Siemens Gigaset 4015 User manual

Gigaset
4015
Be inspired
User Manual and
Safety Precautions
Se incluyen Instrucciones en Español
Sold by:
http://www.TWAcomm.com
Toll Free: [phone]

II
Congratulations
Congratulations on your purchase of the Siemens Gigaset 4015 telephone system!
This phones 2.4 GHz frequency and high-speed digital voice encoding provide re-
ception and voice clarity that is superior to other cordless phones. And, its digital
spread spectrum technology will provide you with secure, private conversations.
Please read the following important information.
For Siemens Customer Care Service, product operation
information, or for problem resolution, call toll-free
1-888-777-0211
7 a.m. to 10 p.m. Central Standard Time EVERY DAY
s
www.icm.siemens.com
DO NOT RETURN
THIS PRODUCT TO THE
STORE!

General
III
Quick reference
Handset
Turn handset on/off
(see page 7) Hold down 
Turn keypad protection on/off
(see page 7) Hold down 4
Turn tones on/off Hold down 5
Make an external call
(see page 12) 
Redial a number
(see page 16) If applicable, select an entry

Copy telephone number
to the Directory (see page 16)
Dial from the Directory
(see page 17)  [Name] and/or 
Dial from the Call Log
(see page 23) If necessary 
Set the handset volume
(see page 42)

Make an internal call
(see page 12) For example:
or

Call all handsets
(see page 12) 5or 
Transfer call to another
handset (see page 39) For example:
-+
Consultation Calls
(see page 39) For example:
-; End:
Set the date (see page 8) 
Set the time
(see page 8)
Set the alarm clock
(see page 10) Enter the time
Backspace
(see page 48)
Answering machine
Play back messages
(see page 29)
To the next message
(see page 30) 
or 
To the next message but one
(see page 30) or 
Repeat the message or 
To the previous message
(see page 30) or 
Delete all old messages 
Delete a specific message
RDL 
MENU SEND TO DIR OK

C LOG OK 
MENU HS SETT OK
H/SET VOL
OK

OK
INT
INT


INT INT INT ALL
INT
INT MENU EXIT OK
MENU BASE SETT OK 
CLOCK
OK
DATE OK
MENU BASE SETT OK CLOCK OK
TIME OK
MENU ALARM CLOCK OK OK
ANS M
OK

 

  MENU
MENU DEL OLD MSG
OK
SURE? OK

IV
General
Handset Diagram
Display and Soft keys
123
ABC DEF
456
JKL MNOGHI
789
TUV
WXYZ
PQRS
0
R
0
TALK
END
OPER
MEM
Flash key
Pause
(hold key down)
Star key
Hold down to
on/off
the ringer
Display
Pound key
Hold down to on/off key-
pad protection
Tal k key
- answer a call
- dial a telephone number
Key 1 (programmable)
Hold down to select the
answering machine/Telco
mailbox
Current display and
soft keys
see below
End key and
On/Off key
- end the call
- cancel function
- one menu level back
(press briefly)
- Return to idle state
(hold down)
- when the telephone is
idle on/off (hold down)
Memory key
Directory key
Open the directory
Charging status
,17 &

--


LED
lights up during a call;
flashes at:
- incoming calls
- new calls
- new messages
- alarm call
Headset jack
Microphone
5'/
,17 &

--

TALK
END
Time
Internal telephone
no. of the handset
Charging status
Alarm clock on signal
(if alarm has
been set)
In the display:
current functions
Kbattery empty
Hbattery fully charged
flashing: battery low
Soft keys:
Press the correspond-
ing keys to initiate the
function shown in the
display.

5'/

General
V
General
Display symbols
Automatic redial
key:
Opens the list
with the last five
telephone num-
bers dialed.
Mailbox icon:
Opens the messages/
entries in the answering
machine/in the Call Log/
Telco voice mail.
There are new messag-
es if the icon flashes.
Intercom key:
Call other regis-
tered handsets.
Menu key:
To access menu
(when the tele-
phone is idle or
during a call).
RDL INT
MENU
 
Scroll through the menu by pressing
the soft key directly below the symbol. Confirm the function selected. End and save the setting.
  OK
,17 &

--

2.

ALARM CLOCK


5'/

--

0(18

Scroll to the left and right
when entering numbers or messages. Delete key (Backspace): Delete input from right to left.
 
