Gram KF 32295-63 N/1 User manual

KF 2330-00 N
KF 32295-63 N/1
EN User guide
DA Betjeningsvejledning
SV Bruksanvisning
NO Bruksanvisning
FI Käyttöohjeet

WARNING!
In order to ensure a normal operation of your fridge/freezing appliance, which uses a completely environmentally friendly
refrigerant the R600a (Flammable only under certain conditions) you must observe the following rules:
Do not hinder the free circulation of the air around the appliance.
Do not use mechanical devices in order to accelerate the defrosting, other than the ones recommended by the
manufacturer.
Do not destroy the refrigerating circuit.
Do not use electric appliances inside the food keeping compartment, other than those that might have been
recommended by the manufacturer.
ADVARSEL!
For at sikre en normal funktion af køle-/fryseskabet, der anvender et komplet miljøvenligt kølemiddel, R600a (Kun brændbar
under særlige forhold), skal du overholde følgende regler:
Undlad at hindre den frie luftcirkulation rundt om apparatet.
Der må ikke anvendes mekanisk udstyr, ud over det af producenten anbefalede, til at fremskynde afrimningsprocessen.
Undgå at beskadige kølekredsløbet.
Undlad at bruge elektrisk udstyr inde i rummet, hvor der opbevares mad, ud over de steder, som producenten evt. har
anbefalet.
VARNING!
För att säkerställa normal användning av kyl- och frysskåpet, som utnyttjar helt miljöanpassade kylmedlet R600a (Endast
antändbart under vissa förhållanden) måste du iaktta följande regler:
Hindra inte fri luftcirkulation runt kyl- och frysskåpet.
Använd inga mekaniska enheter för att påskynda avfrostningen, förutom det som rekommenderas av tillverkaren.
Skada inte kylningskretsen.
Använd inga elektriska enheter inuti matsignalsfacket, utöver det som rekommenderas av tillverkaren.
ADVARSEL!
For å sikre normal drift av kombiskapet, som bruker en fullstendig miljøvennlig kjølevæske – R600a (Kun antennelig under
bestemte forhold), må du overholde følgende regler:
Ikke blokker den frie luftsirkulasjonen rundt apparatet.
Ikke bruk mekanisk utstyr for å akselerere avisingsprosessen annet enn slikt utstyr som produsenten anbefaler.
Pass på så du ikke ødelegger kjølekretsen.
Ikke bruk elektriske apparater inne i de delene av skapet der du lagrer mat, såfremt de ikke er av en slik type som
produsenten anbefaler.
VAROITUS!
Laitteen kylmäaineena on ympäristöystävällinen R600a (syttyvää vain tietyissä olosuhteissa). Jotta laite toimisi
normaalisti, on noudatettava seuraavia ohjeita:
Älä estä ilman vapaata kiertoa laitteen ympäri.
Älä käytä mekaanisia välineitä sulatuksen nopeuttamiseen, paitsi sellaisia, joita valmistaja suosittelee.
Älä vahingoita jäähdytyspiiriä.
Älä käytä ruokalokeroiden sisällä sähkölaitteita, jollei valmistaja niin suosittele.

