Sicma RD User manual

RD Tiller
- 1 -
RD Tiller
USE AND MAINTENANCE MANUAL
903826002~01
TRANSLATION OF ORIGINAL INSTRUCTIONS
MADE IN ITALY

- 2 -
RD Tiller

RD Tiller
- 3 -
INDEX
1. INTRODUCTION 5
1.1 SOME NOTES REGARDING THE USER MANUAL 5
1.2 DECLARATION OF CONFORMITY 6
1.3 LIST OF RESIDUAL RISKS 7
1.4 DELIVERY LETTER 8
1.5 TILLER IDENTIFICATION AND MANUAL CODE 9
1.6 GENERAL DELIVERY NOTES 10
1.7 DECLARED USE 11
1.8 TILLER COMPOSITION 12
1.9 STANDARD AND OPTIONAL SET-UPS 12
2. SAFETY 14
2.1 DEFINITIONS (UNI EN ISO 12100-1:2009) 14
2.2 CONVENTIONAL SYMBOLS 14
2.3 SAFETY PRESCRIPTIONS 15
2.4 OPERATOR REQUISITES 15
2.5 CLOTHING AND PPE 16
2.6 MACHINE USE 16
2.7 SAFETY DEVICES 17
2.8 REASONABLY PREDICTABLE INCORRECT USE 17
2.9 ZERO ENERGY STATE 17
2.10 POSITION OF PICTOGRAMS ON THE MACHINE 18
3. UNLOADING AND UNPACKING THE TILLER 21
3.1 TILLER PROTECTED BY HEAT-SHRINKABLE FILM 21
3.2 TILLER IN WOODEN CRATE 22
4. TECHNICAL FEATURES 24
5. START-UP 26
5.1 CARDAN SHAFT CONNECTION 26
5.2 3-POINT HITCH CONNECTION 28
5.3 ROAD TRANSPORT 29
6. ADJUSTMENTS 29
6.1 ROTATION SPEED CHANGE 29
6.2 CLUTCH ADJUSTMENT 30
6.3 WORKING HEIGHT ADJUSTMENT 30
6.4 COVERS ADJUSTMENT 31
6.5 MACHINING 31
7. STOPS 33
8. ROUTINE MAINTENANCE 35
8.1 CONTROL AND REPLACEMENT OF THE OIL IN THE GEARBOX UNIT 36
8.2 CONTROL AND REPLACEMENT OF THE OIL IN THE LATERAL DRIVE SUMP 37
8.3 CONTROL AND REPLACEMENT OF THE OIL IN THE EXTERNAL ROTOR LATERAL SUPPORT 37
8.4 GREASING 38
8.5 REPLACING HOES/BLADES 38
8.6 CARDAN SHAFT 39
9. CLEANING 39
10. STORAGE AND WINTERING 39
11. SCRAPPING 40

- 4 -
RD Tiller
12. QUICK CONSULTATION TABLES 40
12.1 COUPLING TORQUE TABLE 40
12.2 TROUBLESHOOTING 40
12.3 LUBRICATION INTERVALS 41
13. SPARE PARTS 42
14. WARRANTY 42

RD Tiller
- 5 -
Congratulations on your purchase of the
RD Tiller
The RD Tiller is manufactured by SICMA S.p.A, which has been producing
agricultural machines for over 40 years.
The RD Tiller has all safety and quality requisites required for this type of
equipment.
Remember that to obtain the best performance and make the best of the
production features, it is necessary to know the instructions and information
contained in this manual and follow the same.
1. INTRODUCTION
1.1 SOME NOTES REGARDING THE USER MANUAL
Remember that the USER MANUAL is not an accessory of the tiller but is
an INTEGRAL part and a SAFETY MEASURE (EN 12100-1).
For this reason:
• kept in a good state;
• it must be kept near to the equipment;
• pass it to any operator user, maintenance technician, handler or
successive owner.
In this way, the tiller can be used in the best way for all functions for which
it has been manufactured and in maximum safety.
The manual must not be damaged, it must remain integral (do not rip the
sheets), must be kept away from humidity and heat. During consultation it
must not be covered in grease or its legibility deteriorated.
If this manual is lost or damaged, ask for a copy from the Manufacturer or
nearest Dealer.
To ease consultation, the manual has been divided into parts so that every
phase is described well.
Withthese arrangements,SICMAintendstounmistakably callthe operator's
attention to the dangerous situations that may occur.
RD Tiller
USE AND MAINTENANCE MANUAL
TRANSLATION OF ORIGINAL INSTRUCTIONS

