OVERVIEW
The SiliconDrive 2.5" Drive is an optimal
time-to-market replacement for hard
drives and flash cards or in host systems
that require low power and scalable
storage solutions.
SiliconDrive technology is engineered
exclusively for the high performance, high
reliability, and multiyear product lifecycle
requirements of the Enterprise System
OEM market. Typical end-market
applications include broadband data and
voice networks, military systems, flight
system avionics, medical equipment,
industrial control systems, video
surveillance, storage networking, VoIP,
wireless infrastructure, and interactive
kiosks.
Every SiliconDrive is integrated with
SiliconSystems’ patented PowerArmor
and patent-pending SiSMART
technologies to virtually eliminate storage
systems failures.
PowerArmor prevents data corruption and
loss from power disturbances by
integrating patented technology into every
SiliconDrive.
SiSMART acts as an early warning system
to eliminate unscheduled downtime by
constantly monitoring and reporting the
exact amount of remaining storage system
useful life.
Numerous SiliconSystems’ patented and
patent-pending application-specific
technologies can be integrated into
SiliconDrive to safeguard application data
and software IP. Application notes
detailing these performance-enhancing
options are available under NDA.
FEATURES
• RoHS 6 of 6 compliant
• Integrated PowerArmor and SiSMART
technologies
• Capacity range: 128MB to 16GB
• Supports both 8-bit and 16-bit data
register transfers
• Supports dual-voltage 3.3V or 5V
interface
• Data reliability <1 error in 1014 bits read
• MTBF 4,000,000 hours
• ATA-3 compliant
• Industry standard 2.5" Drive form factor
• Supports PIO modes 0-4 and DMA
modes 0-2
16GB
SSD-D16G(I)-3600
Click here Click here
DATA SHEET
SILICONDRIVE 2.5" DRIVE
SSD-DXXX(I)-3600

REVISION HISTORY SSD-DXXX(I)-3600 DATA SHEET
SILICONSYSTEMS PROPRIETARY
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
All unauthorized use and/or reproduction is prohibited.
3600D-04DSR PAGE II FEBRUARY 2, 2009
REVISION HISTORY
Document No. Release Date Changes
3600D-05DSR February 2, 2009 Updated:
• "System Reliability" table and changed
the name to "Reliability."
• "Related Documentation" table.
Added:
• “Projected Operational Life Span.”
3600D-04DSR August 7, 2008 Updated "Physical Dimensions."
3600D-03DSR May 22, 2008 Updated:
• “Overview.”
• SiProtect information.
SSDS02-3600D-R February 25, 2008 Added a Note below the “DC
Characteristics” table.
SSDS01-3600D-R December 17, 2007 Updated the tRWD Maximum in the “True IDE
Multiword DMA Read/Write Access Timing”
table.
SSDS00-3600D-R September 28, 2007 Initial release.

TABLE OF CONTENTS SSD-DXXX(I)-3600 DATA SHEET
SILICONSYSTEMS PROPRIETARY
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
All unauthorized use and/or reproduction is prohibited.
3600D-04DSR PAGE III FEBRUARY 2, 2009
TABLE OF CONTENTS
Overview.......................................................................................................................... i
Features........................................................................................................................... i
Revision History..............................................................................................................II
List of Figures................................................................................................................VI
List of Tables.................................................................................................................VII
Physical Specifications.................................................................................................1
Physical Dimensions .................................................................................................... 1
Pin Locations................................................................................................................ 2
Jumper Settings ........................................................................................................... 2
Product Specifications.................................................................................................. 3
System Performance.................................................................................................... 3
System Power Requirements....................................................................................... 3
Reliability...................................................................................................................... 4
Projected Operational Life Span .................................................................................. 4
Product Capacity Specifications................................................................................... 5
Environmental Specifications ....................................................................................... 5
Electrical Specification.................................................................................................. 6
Pin Assignments........................................................................................................... 6
Signal Descriptions....................................................................................................... 7
Absolute Maximum Ratings.......................................................................................... 9
Capacitance ................................................................................................................. 9
DC Characteristics ..................................................................................................... 10
AC Characteristics...................................................................................................... 11
I/O Access Read Timing....................................................................................... 11
I/O Access Write Timing....................................................................................... 12
True IDE Read/Write Access Timing.................................................................... 13
True IDE Multiword DMA Read/Write Access Timing .......................................... 14

