Signature Kitchen Suite UPFXC2466 Series User manual

ENGLISH FRANÇAIS ESPAÑOL
OWNER’S MANUAL
FRENCH DOOR REFRIGERATOR
Please read this owner's manual thoroughly before operating
and keep it handy for reference at all times.
UPFXC2466*
Copyright © 2015 - 2017 Signature Kitchen Suite. All Rights Reserved.
www.signaturekitchensuite.com
MFL68507671_Rev.06

2TABLE OF CONTENTS
TABLE OF CONTENTS
3 PRODUCT FEATURES
4 IMPORTANT SAFETY INSTRUCTIONS
7 PRODUCT OVERVIEW
7 Refrigerator Exterior
8 Refrigerator Interior
9 INSTALLATION
9 Installation Overview
9 Product Specifications
10 Unpacking the Refrigerator
10 Choosing the Proper Location
11 Measuring Clearances
11 Removing/Assembling the Refrigerator Door
Handles
12 Removing/Assembling the Freezer Drawer
Handle
12 Removing/Assembling the Doors and
Drawers
13 Removing the Left Refrigerator Door
14 Removing the Right Refrigerator Door
15 Assembling the Right Refrigerator Door
16 Assembling the Left Refrigerator Door
17 Removing the Freezer Drawers
19 Assembling the Freezer Drawers
20 Connecting the Water Line
20 Before You Begin
20 Water Pressure
20 What You Will Need
21 Water Line Installation Instructions
23 Turning On the Power
24 Leveling and Door Alignment
24 Leveling
24 Door Alignment
25 OPERATION
25 Before Use
26 Control Panel
26 Control Panel Features
29 In-Door Ice Bin
29 Detaching the In-Door Ice Bin
29 Assembling the In-Door Ice Bin
30 Automatic Icemaker
30 Turning the Automatic Icemaker On or Off
31 When to Turn the Icemaker Off
31 Normal Sounds You May Hear
31 Preparing for Vacation
32 Operating the Dispenser
33 Ice and Water Dispenser
33 Dispenser
33 Using the Dispenser
33 Locking the Dispenser
33 Cleaning the Dispenser Stand
34 Storing Food
34 Food Preservation Location
35 Food Storage Tips
35 Storing Frozen Food
36 Humidity Controlled Crisper and
Glide’N’Serve
37 Detaching and Assembling the Storage Bins
38 Door-in-Door
40 Adjusting the Refrigerator Shelves
41 SMART FUNTIONS
41 SIGNATURE KITCHEN SUITE Application
43 Smart Grid Function
45 Smart Diagnosis™ Function
46 MAINTENANCE
46 Cleaning
47 Replacing the Fresh Air Filter
47 Replacing the Water Filter
52 TROUBLESHOOTING
62 LIMITED WARRANTY

3
PRODUCT FEATURES
ENGLISH
PRODUCT FEATURES
* Depending on the model, some of the following functions may not be available.
FILTERED WATER AND ICE DISPENSER
The water dispenser dispenses fresh, chilled water.
The ice dispenser dispenses cubed and crushed ice.
DOOR ALARM
The Door Alarm function is designed to prevent the refrigerator from
malfunctioning if a refrigerator door or freezer drawer remains open. If a
refrigerator door or freezer drawer is left open for more than 60 seconds, a
warning alarm sounds at 30-second intervals.
HUMIDITY CONTROLLED CRISPER
The Humidity Controlled Crisper is designed to help keep fruits and
vegetables fresh and crisp. Control the amount of humidity in the crisper by
adjusting the setting between Low and High.
GLIDE‘N’SERVE
Glide‘N’Serve provides storage space with a variable temperature control
that keeps the compartment colder than the refrigerator. It is a convenient
place to store sandwiches or meat to be cooked.
AUTO CLOSING HINGE
The refrigerator doors and freezer drawers close automatically with a slight
push. (The door only closes automatically when it is open at an angle less
than 30°.)
ICE PLUS
Ice production can be increased by approximately 20 percent when the
freezer section is maintained at the coldest temperature for a 24-hour
period.

4IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.
This guide contains many important safety messages. Always read and obey all safety messages.
WARNING
To reduce the risk of fire, electric shock, or personal injury when using your product, basic safety
precautions should be followed, including the following:
Power
yNEVER unplug the refrigerator by pulling on the
power cord. Always grip the plug firmly and pull
it straight out from the outlet.
yIf the supply cord is damaged, it must be
replaced by the manufacturer or its service
agent or a similarly qualified person in order to
avoid a hazard. Do not use a cord that shows
cracks or abrasion damage along its length or at
either the plug or connector end.
yDo not use an uncertified power outlet.
yUnplug the power plug immediately in the
event of a blackout or thunderstorm.
yPlug in the power plug with the power cord
facing downward.
Installation
yContact an authorized service center before you
install or relocate the refrigerator.
yWhen moving your refrigerator away from the
wall, be careful not to roll over or damage the
power cord.
yPrior to use, ensure that you are connecting
this product to a dedicated, grounded electrical
outlet rated for use with this product (115V,
60Hz, AC only). It is the user’s responsibility to
replace a standard 2-prong wall outlet with a
standard 3-prong wall outlet.
yDo not install the refrigerator where there may
be a danger of the unit falling.
Use
yDO NOT allow children to climb, stand, or hang
on the refrigerator doors or on the shelves
in the refrigerator. They could damage the
refrigerator and seriously injure themselves.
yDo not hang on to or place heavy objects on the
refrigerator’s dispenser.
yDo not place heavy or dangerous objects (bottles
with liquid) on the refrigerator.
yDo not put live animals inside the refrigerator.
yDo not allow children to climb into the product
when it is in use.
yIn the event of a gas leak (propane/LPG), ensure
adequate ventilation and contact an authorized
service center before resuming use. Do not
touch or disassemble the electric outlet of the
refrigerator.
yIn the event of a refrigerant leak, move
flammable objects away from the refrigerator.
Ensure adequate ventilation and contact an
authorized service center.
yDo not use or place flammable substances
(chemicals, medicine, cosmetics, etc) near the
refrigerator or store them inside the refrigerator.
Do not place the refrigerator in the vicinity of
flammable gas.
yDo not overfill or pack items too tightly into
door bins. Doing so may cause damage to the
bin or personal injury if items are removed with
excessive force.
WARNING You can be killed or seriously injured if you do not follow instructions.
CAUTION
Indicates an imminently hazardous situation which, if not avoided, may result
in minor or moderate injury, or product damage.
This is the safety alert symbol. It alerts you to safety messages that inform you of
hazards that can kill or hurt you or others, or cause damage to the product.
All safety messages will be preceded by the safety alert symbol and the hazard
signal word WARNING or CAUTION. These words mean:

