SONICBOOMTM SMOKEJET
USER MANUAL
▲Foreword
Thanks for choosing SHOWVEN SONICBOOMTM SMOKEJET.
Please read following manual carefully and completely before operating this product. Operate
according to instructions is very important for safety, and can elongate the service life of the
machine.
▲Product Description
1. Since the introduction of SMOKEJET, it is used in more and more shows to generate smoke column
effect instead of cumbersome CO2 jet.
2. In order to solve the problem of lack of explosive force of present smokejet on market, SHOWVEN
adopting pipeline integration technology on SONICBOOM, ensure stronger smoke burst.
3. Unique constant pressure system, guarantee consistent smoke effect.
▲Functional Characteristics
》Independent smoke column color change
》Patented pipeline integration technology, ensure 0.3s instant smoke burst
》Automatic constant pressure design, highly consistent smoke effect
》220V version SONICBOOM Support 1500W half power mode, easier main power supply.
》Over temp. alarm, no fuel alarm, over voltage alarm etc. multi safety status monitoring. Safer for
use, easier for maintenance.
》Support manual operation on machine control panel
》DMX control, 11 channels and 1 channel optional
》Only use SHOWVEN original FX-S/FX-ST fog fluid, other fluid may lead to clog or malfunction.
》FX-S is quick dissipating fog fluid, the smoke dissipate in seconds, it is perfect choice for creating
instant smoke column.
》FX-ST is special designed to generate sonicboom effect, suggest to use on SONICBOOM X for short
time (less than 2s) effects, the dissipating time is little longer than FX-S.
1

▲Technical Specifications
Model SONICBOOMTM / SONICBOOMTM X
Power Input 220V version: AC220V-240V 50/60Hz
110V version: AC100V-120V 50/60Hz
Fuse 15A/250V
Work Power 220V version: 3,000W/1500W (Half power mode)
110V version: 2000W
LED Power 5W ×35PCS
Heat-up Time 220V version: 5min
110V version: 7min
SONICBOOM Mode YES for SONICBOOM X
Max Continuous Output Duration 8s
Output 55000cuft/min
Max Output Height 10m
Tank Capacity 2.5L
N.W. 17.2Kg
G.W. 19Kg
Machine Size 482×408×215 (mm)
Package Size 560×480×280 (mm)
DMX Channel 11/1
Consumable FX-S/FX-ST
▲Safety Information
》Unauthorized repair are prohibited, it may cause serious incident.
》This product is not waterproof design, please keep it dry, please do not use it when there are fog
fluid leakage or wet from rain.
》Make sure power supply in consistent with the rated voltage of the equipment, and the socket
must well grounded. Unplug and turn off the machine when not use.
》For adult use only, keep it away from fire, inflammable and explosive articles.
》Installed in well ventilated area, ensure at least 50cm space around the machine, cover of the
nozzle is forbidden.
》If the machine fails to work, please stop operation and unplug the machine. Check fog fluid, fuse,
power connection etc. carefully, if can’t solve the problem, please contact SHOWVEN or your local
SHOWVEN partner for advise.
》Only use SHOWVEN original FX-S/FX-ST fog fluid, other fluid may lead to clog or malfunction.
Please do not adding any other material such as pigment, water etc to the fuel bottle.
》To avoid fluid spill, make sure fog fluid not exceed related MAXIMUM fluid level line. When install
SONICBOOM in invert direction, the fuel bottle should installed upward.
》In case of eye contact of fog fluid, please wash it with clean water. If fluid is swallowed immediate
ly look for medical advice.
》Independent smoke column color change
》Patented pipeline integration technology, ensure 0.3s instant smoke burst
》Automatic constant pressure design, highly consistent smoke effect
》220V version SONICBOOM Support 1500W half power mode, easier main power supply.
》Over temp. alarm, no fuel alarm, over voltage alarm etc. multi safety status monitoring. Safer for
use, easier for maintenance.
》Support manual operation on machine control panel
》DMX control, 11 channels and 1 channel optional
》Only use SHOWVEN original FX-S/FX-ST fog fluid, other fluid may lead to clog or malfunction.
》FX-S is quick dissipating fog fluid, the smoke dissipate in seconds, it is perfect choice for creating
instant smoke column.
》FX-ST is special designed to generate sonicboom effect, suggest to use on SONICBOOM X for short
time (less than 2s) effects, the dissipating time is little longer than FX-S.
2

