Sig Sauer ZULU User manual

BINOCULARS
ZULU™
OWNERS MANUAL
ELECTRO-OPTICS
ZULU3™ shown

23
sigoptics.com
INTRODUCTION
ZULU Binoculars utilize category-leading features like high quality glass, fully multi-coated lenses and
phase coated prisms to provide maximum brightness, contrast and optimal resolution. The rugged design
pairs well with the lightweight construction to offer a high level of durability that isn’t reflected in weight.
Fully sealed barrels are nitrogen filled for waterproof and fog-proof performance. Stealth deflection
armor provides a durable surface that deflects light in a manner to keep you concealed from your prey.
The ZULU is covered by the SIG SAUER Electro-Optics Infinite Guarantee.
TABLE OF CONTENTS
This manual is available in the following languages: French, Spanish, German, Italian, Portuguese,
Russian, Afrikaans, Swedish, and Norwegian. Please visit sigoptics.com for Owners Manual downloads.
Introduction..............................................3
Contents ................................................4
Key Features .............................................4
Product Identification ......................................6
Operation ...............................................8
Interpupillary distance of binoculars .........................10
Cleaning ...............................................11
Specifications ...........................................12
SIG SAUER®Electro-Optics Infinite Guarantee™ ................16

45
sigoptics.com
ZULU9™
• Close bridge design
• Phase coated Abbe-Koenig prisms
• HDX (ED High Definition & HT High
Transmittance) glass
• LENSHIELD oleophobic lens coating
• Magnesium housing
• Tripod mount compatible
ZULU7™
• Open bridge design
• SHR Phase coated BAK4 Prisms
• HDX (ED High Definition & HT High
Transmittance) glass
• LENSHIELD oleophobic lens coating
• Tripod mount compatible (15x56mm model
includes tripod adaptor)
ZULU5™
• Close bridge design
• SHR Phase coated BAK4 Prisms
• HD High Definition Glass
• Tripod mount compatible
ZULU3™
• Open bridge design
• SHR Phase coated BAK4 Prisms
• LD Low Dispersion Glass
CONTENTS:
• ZULU Binocular
• Eyepiece and Objective Lens Covers
• Deluxe Neck/Shoulder Strap
• Lens Cloth
• Premium Padded Ballistic Nylon Case
KEY FEATURES:
• SPECTRACOAT™ broadband anti-reflection lens coatings
• LENSARMOR™ abrasion resistant lens coatings
• STEALTH ID™ rubber deflection armor
• Nitrogen filled for waterproof and fog proof performance (IPX-7 rated for complete water immersion up
to 1 meter)
• Multi-position eye-cups
• Eyepiece and objective lens covers, deluxe neck / shoulder strap, lens cloth, and premium ballistic
nylon case

67
sigoptics.com
PRODUCT IDENTIFICATION:
A- Eye Lens
B- Diopter Ring
C- Dataplate (model, magnification, FOV)
D- Focus Wheel
E- Strap Attachment
F- Objective Lens
G- Tripod Adapter Cover (select models)
A
B
D
E
F
C
E
GZULU7™ shown

89
sigoptics.com
OPERATION
SETTING THE DIOPTER ADJUSTMENT
Setting the diopter adjustment of your binocular properly is very important, as properly adjusted
binoculars will prevent eye strain and provide you with a crisp, sharp image.
To set the diopter adjustment on right eyepiece diopter adjustment models:
1. View an object about 100 yards in the distance.
2. Cover the right objective lens with your hand.
4. Cover the left objective lens with your hand.
5. Adjust the diopter adjustment dial located around the right
barrel, near the eyepiece, until the image presented to your right
eye is clear and sharp.
Your binocular is now focused for your eyesight. To make any
adjustments in the field, simply turn the center focus dial while
viewing through both barrels.
Twist-up Eyecups
SIG SAUER binoculars feature eyecups you can twist, or push up
and down to accommodate the eye relief distance required when
wearing eyeglasses.
3. Adjust the center focus wheel (located between the two
barrels) until the image presented to your left eye is clear and
sharp.

10 11
sigoptics.com
Interpupillary distance of binoculars
Interpupillary distance means interocular distances between the right and left eyes.
1. Set the distance between the centers of the right and left ocular lenses of the binoculars to your
Interpupillary distance.
2. Look at a distant object to make an adjustment while folding back the main body of the binoculars.
3. Your Interpupillary distance is correctly set when the field of view can be seen by both eyes as a single
circle (see illustration)
CLEANING
• You can clean the fully armored body by simply wiping off any accumulated dirt or dust.
• Clean the lenses as you would a camera lens.
• Use a standard lens brush to remove dust and then pure alcohol, high-grade glass cleaner, or pure
water on a cotton swab.
Interpupillary distance
is not appropriately set
Shade
Interpupillary distance
is appropriately set
Field of view