EN Index
Safety first /1
Electrical require
ments /2
Transportation instructions /2
Installation instructions /2
Getting to know your appliance /
2
Suggested arrangement of food in the appliance /
2
Temperature control and adjustment /3
Before operating /3
Storing frozen food /
3
Freezing fresh food /
3
Making ice cubes /4
Defrosting /4
How to reposition the doors
/4
Replacing the interior light bulb /
4
Cleaning and care /
4
Do’s and Don’ts /
4
Energy consumption /
5
Inf
ormation concerning the noise /5
Troubleshootin
g /5
Vigtige sikkerhedsanvisninger /
6
K
rav til el-installationen /7
Transportvejledning /
7
Installationsvejledning /
7
Dus med dit apparat /
7
Forslag til pla
cering af madvarer i apparatet /7
Tem
peraturkontrol og –regulering /8
Før ibrugtagning
/8
Opbe
varing af frostvarer /8
Frysning af friske ma
dvarer /8
Fremstilling af isterninger /
9
Afrimning /
9
Sådan vender du dørene
/9
Udski
ftning af den indvendige pære /9
Rengøring og vedligeholdelse /
9
Husk at, og
Undlad at /9
Energiklasse /1
0
Informat
ion om støj /10
Fejlfinding /1
0
Säkerheten först /1
1
E
lektriska krav /12
Transportinstruktioner /1
2
Installationsinstruktioner /1
2
Lär känna din enhet /1
2
Förslag p
å placering av maten i enheten /12
Te
mperaturkontroll och justering /13
Innan du använder enheten
/13
Förvaring av fryst mat /1
3
Infrysning av fär
sk mat /13
Göra isbitar /1
4
Avfrostning /1
4
Så här omplaceras dörren /1
4
Byte a
v innerbelysningens glödlampa /14
Rengöring och vård /1
4
Viktig
a saker att göra och inte göra/14
Energiförbrukning /1
5
Information röran
de buller /15
Felsökning /1
5
DA Register
SV Index
NO Indeks
Sikkerheten først /16
Kr
av til det elektriske anlegget /17
Transportanvisninger
/17
Installasjonsanvisninger
/17
Bli kjent med apparatet
/17
Forslag til plasse
ring av matvarer i kjøleskapet /17
T
emperaturkontroll og justering /18
Før bru
k /18
Lagring av frosne matvarer
/18
Frysing av ferske mat
varer /18
Lag isbiter
/18
Avising
/19
S
lik reposisjonerer du dørene /19
Utskif
ting av lyspæren inne i skapet /19
Rengjøring og stell
/19
Ting du må
gjøre og ting du ikke må gjøre /19
Energiforbruk
/20
Info
rmasjon vedrørende støy /20
Feilsøking
/20
Turval
lisuus ensin /21
Sähkötekniset vaatimukset /2
2
Kuljetusohjeet /2
2
Asennusohjeet /2
2
Laitteen ominaisuudet
/22
Ehdotus ruokien sijoittamisesta
laitteeseen /22
Lämpötilan ohjaus ja säätö /2
3
Ennen käyttöä /2
3
Pakastet
un ruuan säilyttäminen /23
Tuoreen ruuan
pakastaminen /23
Jääpalojen teko /2
3
Sulattaminen /2
3
Oven uudelleensijoittaminen /2
4
Sisälampun vaihtaminen /2
4
Puhdistus ja huolto /2
4
Tee ja älä tee
/24
Energiankulutus /
25
Tietoja käyttöäänistä /
25
Vianetsintä /25
FI Hakemisto

1
C
Figures that take place in this instruction manual are schematic and may not correspond exactly with your
product. If the subject parts are not included in the product you have purchased, then it is valid for other models.
CTallene i denne brugerguide er kladder og kan afvige fra dit produkt. Hvis dit produkt ikke omfatter de relevante
dele, vedrører oplysningerne andre modeller.
CBilderna i den här bruksanvisningen är endast avsedda som exempel och kanske inte överensstämmer med din
produkt. Om produkten inte består av relevanta delar gäller informationen för andra modeller.
CIllustrasjonene i denne brukerhåndboken er ment som utkast, og det er mulig de ikke helt samsvarer med
produktet. Hvis produktet ikke omfatter de aktuelle delene, gjelder informasjonen andre modeller.
CTämän käyttöohjeen kuvat ovat viitteellisiä, eivätkä ne välttämättä vastaa tuotettasi. Mikäli tuotteesi ei sisällä
joitakin osia, tiedot koskevat muita malleja.

2
3
4
7
5
8
6
9

10

Congratulations on your new GRAM fridge/freezer.
Safety first!
Do not connect your appliance to the electricity supply
until all packing and transit protectors have been
removed.
• Leave to stand for at least 4 hours before switching on
to allow the compressor oil to settle if transported
horizontally.
• If you are discarding an old appliance with a lock or a
latch fitted to the door, ensure that it is left in a safe
condition to prevent the entrapment of children.
• This appliance must only be used for its intended
purpose.
• Do not dispose of the appliance on a fire. Your
appliance contains non CFC substances in the
insulation which are flammable. We suggest that you
contact your local authority for information on disposal
and available facilities.
• We do not recommend the use of this appliance in an
unheated, cold room (e.g. garage, conservatory, annex,
shed, out-house etc.).
To obtain the best possible performance and problem-
free operation from your appliance it is very important to
read the user guide carefully. Failure to observe the
user guide may reduce your right to free service during
the guarantee period.
Please keep the user guide in a safe place for easy
reference.
EN User guide
1
This appliance is not intended for people with reduced physical, sensory or mental
capabilities or lack of experience and knowledge unless they have been supervised or
instructed in the use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.

