Signtex Moonlite MAEBB Series Quick start guide

1. Disconnect AC power before servicing.
2. Refer to wiring diagram for proper connections.
3. All servicing should be performed by qualified personnel.
4. Consult your local building code for approved wiring and installation.
5. Do not use this equipment for other than intended use.
6. Do not let power cords touch hot surfaces.
7. Mount and secure the fixture at a location and height to avoid ready access
and tampering by unauthorized persons.
8. The use of accessory equipment is not recommended by the manufacturer
and may cause an unsafe condition.
9. Suitable for wet locations. See product label for temperature limitations.
IMPORTANT SAFEGUARDS READ AND FOLLOW ALL SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
SUITABLE FOR WET LOCATIONS
AMBIENT TEMPERATURE LIMITS:
Standard "BB" models: -20º C to +40º C
High Temp "BB" models (SW): -20º C to +45º C
Remote models: -40º C to +50º C
J- Box and Supply Wiring
1. See above. Assemble standard 4” x 4” deep j-box with 1 ½” extension. Note available knock-outs for
wiring. Remove K.O's in areas shown for wiring and connecters.
2. Align edge of extension flush or just below finish panel surface.
3. SECURITY LIGHTING SWITCH CONTROL (OPTION -SW)
AVAILABLE K.O.'S
4 PLACES
SET EDGE OF BOX
FLUSH TO WALL
FINISH OR
PANEL THICKNESS
STANDARD J-BOX
4 x 4 x 21/8"
EXTENSION RING
4 x 4 x 11/2"
ITEM QTY P/N DESCRIPTION
1 1 346302 CANOPY POWER ASSBY
2 1 206110 BATTERY PACK 3.6V
3 1 206117 BATTERY PACK 4.8V
4 1 346200 LAMP HOUSING ASSBY
23
LAMP
PLUG
4
L N G
120/277 VAC
BUILDING SUPPLY
Black
Red
White
1
OPTIONAL NORMAL ON
CONTROL SWITCH WIRING
GROUND
TO J-BOX
INSTALLATION INSTRUCTIONS AND OWNER'S MANUAL
LED Architectural Emergency Light with Battery Backup
Series MAEBB
Moonlite LED™
5.15.03
SEC CONTROL INPUT VOLTS
STANDARD FIXTURE = 120 VAC
DG FIXTURE = 120/ 277 VAC UNIVERSAL
BATT
L N
LAMPS
RED
(LINE)
BLACK
WHITE
SEC CONTROL
MAKE- SEC ON
BREAK- SEC OFF
120 / 277 VAC
UN- SWITCHED NORMAL INPUT
POWER
SUPPLY

-2-
220 VFW Avenue, Grasonville, MD 21638
TEL: (410) 827-- 8300 Fax:[phone]
[e-mail] www.signtexinc.com
Signtex Inc
LIGHTING
Fixture Assembly
1. Note position of (2) J-Box MOUNT screws and insert (2) #8-32 x ½” PLUG sealing screws with nuts into
Canopy at unused locations.
2. Connect power supply wiring to building supply with standard wire nuts:
BLACK: 120-277VAC:
WHITE: Neutral.
3. Connect GROUND to J-Box
4. Connect optional NORMALLY ON control switch (SW) Wiring.
5. Connect the BATTERY plug. Insert power supply assembly in position and secure to J-Box with two #8-32
x 3/4” MOUNT sealing screws supplied and tighten to compress gasket evenly. DO NOT over tighten.
7. Place Lamp Housing Assembly over Canopy Plate and connect Lamp Plug.
NOTE: If AC power is OFF, the fixture will turn ON under battery power. To minimize battery
discharge, turn AC power ON after fixture is connected.
If fixtures remains in Emergency mode after AC power is applied, depress & hold test button
for one minute & release.
8. Insert Lamp Plug wiring sleeve through center hole in Gasket while placing Lamp Housing in position.
Tighten (2) #6-32 set screws to secure in position.
9. Turn ON building AC supply and operate test switch to confirm emergency operation. Batteries require 24
hrs for full charge. Operate control switch option where supplied to confirm normally ON operation.
GROUND
TO J-BOX
L N G
120/277 VAC TEST SWITCH
& STATUS LIGHT
LAMP HOUSING
ASSBY
POWER
ASSBY
Black
Red
White
(2) # 8-32 x 1/2"
CANOPY PLUG SEALING SCREW
(2) # 8-32 x 3/4"
CANOPY MOUNT SEALING SCREW
BATTERY
PLUG
TOP MT
(OPTION)
OPTIONAL
NORMAL ON
CONTROL
SWITCH WIRING
(2) # 6-32 x 3/8
SET SCREW
LED Architectural Emergency Light with Battery Backup
Series MAEBB
Moonlite LED™
5.15.03
