ShowHouse DIVINE TS254 User manual

CRITICAL DIMENSIONS
(DO NOT SCALE)
Specifications
Rev. 6/08
10" (254mm) MIN
CENTERS
HANDLE
ESCUTCHEON DIA.
2-5/32" (55mm)
SPOUT
ESCTUCHEON DIA.
2-25/32" (71mm)
3-15/32"
(88mm)
2-15/16"
(74mm) 7-5/8"
(194mm)
2-3/16"
(55mm)
3-7/8”
(98mm)
5-15/16”
(151mm)
8-3/16”
(208mm)
5-3/4"
(146mm)
FOR MORE INFORMATION CALL: 1-800-BUY-MOEN
www.moen.com
DIVINE™
Two-Handle Roman Tub Faucet Trim
with Integral Diverter
Models: TS254 series
Valves: S924, S9204
DESCRIPTION
- Metal construction with various finishes identified by suffix
- Three function hand shower
OPERATION
- Lever style handles
- Rotate hot side handle counterclockwise to open
and clockwise to close
- Rotate cold side handle clockwise to open and
counterclockwise to close
FLOW
- Hand shower meets 2.5 gpm max. (9.5 L/min)
STANDARDS
- Third party certified to CSA B125, ASME A112.18.1M,
and all applicable requriements referenced therin
-ADA for lever handles
WARRANTY
- Lifetime limited warranty against leaks, drips and finish defects
to the original consumer purchaser
- 5 year warranty if used in commerical installations
M-pact™System