2
EN User guide
Electrical requirements
Before inserting the plug into the socket make
sure that the voltage and the frequency shown in
the rating plate inside the appliance corresponds
to your electricity supply. We recommend that
this appliance is connected to the mains supply
via a suitably switched and fused socket in a
readily accessible position. The plug has to be
accessible after installation in order to allow
disconnection of the appliance from the supply.
Warning! This appliance must be earthed.
Repairs to the electrical equipment may only be
made by authorised technicians. If the power
cable is damaged, the manufacturer or GRAM
service must replace it in order to avoid danger.
ATTENTION!
This appliance operates with R600a which is an
environmental friendly but flammable gas. During
the transportation and fixing of the product, care
must be taken not to damage the cooling
system. If the cooling system is damaged and
there is a gas leakage from the system, keep the
product away from open flame sources and
ventilate the room for a while.
WARNING -Do not use electrical devices or
other means to accelerate the defrosting
process, others than those recommended by the
manufacturer.
WARNING -Do not damage the refrigerant
circuit.
Transportation instructions
1. The appliance should only be transported in
an upright position. Packaging must be intact
during transportation.
2. If the appliance has been positioned
horizontally during transportation, it must not be
operated for at least 4 hours to allow the system
to settle.
3. Failure to comply with the above instructions
could result in damage to the appliance for which
the manufacturer will not be held liable.
4. The appliance must be protected against rain,
moisture and other atmospheric influences.
Important!
• Avoid touching the bottom of the condenser
metal wires at the back of the appliance while
cleaning or carrying the appliance as you may
receive injuries to your fingers and hands.
• Do not attempt to sit or stand on top of your
appliance as it is not designed for such use. You
could be injured or damage the appliance.
• Make sure that the mains cable is not caught
under the appliance during and after moving it as
this could damage the cable.
• Do not allow children to play with the appliance
or tamper with the controls.
Installation instructions
1. Do not keep your appliance in a room where
the temperature is likely to fall below +10ºC
(50ºF).
2. Do not place the appliance near cookers or
radiators or in direct sunlight, as this will cause
extra strain on the appliance's functions. If
installed next to a heat source or, maintain the
following minimum side clearances:
30 mm from cookers
300 mm from radiators
3. Make sure that sufficient room is provided
around the appliance to ensure free air
circulation (Fig. 2).
• Place the spacer on the back of your appliance
to set the distance between the appliance and
the wall (Fig. 3).
4. The appliance should be positioned on a level
surface. The two front legs can be adjusted as
required. To ensure that your appliance is
standing upright adjust the two front legs by
turning them either clockwise or anti-clockwise,
until firm contact is secured with the floor.
Correct adjustment of the legs prevents
excessive vibration and noise (Fig. 4).
5. Refer to the "Cleaning and Care" section to
prepare your appliance for use.
6. If you want to place two products side by side,
e.g. a refrigerator and a freezer, as a side by side
solution you have to use a decoration kit which
contains a mat and a decoration part. The mat is
mounted on the side of one of the products to
create a space between the products. The
decoration part is placed between the products
to hide the gap between the products (Fig. 2).
The decoration kit is not a part of the product but
can be delivered as an accessory.
Getting to know your appliance (Fig. 1)
1 - Thermostat control and interior light
2 - Fresh Food fan
3 - Removable glass shelves
4 - Fresh zone compartment
5 - Vegetable drawer
6 - Compartment for fast freezing
7 - Ice cube tray support & ice cube tray
8 - Compartments for keeping frozen food
9 - Adjustable front legs
10 - Door shelves
11 - Bottle shelf
12 - Freezer fan
Suggested arrangement of the food in
the appliance
Guidelines for obtaining optimum storage:
1. The fridge compartment is for the short-term
storage of fresh food and drinks.