TABLE OF CONTENTS SSD-DXXX(I)-3600 DATA SHEET
SILICONSYSTEMS PROPRIETARY
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
All unauthorized use and/or reproduction is prohibited.
3600D-04DSR PAGE IV FEBRUARY 2, 2009
ATA and True IDE Register Decoding ........................................................................ 15
Task File Register Specification ................................................................................. 15
ATA Registers............................................................................................................... 16
Data Register ............................................................................................................. 16
Error Register............................................................................................................. 16
Feature Register......................................................................................................... 17
Sector Count Register................................................................................................ 18
Sector Number Register............................................................................................. 19
Cylinder Low Register ................................................................................................ 20
Cylinder High Register ............................................................................................... 21
Drive/Head Register................................................................................................... 22
Status Register........................................................................................................... 23
Command Register .................................................................................................... 24
Alternate Status Register ........................................................................................... 25
Device Control Register ............................................................................................. 26
Device Address Register............................................................................................ 27
ATA Command Block and Set Description................................................................ 28
ATA Command Set .................................................................................................... 28
Check Power Mode — 98h, E5h .......................................................................... 30
Executive Drive Diagnostic — 90h....................................................................... 31
Format Track — 50h ............................................................................................ 32
Identify Drive — ECh............................................................................................ 33
Identify Drive — Drive Attribute Data ............................................................. 34
Idle — 97h, E3h.................................................................................................... 37
Idle Immediate — 95h, E1h.................................................................................. 38
Initialize Drive Parameters — 91h........................................................................ 39
Recalibrate — 1Xh ............................................................................................... 40
Read Buffer — E4h .............................................................................................. 41
Read DMA — C8h................................................................................................ 42

TABLE OF CONTENTS SSD-DXXX(I)-3600 DATA SHEET
SILICONSYSTEMS PROPRIETARY
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
All unauthorized use and/or reproduction is prohibited.
3600D-04DSR PAGE VFEBRUARY 2, 2009
Read Multiple — C4h ........................................................................................... 43
Read Sector — 20h, 21h...................................................................................... 44
Read Long Sector(s) — 22h, 23h......................................................................... 45
Read Verify Sector(s) — 40h, 41h ....................................................................... 46
Seek — 7Xh ......................................................................................................... 47
Set Features — EFh............................................................................................. 48
Set Multiple Mode — C6h .................................................................................... 49
Set Sleep Mode — 99h, E6h................................................................................ 50
Standby — 96h, E2h ............................................................................................ 51
Standby Immediate — 94h, E0h .......................................................................... 52
Write Buffer — E8h .............................................................................................. 53
Write DMA — CAh ............................................................................................... 54
Write Multiple — C5h ........................................................................................... 55
Write Sector(s) — 30h, 31h.................................................................................. 56
Write Long Sector(s) — 32h, 33h......................................................................... 57
Erase Sector(s) — C0h ........................................................................................ 58
Request Sense — 03h ......................................................................................... 59
Translate Sector — 87h ....................................................................................... 60
Wear-Level — F5h ............................................................................................... 61
Write Multiple w/o Erase — CDh.......................................................................... 62
Write Sector(s) w/o Erase — 38h......................................................................... 63
Write Verify — 3Ch............................................................................................... 64
Sales and Support ....................................................................................................... 65
Part Numbering............................................................................................................ 65
Nomenclature ............................................................................................................. 65
Part Numbers ............................................................................................................. 65
RoHS 6 of 6 Product Labeling — Pb-Free Identification Label .................................. 66
Sample Label ............................................................................................................. 66
Related Documentation............................................................................................... 67

LIST OF FIGURES SSD-DXXX(I)-3600 DATA SHEET
SILICONSYSTEMS PROPRIETARY
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
All unauthorized use and/or reproduction is prohibited.
3600D-04DSR PAGE VI FEBRUARY 2, 2009
LIST OF FIGURES
Figure 1: Physical Dimensions......................................................................................... 1
Figure 2: Pin Locations .................................................................................................... 2
Figure 3: Jumper Settings................................................................................................ 2
Figure 4: I/O Access Read Timing Diagram .................................................................. 11
Figure 5: I/O Access Write Timing Diagram................................................................... 12
Figure 6: True IDE Read/Write Access Timing Diagram ............................................... 13
Figure 7: True IDE Multiword DMA Read/Write Access Timing..................................... 14
Figure 8: Sample Label.................................................................................................. 66

