpacking, check the contents of the box. If any parts are missing or damaged, contact your
Highlite International dealer.
Your shipment includes:
●Showtec Accent Spot SW
●Schuko to Power Pro cable (1,8 m)
●Beamshaper 10°
●Beamshaper 40°
●User manual
Fig. 01
Intended Use
This device is intended for professional use as an indoor spot effect. It is suitable only for indoor
installation. This device is not suitable for households and for general lighting.
Any other use, not mentioned under intended use, is regarded as non-intended and incorrect use.
Product Lifespan
This device is not designed for permanent operation. Disconnect the device from the electrical power
supply when the device is not in operation. This will reduce the wear and will improve the device’s
lifespan.
LEDs Lifespan
The light output of the LEDs gradually decreases over time (lumen depreciation). High operating
temperatures contribute to this process. You can extend the lifespan of the LEDs by providing adequate
ventilation and operating the LEDs at the lowest possible brightness.
Text Conventions
Throughout the user manual the following text conventions are used:
●Buttons: All buttons are in bold lettering, for example “Press the UP/DOWN buttons”
●References: References to chapters and parts of the device are in bold lettering, for example:
“Refer to 2. Safety”, “turn the adjustment handle (05)”
●0–255: Defines a range of values
●Notes: Note: (in bold lettering) is followed by useful information or tips

5
Accent Spot SW
Product code: 42542
Symbols and Signal Words
Safety notes and warnings are indicated throughout the user manual by safety signs.
Always follow the instructions provided in this user manual.
DANGER
Indicates an imminently hazardous situation which, if not avoided, will result in
death or serious injury.
WARNING
Indicates a potentially hazardous situation which, if not avoided, could result in
death or serious injury.
CAUTION
Indicates a potentially hazardous situation, which, if not avoided, may result in
minor or moderate injury.
Attention
Indicates important information for the correct operation and use of the
product.
Important
Read and observe the instructions in this document.
Electrical hazard
Provides important information about the disposal of this product.
Symbols on the Information Label
This product is provided with an information label. The information label is located on the mounting
bracket.
The information label contains the following symbols:
This device is designed for indoor use.
This device falls under IEC protection class I.
This device shall not be treated as household waste.
Read and follow the instructions in the user manual before installing, operating or
servicing the device.
Minimum distance from lighted objects.
Caution: Risk of electric shock. Do not open.
Caution: To reduce the risk of electric shock, do not remove cover. No user-
serviceable parts inside. Refer servicing to qualified personnel.

6
Accent Spot SW
Product code: 42542
2. Safety
Important
Read and follow the instructions in this user manual before installing, operating or
servicing this product.
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual.
Warnings and Safety Instructions
DANGER
Danger for children
For adult use only. The device must be installed beyond the reach of children.
●Do not leave various parts of the packaging (plastic bags, polystyrene foam, nails, etc.) within
children’s reach. Packaging material is a potential source of danger for children.
DANGER
Electric shock caused by dangerous voltage inside
There are areas within the device where dangerous touch voltage (> 120 V DC) may be present.
●Do not open the device or remove any covers.
●Do not operate the device if the covers or the housing are open. Before operation, check if the
housing is firmly closed and all screws are tightly fastened.
●Disconnect the device from electrical power supply before service and maintenance, and when the
device is not in use.
DANGER
Electric shock caused by short-circuit
This device falls under IEC protection class I.
●Make sure that the device is electrically connected to ground (earth). Connect the device only to a
socket-outlet with ground (earth) connection.
●Do not cover the ground (earth) connection.
●Do not bypass the thermostatic switch or fuses.
●Do not let the power cable come into contact with other cables. Handle the power cable and all
connections with the mains with caution.
●Do not modify, bend, mechanically strain, put pressure on, pull or heat up the power cable.
●Make sure that the power cable is not crimped or damaged. Examine the power cable periodically
for any defects.
●Do not immerse the device in water or other liquids. Do not install the device in a location where
flooding may occur.
●Do not use the device during thunderstorms. Disconnect the device from the electrical power supply
immediately.