Then:
Press briefly: 1 menu level up
Hold down : Return to the idle state
No input: Automatically return to the idle state

VI
General

Table of Contents
1
Installing the Telephone System ........................3
Date and Time ......................................................8
Making Calls ....................................................... 12
Enhanced Telephone Features .........................16
Call Waiting ........................................................26
Operating the Answering Machine ..................27
Customizing the Answering Machine Settings 32
Handset Operation ............................................36
Individual Handset Settings .............................42
Base Station Settings ........................................44
Connecting the Base Station to a PBX .............46
Appendix ............................................................48
Table of Contents

Table of Contents
2
Troubleshooting ............................................... 49
Customer Care Warranty for Cordless Products
50
Safety Precautions ............................................ 52
Limited Warranty ............................................... 53
Menu .................................................................. 55
Index ................................................................... 57

3
Press Keys:
Installing the Telephone System
Installing the Telephone
System
The package contains the following:
• 1 Gigaset 4015 base station
• 1 Gigaset 4000 handset
• 1 power supply unit
• 1 telephone cord
• 1 belt clip
• 2 AA rechargeable NiCd batteries
• 1 User Manual
• 1 Quick Start Guide
Installing the Base Station
The base station is designed for operation in pro-
tected rooms with a temperature range from +40°F
to +100°F.
Important: For best reception, place the
base in a high central location, away from oth-
er electrical devices.
100°F
40°F

4
Installing the Telephone System
Connecting the Base Station
• Only use the power supply unit included as indicated on the underside of
the base.
• Use the telephone cord supplied. Do not use any old cords.
• Do not use an outlet controlled by a wall switch.
• Insert plug on the telephone cord into telephone jack on base unit (clicks
into place)
• Place cord in cable channel on the bottom of the base
• Insert other end of plug into telephone jack on the wall
• The installation of the base unit should allow at least 8 inches between the
base and persons to be in compliance with FCC RF exposure guidelines
Power supply unit
(110 V AC/60 Hz
with cord )
• Insert the
small plug on
cord into
phone jack
• Place cord in
the base cable
channel
• insert power
supply unit
into wall outlet
Telephone jack and tele-
phone cord
Key to register
additional
handsets/Page
handsets.
1
2

5
Press Keys:
Installing the Telephone System
Setting Up the Handset
Remove the protective plastic film
from display.
Inserting the batteries
• Insert the batteries, as shown above.
• Place cover and push gently upward until it clicks
into place (the unit is shipped with the battery
cover off).
• To open, press the grooved area on the cover and
slide back.
Placing the Handset into the Base Station
and Charging the Batteries
Before using your handset, place it in the base sta-
tion with the display facing upward. After about one
minute, the handset's internal number is shown in
upper left hand corner of display (for example, “1”).
Note:
Your Gigaset is now ready for operation. Your an-
swering machine is set with a standard announce-
ment. Please set date and the time (see page 8), so
that the time of incoming calls can be noted correct-
ly.
• Use only “AA” rechargeable NiCd or NiMH
batteries. Do not use Alkaline, Lithium or
non-rechargeable batteries.
• Never use non-Siemens charging units as
these could damage the batteries and
phone.
For information on how to register additional
handsets (bought separately), see page 37.
+
–
+
–+
–

F

6
Press Keys:
Installing the Telephone System
Leave the handset for about 12–14 hours in the
base station to charge the batteries. The charging
status symbol flashes on the handset, indicating
that the batteries are being charged:
Attaching the Belt Clip
Push the belt clip onto the back of the handset until
the tabs click into place.
KBatteries empty
(symbol flashes) IBatteries 2/3
charged
JBatteries 1/3
charged HBatteries fully
charged
• Once the initial charging operation is com-
pleted, replace your handset into the base
station after each call. Charging is con-
trolled electronically. This ensures opti-
mum charging and prolongs battery life.
• The batteries heat up during charging. This
is normal and not dangerous.
• The battery charging status is correctly dis-
played only after uninterrupted charging/
discharging. You should therefore avoid
opening the battery compartment unnec-
essarily.

