SIA RFU103 User manual

Built-under Freezer
Instruction Manual
MODEL RFU103
SIA

Contents
Cautions---------------------------------------------------------------------------------------1~2
Diagram----------------------------------------------------------------------------------------3
Preparation------------------------------------------------------------------------------------4~5
Operation--------------------------------------------------------------------------------------6
Defrosting,cleaning and de-commissioning-------------------------------------------7
Trouble shooting-----------------------------------------------------------------------------8

Cautions
Disposal of the old appliance
Before disposing an old appliance, please make sure it’s inoperative and safe. Unplug
the appliance and remove or destroy all of the springs, latches, or bolt-locks in order to
avoid the risk of child entrapment.
It must be noted that the refrigeration system contains insulating gases and refrigerants,
which require specialized waste disposal. The valuable materials contained in a refrig-
erator can be recycled. Contact your local waste disposal center for proper disposal of
an old appliance and contact your local authority or your dealer if you have any ques-
tion. Please ensure that the pipe work of your refrigerator dose not get damaged prior to
being picked up by the relevant waste disposal center, and contribute to environmental
awareness by insisting on an appropriate, any-pollution method of disposal.
Disposal of the packaging of your new appliance
All the packaging materials employed in the package of your new appliance may be
disposed without any danger to the environment.
The cardboard box may be broken or cut into smaller pieces and given to a waste paper
disposal service. The wrapping foil is made of polyethylene and the polyethylene pads
and stuffing contain no fluorochloric hydrocarbon.
All these valuable materials may be taken to a waste collecting center and used again
after adequate recycling.
Consult your local authorities for the name and address of the waste materials collect-
ing centers and waste paper disposal services nearest to your house.
Safety Instructions and Warnings
Before starting the appliance, read the information given in the User’s Guide carefully.
The User’s Guide contains very important observations relating to the assembly,
operation and maintenance of the appliance.
Keep the User’s Guide in a safe place and remember to hand it over to the subsequent
owner, if you ever sell the appliance.
The manufacturer does not accept responsibility for any damages that may arise due to
non-observation of the following instruction.
*Damaged appliances are not to be put into operation. In case of doubt ,consult your
supplier.
1

2

Refrigerator Diagram
This diagram may vary slightly with the layout of the refrigerator you
have
just purchased due to technical improvements.
3
①
②
1.Control Panel
2.Drawers

Preparation
Unpacking
Remove all packing materials.
Check attachments and materials
Checking should be conducted with reference to the Packing List. Contact the local
distributor if discrepancies are found.
Ensure proper location of the freezer .
Clean the refrigerator before use.
(See the following section “Cleaning”)
Idle time
After the refrigerator has been sited and cleaned, let it stand for more than 30 minutes
before connecting the power source.
4
123
45
89
6
7
596 596
5
1200
11
5
==
15 15
12
13
m9 m
3
2
14
15
595
009-528
178
480
25
600
Min550
497
540
10