5
IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
yThis product is not to be used for special
purposes such as the storage of medicine or
test materials or for use on ships, etc.
yUnplug the power plug before cleaning or
repairing the refrigerator.
yWhen you replace the light bulb in the
refrigerator, unplug the refrigerator or turn off
the power.
yDo not modify or extend the power cord.
yDo not use a dryer to dry the interior. Do not
light a candle to remove interior odors.
yFor your safety, this appliance must be properly
grounded. Have the wall outlet and the circuit
checked by a qualified electrician to make sure
the outlet is properly grounded.
yDo not use an outlet that can be turned off
with a switch. Do not use an extension cord. It
is the user’s responsibility to replace a standard
2-prong wall outlet with a standard 3-prong wall
outlet.
yDo not, under any circumstances, cut or
remove the third (ground) prong from the
power cord.
yDo not use an adapter plug and plug the power
plug into a multi-outlet extension cord.
yDisconnect the power cord immediately if you
hear a noise, smell a strange odor or detect
smoke coming from the appliance.
yTurn the power off if water or dust penetrates
into the refrigerator. Call a service agent.
yDo not disassemble or modify the refrigerator.
yDo not put hands, feet, or metal objects below
or behind the refrigerator.
yDo not operate the refrigerator or touch the
power cord with wet hands.
yIn refrigerators with automatic icemakers, avoid
contact with the moving parts of the ejector
mechanism or with the heating element that
releases the cubes. Do not place fingers or
hands on the automatic ice-making mechanism
while the refrigerator is plugged in.
yWhen dispensing ice from the dispenser, do
not use crystal ceramics.
yDo not touch the cold surfaces in the freezer
compartment with wet or damp hands, when
your refrigerator is in operation.
yDo not put glass containers, glass bottles or
soda in the freezer.
yThis appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they
have been given supervision or instruction
concerning the use of the appliance by a
person responsible for their safety.
yDo not refreeze frozen food that has thawed
completely. Doing so may result in a serious
health issue.
yIf you are throwing away your old refrigerator,
make sure the CFC coolant is removed for
proper disposal by a qualified servicer. If you
release CFC coolant, you may be fined or
imprisoned in accordance with the relevant
environmental law.
yJunked or abandoned refrigerators are
dangerous, even if they are sitting for only a
few days. When disposing of the refrigerator,
remove the packing materials from the door
or take off the doors but leave the shelves
in place so that children may not easily climb
inside.
yIf connected to a circuit protected by fuses,
use time delay fuse.
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.
WARNING
This product contains chemicals known to the State of California to cause cancer and birth defects
or other reproductive harm.
Wash hands after handling.
To reduce the risk of fire, electric shock, or personal injury when using your product, basic safety
precautions should be followed, including the following:

6IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
CAUTION
Installation
yThe refrigerator must be properly installed
in accordance with the Installer Instructions
that were taped to the front of the
refrigerator.
yBe careful when you unpack and install the
refrigerator. Immediately dispose of plastic
and other packing materials out of reach of
children.
yThe appliance must be positioned for easy
access to a power source.
Use
yClose the door carefully when children are
around.
yKeep fingers out of pinch point areas;
clearances between the doors and cabinets
are necessarily small. Be careful closing
doors when children are nearby.
yIf you store food improperly, be aware that it
may fall and cause injury.
yDo not use aerosols near the refrigerator.
yDo not store articles on the top of the
appliance.
Maintenance
yDo not use strong detergents like wax or
thinners for cleaning. Clean with a soft cloth.
yWipe foreign objects (such as dust and
water) off the prongs of the power plug and
contact areas regularly.
yDo not store, disassemble or repair the
refrigerator by yourself.
yRemove any dust or foreign matter from the
power plug pins.
yDo not use a wet or damp cloth when
cleaning the plug.
yIf the refrigerator is disconnected from the
power supply, you should wait for at least
five minutes before plugging it back in.
yIf you notice a chemical or burning plastic
smell or see smoke, unplug the refrigerator
immediately and contact your Signature
Kitchen Suite Service Center.
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.
To reduce the risk of fire, electric shock, or personal injury when using your product, basic safety
precautions should be followed, including the following:

7
PRODUCT OVERVIEW
ENGLISH
PRODUCT OVERVIEW
Use this page to become more familiar with the parts and features of your refrigerator.
*The appearance and specifications of the actual product may differ depending on the model.
Refrigerator Exterior
Filtered Water and
Ice Dispenser
Dispenses purified water and ice.
LED Display
Displays the refrigerator and
freezer temperature, the water
filter condition and the dispenser
status.
Control Panel
Sets the refrigerator and freezer
temperatures, the water filter
condition and the dispenser mode.
Refrigerator
Freezer
Ez Handle
Easily opens the freezer
door.
LED Light
LED lights up when the
freezer door is opened.
Button
Opens the Door-in-Door
compartment
Handle
Opens and closes
the door.