- 6 -
RD Tiller
1.2 DECLARATION OF CONFORMITY
The machine is delivered accompanied by the following Declaration of
Conformity.
CE DECLARATION OF CONFORMITY
pursuant to Directive 2006/42/CE
The Company
Sicma s.p.a. – C. da Cerreto, 39 – 66010 Miglianico (Ch) – Italy
Tél.: +39 0871 95841 – Fax +39 0871 950295
declares under his own responsibility that the machine:
Type: TILLER
Model: RD
Serial number:
is conform with the essential health and safety requisites of Directive 2006/42/EC.
To verify the conformity with the above Directive, the following have been consulted:
EN Harmonised Standards:
- UNI EN ISO 4254 – 1:2006, EN ISO 4254 – 5:2009, UNI EN ISO 12100 – 2:2009
NationalandInternationaltechnicalSpecicationsandStandards:
- ISO 11684:1995, ISO 13852:1996, UNI 9456:1989.
Thepersonauthorisedtoll-intheTechnicalFileisMr.LorenzoAurora(SoleDirector)
Miglianico. 15-03-2011
Lorenzo Aurora
SOLE DIRECTOR
Lorenzo Aurora
AMMINISTRATORE UNICO
DICHIARAZIONE CE DI CONFORMITA'
ai sensi della Direttiva 2006/42/CE
La ditta
Sicma s.p.a. - C.da Cerreto, 39 - 66010 Miglianico (Ch) - Italy
Tel.: +39 0871 95841 - Fax:+39 0871 950295
dichiara sotto la propria responsabilità che la macchina:
Tipo: FRESATRICE
Modello: RG
Numero di serie:
è conforme ai requisiti essenziali di sicurezza e tutela della salute di cui alla Direttiva 2006/42/CE.
Per la verifica della conformità di cui alla direttiva sopra menzionata, sono state consultate le seguenti:
Norme armonizzate EN:
-UNI EN ISO 4254-1:2006, EN ISO 4254-5:2009, UNI EN ISO 12100-1:2009, UNI EN ISO 12100-2:2009
Norme e Specificazioni Tecniche Nazionali ed Internazionali:
- ISO 11684:1995, ISO 13852:1996, UNI 9456:1989.
La persona autorizzata a compilare il Fascicolo Tecnico è il sig. Lorenzo Aurora (Amministratore unico)
Miglianico, 29-12-2009
Lorenzo Aurora
AMMINISTRATORE UNICO
DICHIARAZIONE CE DI CONFORMITA'
ai sensi della Direttiva 2006/42/CE
La ditta
Sicma s.p.a. - C.da Cerreto, 39 - 66010 Miglianico (Ch) - Italy
Tel.: +39 0871 95841 - Fax:+39 0871 950295
dichiara sotto la propria responsabilità che la macchina:
Tipo: FRESATRICE
Modello: RG
Numero di serie:
è conforme ai requisiti essenziali di sicurezza e tutela della salute di cui alla Direttiva 2006/42/CE.
Per la verifica della conformità di cui alla direttiva sopra menzionata, sono state consultate le seguenti:
Norme armonizzate EN:
-UNI EN ISO 4254-1:2006, EN ISO 4254-5:2009, UNI EN ISO 12100-1:2009, UNI EN ISO 12100-2:2009
Norme e Specificazioni Tecniche Nazionali ed Internazionali:
- ISO 11684:1995, ISO 13852:1996, UNI 9456:1989.
La persona autorizzata a compilare il Fascicolo Tecnico è il sig. Lorenzo Aurora (Amministratore unico)
Miglianico, 29-12-2009

