Showven Creeper AQ mini User manual

V1.0
2020.6
USER MANUAL
Creeper AQ mini Low Fog
Generator
Showven Technologies Co.,Ltd.

★Please read this manual carefully before operating this product.
★Warranty card attached in the manual, please keep it well.
▲Safety Information
\ Unauthorized repair are prohibited, it may cause serious incident.
\ Make sure power supply in consistent with the rated voltage of the equipment, and the
socket must well grounded. Unplug and turn off the machine when not use.
\ Please keep the machine dry, not use in rain or snow. Not use the machine when it is wet
or there are fluid leakage from the machine.
\ Not use the machine in high temperature.
\ Installed in well ventilated area, ensure at least 50cm space around the machine, cover of
the nozzle is forbidden.
\ For adult use only, keep it away from children, fire, inflammable and explosive articles.
\ If the machine fails to work, please stop operation and unplug the machine. Check fog
fluid bottle, water tank, fuse, power connection etc. carefully, if can’t solve the problem,
please contact SHOWVEN or your local SHOWVEN partner for advice.
\ Suggest use SHOWVEN original FX-M fog fluid, other fluid may lead to clog or malfunction.
\ In case of eye contact of fog fluid, please wash it with clean water. If fluid is swallowed
immediately look for medical advice.
\ Please do NOT adding any other material such as grease, pigment, gas etc to the fluid
bottle or water tank.
\ The device shall not be altered and applied to other use purpose.
Thanks for choosing SHOWVEN CREEPER AQ mini low fog generator. Please read following
manual carefully and completely before operating this product. Operate according to
instructions is very important for safety, and can elongate the service life of the machine.
Creeper AQ mini Low Fog
Generator
USER MANUAL
▲Description
SHOWVEN Creeper AQ mini Low Fog Generator USER MANUAL -1-

▲Functional Characteristics
\ Water based, no need of dry ice.
\ Molded enclosure, lighter, durable as well as rustless.
\ Compact yet robust fog output.
\ Multi-optimized air supply system, ensure farther and more uniform fog output.
\ 20 heads atomizers, guarantee thick fog output.
\ Latest rapid heating technology, 1-2min heating up time
\ Patented fog leakage prevention technology, no fog leakage even refill the machine when it
is working
\ User friendly LCD control panel
\ 2L fluid tank, support 1h continuous output.
\ Built-in water tank, support external large water tank.
\ Wireless remote control.
▲Technical Specifications
\ Model: Creeper AQ mini
\ Dimension: 460x 300x 324mm
\ Voltage: AC200-240V, 50-60Hz AC100-120V, 50-60Hz
\ Work Power: 2000W
\ Heat-up Time: Appr. 1-2min
\ Fluid Tank Capacity: 2L
\ Water Tank Capacity: 6.5L
\ DMX-512: YES
\ Remote control: YES
\ Output Adjustable: 1-100
\ Max. Fog Output: 10,000 cuft/min
\ Max. Coverage: Appr. 200㎡
\ Max. Fluid Consumption.: Appr. 32ml/min
\ Max. Water Consumption: Appr. 250ml/min
\ Continuous Output: YES
\ Fully loaded Output Time: 70+ min
\ Consumable: FX-M Fog Fluid, Water
\ Net Weight: 15kg
SHOWVEN Creeper AQ mini Low Fog Generator USER MANUAL -2-

▲Product Overview
①External water tank connection port (φ8 quick connector)
②Fuse
③Power Socket
④3-Pin DMX IN
⑤3-Pin DMX OUT
⑥Power ON/OFF
⑦LCD Control Panel
⑧Water Filling Port, Fluid Tank
⑨Liquidometer
⑩Fog output pipe
▲LCD Control Panel Operation
MENU: switch through setup menu；
+: Parameter up; multiplex “TIMER” (smoke output time)
-: Parameters down; multiplex “VOLUME” (smoke output start)
ENTER: confirm and save parameters (screen will blink once parameter saved); multiplex
“STOP”.
NOTE: Screen will switch to main interface automatically if not press any button in long time.
SHOWVEN Creeper AQ mini Low Fog Generator USER MANUAL -3-
a) LED display area

SHOWVEN Creeper AQ mini Low Fog Generator USER MANUAL -4-
First Line: DMX address and Fan Speed, “:” blinks when there is DMX in signal.
Second Line: Shows machine core temperature and Fog Volume. The machine ready for
operate when temperature value close to 100.
Press “MENU” switch through setup menu.
b) Main Interface
c) Error Information
DMX: 1 FAN: 30
T: 100% FOG: 80%
Error information Explanation
E2 Temp. Sensor Temp. Sensor Malfunction
E3 Water Sensor Low water level of Inner Water Tank, system is pumping water
to inner water tank or liquid level sensor malfunction.
E5 Temp. Over Circuit board malfunction
E6 Heat Fail Heater broken or circuit board malfunction.
d) Setting Menu
Items Explanation
DMX Address DMX address setup
Interval Set Set fog output interval
Fog Volume Output Fog output volume setup
Fan Speed
Value
1~512
5-600s
1-100%
Duration Set Set fog output duration5-600s
1-100% Fan speed setup
Wireless Set Wireless function set
Auto Pump When it is ON, machine will pump water from
exterior water tank to inner tank, and stops
when the inner tank filled up. Please turn it to
OFF when not use exterior water tank.
ON / OFF
ON / OFF
Language Language switch中文/English
Sensor Disp. Generate fog:
2, Stop: 0
Shows the number of working No.of ultrasound
head, display only.