8PRODUCT OVERVIEW
Refrigerator Interior
Water filter
Purifies water.
NOTE
Replace the water filter every 6 months, or
as needed. See Replacing the Filter in this
manual for details.
* (Water filter is only
available on some
models.)
Indoor Ice Bin
Ice cubes are
automatically produced.
Crisper
Controls humidity and
helps vegetables and
fruit to stay crisp.
Auto Closing Hinge
The refrigerator doors
and freezer drawers close
automatically when pushed
slightly.
(The door only closes
automatically when it is open
at an angle of less than 30°.)
Fixed Door Bin
Used to preserve
chilled food or drinks.
Durabase® and Durabase® Divider
The Durabase is a storage space
recommended for the preservation of
large food items. The Durabase Divider is
used to organize the Durabase area into
sections. It can be adjusted from side to
side to accommodate items of different
sizes.
Glide‘N’Serve
Store food items at a
different temperature than
the regular refrigerator
area.
Pullout Drawers
Used for extra storage
within the freezer
compartment.
LED interior lamps
The interior lamps light up the
inside of the refrigerator.
Door-in-Door Case
A convenient storage area for
frequently-used items that require
easy access.
Adjustable Refrigerator Shelf
The shelves in the refrigerator are
adjustable to meet individual storage
needs.
Cheese & Butter Bin
Cheese & Butter and
Condiment bins, that
are specially designed
for these items, making
spreading butter and
slicing cheese easier.
Condiment Bin

9
INSTALLATION
ENGLISH
INSTALLATION
Installation Overview
Read the following installation instructions first after purchasing this product or transporting it to
another location.
1 Unpacking your
refrigerator
2 Choosing the proper
location
3 Disassembling/Assembling
4 Connecting the water
supply and water line
5 Leveling and Door
Alignment
NOTE
Connect to potable water supply
only.
Product Specifications
The appearance and specifications listed in this manual may vary due to constant product
improvements.
Models UPFXC2466*
Description French door refrigerator
Electrical requirements 115 VAC @ 60 Hz
Min. / Max. Water pressure 20 – 120 psi (138 – 827 kPa)
Dimensions
35 3/4” (W) X 30 7/8” (D) X 70 1/4” (H), 42 3/4” (D w/ door open)
908 mm (W) X 785 mm (D) X 1785 mm (H), 1085 mm (D w/ door open)
Net weight 328 lb. (149 kg)

10 INSTALLATION
Unpacking the Refrigerator
Choosing the Proper Location
WARNING
yUse two or more people to move and
install the refrigerator. Failure to do so
can result in back or other injury.
yYour refrigerator is heavy. When moving
the refrigerator for cleaning or service,
be sure to protect the floor. Always pull
the refrigerator straight out when moving
it. Do not wiggle or walk the refrigerator
when trying to move it, as floor damage
could occur.
yKeep flammable materials and vapors,
such as gasoline, away from the
refrigerator. Failure to do so can result in
fire, explosion, or death.
yRemove tape and any temporary labels from
your refrigerator before using.
Do not remove any warning labels, the model
and serial number label, or the Tech Sheet that
is located under the front of the refrigerator.
yTo remove any remaining tape or glue, rub
the area briskly with your thumb.
Tape or glue residue can also be easily removed
by rubbing a small amount of liquid dish soap
over the adhesive with your fingers. Wipe with
warm water and dry.
yDo not use sharp instruments, rubbing
alcohol, flammable fluids, or abrasive
cleaners to remove tape or glue.
These products can damage the surface of your
refrigerator.
yReinstall or adjust shelves as needed.
Refrigerator shelves are installed in the shipping
position. Reinstall shelves according to your
individual storage needs.
Water Water supply must be easily connected for the automatic icemaker.
Water pressure 20–120 psi on models without water filter. 40–120 psi on models with
water filter.
Electricity Use an individual, grounded outlet:115 Volts, 60 Hz, AC, 15 Amps
minimum.
WARNING: Do not overload house wiring and cause a fire
hazard by plugging in multiple appliances in the same outlet
with the refrigerator. To reduce the risk of electric shock, do
not install the refrigerator in a wet or damp area.
Floor Floor must be level and solidly constructed. Adjust the leveling legs to
compensate for any unevenness in the floor. Do not install on carpeting,
soft tile, a platform, or a weakly supported structure.
Ambient
temperature
Temperature must be between 55°F (13°C) and 110°F (43°C). If the
ambient temperature is too low or high, performance may be affected.
Clearances Allow at least 24 in. (61 cm) in front to open the doors. Allow at least
2 in. (5.08 cm) between the back of the refrigerator and the wall. If the
refrigerator is too close to adjacent items, freezing capability may decrease
and electricity consumption may increase.