LIST OF TABLES SSD-DXXX(I)-3600 DATA SHEET
SILICONSYSTEMS PROPRIETARY
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
All unauthorized use and/or reproduction is prohibited.
3600D-04DSR PAGE VII FEBRUARY 2, 2009
LIST OF TABLES
Table 1: System Performance ......................................................................................... 3
Table 2: System Power Requirements ............................................................................ 3
Table 3: Reliability............................................................................................................4
Table 4: Operational Life Span ........................................................................................ 4
Table 5: Product Capacity Specifications ........................................................................ 5
Table 6: Environmental Specifications............................................................................. 5
Table 7: Pin Assignments ................................................................................................ 6
Table 8: Signal Descriptions ............................................................................................ 7
Table 9: Absolute Maximum Ratings ............................................................................... 9
Table 10: Capacitance..................................................................................................... 9
Table 11: DC Characteristics ......................................................................................... 10
Table 12: I/O Access Read Timing ................................................................................ 11
Table 13: I/O Access Write Timing ................................................................................ 12
Table 14: True IDE Read/Write Access Timing ............................................................. 13
Table 15: True IDE Multiword DMA Read/Write Access Timing.................................... 14
Table 16: Task File Register Specification..................................................................... 15
Table 17: Error Register................................................................................................. 16
Table 18: Feature Register ............................................................................................ 17
Table 19: Sector Count Register.................................................................................... 18
Table 20: Sector Number Register ................................................................................ 19
Table 21: Cylinder Low Register.................................................................................... 20
Table 22: Cylinder High Register ................................................................................... 21
Table 23: Drive/Head Register....................................................................................... 22
Table 24: Status Register .............................................................................................. 23
Table 25: Command Register........................................................................................ 24
Table 26: Alternate Status Register............................................................................... 25
Table 27: Device Control Register ................................................................................. 26

LIST OF TABLES SSD-DXXX(I)-3600 DATA SHEET
SILICONSYSTEMS PROPRIETARY
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
All unauthorized use and/or reproduction is prohibited.
3600D-04DSR PAGE VIII FEBRUARY 2, 2009
Table 28: Device Address Register ............................................................................... 27
Table 29: ATA Command Block and Set Description .................................................... 28
Table 30: ATA Command Set ........................................................................................ 28
Table 31: Check Power Mode — 98h, E5h.................................................................... 30
Table 32: Executive Drive Diagnostic — 90h................................................................. 31
Table 33: Format Track — 50h ...................................................................................... 32
Table 34: Identify Drive — ECh ..................................................................................... 33
Table 35: Identify Drive — Drive Attribute Data ............................................................. 34
Table 36: Idle — 97h, E3h ............................................................................................. 37
Table 37: Idle Immediate — 95h, E1h ........................................................................... 38
Table 38: Initialize Drive Parameters — 91h ................................................................. 39
Table 39: Recalibrate — 1Xh......................................................................................... 40
Table 40: Read Buffer — E4h........................................................................................ 41
Table 41: Read DMA — C8h ......................................................................................... 42
Table 42: Read Multiple — C4h..................................................................................... 43
Table 43: Read Sector — 20h, 21h ............................................................................... 44
Table 44: Read Long Sector(s) — 22h, 23h .................................................................. 45
Table 45: Read Verify Sector(s) — 40h, 41h................................................................. 46
Table 46: Seek — 7Xh................................................................................................... 47
Table 47: Set Features — EFh ...................................................................................... 48
Table 48: Set Features’ Attributes ................................................................................. 48
Table 49: Set Multiple Mode — C6h .............................................................................. 49
Table 50: Set Sleep Mode — 99h, E6h ......................................................................... 50
Table 51: Standby — 96h, E2h...................................................................................... 51
Table 52: Standby Immediate — 94h, E0h .................................................................... 52
Table 53: Write Buffer — E8h........................................................................................ 53
Table 54: Write DMA — CAh ......................................................................................... 54
Table 55: Write Multiple — C5h..................................................................................... 55
Table 56: Write Sector(s) — 30h, 31h ........................................................................... 56

