Model SEH-2
Headphone Instructions
The SEH-2 series of headphones are adjusted at the factory for immediate
use with all Sigtronics emergency apparatus intercoms and radio adapters
in emergency vehicles. The headphone is equipped with a single plug and
a coiled cord.
The head strap is adjustable so you may custom t the headphone. Place
the headphone over your head and adjust the strap until minimum pres-
sure is felt on the top of your head. For maximum noise attenuation, the
clamping pressure of the headband has been set at the factory. Releasing
the clamping pressure by bending the headband is not advised, because
loss of attenuation will result.
When you rst connect the headphone, turn the volume control on the
headphone up to the full clockwise position, then adjust the listening
volume with the audio control of either your radio or intercom as appro-
priate. If applicable, crew members should also turn their individual head-
phone volumes up fully. Doing this allows for a full range of adjustment
for each passenger, since those with the most acute hearing can turn their
headphone volume down, if necessary.
continued on back…
The headphone parts may be cleaned with mild soap and water using a
soft cloth. Then dry immediately. Caution: Do Not immerse any part of the
headphone in water or any other liquid. Exposure to moisture may cause
internal corrosion and failure and will void your manufacturers warranty.
Cleaning will help the headphone maintain its “like new” condition for
many years.
WARRANTY
Your headphone is covered by a limited two-year parts and labor warranty.
Please see the enclosed warranty card for details.
You may refer to the parts list on the reverse side, if you choose to replace
parts yourself. The parts list describes parts for this particular headphone
only. Parts lists for other models are available on our Web Site or can be
obtained by contacting Sigtronics Corporation.

SIGTRONICS SEH-2 HEADPHONE PARTS IDENTIFICATION BREAKDOWN
ITEM P/N DESCRIPTION ITEM P/N DESCRIPTION ITEM P/N DESCRIPTION
1100413 HEADBAND EXTRUSION, 4 IN., SE-2 9100049 GROMMET, 5/16 INCH, RUBBER 17 100935 WIRE, #22, JUMPER, HEADSET, 4 INCH
2800220 HEADBAND, METAL, BLACK, WITH GROMMETS, SE-2 10 100567 GROMMET, SE-2 STUD 18 100568 STRAIN RELIEF, CABLE
310 0411 STRAP, HEADSET, SE-2, BLACK 11 100369 EAR SEAL, FOAM FILLED 19 100063 KNOB, 3/8 INCH, BLACK, VOLUME
4100451 STUD, SE-2, EAR CUP TO BAND MOUNT 12 100374 FOAM, SOUND ATTENUATING. NOTCHED, 1/2 INCH 20 100077 POTENTIOMETER
5100108 SCREW, 4-40 X 1/4, THREAD FORMING 13 100376 FOAM, SOUND ATTENUATING. RECEIVER HOLE, 1/2 INCH 21 100858 RECEIVER AND MOUNT, 300 OHM, MONO
6100252 NUT, HEX, 8-32, LOCKING 14 100379 FOAM, SOUND ATTENUATING, RECEIVER COVER, 1/4 INCH 22 100675 OPTIONAL – HEADBAND, METAL, BLACK, LARGE
7100980 EAR CUP, PRINTED AND DRILLED, CABLE SIDE 15 800035 CABLE, HEADSET, STEREO, COILED 23 100402 OPTIONAL – EAR SEAL, GEL FILLED
8100954 EAR CUP, PRINTED AND DRILLED, VOLUME CONTROL SIDE 16 100932 WIRE, CROSSOVER, BEHIND THE HEAD, 23 INCHES












 










