shumatt CRT061 User manual

Shenzhen Shumatt Technology Co., Ltd
0
Universal common rail built-in injector
fix and oil collection kit Instruction
manual
Shenzhen shumatt Technology Co., Ltd.

Shenzhen Shumatt Technology Co., Ltd
PRODUCT NAME：
Universal Common Rail Built-in
Injector Fix and Oil Collection Kit
Model：CRT061
Write：张严巍
Version：
Date：2016.10.26

Shenzhen Shumatt Technology Co., Ltd
1
Universal Common Rail Built-in
Injector Fix and Oil Collection Kit
------CRT060
COPYRIGHT NOTICE
Shenzhen shumatt Technology Co., Ltd .and its partner
companies issued jointly issued including but not limited to
product or copyrighted content and services, etc. all
intellectual property rights, protected by law. Without our
written permission, any units and individuals shall not in any
way or reason to these products, services, information, and
any part of the material will be used, reproduced, modified,
copied, transmitted, or bundled with other products use, sale,
where violations the copyright and other intellectual property
rights, the company will pursue its legal responsibility
according to law.
CONTACT
Shenzhen: shumatt Technology Co., Ltd.
Add: 4th floor Noble Plaza NO269 Qian Jin road Bao An
District Shenzhen China
TEL: [phone]
Web: www.shumatt.net
Email: [email protected]
Cell phone: [phone] Technical
support:[email protected]om
1.INTRODUCTION
Universal Common Rail Built-in injector fix And Oil
Collection Kit is applicable for connections of all built-in
common rail injectors. especially for BOSCH, DELPHI,
DENSON. You can test its injection and return oil.
1.1 Product List
No.
Name
Qty
Note
①
Oil Return Holder
2
②
Sealing Cap
4
③
Oil Inlet Holder
2
④
Oil Catcher
4
⑤
Coil Head Spare Parts
4
⑥
Elastic Valve Spare Parts
4
⑦
Sealing Ring
12
1.2 Product Parts
①
②
③
④
⑤
⑥
⑦

Shenzhen Shumatt Technology Co., Ltd
2
1.3 Product Details
1.4 Step
1. Mount the screw on the oil return device
2. Tighten the screw with wrench and fix the Injector
3. Connect the sealing ring to the oil return device
4. Fix the sealing ring part to the oil return hole
5. Mount the sealing ring on the injector

Shenzhen Shumatt Technology Co., Ltd
3
6. Mount the catcher on injector and tighten the elastic
valve
1.5 Specifications
Specification
Length
21cm
Volume
3024 cm³
Width
18 cm
Weight
1800 g
Height
8 cm
Note
Packing Parameters
Length
22.5 cm
Volume
4168.13 cm³
Width
19.5 cm
Weight
2300 g
Height
9.5 cm
Note