7
Accent Spot SW
Product code: 42542
WARNING
Risk of epileptic shock
Strobe lighting can trigger seizures in photosensitive epilepsy. Sensitive persons should avoid looking at
strobe lights.
Attention
Power supply
●Before connecting the device to the power supply, make sure that the current, voltage and
frequency match the input voltage, current and frequency specified on the information label on the
device.
●Make sure that the cross-sectional area of the extension cords and power cables is sufficient for the
required power consumption of the device.
Attention
General safety
●Do not insert objects into the air vents.
●Do not connect the device to a dimmer pack.
●Do not switch the device on and off in short intervals. This decreases the device’s life.
●Do not shake the device. Avoid brute force when installing or operating the device.
●Change the lens or the LEDs if they are visibly damaged to such an extent that their effectiveness is
impaired, for example by cracks or deep scratches. Contact your Highlite International dealer for
more information, as servicing can be performed only by instructed or skilled persons.
●If the device is dropped or struck, disconnect the device from the electrical power supply
immediately.
●If the device is exposed to extreme temperature variations (e.g. after transportation), do not switch it
on immediately. Let the device reach room temperature before switching it on, otherwise it may be
damaged by the formed condensation.
●If the device fails to work properly, discontinue the use immediately.
Attention
For professional use only
This device shall be used only for the purposes it is designed for.
This device is intended for professional use as an indoor spot effect. Any incorrect use may lead to
hazardous situations and result in injuries and material damage.
●This device is not suitable for households and for general lighting.
●This device is not designed for permanent operation.
●This device does not contain user-serviceable parts. Unauthorized modifications to the device will
render the warranty void. Such modifications may result in injuries and material damage.

8
Accent Spot SW
Product code: 42542
Attention
Before each use, examine the device visually for any defects.
Make sure that:
●All screws used for installing the device or parts of the device are tightly fastened and are not
corroded.
●The safety devices are not damaged.
●There are no deformations on housings, fixations and installation points.
●The lens is not cracked or damaged.
●The power cables are not damaged and do not show any material fatigue.
Attention
Do not expose the device to conditions that exceed the rated IP class conditions.
This device is IP20 rated. IP (Ingress Protection) 20 class provides protection against solid objects greater
than 12 mm, such as fingers, and no protection against harmful ingress of water.
Requirements for the User
This product may be used by ordinary persons. Maintenance may be carried by ordinary persons.
Installation and service shall be carried out only by instructed or skilled persons. Contact your Highlite
dealer for more information.
Instructed persons have been instructed and trained by a skilled person, or are supervised by a skilled
person, for specific tasks and work activities associated with the installation, service and maintenance of
this product, so that they can identify risks and take precautions to avoid them.
Skilled persons have training or experience, which enables them to recognize risks and to avoid hazards
associated with the installation, service and maintenance of this product.
Ordinary persons are all persons other than instructed persons and skilled persons. Ordinary persons
include not only users of the product but also any other persons that may have access to the device or
who may be in the vicinity of the device.

9
Accent Spot SW
Product code: 42542
3. Description of the Device
The Showtec Accent Spot SW is a compact indoor spot effect. It can be used for accent lighting.
The device is delivered with 2 beamshapers (10° and 40°). The device can be used in many applications,
both in rental and fixed installations.
Front View
01) Lens
02) 2 x Adjustment screws
03) Mounting bracket
Fig. 02
Back View
04) 3-pin DMX signal connector IN
05) 3-pin DMX signal connector OUT
06) Control panel: OLED display and
control buttons
07) Safety eye
08) Power Pro connector OUT 100–
240 V, 50/60 Hz (Gray)
09) Power Pro connector IN 100–240 V,
50/60 Hz (Blue)
Fig. 03

