SilverOnyx X9 User manual

X9 CORDLESS HANDHELD VACUUM
Instruction Manual
- Version 2.0 -
Please keep in a safe place for reference.

Important Safety Instructions
IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE.
RETAIN INSTRUCTIONS FOR FUTURE REFERRENCE.
Do not use in rain or leave outdoors while raining.
WARNING: Basic safety precautions should always be observed when using an
electrical appliance, including the following to reduce the risk of re, electrical
shock, or injury.
Personal Safety:
1. Store indoors in a dry place out of the reach of children.
2. Always use responsibly. This appliance can be used by children age 10 years and older.
Persons with reduced physical, sensory or mental capabilities, or lack of experience and
knowledge may use this appliance if they have been given supervision or instruction
concerning the safe use of the appliance and understand the hazards involved.
3. Don’t let children play with the appliance; supervise children using or maintaining the
appliance.
4. Use only manufacturer’s recommended attachments as described in this manual; misuse
or use of any accessory or attachment other than those recommended, may present a risk
of personal injury.
5. Take extra care when cleaning stairs.
6. Keep the appliance and accessories away from hot surface.
7. Do not block the appliances openings or hinder air ow, keep openings free of any
objects including clothing and ngers (and all parts of the body).
Electrical Safety:
1. Only use batteries and chargers supplied by the manufacturer.
2. Never modify the charger in any way.
3. The charger has been designed for a specic voltage. Always check that the mains
voltage is the same as that stated on the rating plate.
4. A charger that is suitable for one type of battery pack may create a risk of re when used
with another battery pack.
5. Before use, check the charger cord for signs of damage or ageing. A damaged or
entangled charger cord increases the risk of re and electric shock.
6. Do not abuse the charger cord.
7. Never carry the charger by the cord.
8. Do not pull the cord to disconnect from a socket, grasp the plug and pull to disconnect.
9. Don’t wrap the cord around the charger when storing.
10. Keep the charger cord away from hot surfaces and sharp edges.
11. The supply cord cannot be replaced. If the cord is damaged the charger should be
discarded and replaced.
12. Do not handle the charger or the appliance with wet hands.
13. Do not store or charge the appliance outdoors.
14. The charger must be removed from the socket before removing the battery, cleaning or
maintaining the appliance.
1
Important Safety Instructions

Battery safety:
1. This appliance includes Li-ion batteries, do not incinerate batteries or expose to high
temperatures, as they may explode.
2. Liquid ejected from the battery may cause irritation or burns.
3. In an emergency situation contact professional help immediately.
4. Leaks from the battery cells can occur under extreme conditions. Do not touch any liquid
that leaks from the battery. If the liquid gets on skin wash immediately with soap and
water. If the liquid gets into the eyes, ush them immediately with clean water for a
minimum of 10 minutes and seek medical attention. Wear gloves to handle the battery
and dispose of immediately in accordance with local regulations.
5. Shorting the battery terminals may cause burns or re.
6. When the battery pack is not in use, keep it away from paper clips, coins, keys, nails,
screws or other small metal objects that could make a connection from one terminal to
another.
7. When you dispose of the appliance remove the battery and dispose of the battery safely
in accordance with local regulations.
Service:
1. Before using the appliance and after any impact, check for signs of wear or damage and
repair as necessary.
2. Do not use the appliance if any part is damaged or defective.
3. Repairs should be carried out by a service agent or a suitably qualied person in
accordance with relevant safety regulations. Repairs by unqualied persons could be
dangerous.
4. Never modify the appliance in any way as this may increase the risk of personal injury.
5. Only use replacement parts or accessories provided or recommended by manufacturer.
Intended use:
1. This appliance has been designed for domestic dry vacuum cleaning only.
2. Do not pick up liquids or use on wet surfaces.
3. Do not pick up anything that is ammable, burning, or smoking.
4. Use only as described in this manual.
5. Don’t use on concrete, asphalt, or other rough surfaces.
WARNING:
1. Do not use water, solvents, or polishes to clean the outside of the appliance; wipe clean
with a dry cloth.
2. Never immerse the unit in water and do not clean in a dish washer.
2
Important Safety Instructions
Important Safety Instructions

3
POWER Button
Press once to turn on low power;
press again for high power; press
again to turn off.
Components
Components
RELEASE Extension Tube
Press to unlock and release
extension tube.
RELEASE Power Brush
Press to unlock and release power
brush head.
POWER BRUSH
For cleaning hard surface oors.
EXTENSION TUBE
For cleaning oors and hard to reach
areas such as curtains, lights, ceilings, etc.
DUST CUP
Dust and debris is collected in the
dust cup until emptied.
DUST BRUSH Accessory
For dusting glass surfaces, electronics,
shelving, wood surfaces, etc.
WALL MOUNT
For convenient charging, and storage
of vacuum and accessories.
CREVICE TOOL Accessory
For cleaning tight areas such as
between sofa cushions, dryer lint
collectors, in corners, etc.
CHARGER
To charge the appliance.
Vacuum
Accessories