EN User guide
2. The freezer compartment is
rated and suitable for the freezing and storage of
pre-frozen food. The recommendation for
storage as stated on the food
packaging should be observed at all times.
3. Dairy products should be stored in the coldest
places in the fridge compartment.
4. Cooked dishes should be stored in airtight
containers.
5. Fresh wrapped produce can be kept on the
shelves. Fresh fruit and vegetables should be
stored in the vegetable drawers.
6. Bottles can be kept in the door shelves or on
the bottle shelf.
7. To store fre
sh meat, wrap it in polythene bags
and place it in the coldest place in the
fridge compartment. Don’t let meat juice from
fresh meat come into contact with other types of
food. For safety, only store fresh meat for two to
three days.
8. For maximum efficiency the removable
shelves should not be covered with paper or other
materials to allow free circulation of cool air.
9. Do not keep vegetable oil on the door
shelves. Keep the food packed, wrapped or
covered. Leftover canned food should not be
stored in the can.
10. To take out the drawers from the freezer
compartment please proceed as in Fig. 9.
Temperature control and adjustment
Operating temperatures are controlled by the
thermostat control (Fig. 5) located on the
ceiling of the fridge compartment. Settings may be
made from MIN., 1 ... 4,MAX., MAX which is the
coldest position. When the appliance is switched
on for thefirst time, the thermostat control should
be adjusted so that after24 hours, the average
fridge temperature is no higherthan +5°C (+41°F).
Werecommend you to set the thermostat control
half way between the MIN. and the MAX. position
and monitor to obtain the desired temperature i. e.
towards MAX. you will obtain a colderfridge
temperature and vice versa.Some sections of the
fridge may be cooler or warmer (such as the
vegetable drawers and the top part of the cabinet)
which is quite normal. The normal storage
temperature of the freezer should be -18°C (0°F).
Lower temperatures maybe obtained by adjusting
the thermostat control towards the MAX. position.
Werecommend that you check the temperature
with an accurate thermometerto ensure that the
storage compartments are kept to the desired
temperature. Remember to read off the
thermometer very quickly as the temperature on
the thermometer will rise very rapidly after you
remove it from the freezer.
Please remember that each time the door is
opened cold air escapes and the internal
temperature rises. Therefore never leave the
door open and ensure that it is closed
immediately after food is put in or removed.
Before operating
Final Check
Before you start using the appliance check that:
1. The front legs have been adjusted for perfect
levelling.
2. The interior is dry and that air can circulate
freely at the back of the appliance.
3. The interior is clean as recommended under
the "Cleaning and care" section.
4. The plug has been inserted into the wall socket
and the electricity is switched on. When the door
is open the interior light will be switched on.
And note that:
5. You will hear a noise as the compressor starts.
The liquid and gases sealed within the refrigeration
system may also make some noise, whether the
compressoris running or not.This is quite normal.
6. The top of the cabinet may be slightly
currugated which is quite normal due to the
manufacturing process used; it is not a defect.
7. We recommend setting the thermostat control
midway and monitor the temperature to ensure
that the appliance maintains the desired storage
temperatures (see the "Temperature Control and
Adjustment" section).
8. Do not load the appliance immediately after it
is switched on. Wait until the correct storage
temperature has been reached. We recommend
checking the temperature with an accurate
thermometer (see the "Temperature Control and
Adjustment" section).
9. Remember to remove all packing materials -
including transportation security in the form of
tape, styrofoam, cardboard, etc. within the
enclosure. It is also important to remove any
styrofoam / cardboard in the evaporator tray on
the back of the closet, otherwise there is a risk
that water is leaking on the floor.
Storing frozen food
Your freezer is suitable for the long-term storage
of commercially frozen food and also can be
used to freeze and store fresh food. If there is an
electrical cut, do not open the door. Frozen food
should not be affected if the electrical cut lasts for
less than 16 hrs. If the electrical cut is longer,
then the food should be checked and either
eaten immediately or cooked and then re-frozen.
Freezing fresh food
Please observe the following instructions to
obtain the best results. Do not freeze too large a
quantity at any one time.
3