12 13
sigoptics.com
ZULU3 SPECIFICATIONS
Model/Magnification 8x32mm 10x32mm
Eye Relief 14.5mm 14.5mm
Exit Pupil 4.0mm 3.2mm
Linear FOV FT at 1000 yards 393 ft 341 ft
Linear FOV M at 1000 M 131 m 114 m
Objective Clear Aperture 32mm 32mm
Angular FOV 7.5 degrees 6.5 degrees
Close Focus Distance 8.2 ft 8.2 ft
Interpupillary distance Distance 56mm - 74mm 56mm - 74mm
Diopter Range +/- 3 +/- 3
Weight 397g / 14oz 454g / 16oz
Length 5.5 in / 139.7mm 5.5 in / 139.7mm
ZULU5 SPECIFICATIONS
Model/Magnification 8x42mm 10x42mm
Eye Relief 17mm 15mm
Exit Pupil 5.3mm 4.2mm
Linear FOV FT at 1000 yards 393 ft 315 ft
Linear FOV M at 1000 M 131 m 105 m
Objective Clear Aperture 42mm 42mm
Angular FOV 7.5 degrees 6.0 degrees
Close Focus Distance 6.5 ft 8.2 ft
Interpupillary distance Distance 56mm - 74mm 56mm - 74mm
Diopter Range +/- 4 +/- 4
Weight 694.5g / 24.5oz 694.5g / 24.5oz
Length 6 in / 152.4mm 6 in / 152.4mm

14 15
sigoptics.com
ZULU7 SPECIFICATIONS
Model/Magnification 8x32mm 10x42mm 15x56mm
Eye Relief 20mm 17mm 15.5mm
Exit Pupil 5.3mm 4.2mm 3.7mm
Linear FOV FT at 1000 yards 378 ft 341 ft 225 ft
Linear FOV M at 1000 M 126 m 114 m 75 m
Objective Clear Aperture 42mm 42mm 56mm
Angular FOV 7.2 degrees 6.5 degrees 4.3 degrees
Close Focus Distance 5.9 ft 5.9 ft 13 ft
Interpupillary distance
Distance
56mm - 74mm 56mm - 74mm 60mm - 76mm
Diopter Range +/- 3 +/- 3 +/- 4
Weight 950g / 33oz 950g / 33oz 1,191g / 42oz
Length 5.8 in / 147.3mm 5.8 in / 147.3mm 7 in / 177.8mm
ZULU9 SPECIFICATIONS
Model/Magnification 9x45mm 11x45mm
Eye Relief 17.3mm 16.7mm
Exit Pupil 5.0mm 4.1mm
Linear FOV FT at 1000 yards 378 ft 315 ft
Linear FOV M at 1000 M 126 m 105 m
Objective Clear Aperture 45mm 45mm
Angular FOV 7.2 degrees 6.0 degrees
Close Focus Distance 6.0 ft 6.0 ft
Interpupillary distance Distance 56mm - 74mm 56mm - 74mm
Diopter Range +/- 3 +/- 3
Weight 950g / 33oz 950g / 33oz
Length 7.5 in / 190.5mm 7.5 in / 190.5mm

16 17
sigoptics.com
SIG SAUER Infinite Guarantee™
• Unlimited Lifetime Guarantee
• Fully Transferable
• No Warranty Card Required
• No Receipt Required
• No Time Limit Applies
• No Charge
If you ever have a problem, no matter the cause, we promise to take care of you when it counts.
Please note that our Infinite Guarantee does not provide coverage for intentional damage, misuse,
cosmetic damage that does not affect the performance of the optic, loss, theft or unauthorized repair or
modification. Excludes electronic components.
I
N
F
I
N
I
T
E
G
U
A
R
A
N
T
E
E
S
I
G
S
A
U
E
R
SIG SAUER Electro-Optics Infinite Guarantee™
SIG SAUER has manufactured the most rugged, dependable high-performance firearms
for over two centuries. Our heritage of design, engineering and precision-manufactured
quality predates the existence of any other optics company worldwide. We understand
the importance of quality in the line of fire, at the shooting range or on your next hunt.
SIG SAUER Electro-Optics had to earn the right to wear that badge and the Infinite
Guarantee has your back, forever. Period.
We will repair or replace your SIG SAUER product in the event it becomes damaged or defective, at no
charge to you. If we cannot repair your product, we will replace it with a product in perfect working order
of equal or better physical condition. It doesn’t matter how it happened, whose fault it was, or where you
purchased it.

18 19
sigoptics.com
NOTES:

FOR PRODUCT SERVICE ON THIS MODEL, PLEASE CALL 603-610-3000
19861 SW 95th Avenue, Portland, OR 97062 USA
sigoptics.com
P/N 7400229-01 R00