LIST OF TABLES SSD-DXXX(I)-3600 DATA SHEET
SILICONSYSTEMS PROPRIETARY
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
All unauthorized use and/or reproduction is prohibited.
3600D-04DSR PAGE IX FEBRUARY 2, 2009
Table 57: Write Long Sector(s) — 32h, 33h .................................................................. 57
Table 58: Erase Sector(s) — C0h.................................................................................. 58
Table 59: Request Sense — 03h................................................................................... 59
Table 60: Extended Error Codes ................................................................................... 59
Table 61: Translate Sector — 87h................................................................................. 60
Table 62: Wear-Level — F5h......................................................................................... 61
Table 63: Write Multiple w/o Erase — CDh ................................................................... 62
Table 64: Write Sector(s) w/o Erase — 38h .................................................................. 63
Table 65: Write Verify — 3Ch ........................................................................................ 64
Table 66: Part Numbering Nomenclature ...................................................................... 65
Table 67: Part Numbers................................................................................................. 65
Table 68: Related Documentation ................................................................................. 67

PHYSICAL SPECIFICATIONS SSD-DXXX(I)-3600 DATA SHEET
SILICONSYSTEMS PROPRIETARY
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
All unauthorized use and/or reproduction is prohibited.
3600D-04DSR PAGE 1FEBRUARY 2, 2009
PHYSICAL SPECIFICATIONS
The SiliconDrive 2.5" Drive products are offered in an industry-standard 2.5"
Drive form factor. See "Part Numbering" on page 65 for details regarding 2.5"
Drive capacities.
PHYSICAL DIMENSIONS
This section provides diagrams that describe the physical dimensions for the
2.5" Drive.
Figure 1: Physical Dimensions
Dimension Millimeters Tolerance (mm) Dimension Millimeters Tolerance (mm)
A 100.00 ±0.25 L 69.85 ±0.25
B 90.60 ±0.125 M 2.00 ±0.125
C 73.03 ±0.125 N 9.40 ±0.10
D 34.93 ±0.125 P 6.00 ±0.125
E 14.00 ±0.125 Q 11.57 ±0.125
F 4.08 ±0.125 R 32.10 ±0.125
G 61.70 ±0.125 S 14.93 ±0.125
H 4.68 ±0.125 T 11.00 ±0.125
I 64.42 ±0.125 U 4.65 ±0.125
J 10.14 ±0.51 V 4.00 ±0.125
K 3.99 ±0.43 W 6.15 ±0.125

PHYSICAL SPECIFICATIONS SSD-DXXX(I)-3600 DATA SHEET
SILICONSYSTEMS PROPRIETARY
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
All unauthorized use and/or reproduction is prohibited.
3600D-04DSR PAGE 2FEBRUARY 2, 2009
PIN LOCATIONS
The following diagram identifies the pin locations of the 2.5" Drive.
Figure 2: Pin Locations
JUMPER SETTINGS
The following diagram defines the SiliconDrive 2.5" Drive jumper settings.
Figure 3: Jumper Settings

PRODUCT SPECIFICATIONS SSD-DXXX(I)-3600 DATA SHEET
SILICONSYSTEMS PROPRIETARY
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
All unauthorized use and/or reproduction is prohibited.
3600D-04DSR PAGE 3FEBRUARY 2, 2009
PRODUCT SPECIFICATIONS
Note: All SiliconDrive 2.5" Drive values quoted are typical at 25°C and
nominal supply voltage.
SYSTEM PERFORMANCE
SYSTEM POWER REQUIREMENTS
Note: The 5V is the only operation for the 16GB capacity.
Table 1: System Performance
Reset to Ready Startup Time (Typical/Maximum) 200ms/400ms
Read Transfer Rate (Typical) 8MBps
Write Transfer Rate (Typical) 6MBps
Burst Transfer Rate 16.7MBps
Controller Overhead (Command to DRQ) 2ms (maximum)
Table 2: System Power Requirements
DC Input Voltage 3.3 ± 10% 5.0 ± 10%
Sleep (Standby Current) <0.5mA <1.0mA
Read (Typical/Peak) 20mA/75mA 30mA/100mA
Write (Typical/Peak) 30mA/75mA 40mA/100mA