10
Accent Spot SW
Product code: 42542
Product Specifications
Model:
Accent Spot SW
Electrical:
Input voltage:
100–240 V AC, 50/60 Hz
Power consumption:
21 W
Physical:
Dimensions:
245 x 160 x 105 mm (L x W x H)
Weight:
1,7 kg
Optics:
Light source:
1 x 25 W A/WW/CW LED
Dimmer:
0–100 %
Strobe:
0–20 Hz
Beam angle (circular):
4,5°
Output:
12250 lx @ 2 m
5445 lx @ 3 m
1960 lx @ 5 m
Total lumen:
531 lm
Lumen White:
CW: 284 lm, WW: 388 lm
CRI:
75
Refresh rate:
1000–12000 Hz
Operation and control:
Control:
Stand-alone (auto, manual, built-in programs, sound-controlled)
Master/Slave (auto, manual, built-in programs, sound-controlled)
DMX-512, RDM
DMX channels:
3, 5, 10 channels
Control panel:
OLED display and buttons
Connections:
Power connections:
Power Pro connectors IN/OUT
Data connections:
3-pin DMX connectors IN/OUT
Signal pin OUT:
Pin 1 (ground), pin 2 (-), pin 3 (+)
Construction:
Housing:
Aluminum die-cast
Color:
Black
IP rating:
IP20
Cooling:
Passive
Thermal:
Maximum ambient temperature ta:
From -20 °C to 45 °C
Minimum distance:
Minimum distance to lighted object:
0,5 m

11
Accent Spot SW
Product code: 42542
Optional Accessories
The device is delivered with the following accessories:
●Product code: 42545 (Beamshaper for Accent Spot Q4/SW (10°)
●Product code: 42547 (Beamshaper for Accent Spot Q4/SW (40°)
You can additionally purchase the following accessories:
●Product code: 42546 (Beamshaper for Accent Spot Q4/SW (20°)
●Product code: 42548 (Beamshaper for Accent Spot Q4/SW (10° x 60°)
Dimensions
Fig. 04
4. Installation
Safety Instructions for Installation
WARNING
Incorrect installation can cause serious injuries and damage of property.
If trussing systems are used, installation must be carried out only by instructed or skilled persons.
Follow all applicable European, national and local safety regulations concerning rigging and trussing.
Personal Protective Equipment
During installation and rigging wear personal protective equipment in compliance with the national and
site-specific regulations.
Installation Site Requirements
●The device can be used only indoors.
●The device can be mounted to a truss or another rigging structure in any orientation.
●The minimum distance to other objects must be bigger than 0,5 m.
●The maximum ambient temperature ta= 45 °C must never be exceeded.
●The relative humidity must not exceed 50 % with an ambient temperature of 45 °C.

12
Accent Spot SW
Product code: 42542
Rigging
The device can be mounted to a truss or other rigging structure in any orientation. Make sure that all
loads are within the pre-determined limits of the supporting structure.
CAUTION
Restrict the access under the work area during rigging and/or derigging.
To mount the device, follow the steps below:
01) Use a clamp to attach the device to the supporting structure, as shown in Fig. 05. Make sure that the
device cannot move freely.
02) Secure the device with a secondary suspension, for example a safety cable. Make sure that the
secondary suspension can hold 10 times the weight of the device. If possible, the secondary
suspension should be attached to a supporting structure independent of the primary suspension. Put
the safety cable through the safety eye (07), as shown in Fig. 05.
Fig. 05

13
Accent Spot SW
Product code: 42542
Angle Adjustment
You can adjust the angle of the device with the 2 adjustment screws (02).
01) Turn the 2 adjustment screws (02) counterclockwise to release them.
02) Tilt the device to the desired angle (see Fig. 06).
03) Turn the 2 adjustment screws (02) clockwise to tighten them. Make sure that the device cannot
move freely after the 2 adjustment screws (02) are tightened.
Fig. 06
Beamshaper Installation
The device is delivered with 2 beamshapers (10° and 40°). To install the beamshapers, follow the steps
below:
01) Put the beamshaper on the lens of the device. The magnets in the beamshaper will keep it in
position.
02) To remove the beamshaper, hold it by the edge and pull it off.
Fig. 07