RD Tiller
- 7 -
1.3 LIST OF RESIDUAL RISKS
Even though SICMA has done everything possible to be in line with state-
of-the-art safety and in compliance with all Directives, Laws and Standards
available, some residual risks still exist:
• CUT/CRUSHING HAZARD DUE TO CONTACT WITH TOOLS (rotor)
• ENTANGLEMENT/DRAGGING HAZARD (rotor and Cardan shaft)
• OVERTURNING/CRUSHING HAZARD (tiller)
• BURNS HAZARD (gearbox)
• CUT/SHEARING HAZARD (rear covers)
Therefore, anyone using the machine or performing maintenance on the
same, must be trained and aware of the fact that dangers exist and in spite
the use of protections to reduce them, it is not possible to eliminate them
totally.
The staff assigned to these operations must always have the use and
maintenance manual available for consultation.
The use and maintenance manual states all indications requested from
point 1.7.4 (User instructions) of Attachment 1 of the Machinery Directive
andspecicrequestismadetocomplywiththeprescriptions,soasnotto
cause accidents that can injure persons.

- 8 -
RD Tiller
1.4 DELIVERY LETTER
The tiller has been manufactured in compliance with the 2006/42/CE
Directive,
and has been designed in compliance with the guide lines of the Technical
Standardsrelativetothetillers,specicallyUNIENISO4254-1:2010and
UNI EN ISO 4254-5:2009.
Therefore, the machine does not represent a danger for the operator if used
according to the instructions in this manual and on condition that the safety
devicesarekeptconstantlyefcient.
This form attests receipt of the tiller:
• the safety devices are present.
• this manual has been delivered.
SICMA INFORMS THAT ANY
MODIFICATION OR TAMPERING OF
THE TILLER OR ANY OPERATION
PERFORMED IN DISAGREEMENT
WITH THAT WRITTEN IN THIS MANUAL,
ESPECIALLY FAILURE TO COMPLY WITH
THE SAFETY PROVISIONS, AS WELL
AS MAKING THE WARRANTY NULL AND
VOID, RELIEVES SICMA FROM ANY
LIABILITY FOR DAMAGE TO OBJECTS
AND INJURY TO PERSONS.
Some of the devices described in this
manual may not be present on your
machine, depending on the chosen set up
and the market of destination.
It must be remembered that all technical
values refer to the standard tiller (see Chap. 4 “Technical Features”) and
the drawings and any other document delivered along with the tiller are the
property of SICMA, which reserves all rights and reminds that they cannot
be made available to third parties without its written approval.
Therefore, any reproduction, even partial, of the text and illustrations us
prohibited.
The information, descriptions and illustrations contained in this manual
reectthestateoftheartofthemachineatthemomentitwasputonthe
market.
The Manufacturer reserves the right, at any time, to apply modications
tothemachineryfortechnicalorcommercialreasons.Suchmodications
do not oblige the Manufacturer to intervene on machines sold up until that
moment, nor to consider this publication inadequate.
Any integration that the Manufacturer will consider opportune to supply
later on must be preserved together with the manual and be considered an
integral part of the same.

RD Tiller
- 9 -
1.5 TILLER IDENTIFICATION AND MANUAL CODE
For any after-sales requests or information regarding the tiller, contact SICMA
or its after-sales centres always stating the model and the serial number
stated on the plate.
Theidenticationcodeofthismanualiswrittenonthecover.
Write the number in a different place so that if this manual is lost or damaged,
another copy can be requested from SICMA or the nearest dealer by also
stating the serial number visible in the marking.
RD Tiller
USE AND MAINTENANCE MANUAL
TRANSLATION OF ORIGINAL INSTRUCTIONS