▲Operation
▲DMX Control
①Check the machine and accessories, ensure it is in good status. Place the machine on a flat
surface, tilting may result in inaccurate water level alarm.
②Fill the liquid tank with FX-M Pro medium fog fluid. Please use original fog fluid from
SHOWVEN, Warranty will be void if any other type fog fluid is used.
③Connect the machine to suitable rated power supply. Please ensure power supply meets the
requirement. Always connect the machine to a protected circuit and ensure it is properly
grounded.
④Turn on the machine, it heat up automatically, and shows “WARMING UP” on LCD screen.
⑤Water Tank Filling
Method 1:
Open the lid of“water filling port”, fill the water tank with pure water, please pay attention
to the water level show on liquidometer, stop filling when it is reached the black line. Or until
the water shortage alarm on LCD screen disappear.
Method 2:
Useφ8 tubes connect with quick connector on machine, and the other end put into exterior
tank, press MENU enter setup interface, find the “Auto Pump” and switch it in to ON status,
press ENTER key to save the change. Machine will filling the inner water tank automatically,
just keep the water in exterior tank is enough for the show. When not use exterior tank,
please do set the “Auto Pump” to OFF status.
⑥Once the machine has reached operating temperature, temp., fog output and fan speed
will show on the screen, please adjustable it accordingly.
⑦Press “+”to start making fog, press “ENTER”to stop.
⑧To turn off the machine, please POWER OFF and unplug the power cable.
⑨For transportation or not use for a long time, please remove the fog output pipe. Drain the
remaining water from fog output nozzle.
SHOWVEN Creeper AQ mini Low Fog Generator USER MANUAL -5-
2 channel mode
Channel Function
First Channel（CH1）Fog output: DMX VALUE 6-255, fog output from 1-100. As
volume increase, the denser the fog, the longer for dissipate.
Second Channel（CH2）
Fan speed: DMX VALUE 6-255, fan speed from 1-100. As
volume decrease, the better the fog stick to the ground but
spread slower.

▲Wireless Control
Wireless control is used to remote control the machine. Before use the wireless function
please make sure machine was ready, wireless status was ON, and no DMX cable connection.
Remote controller:
【A】Fog output START
【B】Fog output STOP
Remote control is optional configuration.
When wireless controller is not working properly, please switch to the Wireless Control menu,
set it into ON status, and press ENTER key to save the change.
When machine on Wireless Control interface, operator can match the CREEPER AQ mini with
remote controller by pressing any key on remote controller for 1s, the machine screen flash
once means match was finished.
▲Product Package
1.Creeper AQ mini Low Fog Generator x 1unit
2.Power Cable x 1 piece
3.Fog Vent and Head x 1 piece
4. 1m φ8 PU pipe x 1 piece
▲Possible reason for fluid spill and block of atomizer
For healthy and best status of machine, please do use SHOWVEN original fog fluid.
A. Fluid spill: heat can’t effectively transmit to fog fluid, leads to insufficient atomization of the
fog fluid in the heating pipe.
Possible reason 1: Use low quality fog fluid. The impurities in low quality fog fluid easily adhere
to the pipe inner wall, which blocks temp. transmission, leads to insufficient atomization.
Possible reason 2: Use inappropriate fog fluid. For different types of fog fluid, the atomization
temperature is different.
B. Heating aluminum pipe clog: early symptom for heating aluminum pipe clog is fog fluid spill
caused by insufficient atomization. Use other brand fluid or not make regular maintenance for
a long time will definitely leads to pipe clog.
C. Solution for above problem: Use SHOWVEN original fog fluid. Make regular maintenance
(every 1-2 month). Use 35% vinegar with 65% distilled water to wash the pump and pipe
system by running the machine 10-15 times.
SHOWVEN Creeper AQ mini Low Fog Generator USER MANUAL -6-

SHOWVEN Creeper AQ mini Low Fog Generator USER MANUAL -7-
Tel:
Warranty Instructions
Warranty Card
★Below situations NOT included in warranty service:
★Invoice and warranty card are necessary when asking for maintenance service
from SHOWVEN.
▲Sincere thanks for your choosing our products, you will receive quality service from us.
▲The product warranty period is one year. If there are any quality problems within 7 days
after shipping out from our factory, we can exchange a brand new same model machine
for you.
▲We will offer free of charge maintenance service for machines which with hardware
Malfunction (except for the instrument damage caused by human factors) in warranty
period. Please don't repair machine without factory permission.
1. Damage caused by improper transportation, usage, management, and maintenance, or
damage caused by human factors;
2. Disassemble, modify or repair products without Showven’s permission;
3. Damage caused by external reasons (lightning strike, power supply etc);
4. Damage caused by improper installation or use;
For product damage not included in warranty range, we can provide paid service.
Product Name:
Purchase Date:
Address:
Problem Feedback
Maintenance Detail:
Service Engineer:
Actual Problem:
Serial No.
Service Date:
