Silhouette SI-1700 Operator's manual

2
IMPORTANT SAFEGUARDS
When using electrical appliances especially when children are present, basic safety
precautions should always be followed to reduce the risk of re, electric shock, and/or
injury to persons, including the following:
1. READ ALL INSTRUCTIONS BEFORE USING THIS IRON.
2. Use iron only for its intended use.
3. To protect against electrical shock, do not place cord, plug or appliance in water or
other liquid.
4. The iron should always be turned to “OFF” before plugging or unplugging from
the outlet. Never yank the cord to disconnect from outlet, grasp plug and pull to
disconnect.
5. Do not allow cord to touch hot surfaces. Let iron cool completely before putting
away. Loop cord loosely around the iron when storing.
6. Always disconnect iron from electrical outlet when lling with water or emptying and
when not in use.
7. Do not operate iron with a damaged cord or if the iron has been dropped or
damaged. To avoid the risk of electrical shock, do not disassemble the iron. Take it
to an authorized service center for examination and or repair. Incorrect reassembly
can cause a risk of electric shock when the iron is used.
8. This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience or knowledge, unless
they have supervision or instruction concerning use of the appliance by a person
responsible for their safety.
9. Children should be supervised to ensure they do not play with the appliance.
10. Do not leave iron unattended while connected or on an ironing board.
11. Burns can occur from touching hot metal parts, hot water or steam. Use caution
when you turn a steam iron upside down as there may be hot water in the reservoir.
12. If the iron is not operating properly, disconnect from the power supply and have the
iron serviced by an authorized service center.
13. The iron must be used and rested on a stable surface.
14. When placing iron in its stand, ensure that the surface on which the stand is placed
is stable.
15. The iron is not to be used if it is dropped, if there are visible signs of damage or if it
is leaking.
16. Your iron is designed to rest on the heel rest. Do not leave the iron unattended. Do
not set the iron on an unprotected surface, even if it is on its heel rest.
17. To avoid a circuit overload, do not operate an iron on the same circuit with another
high wattage appliance.
18. If an extension cord is absolutely necessary, a cord with an ampere rating equal to
or greater than the Maximum rating of the iron shall be used. A cord rated for less
amperage can result in a risk of re or electric shock due to overheating. Care shall
be taken to arrange the cord so that it cannot be pulled or tripped over.
19. The use of accessory attachments not recommended by the appliance manufacturer
may result in re, electric shock or injury to persons.
20. FOR HOUSEHOLD USE ONLY.
SAVE THESE INSTRUCTIONS

3
OPERATING INSTRUCTIONS
PRODUCT MAY VARY SLIGHTLY FROM ILLUSTRATIONS
This appliance is for HOUSEHOLD USE ONLY. It may be plugged into an AC electrical outlet
(ordinary household current). Do not use any other electrical outlet.
CORD PLUG
This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of
electric shock, this plug is intended to t into a polarized outlet only one way. If the plug does
not t into the outlet, reverse the plug and try again. If it still does not t, contact a qualied
electrician. Do not attempt to modify the plug in any way.
SHORT CORD INSTRUCTIONS
A short power supply cord is provided to reduce the hazards resulting from entanglement or
tripping over a longer cord.
LINE CORD SAFETY TIPS
1. Never pull or yank on cord or the appliance.
2. To insert plug, grasp it rmly and guide it into outlet.
3. To disconnect appliance, grasp plug and remove it from outlet.
4. Before each use, inspect the line cord for cuts and/or abrasion marks. If any are found,
this indicates that the appliance should be serviced and the line cord replaced.
5. Never wrap the cord tightly around the appliance, as this could place undue stress on the
cord where it enters the appliance and cause it to fray and break.
Longer detachable power-supply cords or extension cords are available and may be
used if care is exercised in their use. If a longer detachable power-supply cord or
extension cord is used:
1) The marked electrical rating of the cord set or extension cord should be at least as
great as the electrical rating of the appliance, and
2) The cord should be arranged so that it will not drape over the countertop or tabletop
where it can be pulled on by children or tripped over unintentionally.

4
DO NOT OPERATE APPLIANCE IF THE LINE CORD SHOWS ANY DAMAGE, OR IF
APPLIANCE WORKS INTERMITTENTLY OR STOPS WORKING ENTIRELY.
IMPORTANT
During the rst few minutes of initial use, you may notice smoke and/or a slight odor. This is
normal and should quickly disappear. It will not recur after appliance has been used a few
more times.
BEFORE USING
1. Carefully unpack the iron and remove any protective lms or stickers from the sole plate
and the iron.
2. Clean the sole plate with a soft cloth.
3. When using the iron for the rst time, test it on an old piece of fabric to ensure that the
sole plate and water tank are completely clean.
FILLING THE WATER RESERVOIR
• This iron can be used with normal tap water.
• If the water in your area is particularly hard, it is advisable to use distilled or de-mineralized
water to prevent the scale from forming on the critical point of the iron.
• Do not use water that has passed through a home water softening system. This type of
water contains minerals that will decrease the performance and shorten the life of your
iron.
FILLING:
1. Ensure that the iron is disconnected from the power supply before lling. Move the
Steam Control Knob to the picture indicating NO STEAM and the Fabric Selection Dial
to “OFF”.
2. Pour water into the water inlet to the “MAX” line on the water tank. Do not ll over this
line in order to avoid spilling out of water.
NOTE: Always pour any remaining water out of the water tank after use by turning the iron
upside-down over a sink.
HOW TO USE YOUR IRON
SETTING THE TEMPERATURE:
Insert the plug into the wall outlet and stand the iron upright. Turn the Fabric Selection Dial to
the desired setting. The desired setting has been reached when the pilot light has turned off.
The pilot light will cycle on and off indicating the selection is being maintained.
Always check rst to see whether a label with ironing instructions is attached to the article to
be ironed. Follow these instructions in all cases. If ironing instructions are missing but you do
know the kind of fabric, the table on page 5 may help you.
• Sort the laundry out according to iron temperature rst: wool with wool, cotton with
cotton, etc. Start ironing fabrics which require the lowest temperature and progress to
fabric which require a higher temperature. The iron heats up quicker than it cools down.
• If the fabric consists of various types of fabrics, you should select the fabric with the
lowest temperature requirement and iron on that temperature setting.
• 100% wool fabric may be pressed with the iron set to a steam position. Ideally, set the
Steam Control Dial to maximum position and use a dry pressing cloth.
• When ironing woolen fabrics, shining of the fabric may occur. This may be prevented by
turning the garmet inside out and ironing on the reverse side.
• Velvet and other textures which rapidly acquire shiny spots should be ironed in one
direction only (with the nap) applying light pressure.

5
• Always keep the iron moving.
• Silk and other fabrics likely to become shiny should be ironed on the reverse side. To
prevent staining, do not use Spray on silk or other delicate fabrics.
TEXTILE FABRICS FABRIC SELECTION DIAL
Synthetic Acrylic
Modacryl
Polypropylene
Polyurethane
Synthetic - Min Setting
Synthetic Acetate
Triacetate
Synthetic - Min Setting
Synthetic Metallized
Cupro
Polyamide (nylong)
Polyester
Modal
Viscose (rayon)
Synthetic - Min Setting
Silk Silk Silk
Wool Wool Wool
Cotton Cotton Cotton
Linen Linen Linen
SPRAYING:
This function can be used any time and it does not affect the ironing temperature. Fill the iron
with water as described on page 4. Aim the nozzle toward the garmet and press the Spray
Button.
BURST OF STEAM:
This function provides and extra amount of steam to remove stubborn wrinkles. Fill the iron
with water as described on page 4. Turn the Fabric Selection Dial to “MAX”. Press the Burst
of Steam button and steam will penetrate into the garment from the vents in the soleplate.
STEAM IRONING:
This function can be used only at higher temperature settings. Fill the iron with water as
described on page 4. Turn the Fabric Selection Dial to desired setting. Turn the Steam
Control Dial to the desired position and steam will start coming out from the vents in the
soleplate.
NOTE: With convention steam ironing, water may leak from the soleplate if too low a
temperature has been selected. If this happens, turn the Fabric Selection Dial to the advised
position. Steam will recommence as soon as the appropriate temperature has been reached.
DRY IRONING:
This function can be used when steam is not needed. Make sure the Steam Control Dial is
set to the picture indicating NO STEAM before you begin. Turn the Fabric Selection Dial to
the desired setting.
CARE AND CLEANING
This appliance contains no user serviceable parts. Do not try to repair it yourself. Refer it to
qualied service personnel if servicing is needed.