16
18
17
DOOR REVERSAL
6. Remove the two screws, which attach the lower hinge to the appliance door (Fig. 5). Take
special care and hold the appliance door with the other hand.
7. Holding the door, swing the lower door hinge away from the door using the other hand, then
detach the door from the appliance body (Fig. 6).
8. Remove the two screws , which attach the upper hinge to the body and the two screws hol-
ding the lower hinge to the appliance body (Fig. 7).
9. Screw the upper and lower hinge on the opposite side of the appliance body using suitable
screws (Fig. 8). Upper hinge should be mounted on the other side of the appliance as the lower
hinge. The lower hinge should be mounted on the other side of the appliance as the upper
hinge.
With the hinges open, hold the door parallel to the appliance body and screw the hinges to the
door using suitable screws while taking proper care.
10. Make sure that the door is properly aligned with the appliance body (Fig. 9).
INSTALLATION OF THE APPLIANCE
Installation of the appliance should be performed by a qualified installer. The appliance should be
placed in furniture case (Fig. 10). Once the appliance is placed correctly, adjust the height of the ap-
pliance by turning the 4 adjustable feet as appropriate. If necessary, adjacent appliances sho-
uld be braced with a bracket fixed by screws and fitted in furniture (Fig. 11). There is a special strip
at the top of the appliance.Attach it to the underside of the cabinet with appropriate screws supplied
with the assembly kit (Fig. 16). Decorative strip must not block the vents located in the bottom casing
unit, the strip must be cut to size (Fig. 17). The depth of the bottom casing unit can be adjusted by
moving it forwards or backwards. Once properly adjusted, tighten the mounting screws (located in
the openings on both sides of the casing unit) with a cross-head screwdriver. This will permanently
attach the casing unit (Fig. 18).
FITTING FURNITURE BOARD TO APPLIANCE DOOR
Placethemountingbracketonfurnitureboardandpositionitaccordingly(Fig.12).Thedistancebetween
the furniture board and the underside of the worktop should be 5 mm (Fig. 13).Attach the mounting
bracket using suitable screws supplied in the installation kit. Pull out the mounting bracket cover and
screwinthetwospecialscrews(2)intheappliancedoors(Fig.14).Attachfurnitureboardwiththefixed
mounting bracket to the appliance door. Secure the furniture board with suitable nuts (item 3, Figure
14). Make sure the furniture board assembly is positioned correctly relative to the appliance (Fig. 15).
Using the supplied screws, attach the furniture board assembly to the bottom of the appliance door
(Fig. 15). Replace the mounting bracket cover in its original location.
1. Unplug the appliance before reversing the door opening direction.
2. Remove food from the appliance.
3. Remove caps on the front of the refrigerator body (Fig. 1, Fig 2).
4. Remove the two screws, which attach the upper hinge to the appliance door (Fig. 3). Take spe-
cial care and hold the appliance door vertically.
5. Holding the door, swing the upper door hinge away from the door using the other hand (Fig. 4).
Be especially careful during this step, as the hinge may close and cause injury.
5

6
1 2
3
4 5
OFF
S S
1. Thermostat Dial
The thermostat automatically keeps the internal temperature at a constant level. The
temperature is regulated by the thermostat dial, located on the freezer control penal.
To change the temperature, turn the dial anti-clockwise from 1 (highest temperature)
to 5 (coldest temperature). We recommend that you start with the appliance set to
position 3.
2. Super freeze switch
When fast freezing is needed, turn on the fast freezing function button with the
indication that yellow light is on. After 24 hours, the function will be switched off
automatically. During fast freezing, press and hold the fast freezing button for 3
seconds, then the function will be manually switched off immediately.
3. Power indicator light
This green light will illuminate when the freezer is switched on.
4. Over temperature indicator light
This red light will illuminate when the temperature inside the freezer is too high. This
may illuminate after the door has been opened, or when fresh food is added and
should switch off again once the temperature within the freezer has stabilized.
5. Super freeze indicator light
This yellow light will illuminate when the super freezer function has been switched on
with the super freeze switch (2).
USE
The freezer compartments are designed to store frozen food.
Never put warm or hot food in the freezer, allow them to cool fully first
Follow the instructions on the packing for storage of froze food. If no information
is provided, foods should not be stored for more than three months after the
purchase date.
Never put sparkling drinks or bottles of liquid in the freezer as they can explode.

freezer
11
freezer
freezer
freezer freezer
freezer
freezer freezer
7

If you have any problems with your appliance, you should check the troubleshooting prior to calling
CustomerCare to prevent unnecessary service calls and potential cost.
If the appliance is not working
•Check there is power to the appliance:
•The house fuses are intact and the fuse in the plug has not blown.
•The thermostat is not set to 0 (off position).
•The plug socket is functioning fine. T
•The temperature of the room is adequate (10 o
C or above).
The appliance is working, but not very well
•The appliance is not overloaded.
•The thermostat is set to an appropriate temperature.
•The door is closing properly.
•The cooling system at the rear of the appliance is clean and free of dust, and not touching the rear wall.
•There is enough ventilation at the side and rear walls.
•The temperature of the room is adequate (10 o
C or above).
The appliance is noisy
•The appliance is level and stable.
•The side and rear walls are clear, and there is nothing resting on the appliance.
•The cooling gas in the refrigerator will make a slight bubbling noise, even when the compressor is not running.
There is water in the lower part of the refrigerator compartment
•The drain hole in the channel at the back of the compartment is clear.
8