11
INSTALLATION
ENGLISH
Removing the Handles
1Loosen the set screws with a 3/32 in.
Allen wrench and remove the handle.
2Loosen the mounting fasteners that
connect to the refrigerator
door and handle using
a 1/4in. Allen wrench, and
remove the mounting
fasteners.
Measuring Clearances
yCheck the dimensions of the product and the
installation path to ensure there is sufficient
room to move the refrigerator through doors
or narrow openings.
yIf an opening is too narrow to fit the
refrigerator through, remove the refrigerator
doors. See Removing/Assembling the Doors
and Drawers in this manual.
yThe installation location chosen for the
refrigerator should allow space behind the
unit for connections and airflow and space in
front to open the doors and drawers.
2” (5.08 cm)
24” (61 cm)
Removing/Assembling the
Refrigerator Door Handles
Tools Needed
3/32 in. Allen wrench
¼ in. Allen wrench
Assembling the Handles
1Assemble the mounting fasteners at
both ends of the handle using a 1/4in.
Allen wrench.
2Place the handle on the door by fitting
the handle footprints over the mounting
fasteners and
tightening
the set
screws
with a 3/32 in.
Allen wrench.
NOTE
When it is necessary to move the
refrigerator through a narrow opening,
removing the doors is the recommended
procedure. If it is necessary to remove
the handles, follow the directions below.

12 INSTALLATION
Tools Needed
Flat-head screwdriver
10 mm or 13/32 in. socket wrench
Phillips screwdriver
Removing/Assembling the
Freezer Drawer Handle
Removing the Handles
1Loosen the set screws located on the
lower side of the handle with a 1/8in. Allen
wrench and remove the handle.
2Loosen the mounting fasteners that
connect to the
freezer drawer
and handle
using a 1/4in.
Allen wrench,
and remove
the mounting
fasteners.
Assembling the Handles
1Assemble the mounting fasteners at
both ends of the handle using a 1/4in. Allen
wrench.
2Place the handle on the door by fitting
the handle
footprints over
the mounting
fasteners and
tightening the
set screws
with a 1/8in.
Allen wrench.
WARNING
yIf your entrance door is too narrow for the
refrigerator to pass through, remove the
refrigerator doors and move the refrigerator
sideways through the doorway.
yUse two or more people to remove and
install the refrigerator doors. Failure to do
so can result in back or other injury.
yDisconnect the electrical supply to the
refrigerator before installing. Failure to do
so could result in serious injury or death.
yDo not put hands, feet or other objects into
the air vents or bottom of the refrigerator.
You may be injured or receive an electrical
shock.
yBe careful when handling the hinge and
stopper, to avoid injury.
yRemove food and bins before detaching the
doors and drawers.
Removing/Assembling the
Doors and Drawers
When it is necessary to move the refrigerator
through a narrow opening, removing the doors
is the recommended procedure.
WARNING
When assembling or disassembling the
handle:
yGrasp the handle tightly to avoid dropping it.
yDo not swing the handle into nearby people
or animals.
yMake sure that the bracket hole of the
handle fits properly into the stopper bolt of
the door. Assemble the set screws to fix
the handle into place.
yMake sure that there is not a gap between
the door and handle after assembling the
handle.