7
Press Keys:
Installing the Telephone System
Turning Handset On/Off
To turn handset on/off, hold down the End key –
you will hear a confirmation beep*.
Turning Keypad Lock On/Off
You can disable the handset keys when carrying the
unit in your pocket or bag. This protects the keypad
against inadvertent activation. If there is an incom-
ing call, the key lock is automatically turned off and
turned on after the call has ended.
Answering a call: Press the Talk key.
4To turn keypad lock on/off, hold down the pound key
– you will hear the confirmation beep*.
Headset
• Insert the headset plug into the jack on the left
side of the handset.
• To answer a call, press the -key.
• To end a call, press the -key.
The handset is turned on as soon as you in-
sert the batteries and place the handset in
the base station.
911/Emergency Calls cannot be made when
the keypad is locked.
* Confirmation beep = rising tone sequence,
Error beep = falling tone sequence.
Headsets may be purchased separately.

8
Press Keys:
Date and Time
Date and Time
Setting the Date and the Time
The date and time settings are necessary in order
for the date and time of the arrival of messages/in-
coming calls to be displayed correctly. If you sub-
scribe to Caller ID, the time and date will be auto-
matically set with the first incoming call. If not,
manually set by using the steps below. You can also
set the clock mode, to the 12 hour mode (AM and
PM) or 24 hour mode.
Date
NNNNNNNNNNNN
MENU Open the Menu.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
BASE SETT Scroll to Base Setting and press OK.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
CLOCK Scroll to Clock and press OK.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
DATE Select Date and press OK.
The current setting is displayed in the MM-DD-YY
mode.
For example:
L0-0L Enter the month/day/year (for example, 05-25-01 as
shown).
NNNNNNN NNNNNNN
 If necessary, skip to a digit to correct it.
NNNNNNN
Save the setting by pressing OK.
Time
NNNNNNNNNNNN
MENU Open the Menu.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
BASE SETT Scroll to Base Setting and press OK.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
CLOCK Scroll to Clock and press OK.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
TIME Scroll to Time and press OK.
• The default setting is 12 hour mode.
• If you subscribe to Caller ID the date and
time may be sent from your telephone ser-
vice and will be automatically set.
• If you want to voice stamp your answering
machine, you must set the date and time.

9
Press Keys:
Date and Time
The current setting is displayed as HH:MM.
For example:
LL Enter the hours/minutes for example, 10:30 as
shown.
NNNNNNN NNNNNNN
 If necessary, skip to a digit to correct it.
NNNNNNN
Save the setting by pressing OK.
If 12 hour mode is set as Clock Mode:
NNNNNNN NNNNNNN
AM Select AM and press OK.
or
NNNNNNN NNNNNNN NNNNNNN
PM Scroll to PM and and press OK.
NNNNNNN
Save the setting by pressing OK.
Display Mode (12 or 24 Hours)
NNNNNNNNNNNN
MENU Open the Menu.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
BASE SETT Scroll to Base Setting and press OK.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
CLOCK Scroll to Clock and press OK.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
CLOCK MODE Scroll to Clock Mode and press OK.
NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
24 H Select 24 hour mode and press OK.
or
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
12 H Scroll to 12 hour mode and press OK.
By default, the clock is set to the 12 hour
mode.

10
Press Keys:
Date and Time
Setting the Alarm
Your Gigaset has an alarm function to help you keep
track of your schedule.
Turning the Alarm On
The active alarm rings every day at the set time.
NNNNNNNNNNNN
MENU Open the Menu.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
ALARM CLOCK Scroll to Alarm Clock and press OK
(marked with a ').
For example:
LL Enter the time for the alarm (hours/minutes).
For example, 10:30 AM as shown.
NNNNNNN NNNNNNN
 If necessary, skip to a digit to correct it.
NNNNNNN
Save the setting by pressing OK.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
AM Then select AM or PM and press OK.
Turning the Alarm Off
The alarm clock is set, but you do not want the
alarm to sound.
NNNNNNNNNNNN
MENU Open the Menu.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
ALARM CLOCK Scroll to Alarm Clock and press OK.
The alarm is turned off. The asterisk before the time
display is no longer shown.
A prerequisite for this function that you have
set date and time (see page 8).
,17

--

5'/

&
The asterisk
indicates that
the alarm
clock is set.