6
SELF-CLEAN FUNCTION:
This function can be used to self clean your iron and remove scale and impurities. Use the
self-clean function once every two weeks. If the water in your area is very hard, the self-clean
function should be used more frequently.
1. Make sure the appliance is unplugged.
2. Set the Steam Control Knob to the far left position “Self-Clean”.
3. Fill the water tank to the maximum level.
4. Select the maximum ironing temperature.
5. Plug into wall outlet.
6. Unplug the iron when the temperature pilot light has gone out.
7. Hold the iron over the sink and gently shake the iron back and forth. (Steam and boiling
water will come out of the soleplate. Impurities and akes (if any) will be ushed out.)
8. Repeat if necessary.
CLEANING:
• Before cleaning, ensure that the iron is disconnected from the power supply and has
completely cooled down.
• Deposits and other residues on the soleplate can be removed with a rough cloth soaked
in a vinegar/water solution.
• The main iron body may be wiped with a damp cloth and then polished with a dry cloth.
• Do not use abrasives on the soleplate.
STORAGE:
• Before storing, turn the Fabric Selection Dial to “OFF” and the Steam Control Knob to the
picture indicating NO STEAM.
• Ensure that the iron is disconnected from the power supply.
• Pour any remaining water out of the tank.
• Stand the iron upright on its heel rest and allow to cool completely.
• Loosely loop the power cord together and store the iron on its heel rest.
HELPFUL HINTS
• Always read garment labels and follow the manufacturer’s ironing instructions.
• Sort the articles to be ironed according to the type of fabric.
• You should rst iron garments requiring low temperature to avoid damaging them with
an iron that is too hot.
• If you are unsure of the fabric content of the garment, test a small area, such as a seam
or facing, before ironing a visible area. Start with a low temperature and gradually
increase the heat to nd the best setting.
• When changing the temperature from a high setting to a low setting, allow approximate-
ly 5 minutes for the lower temperature to be reached.
• When steam ironing, use long, slow passes over the fabric. This will allow the steam to
penetrate the fabric while allowing the heat of the soleplate to dry out the moisture.
• To iron linens, turn garment inside out. Be careful not to use and iron that is too hot
because the lining may melt or stick to the soleplate.
• To iron zippers, use an ironing cloth or make sure the zipper is closed and iron over the
ap. Never use iron over an unprotected zipper.

7
ONE YEAR LIMITED WARRANTY
SELECT BRANDS, INC. warrants, subject to the conditions stated below, that from the date of purchase,
this product will be free from mechanical defects for a period of one (1) year. SELECT BRANDS,
INC., at its option, will repair or replace this product found to be defective during the warranty period.
Should this product become defective by reason of improper workmanship or material defect during
the specied warranty period, Select Brands, Inc. will repair or replace the same effecting all necessary
parts replacements for a period of one year from the date of purchase. Transportation charges on parts,
or products in whole, submitted for repair or replacement, under this warranty, must be borne by the
purchaser.
CONDITIONS: This warranty is valid for the original retail purchaser from the date of initial retail purchase
and is not transferable. Keep the original sales receipt. Proof of purchase is required to obtain warranty
service or replacement. Dealers, service centers, or retail stores do not have the right to alter, modify or
in any way, change the terms and conditions of this warranty.
Warranty registration is not necessary to obtain warranty on Select Brands, Inc. products. Save your proof
of purchase receipt.
ABOUT YOUR PRODUCT WARRANTY: Most warranty repairs are handled routinely, but sometimes
requests for warranty service may not be appropriate. For example, warranty service would NOT apply
if the product damage occurred because of misuse, lack of routine maintenance, shipping, handling,
warehousing or improper installation. Similarly, the warranty is void if the manufacturing date or the
serial number on the product has been removed or the equipment has been altered or modied. During
the warranty period, the authorized service dealer, at its option, will repair or replace any part that, upon
examination, is found to be defective under normal use and service.
NORMAL WEAR: This warranty does not cover normal wear of parts or damage resulting from any
of the following: Negligent use or misuse of the product; Improper voltage or current; Use contrary to
the operation instructions; Deviation from instructions regarding storage and transportation; Repair or
alteration by anyone other than SELECT BRANDS, INC. or an authorized service center. Further, the
warranty does not cover Acts of God, such as re, ood, hurricanes and tornadoes.
SELECT BRANDS, INC. shall not be liable for any incidental or consequential damages caused by the
breach of any express or implied warranty. Except to the extent prohibited by applicable law, any implied
warranty of merchantability or tness for a particular purpose is limited in duration to the duration of
the above warranty. Some states, provinces or jurisdictions do not allow the exclusion or limitation of
incidental o consequential damages or limitations on how long an implied warranty lasts, so the above
limitations or exclusion may not apply to you. This warranty gives you specic legal rights, and you may
also have other rights that vary from state to state or province to province.
HOW TO OBTAIN WARRANTY SERVICE: You must contact SELECT BRANDS, INC. Customer Service
at 1-913-663-4500. A Customer Service representative will attempt to resolve warranty issues over the
phone. If telephone resolution is not possible, the Customer Service representative will require your
assistance in performing routine diagnostic procedures. This warranty is effective for the time periods
listed above and subject to the conditions provided for in this policy.
To register this product and view other ne products, visit us online at www.selectbrands.com
SILHOUETTE is a registered trademark of Select Brands, Inc. 66219
Made in China

8