- 10 -
RD Tiller
1.6 GENERAL DELIVERY NOTES
The tiller and its parts and/or accessories are normally delivered by lorry or
container.
On receipt of the machine, check that:
• the supply corresponds with the order specications (see transport
document or packing-list)
• there is no damage to the tiller or accessories
• in the event of damage or missing pieces, inform the SICMA or its area
representatives, the carrier or its insurance immediately in detail and/
or with photos
• the spare parts or equipment supplied are sometimes in separate
containers.
The machine is delivered by SICMA equipped with the following supplies:
1 - CARDAN SHAFT
2 - TILLER USEAND MAINTENANCE MANUAL
3 - CARDAN SHAFT USEAND MAINTENANCE MANUAL
4 - CE DECLARATION OF CONFORMITY
1
3
2
RD Tiller
USE AND MAINTENANCE MANUAL
TRANSLATION OF ORIGINAL INSTRUCTIONS
Lorenzo Aurora
AMMINISTRATORE UNICO
DICHIARAZIONE CE DI CONFORMITA'
ai sensi della Direttiva 2006/42/CE
La ditta
Sicma s.p.a.- C.da Cerreto,39 - 66010 Miglianico (Ch) - Italy
Tel.:+39 0871 95841 - Fax:+39 0871 950295
dichiara sotto la propria responsabilità che la macchina:
Tipo: FRESATRICE
Modello: RG
Numero di serie:
è conforme ai requisiti essenziali di sicurezza e tutela della salute di cui alla Direttiva 2006/42/CE.
Per la verifica della conformità di cui alla direttiva sopra menzionata, sono state consultate le seguenti:
Norme armonizzate EN:
-UNI EN ISO 4254-1:2006, EN ISO 4254-5:2009, UNI EN ISO 12100-1:2009,UNI EN ISO 12100-2:2009
Norme e Specificazioni Tecniche Nazionali ed Internazionali:
- ISO 11684:1995, ISO 13852:1996,UNI 9456:1989.
La persona autorizzata a compilare il FascicoloTecnico è il sig. Lorenzo Aurora (Amministratore unico)
Miglianico, 29-12-2009
Lorenzo Aurora
AMMINISTRATORE UNICO
DICHIARAZIONE CE DI CONFORMITA'
ai sensi della Direttiva 2006/42/CE
La ditta
Sicma s.p.a.- C.da Cerreto,39 - 66010 Miglianico (Ch) - Italy
Tel.:+39 0871 95841 - Fax:+39 0871 950295
dichiara sotto la propria responsabilità che la macchina:
Tipo: FRESATRICE
Modello: RG
Numero di serie:
è conforme ai requisiti essenziali di sicurezza e tutela della salute di cui alla Direttiva 2006/42/CE.
Per la verifica della conformità di cui alla direttiva sopra menzionata, sono state consultate le seguenti:
Norme armonizzate EN:
-UNI EN ISO 4254-1:2006, EN ISO 4254-5:2009, UNI EN ISO 12100-1:2009,UNI EN ISO 12100-2:2009
Norme e Specificazioni Tecniche Nazionali ed Internazionali:
- ISO 11684:1995, ISO 13852:1996,UNI 9456:1989.
La persona autorizzata a compilare il FascicoloTecnico è il sig. Lorenzo Aurora (Amministratore unico)
Miglianico, 29-12-2009
4
SOLE DIRECTOR
CE DECLARATION OF CONFORMITY
pursuant to Directive 2006/42/CE
The Company
Sicma s.p.a. – C. da Cerreto, 39 – 66010 Miglianico (Ch) – Italy
Tél.: +39 0871 95841 – Fax +39 0871 950295
declares under his own responsibility that the machine:
Type: TILLER
Model: RD
Serial number:
is conform with the essential health and safety requisites of Directive 2006/42/EC.
To verify the conformity with the above Directive, the following have been consulted:
EN Harmonised Standards:
- UNI EN ISO 4254 – 1:2006, EN ISO 4254 – 5:2009, UNI EN ISO 12100 – 2:2009
NationalandInternationaltechnicalSpecicationsandStandards:
- ISO 11684:1995, ISO 13852:1996, UNI 9456:1989.
Thepersonauthorisedtoll-intheTechnicalFileisMr.LorenzoAurora(SoleDirector)
Miglianico, 15-03-2011