13
INSTALLATION
ENGLISH
2Remove the screw from the hinge cover
at the top of the refrigerator. Lift the hook
(not visible), located at the bottom of the
front side of the cover with a flat-head
screwdriver.
3Remove the cover and pull out the tube .
Disconnect all wire harnesses .
4Rotate the hinge lever counterclockwise
. Lift the top hinge free of the hinge
lever latch.
CAUTION
When lifting the hinge free of the latch, be
careful that the door does not fall forward.
Hinge Lever Latch
5Lift the door from the middle hinge pin and
remove the door.
CAUTION
Place the door, inside facing up, on a
non-scratching surface.
Removing the Left Refrigerator Door
1The water supply is connected to the
upper right part of the rear surface of the
refrigerator. Remove the ring in the joint
area. Hold the water supply connection
and gently push the Collet to detach the
water supply line as shown in and .
NOTE
Detachment of the water supply line is
applicable only when detaching the left
refrigerator door.
Collet

14 INSTALLATION
Removing the Right Refrigerator
Door
1Remove the top hinge cover screw .
Lift the hook (not visible), located at the
bottom of the front side of the cover ,
with a flat-head screwdriver.
2Detach the wire harness .
CAUTION
When lifting the hinge free of the hinge
lever latch, be careful that the door
does not fall forward.
Hinge Lever Latch
3Rotate the hinge lever clockwise.
Lift the top hinge free of the hinge
lever latch.
4Lift the door from the middle hinge pin and
remove the door.
CAUTION
Place the door on the floor, inside
facing up, on a non-scratching surface.

15
INSTALLATION
ENGLISH
Install the right-side door first.
1Make sure that the plastic sleeve is
inserted in the bottom of the door. Lower
the door onto the middle hinge pin as
shown in the figure.
2Fit the hinge over the hinge lever latch
and slot it into place. Rotate the lever
counterclockwise to secure the hinge.
Assembling the Right Refrigerator Door
Hinge Lever Latch
4Make sure that the door-switch located
inside the cover is tightly connected.
Position the cover in its place. Insert and
tighten the cover screw .
3Connect the wire harness .

16 INSTALLATION
Assembling the Left Refrigerator
Door
Install the left refrigerator door after the right
door is installed.
1Make sure that the plastic sleeve is
inserted in the bottom of the door. Install
the refrigerator door onto the middle hinge.
2Fit the hinge over the hinge lever latch
and slot it into place. Rotate the lever
clockwise and fasten the hinge.
3Connect all the wire harnesses.
Hinge Lever Latch
4Push the water supply tube into the hole
on the top case and pull it through the
backplate.
5Hold the water supply connection and
gently push in the collet to connect the
water supply line as shown in and .
Insert the tube at least 5/8inch (15 mm) into
the connector. Assemble the clip to the
joint part for fastening.
6Make sure that the door-switch located
inside the cover is tightly connected. Place
the cover in its position and tighten the
cover screw .
Collet

17
INSTALLATION
ENGLISH
CAUTION
yUse two or more people to remove and
install the freezer drawer. Failure to do so
can result in back injury or other injury.
yDo not hold the handle when removing
or replacing the drawer. The handle may
come off, resulting in personal injury.
yBe careful of sharp hinges on both sides
of the drawer.
yWhen you lay the drawer down, be
careful not to damage the floor.
yDo not sit or stand on the freezer drawer.
yTo prevent accidents, keep children
and pets away from the drawer. Do not
leave the drawer open. If the Durabase
®
storage bin is removed from the freezer
drawer, there is sufficient space for a
small child or pet to crawl inside.
NOTE
1) Gently press the collet and insert the
tube until only one line shows on the
tube.
(Correct)
(Incorrect)
2) Pull the tube to make sure that the
tube is tightly fastened and then insert
the clip.
Removing the Freezer Drawers
In the following figures, the Pullout Drawers
located above the freezer drawer are not
shown for clarity.
Collet
Tube
Insert Line
Clip
(Durabase®)

18 INSTALLATION
2Pull the upper pullout drawer open to full
extension.
3Gently lift and pull out the ice bin.
On the left rail, use a flat blade screwdriver
to push in on the tab to release the drawer
from the rail, as shown below. Once the
left side is loose, push the tab on the right
side with your finger to release the drawer.
Lift the front of the drawer up, then pull it
straight out.
4
Remove the Durabase basket from the rail
assembly. Remove the screws from the rails
at both ends of the freezer drawer.
5
Grip both sides of the drawer and pull it up to
remove it from the rails.
6
Hold both rails and push them in
simultaneously.
CAUTION
Do not hold the handle when removing
or replacing the drawer. The handle may
come off, causing personal injury.
1Open the freezer drawer. Open the lower
pullout drawer, lift the front of the drawer,
and then pull the drawer out.