▲Operation
1. Please read above safety information carefully before operating the machine.
2. Fill the fluid tank with SHOWVEN original fog fluid, pay attention to the maximum fill level.
3. Connect the machine to suitable rated power supply, due to the work power is relatively high,
please ensure power supply meets the requirement.
4. Turn on the machine, it heat up automatically, and shows “warm up” on LCD screen.
5. Once the machine has reached operating temperature, “Warm up” disappear and temperature
reached at around 100%, pressure at around 100%. Now the machine is ready for operation.
6. After each firing, wait a few seconds to start the next firing, allow the pressure and temperature
are stable.
▲Button Function
“MENU": switch through setup menu
“+”: Parameter up; multiplex “TIMER” (smoke output time)
“-”: Parameters down; multiplex “VOLUME” (smoke output start)
“ENTER”: confirm and save parameters (screen will blink once when save successfully); multiplex
“STOP”.
NOTE: Screen will switch to main interface automatically if not press any button in long time.
First Line: DMX address, “:” blinks when there is DMX signal.
Second Line: shows machine core temperature T and pressure P. The machine ready for operate only
when both temperature and pressure value close to 100%.
a) Main Interface
Error information:
Error information
E0 System IC
E1 Pressure
E2 K temp. Sensor
E3 Evacuate
E6 Heat Fail
E5 Temp Over
Explanation
Circuit fault
Pressure faults, no fog fluid or pump error
Temperature sensor fault
Evacuate fuel pipe fault
Heating element damage or circuit fault
Circuit fault
》Unauthorized repair are prohibited, it may cause serious incident.
》This product is not waterproof design, please keep it dry, please do not use it when there are fog
fluid leakage or wet from rain.
》Make sure power supply in consistent with the rated voltage of the equipment, and the socket
must well grounded. Unplug and turn off the machine when not use.
》For adult use only, keep it away from fire, inflammable and explosive articles.
》Installed in well ventilated area, ensure at least 50cm space around the machine, cover of the
nozzle is forbidden.
》If the machine fails to work, please stop operation and unplug the machine. Check fog fluid, fuse,
power connection etc. carefully, if can’t solve the problem, please contact SHOWVEN or your local
SHOWVEN partner for advise.
》Only use SHOWVEN original FX-S/FX-ST fog fluid, other fluid may lead to clog or malfunction.
Please do not adding any other material such as pigment, water etc to the fuel bottle.
》To avoid fluid spill, make sure fog fluid not exceed related MAXIMUM fluid level line. When install
SONICBOOM in invert direction, the fuel bottle should installed upward.
》In case of eye contact of fog fluid, please wash it with clean water. If fluid is swallowed immediate
ly look for medical advice.
3

1. Please read above safety information carefully before operating the machine.
2. Fill the fluid tank with SHOWVEN original fog fluid, pay attention to the maximum fill level.
3. Connect the machine to suitable rated power supply, due to the work power is relatively high,
please ensure power supply meets the requirement.
4. Turn on the machine, it heat up automatically, and shows “warm up” on LCD screen.
5. Once the machine has reached operating temperature, “Warm up” disappear and temperature
reached at around 100%, pressure at around 100%. Now the machine is ready for operation.
6. After each firing, wait a few seconds to start the next firing, allow the pressure and temperature
are stable.
Example of “TIMER” setting function in the menu:
①“set interval 10s”
②“set duration 2s”
SONICBOOM will repeat: firing 2s, interval of 10s, firing 2s, interval 10s…
Press “VOLUME” button under main interface, SONICBOOM activated and start to generate smoke,
and press “STOP” to stop the machine.
LED color setting:
0: LED OFF 1: RED 2: GREEN 3: BLUE 4: PINK
5: PURPLE 6: ORANGE 7: YELLOW 8: SKY BLUE 9: WHITE
Above setting disabled when use DMX console, LED color determined by setting on console.
When choose 1 channel mode, LED color determined by single channel, DMX value and related color
as below:
Press “MENU” switch through setup menu.
b) Setting Menu
c) Advanced Interface
Color
DMX value
SMOKE OFF
0-40
RED
41-60
GREEN
61-80
BLUE
81-100
PINK
101-120
PURPLE
121-140
ORANGE
141-160
YELLOW
161-180
SKY BLUE
181-200
WHITE
201-220
Random
221-235
LED OFF
236-255
Items
DMX 512 Address
Power Regulation
Color Optional
SonicBoom Mode
Single Channel
Explanation
Set DMX address
Setting working power for the
machine
LED color set when manual firing
Setting working mode
Single channel mode set
Range
1~506
Standard/Half Power
0~10
Regular mode/Sonicboom mode
ON/OFF
Press “MENU” for 3s, enter advanced setting interface
Item
Manual Evacuate
Interval Set
Duration Set
Wireless Remote
Language
Explanation
Manual Evacuate when pressure always insufficient
Interval time
Smoke output duration
Wireless ON/OFF switch
Language switch
Value
ON/OFF
0-200
0-8
ON/OFF
Chinese/English
Manual Pump For maintenanceON/OFF
4

