LightVerse®Pro Enclosure Installation Instructions
To open the doors, ensure the tamper resistant latch is not
engaged (if engaged, utilize key and unlock) and grab from
either side or the top.
The mounting brackets can be mounted in three positions to
provide different position placement in the mounting rails of a
cabinet or rack.
12
Attach mounting
brackets to each side
of enclosure using
mounting bracket
washers and screws
(2 per side for 1U, 4 per
side for 2U and 4U).
3
Mount enclosure to rack or cabinet
rails using the included #12-24
screws with washers.
4
Fron
t
Rear
Hardware and Accessories Tools
The open hole design of the rack mounting brackets can be utilized
to allow for easier mounting. 1. Screw in mounting screws at desired
height for bottom of the enclosure in the rack. The enclosure can
then be lowered down onto the partially installed screw, tighten
screws. 2. While the enclosure is held in place by the lower screws,
the top screws can then be used to secure it.
1
2
B
ACD
EFGH
IJ
K
L
A. Fiber Managers (8)
B. Mounting Bracket screws and
washers, 1U (4) 2U and 4U (8)
C. Rear tray restrictor screw (1)
D. Tamper resistant latch keys (2)
E. Laser warning labels (2)
F.Rear guided fiber management
bracket (1)
G. Roll of Velcro straps (1)
H. Velcro dots (2)
I. Tie wraps (2 with the 1U, 4 with the
2U and 4U)
J. Rack 12-24 screws & washers (4)
K. Rear cable plate and screw (1)
M
K. Diagonal cutter
L. Philips head screwdriver
M. Flat head screwdriver
K

To slide the tray to the forward jumper access position, 1. pull side
plunger out while 2. pulling the management feature(s) forward as
shown (Do NOT use label holder). Release the plunger as pulling
forward to allow for the tray to stop at the next position.
To access the jumper manager, rotate
the manager latch left or right.
The front and rear doors can be removed by pressing the hinge
points out as shown. To re-attach the doors, reverse the process.
The tray may be moved forward and backward to several positions by opening
applicable door and pulling the spring-loaded positioning pin out. In the same
manner, the tray can be completely removed out of the front or the back to aid
in dressing fiber into it.
Rear internal cable
securing plate can be used
on either left or right side.
Mount on the side opposite
of where the cable enters
the enclosure.
Rear internal cable
securing plate secures
using key and post
features in the bottom of
the plate and the tray. A
securing screw is screwed
in from the bottom of the
tray to lock it into position.
1
2
67
89
Front
Back
5
LightVerse®Pro Enclosure Installation Instructions

1
1
2
2
21
To insert the module or cassette
from the front of the panel, push
it inward while compressing the
front of the release tabs until
locked into position.
To remove, compress the front
of the release tabs on each side
of the module or cassette and
pull forward.
To insert the adapter
plate, ensure that the
SIEMON logo is facing
up as shown
1. Insert the tab on the
left side of the plate into
the panel.
2. Rotate the latching
side into the panel until it
snaps into place.
To remove the adapter plate,
depress the latch on the right
side of the plate and rotate
toward the left. The plate can
then be removed from the panel.
To insert the module or cassette from the
back of the panel, push it forward until
locked into position.
To remove the module or
cassette from the rear of the
panel, pull the release tether
straight back to disengage
from the panel and pull the
module free.
LightVerse Adapter Plates
1
Ensure that only the front of
the release tabs are depressed
as the cassette is inserted or
removed from the front.
Ensure that the cassette is level
while being inserted.
Adapter plates can pass forward or backward
though the openings in the panel as shown.
10 11
12 13
14 15
LightVerse Adapter Plates
LightVerse Adapter Plates Plug and Play Modules & Splice Cassettes
Plug and Play Modules & Splice Cassettes
1
2
Plug and Play Modules & Splice Cassettes
LightVerse®Pro Enclosure Installation Instructions

1
1. Pull rear right cover latch out to the side and hold in place.
2. Grab rear of cover and slide backwards 25mm (1 in.).
3. Lift cover upward and off.
1. Lay cover on top of enclosure so that the
right rear cover latch looks as shown above.
To re-install the cover, reverse the removal steps.
2. Side tabs on the rear of the
left and right side of the cover
should look as shown above.
3. With cover laying in position
on top of enclosure, push
forward with equal pressure on
the left and right side of the
cover until the cover latch locks
the cover in place.
17
16 Enclosure Cover Removal (2U and 4U)
2
3
Enclosure Cover Installation (2U and 4U)
LightVerse®Pro Enclosure Installation Instructions

18
1. Pull rear right cover latch out to the side
and hold in place.
2. Grab rear of cover and slide backwards 1 in.
3. Lift cover upward and off.
1U Enclosure (Top Cover Detached View)
1U Enclosure (Top Cover Removal)
19
20
Enclosure Cover Installation (2U and 4U)
1
23
LightVerse®Pro Enclosure Installation Instructions

21
22 1U Enclosure (Top Cover Re-attach View)
1. Lay cover on top of
enclosure so that the right
rear cover latch looks as
shown above.
2. Side tabs on the rear of the
left and right side of the cover
should look as shown above.
3. With the cover laying in
position on top of the enclosure,
push forward with equal
pressure on the left and right
side of the cover until the cover
latch locks the cover in place.
1U Enclosure Top Cover Re-Install
2
3
23
To access the label holder:
1. Pull the center tab of the red label
holder located under the front door as
shown. Do NOT pull label holder out
with door open.
2. Bend the label holder down to view The label holder can also be accessed
with the fiber tray pulled out to the
jumper access position.
1
1
LightVerse®Pro Enclosure Installation Instructions
2
Enclosure (Label Holder Access)