11
Press Keys:
Date and Time
Stopping the Alarm Sound
An alarm clock rings and the LED flashes (about 30
seconds). Press any key on the handset to turn off
the alarm sound.
Area Codes
To conveniently call back a user from the call log
(see page 23) you will need to key in and store the
code for the area where your telephone is installed
(Local Area Code). If it is installed in a Multiple Area
Code Area you will also have to key in and store the
Extra Codes for that area.
Local Area Code
NNNNNNNNNNNN
MENU Open the Menu.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
BASE SETT Scroll to BASE SETT and press OK.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
AREA CODES Scroll to AREA CODES and press OK.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
LOC A CODE Scroll to LOC A CODE and press OK.
Key in your Local Area Code.
NNNNNNN
Confirm.
NNNNNNNNNNNN
SAVED Saved will be displayed.
Extra Codes
NNNNNNNNNNNN
MENU Open the Menu.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
BASE SETT Scroll to BASE SETT and press OK.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
AREA CODES Scroll to AREA CODE and press OK.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
EXTRA CODES Scroll to EXTRA CODES. The first entry of list of
codes will be displayed.
NNNNNNNNNNNN
MENU Press Menu.
Key in the Extra Code.
NNNNNNN
Confirm.
NNNNNNNNNNNN
SAVED Saved will be displayed.
Repeat the last steps until all the Extra Codes for
your area have been keyed in.
There is no snooze setting. The alarm will
sound until turned off.

12
Press Keys:
Making Calls
Making Calls
Making an External Call
 Dial the telephone number. If necessary use the
backspace key to correct single digits.
Press the Talk key.
To end the call, press the End key.
Making Intercom Calls
Intercom calls are calls to other registered handsets
and does not tie up your telephone line (for exam-
ple, calls within your home from the kitchen to the
living room).
For example:
NNNNNNNN"""
-Press the Intercom soft key and enter the desired
handset's telephone number,
or
NNNNNNN NNNNNNN
  Select the desired handset and press the Talk key.
Paging All Handsets
NNNNNNNN"""
5Press the Intercom soft key and then press the Star
key
or
press the Talk key.
Ending a Call
Press the End key.
• You can also press the Talk key firstand
then enter the telephone number – each
digit is dialed immediately.
• You can cancel the dialing operation with
the End key.
• You can insert a pause, for example for in-
ternational calls, by holding down the Flash
key located in lower left hand corner of
handset.

13
Press Keys:
Making Calls
Answering a Call
Press the Talk key.
or
F? Pick up the handset from the base station or charg-
er (default: Auto talk, see page 43).
Answering Caller ID Calls
Caller ID is a service provided by the local telephone
company which allows your Gigaset to display the
name and number of the person who is calling you.
Contact your local telephone company to subscribe
to Caller ID service.
As incoming call is displayed if follows:
NNNNNNNNNNNNNNNNNNNNNNNNNNNN
5125551212 First the number of the incoming call is displayed as
follows.
NNNNNNNNNNNNNNNNNNNNNNNNNNNN
JANE DOE After a moment the name is then displayed as fol-
lows.
If the number is stored in your directory, only the
name stored will appear.
NNNNNNNNNNNNNNNNNNNNNNNNNNNN
<< >> If you have not applied for Caller ID service.
NNNNNNNNNNNNNNNNNNNNNNNNNNNN
PRV CALL If the number and/or name is suppressed by the
caller, PRV CALL will be displayed instead of the rel-
evant information.
NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN
OUT OF AREA If the number and/or name is not available to your
telephone company, OUT OF AREA will be dis-
played instead of the relevant information..
NNNNNNNNNNNNNNNNNNNNNNNNNNNN
OUT OF AREA If the caller is unknown or no available Caller ID in-
formation is received by the local telephone
company.
• If the incoming name is longer than 12 let-
ters only the first 11 are displayed.
• If the incoming number is longer than 12
letters only the first 11 are displayed.

14
Press Keys:
Making Calls
Listening in at the Base Station
You can switch on the base station speaker, so that
people in the room can hear what your caller is say-
ing.
NNNNNNNNNNNN
MENU Open the Menu.
NNNNNNN NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN NNNNNNN
BASE SPKR Scroll to Base Speaker and press OK.
To deactivate, repeat this procedure.
Picking up a call from the answering
machine
While the answering machine is recording a mes-
sage (9-symbol is flashing), you can still answer
the call if you want to talk to the caller.
Press the talk key.
The recording stops and you can talk to the caller.
This is for listening only. It is not a speaker-
phone because it has no microphone. Before
you activate this feature, you should inform
your caller about your intention.