4
2
3 4
Insert power
adapter into
power input
on back of unit
and then plug
into electrical
outlet.
First Use
First Use
When the battery is low,
the power light will blink
red indicating charging is
in progress.
When the battery is fully
charged, the light will turn
solid green.
1
Unbox vacuum and accessories,
and remove protective plastic
wrap and shipping materials.
X9
Cor
dles
s
HA
N
D
H
E
LD V
ACUU
M
Po
w
e
r
f
ul
2
S
p
e
ed
Hand
h
eld
Va
c
uu
m
with
H
E
PA
Filtr
a
t
io
n
1 2
A wall mount is included for
convenient storage and access
to your vacuum and accessories.
Use the provided screws (and wall
anchors, if necessary) to hang.
To hang, align the notch
in the back of the vacuum
battery with the hook in
the wall mount.
WALL MOUNT
UNPACK & CHARGE

5
Cleaning Floors
Cleaning Floors
1 2
3 4a
Insert the metal
extension tube into the
body and push until you
hear a ‘click’ sound.
Connect the dust cup
assembly and handle
together.
Attach the power
brush to the
extension tube and
push until you hear
the ‘click’.
Press the POWER button to
turn on the appliance.
4b The appliance will turn on
to LOW power. Press the
button again to switch to
HIGH power. Press a 3rd
time to power off.
ON/Low
HIGH
OFF

6
Cleaning Stairs & Other Surfaces
Cleaning Stairs & Other Surfaces
1 2a
2b
3a
Connect the dust cup
assembly and handle
together.
Insert the dust brush tool
into the body and push
until you hear the ‘click’.
Press the POWER button to
turn on the appliance. 3b The appliance will turn on
to LOW power. Press the
button again to switch to
HIGH power. Press a 3rd
time to power off.
ON/Low
HIGH
OFF
2c
Insert the power brush
head into the body and
push until you hear the
‘click’.
Insert the crevice tool
into the body and push
until you hear a ‘click’
sound.

7
Care & Maintenance
Care & Maintenance
1 2
3 4
Pull on the dust cup latch
with your thumb.
Note: hold over trash bin/bag
to catch debris after opening
dust cup.
Press the lock release button to
remove the extension tube or
accessory tool.
Shake body to empty dust
cup.
Push dust cup cover up until
the latch ‘clicks’ in place to
ensure it is fully closed.
EMPTY DUST CUP
1
Press the battery release button to
detach the battery from the dust
cup.
FILTER MAINTENANCE 2Grasp the dust cup rmly
and twist the top counter-
clockwise to open.

8
Care & Maintenance
Care & Maintenance
3 4
5 6
Wash/rinse the lter case and
HEPA lter with water ONLY.
Remove lter case from
dust cup and twist counter-
clockwise to remove lter
from it’s holder.
Allow the lter case and
HEPA lter time to dry
completely before re-
assembly.
After drying, place the lter
back in its holder and twist
to secure.
7 8
Place the lter assembly back
into the dust cup. Align with
the markings shown below. Place dust
cup cover
back onto
dust cup and
turn clock-
wise while
pushing down
to lock in
place.
3

9
Troubleshooting
Troubleshooting
Problem Battery
Indicator
Possible Cause Solution
Appliance
cannot be
recharged.
Battery
indicator does
not ash.
1. The charging plug may
be loose in the socket.
2. Power adapter is not
securely attached to the
appliance.
Attach the power adapter
securely to the appliance.
Battery
indicator keeps
ashing after
charging for
very long time.
The internal PCB board
may be defective or
damaged.
This problem can only be
xed by a professionally
trained person. Please
send or take appliance to
an after-service depot.
Brush does
not work, and
main unit
does not work
either.
Battery
indicator
ashes red
when pressing
the POWER
button.
1. Power is off.
2. Brush is totally blocked
by hair or other debris.
3. There may be a short on
the circuit inside the brush.
1. Recharge the appliance.
2. Remove blockage from
brush.
3. This problem can only
be xed by a professionally
trained person. Please
send or take appliance to
an after-service depot.
Brush does
not work,
but main
unit works
normally.
Battery
indicator is
normal.
1. Low battery.
2. Power connection is
interrupted.
3. The rubber belt inside
the brush head may be
loose.
1. Recharge the appliance.
2. Make sure dust cup
cover is seated properly
on dust cup, and check
all connections between
attachments.
3. This problem can only
be xed by a professionally
trained person. Please
send or take appliance to
an after-service depot.
Appliance
does not pick
up debris /
suction power
is weak.
Batter indicator
is normal.
1. Dust cup is full.
2. Dust cup lter needs to
be cleaned or replaced.
3. Brush is blocked by hair
or other debris.
1. Clean the dust cup.
2. Clean the lter
according to the
instructions.
3. Remove blockage from
brush.

10
Technical Specifications
Technical Specications
Model X9-LI-BLK
Battery 22.2V/2,200mAh
Charging Time 4 hours
Battery Charger Output 26V/500mAh
Net Weight 2.3Kg
Usage Time 40min (low); 20min (high)
Power 130W
Suction Power 9Kpa
Airow 20m3/s

SilverOnyx LLC
14807 S Heritagecrest Way, Ste B
Bluffdale, UT 84065
801-341-2845
suppor[email protected]om
Go to shop.silveronyx.com for replacement parts.
