ShowHouse Chrome S516 Application guide

Order by Part Number for use with S936 3/4" Thermostatic & S956 Volume Control valves
Valve Sold Separately
Rev. 10/10
TO ORDER PARTS CALL: 1-800-BUY-MOEN
www.moen.com
Replacement Parts
Waterhill™
ExactTemp®3/4”Thermostatic Vertical Spa Trim
Models: TS516 Chrome
TS516BN Brushed Nickel
TS516ORB Oil Rubbed Bronze
TS516NL Nickel
TS516WR Wrought Iron
Showerhead
S112 Chrome
S112BN Brushed Nickel
S112ORB Oil Rubbed Bronze
S112NL Nickel
S112WR Wrought Iron
Shower Arm & Flange
S113 Chrome
S113BN Brushed Nickel
S113ORB Oil Rubbed Bronze
S113NL Nickel
S113WR Wrought Iron
Body Sprays
A501 Chrome
A501BN Brushed Nickel
A501ORB Oil Rubbed Bronze
A501NL Nickel
A501WR Wrought Iron
Escutcheon Kit
131187 Chrome
131187BN Brushed Nickel
131187ORB Oil Rubbed Bronze
131187NL Nickel
131187WR Wrought Iron
Hand Held Shower
114341 Chrome
114341BN Brushed Nickel
114341ORB Oil Rubbed Bronze
114341NL Nickel
114341WR Wrought Iron
Drop ell
A725 Chrome
A725BN Brushed Nickel
A725ORB Oil Rubbed Bronze
A725NL Nickel
A725WR Wrought Iron
Bracket
114348 Chrome
114348BN Brushed Nickel
114348ORBOil Rubbed Bronze
114348NL Nickel
114348WR Wrought Iron
Hose
A726 Chrome
A726ST (used for brushed Nickel)
A726ORB Oil Rubbed Bronze
A726NL NIckel
A726WR Wrought Iron
Tall Ring Escutcheon Kit
130153 Chrome
130153BN Brushed Nickel
130153ORB Oil Rubbed Bronze
130153NL Nickel
130153WR Wrought Iron
Thermostatic
Handle Kit
131195 Chrome
131195BN Brushed Nickel
131195ORB Oil Rubbed Bronze
131195NL Nickel
131195WR Wrought Iron
Volume Handle Kit
131191 Chrome
131191BN Brushed Nickel
131191ORB Oil Rubbed Bronze
131191NL Nickel
131191WR Wrought Iron
Short Ring Escutcheon Kit
(2-11/16” O.D.)*
130152 Chrome
130152BN Brushed Nickel
130152ORB Oil Rubbed Bronze
130152NL Nickel
130152WR Wrought Iron
Thermostatic Handle Cap Kit
132320 Chrome
132320BN Brushed Nickel
132320ORB Oil Rubbed Bronze
132320NL Nickel
132320WR Wrought Iron
Volume Handle Cap Kit
130150 Chrome
130150BN Brushed Nickel
130150ORB Oil Rubbed Bronze
130150NL Nickel
130150WR Wrought Iron
Override Screw Kit
130147 Chrome
130147BN Brushed Nickel
130147ORB Oil Rubbed Bronze
130147NL Nickel
130147WR Wrought Iron
Handle Insert
116628 Chrome
116628BN Brushed Nickel
116628ORBOil Rubbed Bronze
116628NL Nickel
116628WR Wrought Iron
* Optional Larger Escutcheon
Ring (3-1/16” O.D.)
129102 Chrome
129102BN Brushed Nickel
129102ORB Oil Rubbed
Bronze
129102NL Nickel
129102WR Wrought Iron
