Fusion
120 or 277VAC Input
12VDC 72 Watt Output
INSTALLATION AND
OPERATING
INSTRUCTIONS
IMPORTANT
SAFEGUARDS
When using electrical equipment, basic safety
precautions should always be followed, including the
following:
READ AND FOLLOW ALL
SAFETY INSTRUCTIONS
All servicing should be performed by qualified
personnel only.
Equipment should be mounted in locations and at
heights where it will not be readily subjected to
tampering by unauthorized personnel.
The use of accessory equipment not recommended
by the manufacturer may cause an unsafe condition.
Do not use this equipment for other than intended
use.
Do not use outdoors.
Do not let supply cords touch hot surfaces.
Do not mount near gas or electric heaters.
Caution: Halogen cycle lamp(s) are used in this
equipment. To avoid shattering: Do not operate
lamp in excess of rated voltage, protect lamp against
abrasion and scratches and against liquids when lamp
is operating, dispose of lamp with care.
Halogen cycle lamps operate at high temperatures.
Do not store or place flammable materials near lamp.
Use caution when servicing batteries. Battery acid
can cause burns to skin and eyes. If acid is spilled on
skin or eyes, flush acid with fresh water and contact
a physician immediately.
CAUTION: To avoid electrical overload, total
connected lamp load (factory and field installed)
should not exceed output rating.
SAVE THESE
INSTRUCTIONS
WARNING –Shut off AC power to branch
circuits to which units will be connected. All
wiring should be per N.E.C. Articles 501-4(b) and
local codes.
To maintain warranty, equipment with batteries
must be installed or placed on charge within
prescribed period after shipment.

July 2018
443580499131
Signify North America Corporation
200 Franklin Square Drive
Somerset, NJ 08873, USA
Phone: [phone]
www.chloride-lighting.com
Signify Canada Ltd./Signify Canada Ltée.
281 Hillmount Road,
Markham, ON, Canada L6C 2S3
Phone: [phone]
GENERAL INSTRUCTIONS
Follow the “Step 1” that is appropriate to the
desired mounting orientation. Steps 2 through 7
apply to both wall and ceiling installations.
Step 1 - Recessed Sheetrock Wall Mount (14-
1/4” x 9-1/8” cutout required)
Remove one knockout in sheetmetal housing for
AC service entry.
Unit is attached to studs through holes provided in
sides of enclosure.
ATTENTION: Unit must be framed in properly on
at least two sides in order to ensure adequate
support.
Break away tabs are provided on the edges of the
larger sheetmetal box and are recommended to be
removed for rough-in installations. These tabs may
be removed by bending them until they snap off
using large pliers or klines. Beware of any sharp
edges remaining after removal. A “Sheetrock
Thickness Gauge” is printed on the sides of the
housing to help set the box at the correct depth.
Line up the edge of the line corresponding to the
finished sheetrock thickness with the outer surface
of the stud before securing the backbox to the stud.
After sheetrock installation, the leading edge of the
backbox should be flush with the outer sheetrock
surface (room or finished surface).
Step 1 - Sheetrock Ceiling Mount (14-1/4” x 9-1/8”
cutout required) Note: This product is U.L. approved
for use in IC rated ceiling constructions.
Remove one knockout in sheetmetal housing for AC
service entry.
Unit is attached to studs through holes provided in sides
of enclosure.
ATTENTION: Unit must be framed in properly on at
least two sides in order to ensure adequate support.
Break away tabs are provided on the edges of the
larger sheetmetal box and are recommended to be
removed for rough-in installations. These tabs may
be removed by bending them until they snap off using
large pliers or klines. Beware of any sharp edges
remaining after removal. A “Sheetrock Thickness
Gauge” is printed on the sides of the housing to help set
the box at the correct depth. Line up the edge of the line
corresponding to the finished sheetrock thickness with
the outer surface of the stud before securing the backbox
to the stud. After sheetrock installation, the leading edge
of the backbox should be flush with the outer sheetrock
surface (room or finished surface).
Step 1 - Grid Ceiling Mount (14-1/4” x 9-1/8”cutout
required) Note: This product is U.L. approved for use
in IC rated ceiling constructions.

July 2018
443580499131
Signify North America Corporation
200 Franklin Square Drive
Somerset, NJ 08873, USA
Phone: [phone]
www.chloride-lighting.com
Signify Canada Ltd./Signify Canada Ltée.
281 Hillmount Road,
Markham, ON, Canada L6C 2S3
Phone: [phone]
(Note: Grid ceiling installation requires Chloride p/n
FBHK bar hanger kit.) Remove one knockout in
sheetmetal housing for AC service entry. Two grid
ceiling adapters are provided –one for each side of the
main housing. They are attached to the main housing by
removing the four oblong knockouts in the short sides of
the main housing and using the four #8 nuts provided.
Place bar hangers though the lowest set of holes in the
adapters and attach to ceiling grid. Adjust the vertical
alignment so that the backbox flanges are flush with the
bottom (room side) of the ceiling tile.
Step 2 -
Connect red battery lead by pushing connector halves together (see above illustration). Refer to “AC
Hookup” table below for AC supply wiring guide.
AC Hookup
120VAC Operation
277VAC Operation
White Wire –Common
White Wire –Common
Black Wire –120VAC Line
Black Wire –Cap Off
Blue Wire –Cap Off
Blue Wire –277VAC Line
Green Wire - Ground
Green Wire - Ground
CAUTION: Unused primary wire must be insulated to prevent shorting.