PRODUCT SPECIFICATIONS SSD-DXXX(I)-3600 DATA SHEET
SILICONSYSTEMS PROPRIETARY
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
All unauthorized use and/or reproduction is prohibited.
3600D-04DSR PAGE 4FEBRUARY 2, 2009
RELIABILITY
PROJECTED OPERATIONAL LIFE SPAN
* There are unlimited read cycles. Service life is determined using
SiliconSystems’ LifeEst calculation at 100% duty cycle with 25% write cycles.
LifeEst is a comprehensive measurement that considers numerous factors to
determine the projected life span of a SiliconDrive. A white paper that
describes the benefits of LifeEst and how to calculate it can be found at http://
www.siliconsystems.com/resources/Documents/Whitepaper/
SiliconSystems_NAND_Evolution.pdf.
The actual life of a SiliconDrive is dependant on the customer usage model.
SiSMART is a patented technology of SiliconSystems that enables host
systems to monitor actual usage of a SiliconDrive in real time. SiSMART
measures and reports the remaining life of a SiliconDrive. For more
information on SiSMART, refer to the Eliminating Unscheduled Downtime by
Forecasting Useable Life white paper at http://www.siliconsystems.com/
technology/pdfs/SiliconDrive_SiSMART.pdf.
Table 3: Reliability
MTBF (@ 25ºC) 4,000,000 hours
Bit Error Rate <1 non-recoverable error in 1014 bits read
Table 4: Operational Life Span
SiliconDrive Part# Capacity Service Life* GB Written per Day
SSD-D16G-3600 16GB 648.7 Years @ 135.2GB
SSD-D08G-3600 8GB 324.3 Years @ 135.2GB
SSD-D04G-3600 4GB 162.2 Years @ 135.2GB
SSD-D02G-3600 2GB 81.1 Years @ 135.2GB
SSD-D01G-3600 1GB 40.5 Years @ 135.2GB
SSD-D51M-3600 512MB 20.3 Years @ 135.2GB
SSD-D25M-3600 256MB 10.1 Years @ 135.2GB
SSD-D12M-3600 128MB 5.1 Years @ 135.2GB

PRODUCT SPECIFICATIONS SSD-DXXX(I)-3600 DATA SHEET
SILICONSYSTEMS PROPRIETARY
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
All unauthorized use and/or reproduction is prohibited.
3600D-04DSR PAGE 5FEBRUARY 2, 2009
PRODUCT CAPACITY SPECIFICATIONS
* = All IDE drives 8GB and larger use 16383 cylinders, 16 heads, and 63 sectors/track due to
interface restrictions.
ENVIRONMENTAL SPECIFICATIONS
Table 5: Product Capacity Specifications
Product
Capacity Capacity (Bytes) Number of Sectors Number of Cylinders Number of Heads
Numberof
Sectors/
Track
128MB 130,154,496 254,208 993 8 32
256MB 260,571,136 508,928 994 16 32
512MB 521,773,056 1,019,088 1011 16 63
1GB 1,047,674,880 2,046,240 2030 16 63
2GB 2,098,446,336 4,098,528 4066 16 63
4GB 4,224,761,856 8,251,488 8186 16 63
8GB 8,455,200,768 16,514,064 16,383* 16 63
16GB 16,494,428,160 32,215,680 16,383* 16 63
Table 6: Environmental Specifications
Temperature 0ºC to 70ºC (Commercial)
-40ºC to 85ºC (Industrial)
Humidity 8% to 95% non-condensing
Vibration 16.3gRMS, MIL-STD-810F, Method 514.5, Procedure I,
Category 24
Shock 1000G, Half-sine, 0.5ms Duration
50g Pk, MIL-STD-810F, Method 516.5, Procedure I
Altitude 80,000ft, MIL-STD-810F, Method 500.4, Procedure II

