SilverOnyx S7 User manual

S7 CORDLESS STICK VACUUM
Instruction Manual
- Version 1.0 -
Please keep in a safe place for reference.

Important Safety Instructions
IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE.
RETAIN INSTRUCTIONS FOR FUTURE REFERENCE.
Do not use in rain or leave outdoors while raining.
WARNING: Basic safety precautions should always be observed when using an
electrical appliance, including the following to reduce the risk of re, electrical
shock, or injury.
Personal Safety:
1. Store indoors in a dry place out of the reach of children.
2. Always use responsibly. This appliance can be used by children age 10 years and older.
Persons with reduced physical, sensory or mental capabilities, or lack of experience and
knowledge may use this appliance if they have been given supervision or instruction
concerning the safe use of the appliance and understand the hazards involved.
3. Don’t let children play with the appliance; supervise children using or maintaining the
appliance.
4. Use only manufacturer’s recommended attachments as described in this manual; misuse
or use of any accessory or attachment other than those recommended, may present a risk
of personal injury.
5. Take extra care when cleaning stairs.
6. Keep the appliance and accessories away from hot surface.
7. Do not block the appliances openings or hinder air ow, keep openings free of any
objects including clothing and ngers (and all parts of the body).
Electrical Safety:
1. Only use batteries and chargers supplied by the manufacturer.
2. Never modify the charger in any way.
3. The charger has been designed for a specic voltage. Always check that the mains
voltage is the same as that stated on the rating plate.
4. A charger that is suitable for one type of battery pack may create a risk of re when used
with another battery pack.
5. Before use, check the charger cord for signs of damage or ageing. A damaged or
entangled charger cord increases the risk of re and electric shock.
6. Do not abuse the charger cord.
7. Never carry the charger by the cord.
8. Do not pull the cord to disconnect from a socket, grasp the plug and pull to disconnect.
9. Don’t wrap the cord around the charger when storing.
10. Keep the charger cord away from hot surfaces and sharp edges.
11. The supply cord cannot be replaced. If the cord is damaged the charger should be
discarded and replaced.
12. Do not handle the charger or the appliance with wet hands.
13. Do not store or charge the appliance outdoors.
14. The charger must be removed from the socket before removing the battery, cleaning or
maintaining the appliance.
1
Important Safety Instructions

Battery safety:
1. This appliance includes Li-ion batteries, do not incinerate batteries or expose to high
temperatures, as they may explode.
2. Liquid ejected from the battery may cause irritation or burns.
3. In an emergency situation contact professional help immediately.
4. Leaks from the battery cells can occur under extreme conditions. Do not touch any liquid
that leaks from the battery. If the liquid gets on skin wash immediately with soap and
water. If the liquid gets into the eyes, ush them immediately with clean water for a
minimum of 10 minutes and seek medical attention. Wear gloves to handle the battery
and dispose of immediately in accordance with local regulations.
5. Shorting the battery terminals may cause burns or re.
6. When the battery pack is not in use, keep it away from paper clips, coins, keys, nails,
screws or other small metal objects that could make a connection from one terminal to
another.
7. When you dispose of the appliance remove the battery and dispose of the battery safely
in accordance with local regulations.
Service:
1. Before using the appliance and after any impact, check for signs of wear or damage and
repair as necessary.
2. Do not use the appliance if any part is damaged or defective.
3. Repairs should be carried out by a service agent or a suitably qualied person in
accordance with relevant safety regulations. Repairs by unqualied persons could be
dangerous.
4. Never modify the appliance in any way as this may increase the risk of personal injury.
5. Only use replacement parts or accessories provided or recommended by manufacturer.
Intended use:
1. This appliance has been designed for domestic dry vacuum cleaning only.
2. Do not pick up liquids or use on wet surfaces.
3. Do not pick up anything that is ammable, burning, or smoking.
4. Use only as described in this manual.
5. Don’t use on concrete, asphalt, or other rough surfaces.
WARNING:
1. Do not use water, solvents, or polishes to clean the outside of the appliance; wipe clean
with a dry cloth.
2. Never immerse the unit in water and do not clean in a dish washer.
2
Important Safety Instructions
Important Safety Instructions

3
Components
Components
HANDHELD/
MOTOR
HANDLE
POWER Switch
HANDHELD
RELEASE
CHARGING SEAT BACK
BRUSH Accessory
CREVICE TOOL
CHARGER
CHARGING SEAT BASE
LED Lamp
FLOOR BRUSH
WHEELS
ROTATING
BRUSH
CHARGING
Port
DUST Collector
POWER Button
CHARGING
Indicator
HANDLE
SUCTION Inlet
AIR Outlet
DUST Collector
Release Button
ACCESSORIES