14
Accent Spot SW
Product code: 42542
Connecting to Power Supply
DANGER
Electric shock caused by short-circuit
The device accepts AC mains power at 100–240 V and 50/60 Hz. Do not supply power at any other
voltage or frequency to the device.
This device falls under IEC protection class I. Make sure that the device is always electrically connected
to the ground (earth).
Before connecting the device to the socket-outlet:
●Make sure that the power supply matches the input voltage specified on the information label on
the device.
●Make sure that the socket-outlet has ground (earth) connection.
Connect the device to the socket-outlet with the power plug. Do not connect the device to a dimmer
circuit, as this may damage the device.
Power Linking of Multiple Devices
This device supports power linking. Power can be relayed to another device via the power OUT
connector. Note that the input and the output connectors have different designs: one type cannot be
connected to the other.
Power linking of multiple devices must be carried out only by instructed or skilled persons.
WARNING
Incorrect power linking may lead to overload of the electrical circuit and result in serious
injuries and damage of property.
To prevent overload of the electrical circuit, when power linking multiple devices:
●Use cables with sufficient current-carrying capacity. The power cable supplied with the device is not
suitable for power linking of multiple devices.
●Make sure that the total current draw of the device and all connected devices does not exceed the
rated capacity of the power cables and the circuit breaker.
●Do not link more devices on one power link than the maximum recommended number.
Maximum recommended number of devices:
●at 100–120 V: 50 devices
●at 200–240 V: 50 devices

15
Accent Spot SW
Product code: 42542
5. Setup
Warnings and Precautions
Attention
Connect all data cables before supplying power.
Disconnect power supply before connecting or disconnecting data cables.
Stand-alone Setup
When the Accent Spot SW is not connected to a controller or to other devices, it functions as a stand-
alone device. It can be operated manually.
For more information about the control modes, refer to 6.2. Control Modes on page 18.
DMX Connection
DMX-512 Protocol
You need a DMX serial data link to run light shows of one or more devices using a DMX-512 controller or
to run synchronized shows of two or more devices set in a master/slave operating mode.
The Accent Spot SW has 3-pin DMX signal IN and OUT connectors.
The pin assignment is as follows: pin 1 (ground), pin 2 (-), pin 3 (+).
Devices on a serial data link must be daisy-chained in a single line. The number of devices that you can
control on one data link is limited by the combined number of the DMX channels of the connected
devices and the 512 channels available in one DMX universe.
To comply with the TIA-485 standard, no more than 32 devices should be connected on one data link.
In order to connect more than 32 devices on one data link, you must use a DMX optically isolated
splitter/booster, otherwise this may result in deterioration of the DMX signal.
Note:
●Maximum recommended DMX data link distance: 300 m
●Maximum recommended number of devices on a DMX data link: 32 devices

16
Accent Spot SW
Product code: 42542
DMX Cables
Shielded twisted-pair cables with 3-pin XLR connectors must be used for reliable DMX connection. You
can purchase DMX cables directly from your Highlite International dealer or make your own cables.
If you use XLR audio cables for DMX data transmission, this may lead to signal degradation and unreliable
operation of the DMX network.
When you make your own DMX cables, make sure that you connect the pins and wires correctly as
shown in Fig. 08.
Fig. 08
Master/Slave Setup
The Accent Spot SW supports master/slave control mode. To connect multiple devices in master/slave
setup, follow the steps below:
Connect the first device’s DMX OUT connector to the second device’s DMX IN connector.
Repeat step 1 to connect all devices as shown in Fig. 09. The first connected device will be
automatically recognized as the master device.
Set all subsequent devices as slave devices. See 6.6.5. Slave Mode on page 26 for more information.
Connect a DMX terminator (120 Ω resistor) to the DMX OUT connector of the last device in the setup.
Fig. 09