▲ DMX Channel
▲ E1 Pressure error explanation
11 DMX channels for SONICBOOM.
NOTE: Manual function disabled when DMX connected.
In order to protect pump, SONICBOOM will running self check program to find out whether there
are fog fluid in the fuel pipe.
1. E1 pressure error activation
When there is no fog fluid in the fuel tank, system can not reach preset pressure even turn on for
a long time. The pump will stop working, and report E1.
2. Way to clear E1 error
① Fill the fog fluid tank, then restart the machine.
② Press “VOLUME” to reset.
③ DMX Channel 1, start a firing.
▲Upside-down installation
For upside-down installation, please remove the bottom panel of fluid tank, and installed to the other
side (top panel), the fluid tank should installed upward as below picture. For safety, hanging installa-
tion should install safety rope.
Channels
Channel 1
Channel 2
Channel 3
Channel 4
Channel 7
Channel 6
Channel 5
Channel 8
Channel 9
Channel 10
Channel 11
Function
Firing: (0-9) OFF, ( 10-255) ON
Inner LED RED: (0-9) OFF, (10-255) LED brightness increase
Inner LED GREEN: (0-9) OFF, (10-255) LED brightness increase
Inner LED BLUE: (0-9) OFF, ( 10-255) LED brightness increase
Outer LED BLUE, (0-9) OFF, (10-255) LED brightness increase
Outer LED GREEN, (0-9) OFF, (10-2551) LED brightness increase
Outer LED RED: (0-9) OFF, (10-255) LED brightness increase
LED Random: (0-9) OFF, (10-255) LED random color, use together with channel 9.
LED color change speed: (0-9) OFF, (10-255) LED color change speed increase
LED strobe: (0-9) OFF, (10-255) LED strobe increase
LED dimmer, (0-9) OFF, (10-255) LED brightness increase
5

For healthy and best status of machine, please do use SHOWVEN original fog fluid.
▲Maintenance
1. Use SHOWVEN original fog fluid for the best effect of SONICBOOM. Warranty will be void if any
other type fluid is used.
2. Don’t disassemble the machine by unauthorized person, modifications to the machine are not
allowed.
3. Excessive dust, liquid or dirt etc on the equipment will affect performance of the machine and
cause poor heat dissipation. Remove dust with air compressor, vacuum or soft brush. Use a damp
cloth to clean the case.
4. Before storing the machine, run distilled water through the system to help avoid condensing the
pump or heater.
5. To keep the best status and performance of machine, it is recommended to running the machine
at least once per month.
6. After continuous use of 40h (or 1-2month), please use 35% vinegar with 65% distilled water to
wash the pump and pipe system by running the machine 10-15 times.
▲ Possible reason for the block of atomizer
A. Fluid spill: heat can’t effectively transmit to fog fluid, leads to insufficient atomization of the fog
fluid in the heating pipe.
Possible Reason 1: Use other type of low quality fog fluid instead of SHOWVEN original fog fluid.
Possible Reason 2: Use inappropriate fog fluid. For different types of fog fluid, the atomization tem-
perature is different.
B. Heating aluminum pipe clog: early symptom for heating aluminum pipe clog is fog fluid spill
caused by insufficient atomization. Use other brand fluid or not make regular maintenance for a
long time will definitely leads to pipe clog.
C. Solution for above problem: Use SHOWVEN original fog fluid. Make regular maintenance (every
1-2month). Use 35% vinegar with 65% distilled water to wash the pump and pipe system by
running the machine 10-15 times.
6

Warranty Instructions
Warranty Card
★Below situations NOT included in warranty service:
★Invoice and warranty card are necessary when applying for maintenance service from
SHOWVEN.
▲Sincere thanks for your choosing SONICBOOMTM SMOKEJET, you will receive quality service from us.
▲The product warranty period is one year. If there are any quality problems within 7 days after ship
ping out from our factory, we can exchange a brand new same model machine for you.
▲We will offer free of charge maintenance service for machines which with hardware malfunction
(except for the instrument damage caused by human factors)in warranty period. Please don't repair
machine without factory permission.
1. Damage caused by improper transportation, usage, management, and maintenance, or damage
caused by human factors;
2. Disassemble, modify or repair products without Showven’s permission;
3. Damage caused by external reasons (lightning strike, power supply etc);
4. Damage caused by improper installation or use;
For product damage not included in warranty range, we can provide paid service.
Product Name:
Purchase Date:
Tel:
Address:
Problem Feedback
Maintenance Detail:
Service Engineer:
Actual Problem:
Serial No.
Service Date:
7


Showven Technologies Co., Ltd
Add: Building B1, Changsha E-center No.18, Xiangtai Road, Economic & Technology
Development Zone, Hunan, China
Tel: +86-731-83833068
Web: www.showven.cn
E-mail: [email protected]
Table of contents
Other Showven Fog Machine manuals