ELECTRICAL SPECIFICATION SSD-DXXX(I)-3600 DATA SHEET
SILICONSYSTEMS PROPRIETARY
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
All unauthorized use and/or reproduction is prohibited.
3600D-04DSR PAGE 6FEBRUARY 2, 2009
ELECTRICAL SPECIFICATION
PIN ASSIGNMENTS
The following table describes the SiliconDrive 2.5" Drive 44-pin IDE connector
signals. Table 7: Pin Assignments
Pin IDE-ATA Pin IDE-ATA
1-RESET 2GND
3D7 4D8
5D6 6D9
7D5 8D10
9D4 10D11
11 D3 12 D12
13 D2 14 D13
15 D1 16 D14
17 D0 18 D15
19 GND 20 KEY
21 DMARQ 22 GND
23 -IOWR 24 GND
25 -IORD 26 GND
27 IORDY 28 -CSEL
29 -DMACK 30 GND
31 INTRQ 32 -IOCS16
33 A1 34 -PDIAG
35 A0 36 A2
37 -CS0 38 -CS1
39 -DASP 40 GND
41 VCC 42 VCC
43 GND 44 NC

ELECTRICAL SPECIFICATION SSD-DXXX(I)-3600 DATA SHEET
SILICONSYSTEMS PROPRIETARY
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
All unauthorized use and/or reproduction is prohibited.
3600D-04DSR PAGE 7FEBRUARY 2, 2009
SIGNAL DESCRIPTIONS
Table 8: Signal Descriptions
Signal Name Pin(s) Type Description
A2-A0 36, 33,
35
IAddress Inputs. These signals are
asserted by the host to access the task
registers in the device.
-CS0,-CS1 37, 38 I In the true IDE mode, -CS0 is the chip
select for the task file registers while -CS1
is used to select the Alternate Status
register and the Device Control register.
-CSEL 28 I Cable Select. This internally pulled-up
signal is used to configure this device as a
master or a slave when the jumper
configuration is in CSEL mode.
When this pin is:
• Grounded by the host, this device is
configured as a master.
• Open, this device is configured as a
slave.
D15-D0 18, 16,
14, 12,
10, 8, 6,
4, 3, 5, 7,
9, 11, 13,
15, 17
I/O Data Inputs/Outputs. This is the 8-bit or
16-bit bidirectional interface between the
host and device. The lower eight bits are
used for 8-bit register transfers.
-DMACK 29 I DMA Acknowledge. This signal is used by
the host in response to DMARQ to initiate
DMA transfers. The DMARQ/-DMACK
handshake is used to provide flow control
during the transfer. When -DMACK is
asserted, -CS0 and -CS1 are not asserted
and transfers are 16-bits wide.
DASP 39 I/O Disk Active/Slave Present. This open
drain output signal is asserted low any time
the drive is active. In a master/slave
configuration, this signal is used by the
slave to inform the master that a slave is
present.

ELECTRICAL SPECIFICATION SSD-DXXX(I)-3600 DATA SHEET
SILICONSYSTEMS PROPRIETARY
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
All unauthorized use and/or reproduction is prohibited.
3600D-04DSR PAGE 8FEBRUARY 2, 2009
DMARQ 21 O DMA Request. This signal is used for DMA
transfers between the host and device.
DMARQ is asserted by the device when the
device is ready to transfer data to/from the
host. The direction of data transfer is
controller by -IORD and -IOWR. This signal
is used in a handshake manner with
-DMACK (i.e., the device waits until the
host asserts -DMACK before negating
DMARQ, and reasserts DMARQ if there is
more data to transfer). The DMARQ/
-DMACK handshake is used to provide flow
control during the transfer.
GND 2, 19, 22,
24, 26,
30, 40,
43
-Ground. The device ground signal.
INTRQ 31 O Interrupt Request. This signal is an active
high interrupt request to the host.
IORDY 27 I I/O Channel Ready. The signal is negated
to extend the host transfer cycle of any host
register access.
-IORD 25 I Device I/O Read. This is the read strobe
signal from the host. The falling edge of
IORD enables data from the device onto
the data bus. The rising edge of IORD
latches data at the host. The host does not
act on the data until it is latched.
-IOWR 23 I Device I/O Write. This is the write strobe
signal from the host. The rising edge of
IOWR# latches data from the data bit
signals. The device does not act on the
data until it is latched.
KEY 20 - Key. Reserved for the Connector Key.
-PDIAG 34 I/O Pass Diagnostic. This open drain signal is
asserted by the slave to indicate to the
master that it has passed its diagnostics.
Table 8: Signal Descriptions (Continued)
Signal Name Pin(s) Type Description