The internal tray can be completely removed from the
front or rear of the enclosure.
Quarter round fiber managers
can be used to create 4 individual
corners (as shown in Step 26), 2
half circles or 1 complete circle
ring (shown below).
Note: With Plug and Play
modules and splice cassettes,
not all fiber management
positions will be usable.
Quarter round fiber managers lock into
position on the internal tray by sliding
the tab under the lances until the lock
pin engages into the hole in the tray.
To remove: 1. lift bottom manager and
2. slide out.
1
2
Quarter round fiber
managers lance
positions shown.
Note: The center
positions should not be
used if using splice trays.
24 25
26
When used, splice tray(s)
should be positioned in the
center of the fiber storage
platform as shown. Secure
the tray(s) to the floor of the
fiber storage tray using the
Velcro strap and lance points
as shown.
When managing
large volumes of
fiber, Velcro
loops may
alternatively be
used in lance
points as shown.
27 28
Note: If using only one splice tray Velcro dots included with
the enclosure can be used to stabilize the tray in
conjunction with the strap shown above. Dots should be
placed as shown on the underside of the tray.
LightVerse®Pro Enclosure Installation Instructions

Quarter Round Fiber Manager (Mounting Examples)
Fiber Management examples with adapter plates/modules/cassettes
32 33
If the guided fiber management brackets on
the fiber entry point (either left or right) are
not being used the bracket slot blank should
be in place.
To remove the blank, place small flat head
screwdriver into the slot in the blank as
shown. Leverage screwdriver forward to
slide blank forward.
Completely slide blank back and remove
from slot.
31
29
30
LightVerse®Pro Enclosure Installation Instructions

If the cable slack for forward
jumper motion is stored
outside the 2U and
4U enclosures, the cable can
be secured to the rear cable
securing plate (located
closest to the fiber entrance)
at the rear of the enclosure
and a loop of 1-2 feet should
be left outside the enclosure
in vertical pathway as shown.
Note: The 1U enclosure has
an integrated center cable
securing plate.
37
If the cable slack for forward jumper
motion is stored inside the 2U and
4U enclosures, the externally
mounted rear fiber management
bracket should be used in
conjunction with the internally
mounted rear cable securing plate
as shown. Slack should be enough
to reach first jumper position when
tray is moved forward. 1. Secure
fiber to internal rear cable mounting
plate. 2. Pull tray forward to jumper
position. 3. Secure fiber to external
guided fiber management bracket
and return tray to storage position.
Note: The 1U enclosure has
an integrated center cable
securing plate.
38
When using an internal jumper slack bend,
mount the rear fiber management bracket
on the side of the fiber entry (left or right).
Align the bracket with the mounting
channel on the enclosure.
Push the bracket forward until it locks into
place. The release tab on the bracket may
be depressed to ease entry force.
34 35 36
3
1
2
LightVerse®Pro Enclosure Installation Instructions

39
If the sliding tray is to be pulled out the back with jumpers installed, it is necessary to remove them from the jumper management guides and
route forward as shown, to allow for the tray to retract without damaging the jumpers.
When rear access to the enclosure is
necessary after the inbound fiber(s) have
been secured to the rear fiber management
bracket, disengage the bracket by
depressing the release tab.
While taking hold of both the fiber and the
bracket, slide bracket backwards with the
tray movement to gain access to the back of
the rear of the enclosure.
When returning the fiber tray to storage
position, re-engage the bracket in its slot
and push forward to lock position.
40 41 42
Cable may also be routed directly out the rear of the enclosure. If this option is utilized, the rear door must be removed to allow cable exit.
43
LightVerse®Pro Enclosure Installation Instructions

LightVerse®Pro Enclosure Installation Instructions
To engage the tamper resistant latch,
insert key as shown.
Push key in to engage the latch. Remove key by pulling key straight back.
Door with tamper
resistant latch
disengaged
44
45 46 47
1
2
To disengage the tamper resistant latch,
insert key as shown.
1
2
Rotate key to horizontal orientation
and pull back to disengage the latch.
Rotate key back to vertical orientation
and pull back to remove key.
48 49 50
Key may be stored onto side of rear door.
Rear Door
Door with tamper
resistant latch
engaged

LightVerse®Pro Enclosure Installation Instructions
©2022 Siemon Rev. C 0922 100.28081.00
Attach recommended Laser Safety labels onto either the left or right side of the front and rear doors as shown.
51
Global Headquarters
Watertown, Connecticut USA
Tel: [phone]
For a complete listing of our global offices, please visit our website.
To ensure you have the latest
revision to this document, please visit: www.siemon.com
To assist safe installations, comply with the following:
A. Use caution when installing or modifying telecommunications circuits.
B. Never touch uninsulated wire terminals unless the circuit has been disconnected.
C. Never install this device in a wet location.
D. Never install wiring during a lightning storm.
Lors de l'installation, respectez les consignes de sécurité suivantes:
A. Utiliser avec prudence lors de l'installation ou de la modification circuits de
télécommunications.
B. Ne jamais toucher les bornes de fil métallique non isolés sauf si le circuit a été débranché.
C. Ne jamais installer cet appareil dans un endroit humide.
D. Ne jamais installer pendant un orage.
