Show Tec Shogun 3D+RGB User manual

Shogun 3D+RGB
ORDERCODE 30974

ATTENTION
Warning
1. Must operate according to the user manual. Don't separate the light personally.
Call the technician when the machine breaks down.
2. Please do not see the laser beam directly to avoid any damage.
3. Before connect or disconnect the power, please adjust the luminance of the
laser diode to the least to avoid any damage to the laser diode.
4 . This unit should be keep dry, do not use in the rain or dank and dusty
environment. It can be use in the outdoor with the water-proof cover protector.
5. Set the light immobility and try to avoid strong shake or hit.
6. Prevent dust into the equipment to avoid problems.
7. Please keep that there's no other equipment or decorating materials obstructed
the exhaust fan and the vent-pipe when the equipment was working.
8. Before connect power, check the plug is immobility or not, power line should
be connect well.
9. Please do not open or close the equipment frequently that's to avoid any affect
to the life span of the laser diode, and try the best to avoid the long time
working.
10. Due to the characteristic of the laser diode, after three hours working, it
should be close at least 25 minutes until the laser diode cooling then work
again.
11. Don't touch the light or draw the power line when your hand was wet. And do
not pull the electronic power line.
12. Maintain the distance at least 10M above from the equipment to the object.
13. This equipment does not have any parts can repair for the users, please do not
open the equipment.
14. When the laser diode became dim or damaged please contact the dealer timely.
15. To use the original package when transport again and to avoid shake.
16. When use this equipment, you must turn on the lamp at first and then start the
computer .If you open software before turn on the lamp, please restart the
software.
Don't look the light directly to prevent make some destroy witheyes..
2 Keep the space between light equipments and the lighted things more than 10 M.
1 、
、

OPEN THE BOX FOR CHECKING
INSTALLATION
In order to use this product safety and reasonable for the users, please read over
this manual carefully before use and the operation must strictly according to this
manual to avoid any damage to the product and personal safety.
Once after received this products please take and put carefully. And check
carefully that whether the product was damaged or not during the transportation and
pleasecheck the following things were enclosed:
Laser light 1PCS Graphics USB card 1PCS
9 pin signal line 1PCS USB connection cable 1pcs
3 pin signal line 1pcs User manual 1pcs
Power cable 1PCS Install CD-ROM 1PCS
1. Please check the voltage whether is the same with the one showed on the
equipment or not.
2. It must ask for the technical person and set the light safety when installation.And
let thelight beam atthe suitable angle.
3. When install this equipment please make sure there's no flammable surfaces
(decorated things, etc) within at least 1.5M and maintain minimum distance of
0.5M from the equipment to the walls.
4. Please make sure that there's no other equipment or decorating materials
obstructed the exhaust fan andthe vent-pipe.
5. Productsshould beinstallimmobility.
6. In case of safety, it's very importantthat to connect theearth with line.

CONTROLBOARDINSTRUCTION
POWER INPUT:
POWER ON/OFF:
Donwload2:
MIC:
MIN-MAX:
ADDRESS:
ILDA DB 25 F Connector
NOTE:
1. PC SIGNALIN ILDADB 25Fconnector s
2.
3.
PC SIGNALIN ILDADB 25FConnector
Input power, with inner fuse.
power on/off
Download method 2 used
Receive Music.
Musicsensitivity potentiometer
the 10 code is switch code. When the 10 code is OFF, 1~9 are
function codes. When function code is 0, the working mode is Music Active
(Master mode); when function code is 1, the working mode is Automatic (Master
mode); when function code is 2 or more, the working mode is Slave mode. When
the 10 code is ON,1~9 will be DMX address codes. The address code of first
light usually by1, the second light is 14 and so on.
: signal input connection port of the laser perform
software that in accordance withthe ILDAstandard.
When and connection port are free,
the lamp will drive by the inside program, temporality it can control by music or
DMX512 signal.
After connect the ILDA DB 25F, The lamp will change to ILDA connected port
drive mode ,this connection port can receive all the signal of laser perform
software that accord with the ILDA stand rd, such as LD-2000 of Pangolin
Company.
4.When the and the were connected, then
the system will at an abnormal statement, lamp still control by inside program ,
but not respond to the exterior input signal.
PCSIGNALIN/OUT:
DMXIN/OUT:
PC SIGNAL IN
USBconnection port signal input/output
DMX512 signal input/output
When connects with USB interfacial card, the lamp will be
control by software which wasinstalledin the computer.
a
th th
th
’
Power 120W Cla ss 1
Red Laser Class 3B 635nm >150mW
Green Laser Class 3B 532nm >60mW
Blue Laser Class 3B 473nm >100mW
RGB LASER