ELECTRICAL SPECIFICATION SSD-DXXX(I)-3600 DATA SHEET
SILICONSYSTEMS PROPRIETARY
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
All unauthorized use and/or reproduction is prohibited.
3600D-04DSR PAGE 9FEBRUARY 2, 2009
ABSOLUTE MAXIMUM RATINGS
CAPACITANCE
-RESET 1 I Device Reset. An active low signal. When
active, this signal sets all internal registers
to their default state. This signal is held
asserted until at least 25μs after power has
been stabilized during the device power-on.
VCC 41, 42 - Device Power Supply. The device power
+3.3V/5V signal.
Table 8: Signal Descriptions (Continued)
Signal Name Pin(s) Type Description
Table 9: Absolute Maximum Ratings
Symbol Parameter Minimum Maximum Units
TsStorage Temperature -55 125 °C
TAOperating Temperature -40 85 °C
VCC VCC with Respect to GND -0.3 6.7 V
Vin Input Voltage -0.5 3.8 V
Vout Output Voltage -0.3 3.6 V
Table 10: Capacitance
Symbol Parameter Maximum Units
Cin Input Capacitance 35 pF
Cout Output Capacitance 35 pF
CI/O Bidirectional Capacitance 35 pF

ELECTRICAL SPECIFICATION SSD-DXXX(I)-3600 DATA SHEET
SILICONSYSTEMS PROPRIETARY
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
All unauthorized use and/or reproduction is prohibited.
3600D-04DSR PAGE 10 FEBRUARY 2, 2009
DC CHARACTERISTICS
*(1) Except the pulled-up/pulled-down pin.
Table 11: DC Characteristics
Symbol Parameter 5V ±10% Units
Minimum Maximum
VCC Power Supply Voltage 4.5 5.5 V
ILI Input Leakage *(1) Current - 5 μA
ILO Output Leakage *(1) Current - 5 μA
VCCR VCC Read Current - 80 mA
VCCW VCC Write Current - 80 mA
VCCS VCC Standby Current - 0.5 mA
VIL Input Low Voltage -0.3 0.3 x VCC V
VIH Input High Voltage 7 x VCC V
CC + 0.3 V
VOL Output Low Voltage - 0.4 V
VOH Output High Voltage VCC - 0.4 - V

ELECTRICAL SPECIFICATION SSD-DXXX(I)-3600 DATA SHEET
SILICONSYSTEMS PROPRIETARY
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
All unauthorized use and/or reproduction is prohibited.
3600D-04DSR PAGE 11 FEBRUARY 2, 2009
AC CHARACTERISTICS
I/O Access Read Timing
Figure 4: I/O Access Read Timing Diagram
Note: (1) IOIS16 and INPACK are not supported.
Table 12: I/O Access Read Timing
Symbol Parameter Minimum Maximum Units
tDVRL Data Delay after IORD - 50 ns
tIGHQX Data Hold following IORD 5 - ns
tIGLIGH IORD Pulse Width 65 - ns
tAVIGL Address Setup before IORD 25 - ns
tGHAX Address Hold following IORD 10 - ns
tCLIGL CE Setup before IORD 5 - ns
tCHIGH CE Hold following IORD 10 - ns
tRLIGL REG Setup before IORD 5 - ns
tRHIGH REG Hold following IORD 0 - ns
tIGLINL INPACK Delay falling from IORD - (1) ns
tIGHINH INPACK Delay Rising from IORD - (1) ns
tAVISL IOIS16 Delay Falling from Address - (1) ns
tAXISH IOIS16 Delay Rising from Address - (1) ns
A[10::0]
____
REG
__
CE
___
IORD
______
INPACK
______
IOIS16
tRLIGL
tGHAX
D[15::0]
tCLIGL tCHIGH
tRHIGH
tIGLIGH
tAVIGL tIGHINH
tIGLINL tAXISH
tAVISL
tDVRL tIGHQX