RD Tiller
- 11 -
1.7 DECLARED USE
The RD Tiller has been designed expressly to work land and has been
developed with the sole purpose of loosening, turning and oxygenating the
land in order to prepare it for sowing.
It has been manufactured to be coupled to tractors that can support the
weight of the tiller, with hydraulic lifting device and universal three point
hitch and to be activated by the tractor PTO via Cardan transmission.
USE ENVIRONMENT
The tiller works:
• inopenelds,onnonfriableland,notexcessivelystonywithamaximum
gradient of 3°
• inenvironmentswithatemperaturefrom0˚÷50˚C.
IMPROPER USE
Anyusedifferenttothatdeclaredistobeconsidered
improper.
Sometimes the operator uses the tiller incorrectly,
below nd some examples the must NOT BE
PERFORMED.
The operator must not:
• connect the tiller to a Cardan shaft with greater
or smaller power
• work in reverse gear compressing the earth
with hood press
• couple the tiller to vehicles of unsuitable power
or weight
• assemble the tiller without securing the rebound tie rods of the three-
point hitch of the tractor’s elevator
• lift the equipment when the PTO is rotating
• make curves or reverse with the tiller lowered.
Remember that the tiller is developed only with the purpose of the declared
use.
Any other use is to be considered improper.

- 12 -
RD Tiller
1.8 TILLER COMPOSITION
1 Chassis
2 Lower point hitches
3 Upper three-point hitch
4 Cardan shaft protection
5 Third point mast
6 Rotor
7 Hoes
8 Side skids
9 Drive sump
10 Bonnet
1.9 STANDARD AND OPTIONAL SET-UPS
TYPES OF TOOLS
A - SQUARE HOE
B - CURVED HOE
C - BLADE WITH 2 HOLES
A B C
1
2
34
6
7
5
9
10
8

RD Tiller
- 13 -
TYPES OF ROTOR
The purpose of the rotor is to work the earth in order to
reduce the sods into smaller pieces, keeping the earth soft.
Depending on the different features of earth to be worked,
SICMA has developed and offers various types of rotor:
ROTOR
A - STANDARD ROTOR: for land in normal conditions
B - PUGLIA ROTOR: has the end hoes facing inwards and
is recommended when working near to plants, avoiding
damage to the roots
C - BLADE ROTOR: for wet and hard land
ACCESSORIES AND REAR ROLLERS
D - SPIKED ROLLER: for stony, argillaceous land or with high
level of humidity
E - FRONT WHEELS: for a further working height adjustment
F - CRUSHER: for grinding and conveying sods
G - EARTH COVER: to contain the earth inside the tiller
D
E
G
A
B
C
F

- 14 -
RD Tiller
2. SAFETY
During consultation of this use and maintenance manual and on the
equipmentitself,itispossibletondseveralsymbolswhosemeaningsare
illustrated below.
2.1 DEFINITIONS (UNI EN ISO 12100-1:2009)
DANGER:
A potential source of physical injury or damage to health.
DANGEROUS AREA:
Any area within and/or in proximity of a machine in which the presence of a
person constitutes a risk for the safety and health of the same.
The dangerous area is the area around the machine (attached to the tractor)
up to a distance of 1 metre.
EXPOSED PERSON:
any person that is totally or partially inside a dangerous area.
CRITICAL AREA
The critical area is that between the tractor and the equipment (Cardan
shaft area).
2.2 CONVENTIONAL SYMBOLS
ATTENTION GENERAL HAZARD
Informs the staff assigned that the operation described has the risk of
physical injury if not performed with respect to the Safety Standards.
NOTE
Informs the staff assigned of information whose content is of relevant
consideration and importance.
WARNING
Informs the staff assigned of information whose content can cause slight
injury to persons or damage to the machine if not respected.
MACHINE OPERATOR OR DRIVER
Identies qualied staff, i.e. with specic skills, as the operations are
completely manual, therefore refer to the preparation and sensitivity of the
machine driver to obtain the best qualitative results. It is therefore prohibited
for the operator to perform operations that are the responsibility of the
maintenance technician.