19
INSTALLATION
ENGLISH
4Insert the upper pullout drawer into the
frame, and push the drawer back into place
until you hear a click.
5Place the ice bin back in the upper pullout
drawer.
6Insert the lower pullout drawer in the rail
assembly.
Assembling the Freezer Drawers
1
Pull out both rails simultaneously, until both
rails are fully extended.
2
Grasp the freezer drawer on each side and
hook the drawer supports into the rail tabs
located on both sides.
CAUTION
Do not hold the handle when removing
or replacing the drawer. The handle
may come off, causing personal injury.
3Lower the door into its final position and
tighten the screws located on both sides.
Insert the Durabase basket in the rail
assembly.

20 INSTALLATION
CAUTION
Wear eye protection during installation
to prevent injury.
Connecting the Water Line
Before You Begin
This water line installation is not covered by the
refrigerator warranty. Follow these instructions
carefully to minimize the risk of expensive water
damage.
Water hammer (water banging in the pipes) in
house plumbing can cause damage to refrigerator
parts and can lead to water leakage or flooding.
Call a qualified plumber to correct water hammer
before installing the water supply line to the
refrigerator.
If you use your refrigerator before connecting
the water line, make sure the icemaker power
button is turned off.
Water Pressure
The water pressure must be between 20 and
120 psi. If the refrigerator is installed in an area
with low water pressure (below 20 psi), you can
install a booster pump to compensate for the low
pressure.
If a reverse osmosis water filtration system is
connected to your cold water supply, this water
line installation is not covered by the refrigerator
warranty. Follow the instructions carefully to
minimize the risk of expensive water damage.
If a reverse osmosis water filtration system is
connected to your cold water supply, the water
pressure to the reverse osmosis system needs
to be a minimum of 40 to 60 psi (276-414 kPa or
2.8-4.2 kgf/cm², less than 2-3 sec. to fill a cup of
7 oz or 198 cc capacity).
If the water pressure from the reverse osmosis
system is less than 20 psi or 138 kPa or 1.4 kgf/
cm² (takes more than 4 sec to fill a cup of 7 oz or
198 cc capacity):
yCheck to see if the sediment filter in
the reverse osmosis system is blocked.
Replace the filter if necessary.
yAllow the storage tank on the reverse
osmosis system to refill after heavy
usage.
yIf the issue concerning water pressure
from reverse osmosis remains, call a
licensed, qualified plumber.
yAll installations must be in accordance
with local plumbing code requirements.
What You Will Need
yCopper Tubing, ¼ in. outer diameter, to
connect the refrigerator to the water
supply. Be sure both ends of the tubing
are cut square.
yTo determine how
much tubing you need:
measure the distance
from the water valve on the back of
the refrigerator to the water supply
pipe. Then, add 8 feet (2.4 m). Be sure
there is sufficient extra tubing (about 8
feet [2.4 m] coiled into 3 turns of about
10 in. [25 cm] diameter) to allow the
refrigerator to move out from the wall
after installation.
yPower drill.
y½ in. or adjustable
wrench.
yFlat blade and Phillips
head screwdrivers.
yTwo ¼ in. outer
diameter compression
nuts and 2 ferrules (sleeves) to connect the
copper tubing to the shutoff valve and
the refrigerator water valve.
CAUTION
Do not install the icemaker tubing in
areas where temperatures fall below
freezing.
CAUTION
To prevent burns and product damage,
only connect the refrigerator water line to
a cold water supply.