The product has 13 operate channels(international standard DMX512 signal),The details
as follow
：
DMX512 OPERATE
CHANNEL
1
Control Mode
DMX512
VALUE
FUNCTION
2
Color
Close
White
Full multi color
Stochastic single color
Stochastic multiple color
Fluent
Red
Yellow
Green
Cyan
Blue
Purple
0~255
3Pattern
64 patterns(0~255)/4=(0~63)
12 grade speed(0~255)/23=(0~11)
No rolling
Horizontal roll
Vertical roll
Horizontal & vertical roll
5
horizontal &
vertical roll
4 Speed
192~255
128~191
0~255
0-63
64~127
0~22
23~45
46~68
69~91
92~114
115~137
138~160
161~183
184~206
207~229
230~252
253~255
0-63
64~127
128~191
192~255
MusicActive, 5-13channels out of effect
Stand Alone, 5-13 channels out of effect
Manual (MusicActive)
Manual (Automatic)
LSB
MSB
music mode/auto mode/slave mode setting:
FUNCTION
MUSIC MODE
AUTO MODE
SLAVE MODE
This bit disable DMX mode and
enable music/auto slave mode
DMX address code setting:
in the binary, each digit have 0 or 1 just correspond to OFF or ON switch situation. “” “” “ ” “ ”
Example for DMX address code:
DECIMAL
This bit enable DMX mode
No Rotation & No Point-Draw
Rotation
Point-Draw(Only Point)
Rotaion & Point-Draw
6
Rotation &
Point-Draw
192~255
128~191
0-63
64~127

255 grade speed
42 grade size(1~255)/6=(0~42)
0~19 reduce 21~42blow up20 original size
No move
Horizontal move
Vertical move
Horizontal & vertical move
7
Horizontal &
vertical move
8
Horizontal &
vertical stretch
No
Horizontal
V
stretch
stretch
ertical stretch
Horizontal & vertical stretch
10
Slow-draw
speed
13
Size
192~255
0~255
1~255
0~63
64~127
128~191
0-63
64~127
192~255
128~191
9
Small To Large &
Large To Small
No
Zoom from one point to large
Zoom from large to one point
Zoom
0~85
86~169
170~255
11
Scan Speed
0~255
255 grade speed (fast to slow)
12
Change Color Speed
0~255
12 grade speed(0~255)/23=(0~11) (fast to slow)
Original size
0
SPECIFICATION
MAINTAIN











Voltage:AC 220V~240V, 50/60Hz
Signal input power: -15~+15V
X/Y axes beam scanning optical angle: 0~+/-30
Input signal bandwidth: 0~1000Hz
Condition temperature: -10 C~35 C
Total power: 120W
Laser light power:
Net weight: 27 kg
Dimension: 62
Maintenance should be performed every 15-day period, by using a sponge which is
dipped with alcohol, rather than wet cloth or other chemical liquid, to clean the mirror.
Warning: Power must be disconnected before maintenance or repair. Do not look at the
light source directly.
NOTE: Don't seperate laser machine from laser power and repaire them by yourself
otherwise no good repair service will be supplied.
°
°°
Red Laser Class 3B 635nm >150mW
Green Laser Class 3B 532nm >60mW
Blue Laser Class 3B 473nm >100mW
ATTENTION: DISCONNECT INPUT POWER BEFORE MAINTAIN.
DON'T LOOK STRAIGHTLY AT THE LIGHT SOURCES.
Frequency of MCU :24MHz
Size of flash rom for download :32K Byte
x 30 x 19.5 cm

B
1234 56 78 9
1234 5
678 9
TTL-SWITCH BOARD
Description for TTL-switch board:
This board have three input source,
(X1,Y1,R1,G1,B1) and
(X2,Y2,R2,G2,B2) and
(X3,Y3,R3,G3,B3).
The signal & determine who can become master.
If S2=0 and S3=1 then become master.
If S2=1 and S3=0 then become master.
If S2=1 and S3=1 then become master.
they are
If S2=0 and S3=0 then become master.
Internal Programboard
ILDADB25F
USB graphics interface card
S2 S3 ILDADB25F
USB g.i.c
Internal P.B.
Internal P.B.
Lin
S2 & S3

X
Y
Intensity/Blanking
Interlock A
Red
Blue
Deep blue
Yellow
Cyan
Z
Not connected
Shutter
X
Y
－
＋
＋
＋
＋
＋
＋
＋
＋
＋
＋
－
－
－
－
－
－
－
－
－
Green
Intensity/Blanking
Interlock B
Red
Green
Blue
Deep blue
Yellow
Cyan
Z
Ground
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
-5 to 5V
-5 to 5V
0V to 2.5V
Connected to pin17 insidethe Qm2000
Depth Z(notintensity), -5 to 5V
5Vto 5V
＋
＋
＋
＋
＋
＋
＋
＋
＋
＋
＋
－＋
－＋
－
－
－
－
－
－
－
－＋
0V to 2.5V
0V to 2.5V
0V to 2.5V
0V to 2.5V
0V to 2.5V
0V to 2.5V
0V to 5V
5Vto 5V
2.5V to 0V
Connected to pin 4 inside the Qm2000
2.5V to 0V
2.5V to 0V
2.5V to 0V
2.5V to 0V
2.5V to 0V
2.5V to 0V
5V to 5V
Cableshield
Appendix ：
ILDA DB 25F PINOUTS DB 25 definens
Version 1.0

2005 Showtec.