RD Tiller
- 15 -
MECHANICAL MAINTENANCE STAFF
Qualiedtechnicianabletointerveneonmechanicalpartsinordertomake
all regulations, maintenance interventions and repairs necessary.
EXTRAORDINARY INTERVENTIONS
Any maintenance interventions highlighted by the symbol at the side are to
be requested from the manufacturer or authorised workshops.
PERSONAL PROTECTIONS (PPE)
The presence of one of the symbols at the side imposes the use of the
corresponding PPE by the operator, as the risk of accident is implicit.
RECOMMENDATION
It refers to a work mode experimented on eld, knowing well that every
operator will develop his own way of operating.
2.3 SAFETY PRESCRIPTIONS
Even though SICMA has applied all possible safety devices on the
equipment, it must be remembered that it can be dangerous for health if
not used correctly. It is therefore advised to read and comply with the safety
prescriptions listed below.
Before using the equipment, all operators MUST have read and understood
the safety prescriptions and the entire user manual.
• Themachineisnotsuitabletobeusedinothersectorsthaninagriculture.
• Anyusedifferenttothatspeciedistobeconsideredimproper.
• The manual must always be on hand, in a way to consult it when
necessary. If it should be lost or damaged, request a replacement copy
from SICMA.
• Do not climb onto, sit on or rest on the equipment for any reason,
whetheritisonorinthezeroenergystate.
2.4 OPERATOR REQUISITES
• The machine must only be used by one operator driving the tractor.
• The machine must be used exclusively by authorised, instructed and
trained operators. The operator, besides having read and understood
the instructions contained in this manual, must also be sufciently
prepared on the proper use of the machine and must have a driving
license. The operator must contact the dealer or the manufacturer if
in doubt regarding use of the machine or interpretation of this manual.
• The operator must make sure that no person or animal stops within the
radius of action of the same during machine functioning. Never activate
the machine near to persons standing or transiting within the radius of
action of the machine.
• Do not use the machine if you are tired, ill or under the effect of alcohol,
medicines or drugs.

- 16 -
RD Tiller
• The correct operator position is in the tractor driving seat. From this
position he must also control that there are no persons exposed in the
dangerous area in the work phase.
2.5 CLOTHING AND PPE
• Staffmustuse thesafety suppliesandPPE duringuse and maintenance
of the vehicle.
The correct clothing to be worn during maintenance operations and use of
the tiller is:
• gloves
• accident-prevention shoes or boots with steel toe-cap
• glasses
• overall with elastic on the wrists, ankles and around the waist.
Moreover:
• given that the machine can generate emissions of dust during working,
if the tractor does not have a closed cab, the operator must wear an
anti-dust mask (especially on dry and dusty land)
• if the tractor does not have a sound-proof cab, the operator must wear
hearing protections (especially on stony land)
• the operator assigned to the machine must not wear items of clothing
that can cause entanglement (scarves, belts, wide sleeves, etc.).
2.6 MACHINE USE
• The machine is usually used during the day. If night-time use is
exceptionally requested or use in conditions of reduced visibility, a
tractor lighting system or an auxiliary lighting system must be used.
• AnyarbitrarymodicationmadeonthismachineliftsSicmafromany
responsibility for damage or injuries that could result to operators, third
parties or to objects.
• Check the machine thoroughly before each start-up.
• Check the tightness of all screws every day (consult the tightness table
on page 40). If necessary, tighten them and also control the metal
structures and repair them if necessary.
• Checkthatthe retainerchainssnap hooksofthe Cardanshaft protection
are hooked in the appropriate slot, in a way that the plastic protection
remains at a standstill and does not turn with the Cardan shaft itself.
• Before getting out of the tractor and before any maintenance operation,
activate the parking brake, turn the engine off, remove the ignition key
from the dashboard and keep it.
• The hoes rotate rapidly when the machine is functioning: stay at a safe
distance to prevent accidental contact with moving tools or with thrown
objects.