July 2018
443580499131
Signify North America Corporation
200 Franklin Square Drive
Somerset, NJ 08873, USA
Phone: [phone]
www.chloride-lighting.com
Signify Canada Ltd./Signify Canada Ltée.
281 Hillmount Road,
Markham, ON, Canada L6C 2S3
Phone: [phone]
Step 3 -
Snap MR-16 lamps into position as shown. Remove 4 pin lamp connector from main housing. Push
lamp sockets onto pins on MR-16 lamps.
Note: The reflector/lens system has been designed so that rotation of the system will not be required for
most installations. Reflectors and lenses may be rotated 90° if necessary.
Step 4 -
Connect flex cable connectors from circuit board assembly and cover together as shown. The flex cable
is keyed for proper alignment and locking. Ensure that connector is fully seated. Reconnect the 4 pin
lamp connector from Step 3.

July 2018
443580499131
Signify North America Corporation
200 Franklin Square Drive
Somerset, NJ 08873, USA
Phone: [phone]
www.chloride-lighting.com
Signify Canada Ltd./Signify Canada Ltée.
281 Hillmount Road,
Markham, ON, Canada L6C 2S3
Phone: [phone]
Step 5 –
Snap front panel onto enclosure. Front panel may be removed by inserting a flat bladed instrument such
as a putty knife or screwdriver under the edge and gently prying away from mounting surface.
CAUTION: The halogen lamps used in this product operate at very high
temperatures. Care should be taken when servicing unit to avoid burns.
Note: A. This equipment is provided with a lockout feature whereby connecting battery leads prior to
energizing AC power will not turn on the emergency lamps. After AC power is energized the
emergency lamps will turn on upon AC power failure.
B. This equipment is provided with a low battery disconnect feature which prevents full
discharge of batteries. If the building is to be unoccupied for an extended period and AC
power is shut off, the batteries should be disconnected from the charger to prevent damage.
C. The batteries provided in this equipment are sealed and require no maintenance.

July 2018
443580499131
Signify North America Corporation
200 Franklin Square Drive
Somerset, NJ 08873, USA
Phone: [phone]
www.chloride-lighting.com
Signify Canada Ltd./Signify Canada Ltée.
281 Hillmount Road,
Markham, ON, Canada L6C 2S3
Phone: [phone]
Self Diagnostic System Operation –Emergency Light or EXIT Sign Products
Normal Power Up Sequence
At power up the red and green LED indicators will alternately flash for one to two seconds. Next the product will execute
a “Power Up Quick Test” causing the green LED indicator to flash rapidly. If any faults are detected during the “Power Up
Quick Test” these will be evident by a flashing red LED indicator. If the audible diagnostic option has been ordered, the
flashing red LED will be accompanied by a simultaneous beeping tone. (Note: A continuous rapid alternating Red/Green
flash with rapid beeping tone indicates 277V applied to 120V input lead. TURN OFF POWER IMMEDIATELY!)
Emergency Operation
Emergency operation occurs when AC power fails. The product remains in emergency operation until AC power is
restored or battery capacity is depleted. During emergency operation both red and green LED indicators are disabled.
User Interface
Green LED indicator
•Slow Flash/Continuous ON = AC power present; normal operating condition
•Rapid Flash = product performing an automatic or manually initiated diagnostic test
Red LED indicator
•Single Flash = battery fault
•Two Flashes = lamp failure (light bar failure –EXIT signs)
•Three Flashes = charger fault
•Four Flashes = transfer fault
(If more than one fault condition is present simultaneously, the red LED will flash the indication pattern for each
fault independently then repeat the cycle.)
Pushbutton Test Switch
•Long Press (longer than 0.5sec) transfers product to emergency operation during time the button is
pressed.
•Short Press initiates self diagnostic activities as follows:
➢One Press cancels diagnostic test presently running.
➢Two Presses starts a one minute diagnostic test.
➢Three Presses starts a 90 minute diagnostic test.
➢Four Presses conducts a lamp load calibration (emergency light products only).
➢Seven Presses initiates a system reset.
(Note: the microprocessor will allow up to seven, one minute diagnostic tests within the first 24 hours of
operation. Allow 24 hours of charging before performing any long duration testing.)
Buzzer (optional)–Sounds in unison with the flashing red LED if a fault condition is present. Buzzer may be
silenced for up to 196 hours by a short press of either the test switch or the optional IR remote control device
“silence” button. Correcting fault condition will cancel fault notification. Lamp failure indication requires a
manually activated diagnostic test after lamp replacement to cancel notification.
IR Remote Control (optional)- is a hand held device that allows remote activation of diagnostic testing and
silencing of the optional buzzer during fault conditions.
