SHW OD-09A ZR03 User manual

SHW 55-Inch Electric Height Adjustable
Desk
Model :OD-09A#ZR03
Toll Free: [phone]

Setting Table Height Restrictions
After completing initialization, you can set the minimum and maximum height range for the table.
Step 1: Raise/lower the table to your desired table height by pressing the “Up” or ”Down” key.
Step 2: Press and hold “M” for a couple of seconds. The LED Display will begin to flash.
● Set the High Restriction:
○ While it is flashing, press the “Up” Key until you hear two beeps.
● Set the Low Restriction:
○ While it is flashing, press the “Down” Key until you hear two beeps.
Remove Restriction:
● Press and hold “M” until you hear two beeps and the LED flashes “ - - “.
Table Height Restrictions Note:
● The higher height restriction must be greater than the lower height restriction. Likewise, the lower
height restriction must be less than the higher height restriction. Otherwise, the settings will be
invalid.
● The Initialization Process will remove the Height Restrictions.
Important:
● Once the desk has been assembled, adjust the glide so that the desk is leveled and stable.
● The "Initialization Process" must be followed during first time use.
● If any parts are changed or adjusted, the "Initialization Process" must be done again.
● Make sure the desk is clear of any objects when positioning the desk.
●DO NOT place any object in the path of the desk to ensure the safety of the object while adjusting
the desk’s height.
- 1 -
P
Do not climb, sit or stand on this piece of fumiture

- 2 -

Left Leg With
Motor (x1)
Right Leg Without
Motor (x1)
Base (x2) Side Connector (x2) Side Supporting
Bracket (x2)
Motor Rod (x1) Desk Top Front (x1)
Desk Top Rear (x1) Controller (x1) Cable (x1)
M6x16 Screws (x28)
NST4x16 Screws (x2)
O4mm Allen Wrench (x1)
PDowel (x8)
Q
R
Power Supply (x1)
Identify all the components
Hardware identification
AB C DE
Motor
Connector (x1)
F G HPower Supply
Holder (x1)
I
JKLM
Velcro (x4)
Note:To organize cables
- 3 -

N
N
P
M6x16 Screws (x8)
N
4mm Allen Wrench (x1)
P
M6x16 Screws (x8)
N
4mm Allen Wrench (x1)
P
N
N
A
Step 1
Step 2
B
C
C
D
D
D
D
- 4 -

N
N
M6x16 Screws (x4)
N
4mm Allen Wrench (x1)
P
Step 3
Step 4
E
E
E
F
F
Insert “Part F” Motor Connector all the
way inside.
- 5 -

Step 5
Step 6
G
H
H
G
F
1) Insert “Part G” to “Part F” and push it into the
inside spring.
2) Twist the motor rod with force to fit the other side
connector, then release it to connect.
"Position of the Wire basket can be
adjusted to the right, middle, or left
for your convenience."
- 6 -

Q
Dowel (x8)
Q
Connect Cable To The Power Supply
Step 7
Step 8
I
J
L
L
L
M
M
- 7 -

N
N
M6x16 Screws (x8)
N
4mm Allen Wrench (x1)
P
Step 9
I
J
ST4x16 Screws (x2）
O
Step10
O
K
- 8 -

Connect Motor Cable To The Power Supply
Connect Controller Cable To The Power Supply
Step 11
A
K
1. Plug the power cable into an “electrical” outlet.
2. Press and hold the down key until the display shows “Rst”.
3. Hold the down key as the desk lowers to the bottom and
back up a little.
4. Release the down key when the display shows “70.5”.
Initialization / Reset Instructions:
AK
K
- 9 -

LED Display: Press any key once to wake up the LED display.
Up Key : Press and hold the UP key to raise the desk .
Down Key : Press and hold the DOWN key to lower the desk.
Memory Key :
--
- 10 -
123
4
●
●
●
●
Saving a height setting: Press and hold any numbered key until you hear a beep.
Applying a height setting: Press any numbered key and the desk will adjust automatically.
。
。
Notes:
●Stop the desk's movements at any time by pressing any key.
●Height settings will remain when unplugged.

ErrorCodeInstructions


InitializationProcess/ResettingYourDesk

The“InitializationProcess”mustbedonebeforeusingthedeskforthefirsttimeandalsofor
resettingyourdesk.Toresetthedesk,pressandholdtheDOWNkeyfor10secondsuntilthe
LEDdisplayshows“Rst”andthedeskwillstarttoslowlylower.KeepholdingtheDOWNkey
whilethedeskismovingandtheLEDisstillshowing"Rst".Thedeskwillreachitslowestsetting
andthenmoveupslightlyuntiltheLEDshows"70.5".OncetheLEDdisplays"70.5",youmay
releasetheDOWNkey.The"InitializationProcess"isnowcomplete.
- 11 -
Error Code Reason Solution
Er1 Motor Line Open Circuit 1. Disconnect and reconnect all the cable lines from
“Part K” and “Part M”. The LED will display “Rst”.
2. Press and hold the DOWN key until the desk
stops moving and the LED displays “70.5”.
3. If the above step fails, please contact Customer
Service at [email protected]
OL Low Main Voltage 1. Weight limit over 110 lbs, please remove some
items off the table and try again.
2. If the above step fails, please contact Customer
Service at [email protected] for
further assistance.
OH Motor Overheat 1. Press any key to restart the function.
2. If the above step fails, please contact Customer
Service at [email protected] for further
assistance.
Rst Initialization Process Desk in the process of resetting. Press and hold the
DOWN key for the desk to slowly lower until it
reaches its lowest setting. Keep holding the DOWN
key until it stops moving and the LED displays "70.5"
(70.5 cm). The desk may now be operated as
normal.