RD Tiller
- 17 -
2.7 SAFETY DEVICES
• Beforeusing the machine, makesure that all safetydevices are properly
in place and in good conditions. If there are failures or damage to the
guards, replace them immediately.
• Do not tamper with or bypass safety devices for any reason.After every
cleaning and maintenance intervention, all of the safety devices must
be restored and*or all protection guards closed. Check also that tools,
cloths or various materials do not remain in the drive compartments.
• Thesignsappliedtothemachinesupplyaseriesofimportantindications:
compliance with the same is for your safety.
• Makesurethesafetypictogramsareingoodconditions.Ifthepictograms
has deteriorated, they must be replaced with other original versions
requested from the manufacturer and placed in the position indicated
by the use and maintenance manual.
2.8 REASONABLY PREDICTABLE INCORRECT USE
The operator must not:
• connect the tiller to a Cardan shaft with greater or smaller power
• work in reverse gear compressing the earth with hood press
• makemodicationstotheequipmentthatcouldjeopardisesafety
• perform makeshift repairs in order to work.
Moreover, it is prohibited to:
• couple the tiller to vehicles of unsuitable power or weight
• assemble the machine without securing the rebound tie rods of the
three-point hitch of the tractor’s elevator
• lift the equipment when the PTO is rotating
• tamper with hydraulic circuits
• use the machine to transport and/or to lift persons, animals or objects
• work on ground with gradient over 3°.
Sicma declines any liability for accidents deriving from the failure to comply
with the prescriptions indicated below.
Given the particular stress to which the equipment is subjected and for
safety reasons, if pieces are replaced, only use original spare parts.
2.9 ZERO ENERGY STATE
The"zeroenergystate"isdenedasthestateinwhichthetilleristobetaken
before performing any cleaning, lubrication and maintenance operation.
Performthefollowingoperationstotakethetillertothe"zeroenergystate":
• positionthetilleronstable,atlandwithmaximumgradientof3°
• disable the PTO from the tractor
• engage the tractor hand brake
• switch the tractor off, remove the key and keep it
• get off the tractor and disconnect the Cardan shaft from the PTO tractor.
• disconnect the hydraulic points
• position the outrigger in the stop position
• disconnect the 3-point hitch.

- 18 -
RD Tiller
2.10 POSITION OF PICTOGRAMS ON THE MACHINE
6
5
7
2
10 5
4
3
1
2
14
3
8
8
9
4
11 12 13

RD Tiller
- 19 -
SAFETY PICTOGRAMS
1000
OIL
004
Attention
Read all instructions and safety rules carefully before using the machine. Stop engine
and remove key before starting maintenance or repairs.
1000
OIL
004
Foot injury hazard
Keep at a safe distance from the machine.
1000
OIL
004
Thrown objects on entire body
Keep at a safe distance from the machine.
Handinjuryhazard:donotopenorremovesafetyguardswhilethemachineisoperating.
1000
OIL
004
Hand injury hazard
Keep safety guards in position while operating.
1000
OIL
004
Foot injury hazard
Rotating tools: keep a safety distance from the machine.
Attachment point
For lifting the machine.
1000
OIL
004
Input 540 rpm
Use of a 540 rpm power takeoff.
1000
OIL
004
Shearing hazard
Do not approach the hands.
1000
OIL
004
Burns hazard
Do not touch hot surfaces.
1
2
3
4
5
6
7
8
9

- 20 -
RD Tiller
IDENTIFICATION PICTOGRAMS
CE plate
Stating the main data with serial number and CE mark.
Gear plate
Numberofrotorrevsdependingonthevariousgearcombinations.
RD Plate
Machine model.
Width plate
Width of the machine in cm.
1000
OIL
004
OIL
Indication of lubrication oil load point.
11
12
13
14
10
Table of contents
Other Sicma Tiller manuals