17
Accent Spot SW
Product code: 42542
DMX Linking
To connect multiple devices on one DMX data link, follow the steps below:
Use a 3-pin DMX cable to connect the DMX OUT connector of the lighting controller to the DMX IN
connector of the first device.
02) Connect the first device’s DMX OUT connector to the second device’s DMX IN connector with a
3-pin DMX cable.
03) Repeat step 2 to connect all devices in a daisy-chain as shown in Fig. 10.
04) Connect a DMX terminator (120 Ω resistor) to the DMX OUT connector of the last device on the data
link.
Fig. 10
DMX Addressing
In a setup with multiple devices, make sure that you set the DMX starting address of each device
correctly. The Accent Spot SW has 3 personalities: 3 channels, 5 channels and 10 channels.
If you want to connect multiple devices on one data link and use them in 10-channel mode, for
example, follow the steps below:
Set the starting address of the 1st device on the data link to 1 (001).
02) Set the starting address of the 2nd device on the data link to 11 (011), as 1 + 10 = 11.
03) Set the starting address of the 3rd device on the data link to 21 (021) as 11 + 10 = 21.
04) Continue assigning the starting addresses of the remaining devices by adding each time 10 to the
previous number.
Make sure that you do not have any overlapping channels in order to control each Accent Spot SW
correctly. If two or more devices are addressed similarly, they will work similarly.

18
Accent Spot SW
Product code: 42542
6. Operation
Safety Instructions for Operation
Attention
This device must be used only for the purposes it is designed for.
This device is intended for professional use as an indoor spot effect. It is suitable only for indoor
installation. This device is not suitable for households and for general lighting.
Any other use, not mentioned under intended use, is regarded as non-intended and incorrect use.
Attention
Power supply
Before connecting the device to the power supply, make sure that the current, voltage and frequency
match the input voltage, current and frequency specified on the information label on the device.
Control Modes
The Accent Spot SW can be operated with a DMX controller and as a stand-alone device.
The Accent Spot SW supports the following control modes:
●Stand-alone: Auto, Manual, Built-in programs, Sound-controlled
●Master/Slave: Auto, Manual, Built-in programs, Sound-controlled
●DMX-512, RDM: 3, 5, 10 channels
For more information about how to connect the devices, refer to 5. Setup on pages 15–17.
To run the auto program, in auto operation mode, select Auto in the Main Menu. See 6.6.3. Auto Mode
on page 24 for more information.
To operate the device manually as a stand-alone device, adjust the intensity values for the colors.
See 6.6.2. Manual Mode on page 24 for more information.
To run one of the built-in programs without a DMX controller:
01) Select Program Mode in the Main Menu.
02) Select one of the 7 color presets (Program 1) or one of the 6 built-in chases (Programs 2–7). See 6.6.4.
Program Mode on page 25 for more information.
To operate the device in the sound-controlled mode, set the sound sensitivity of the device. See
6.6.6. Sound-controlled Mode on page 26 for more information.

19
Accent Spot SW
Product code: 42542
To operate multiple devices in the master/slave mode:
01) Use the first device as a master and use the remaining devices as slaves. See 6.6.5. Slave Mode on
page 26 for more information.
02) Operate the master device in the Auto mode, Manual mode, Built-in Programs mode or the Sound-
controlled mode. For more information, see 6.6.3. Auto Mode on page 24, 6.6.2. Manual Mode on
page 24, 6.6.4. Program Mode on page 25 and 6.6.6. Sound-controlled Mode on page 26.
To operate the device with a DMX controller:
01) Set the DMX starting address of the device in the Address menu. See 5.3.5. DMX Addressing on page
17 and 6.6.1.1. DMX Address on page 23.
02) Select the behavior of the device in case there is no DMX signal in the DMX Fail pop-up submenu.
See 6.6.7.4. DMX Failure Settings on page 28.
03) Select the DMX channel mode. See 6.6.1.2. DMX Channel Mode on page 24 for more information.
See 6.7. DMX Channels on page 30 for complete overview of all DMX channels.
Control Panel
A) OLED display
B) UP button
C) DOWN button
D) SETUP button
E) MODE button
Fig. 11
●Use the MODE button to exit the current submenu and to return to the Main Menu.
●Use the UP/DOWN buttons to navigate through the menus or to increase/decrease numeric values.
●Use the SETUP button to open the desired menu, to confirm your choice or to set the currently
selected value.