EN User guide
The qualityof the food is best preserved when it is
frozen right through to the core asquickly as
possible. Do not exceed the freezing capacity of your
appliance in 24 h. Placingwarm food in the freezer
compartment causesthe compressor to operate
continously until the food is frozen solid. This can
temporarily lead to excessive coolingof the
refrigeration compartment.When freezingfresh food,
keep the thermostat control at the medium position.
Small quantities of foodup to 1/2 kg (1 lb) can be
frozen without adjusting the thermostat control.
Making ice cubes
Fill the ice cube tray 3/4 with water and place it in
the freezer. Loosen frozen trays with a spoon
handle or a similar instrument; never use sharp-
edged objects such as knives or forks.
Defrosting
A) Fridge compartment
The fridge compartment defrosts automatically.
The defrost water runs to the drain tube via a
collection container at the back of the appliance.
Check that the tube is permanently placed with
its end in the collecting tray on the compressor to
prevent the water spilling on the electric
installation or on the floor (Fig. 6).
B) Freezer compartment
As this appliance is supplied with the NO FROST
feature it means that the defrosting is completely
automatic. No intervention from your side is
requiered. The water is collected on the
compressor tray. Due to the heat of the
compressor the water is evaporated.
Never use hairdryers, electrical heaters or other
such electrical appliances for defrosting.
Warning!
The fans inside the freezer and fresh food
compartments circulates cold air. Never insertany
object through the guard.Do not allow children to
play with the freezer fan.Never store products that
contain inflammable propellant gas such as
dispensers, spray cans etc. or explosive substances.
Don’t cover the shelves with any protective
materials, which may obstruct air circulation.
Do not allow children to play with the
appliance or the controls.
Do not obstruct the fan guards to ensure
that you
obtain the best possible performance from your
appliance (Fig. 7 and Fig. 8).
Warning!
Your appliance is fitted with a circulatingfan which is
essential for the performance of the freezer. Please
ensure that the fan is not blocked (stopped) or
impaired by food or packaging. Blocking (stopping)
or impairing the fan can result in an increase of the
internal freezer temperature (Thawing).
How to reposition the doors
Proceed in numerical order (Fig. 10).
Replacing the interior light bulb
To change the Bulb/LED used for illumination of
your refrigerator, call your Authorised Service.
The lamp(s) used in this appliance is not suitable
for household room illumination. The intended
purpose of this lamp is to assist the user to place
foodstuffs in the refrigerator / freezer in a safe
and comfortable way. The lamps used in this
appliance have to withstand extreme physical
conditions such as temperatures below -20°C.
Cleaning and care
1. We recommend that you switch off the
appliance at the socket outlet and pull out the
mains plug before cleaning.
2. Never use any sharp instruments or abrasive
substances, soap, household cleaner, detergent
or wax polish for cleaning.
3. Use luke warm water to clean the cabinet of
the appliance and wipe it dry.
4. Use a damp cloth wrung out in a solution of
one teaspoon of sodium bicarbonate to one pint
of water to clean the interior and wipe it dry.
5. Make sure that no water enters the
thermostat control box.
6. If the appliance is not going to be used for a
long period of time, switch it off, remove all food,
clean it and leave the door ajar.
7. Any dust that gathers on the condenser,
located at the back of the appliance, should be
removed once a year with a vacuum cleaner.
8. Check the door seals regularly to ensure that
they are clean and free from food particles.
9. Never:
• Clean the appliance with unsuitable material;
such as petroleum based products.
• Subject it to high temperatures in any way.
• Scour, rub etc., with abrasive material.
10. To remove a door tray, remove all the
contents and then simply push the door tray
upwards from the base.
11. Make sure that the special plastic containerat
the back of the appliance which collects the thawed
wateris clean at all times. If you want toremove the
tray to clean it, follow the instructions below:
• Switch off the socket and pull out the mains plug.
• To remove the water collector tray pull and turn
(left-right).
• Clean and wipe it dry.
• Reassemble the tray by reversing the
sequence and operations.
12. To remove a drawer, pull it as far as possible,
tilt it upwards and then pull it out completely.
Do’s and Don’ts
Do clean your appliance regularly (See
"Defrosting").
Do keepfoodforas short atime aspossible and
adhereto"Best Before" and "Useby"etc.dates.
Do defrost food in the fridge compartment.
4