2
4
1 2
Insert power adapter into
power input on bottom of
charging base, then feed
through groove in base.
First Use
First Use
Place nose of handheld unit
in groove on base, and push
handle until it snaps in place.
1
Slide charging back into charging
base and snap into place.
1 2
1) Remove screw from back of
handle;
2) Slide handle over base;
3) Insert and
tighten screw to
secure handle
to base.
Plug power
supply adapter
into wall outlet.
When charging
begins the
indicator will turn
red. Charging will
be complete in
about 5 hours, at
which time the
indicator will turn
off.
ASSEMBLE CHARGER
ASSEMBLE HANDLE
Place vacuum
on charging
base, aligning
the charging
port with the
adapter on
the base.
CHARGING
Charging
Port

5
Operating the Vacuum
Operating the Vacuum
1 2
3 4
When in operation, the
charging indicator will be
solid green.
Slide the POWER swich
down once to turn on the
appliance in low speed.
Slide again for high speed,
and slide up to turn off.
The vacuum is
equipped with
an LED lamp to
see dark corners,
under furniture,
etc.
Press the
RELEASE
lock button
to remove
the handheld
unit from the
vacuum.
5Insert CREVICE tool into
suction end of handheld
unit for cleaning in tight
areas.
1x
Low
2x
High
6Insert BRUSH tool into
suction end of handheld
unit for cleaning
of fabrics, glass,
electronics, etc.

6
Care & Maintenance
Care & Maintenance
1 2
3
5
Press the dust collector
release button to remove
from the body of the
handheld unit.
Empty dust collector into
trash bin.
Gently knock debris and
dust from the lter ele-
ment and lter screen.
6Reassemble lter and dust
collector, then attach to
body (see diagram below) -
you will hear a click sound
when connected properly.
4
Lift off dust collector and
remove the lter.
Remove lter element
from lter screen.
DUST COLLECTOR
EMPTY DUST CUP

7
Care & Maintenance
Care & Maintenance
1 2
3 4
Remove the driving belt from
the brush.
Use a coin
to unlock
the brush
compartment
on the
underside
of the brush
head as
shown here.
Pull brush to remove from
brush head.
Carefully cut away any
hair, yarn, or other debris
entangled in the brush.
CLEAN BRUSH HEAD
5Clean the brush by running
under water. NOTE: be
sure to let the brush dry
thoroughly before replacing.
6Remove any trapped debris
from the underside of the
brush head, and wipe down
with a damp cloth.
Driving
Belt

8
Care & Maintenance
Care & Maintenance
1 1
2 3
After removing the
dust collector from
the body, remove
the lter screen and
lter element. The
dust collector may
then be washed
with a mild soap
and soft cloth/
sponge.
Filter screen and lter
element may be washed with
a mild soap and soft brush/
cloth. Rinse lter
element under
running water
to remove any
polluntants.
NOTE: be sure to
let all parts dry
thoroughly before
reassembly.
1 2
Use a screwdriver to access the
battery on the underside of the
handheld unit.
Pull battery to remove, then
while pressing down on the
tab, pull the battery connec-
tor apart to disconnect. Insert
new battery in reverse order.
CLEAN DUST CUP CLEAN FILTER
Before washing the lter screen and
lter element, carefully knock out
any dust or debris.
REPLACE BATTERY

9
Troubleshooting
Troubleshooting
Problem Battery
Indicator
Possible Cause Solution
Appliance
cannot be
recharged.
Charging
indicator does
not light.
1. The charging plug may
be loose in the socket.
2. Power adapter is not
securely attached to the
appliance.
Attach the power adapter
securely to the appliance.
Battery
indicator stays
on longer than
6 hours.
The internal PCB board
may be defective or
damaged.
This problem can only be
xed by a professionally
trained person. Please
send or take appliance to
an after-service depot.
Floor brush
does not work,
and handheld
unit does not
work either.
Battery
indicator does
not light up.
1. Power is off.
2. Brush is totally blocked
by hair or other debris.
3. There may be a short on
the circuit inside the brush.
1. Recharge the appliance.
2. Remove blockage from
brush.
3. This problem can only
be xed by a professionally
trained person. Please
send or take appliance to
an after-service depot.
Brush does
not work, but
handheld
unit works
normally.
Battery
indicator is
normal.
The rubber belt inside the
brush head may be loose.
Check the drive belt (see
cleaning instructions
on Page 7). If belt is
connected properly, please
send or take appliance to
an after-service depot.
Appliance
does not pick
up debris /
suction power
is weak.
Batter indicator
is normal.
1. Dust cup is full.
2. Dust cup lter needs to
be cleaned or replaced.
3. Brush is blocked by hair
or other debris.
1. Clean the dust cup.
2. Clean the lter
according to the
instructions.
3. Remove blockage from
brush.

10
Technical Specifications
Technical Specications
Model S7-LI-BLK
Battery 18.5V/2,200mAh
Charging Time 5-6 hours
Battery Charger Output 15V/800mAh
Net Weight 3.1Kg
Usage Time 40 min (low); 25 min (high)
Power 120W
Suction Power 4Kpa
Airow 20m3/s

SilverOnyx LLC
14807 S Heritagecrest Way, Ste B
Bluffdale, UT 84065
801-341-2845
[email protected]
Go to shop.silveronyx.com for replacement parts.
