Simmonsigns Solar Pulsa User manual

Doc Ref: IG122
Issue Date: Apr 2019
Issue Number: 5
Simmonsigns Limited reserves the right to alter or improve this guide without prior notice.
Installation Guide
Solar Pulsa
simmonsigns.co.uk
SOLAR PULSA
Safety first
Wiring should be carried out in accordance with
current regulations by qualified engineers.
Ensure correct equipment is used to mount
components.
Tools required
5mm Security Allen key
6mm Security Allen key
13mm A/F Combination Spanner
13mm A/F Socket & Ratchet
3mm Spade End screwdriver
Solar Pulsa Post Installation
Solar Panel Installation
3) Tighten the 4 No M10 socket set screws.
Install the Pulsa
1) Drill a Ø14mm hole in the post at the required
height (2421mm from ground level to give a
height of 2100mm to the base of the Pulsa) -
ensure the hole is free from burrs and sharp
edges.
2) Pass the supply cable down the post to the
regulator assembly located in the base of the
post.
3) Fix the Pulsa to the post in accordance with the
standard Pulsa installation instructions found with
the Pulsa.
Connection
Battery & Regulator Assembly
1) Remove the battery and carrier from the
wooden board.
2) Secure the wooden board into the base of the
column using an M8 full nut and penny washer.
3) Replace the battery and carrier onto the
wooden board.
1) A qualified engineer should now make
connections to the regulator strictly in accordance
with the sunsaver operators manual supplied.
2) Once the above instruction has been completed,
the Smart Pulsa should then flash twice. A
calendar file can now be uploaded
3) Please ensure the Solar panel is placed with clear
line of sight to the sun, all year round.
Note: Failure to follow these instructions may
result in premature failure of the product.
[phone]
[phone]
[email protected]
Telford Shropshire
TF3 3AS
Install the post in line with the manufacturers
guidelines, taking into account the type of soil,
1) Place the pre-wired solar panel assembly onto
the top of the post passing the cable down the
post and into the base section.
2) Fix the panel spigot assembly to the post top
using its 4 No M10 socket set screws. Ensuring
that in the UK, the panel faces true south
Solar Panel
PULSA
Battery Assembly
Product Weights
SMART Pulsa GPRS Pulsa
15 kg
6.25 kg
9.26 kg
23 kg
6.25 kg
9.26 kg
Windage Information
Please see diagrams overleaf for general arrangement and
dimensions.

Doc Ref: IG122
Issue Date: Apr 2019
Issue Number: 5
Simmonsigns Limited reserves the right to alter or improve this guide without prior notice.
Installation Guide
Solar Pulsa
simmonsigns.co.uk
Post Assembly Figure B
Smart Pulsa
Post supplied
by others
Battery &
Regulator
Assembly
M8 full nut &
penny washer
Ground Level
400mm
Foundation
1000mm
Deep foundation
500mm
Door height
ø168mm
ø168mm
Ø89
1 x cable
entry hole
required in
post.
M8 x 40mm
stud central
to door
apperture
100mm min.
door width
ø89mm
220mm
640mm
3799mm
4390mm
2440mm
274mm
4 x M10 socket
set screws
2 x M10 X 20
security button
head screws
70o fixed
angle for UK
applications
2100mm
1890mm
5000mm
Solar Panel
Note: Ensure the Solar Panel has a clear
aspect directly south with no risk of
shadow falling on the panel.
Figure C,
Panel spigot
Battery and
carrier fixed to
wooden board
Regulator 2 x In-Line
Fuses
1 Per Battery
[phone]
[phone]
[email protected]
Staord Park 5
Telford Shropshire
TF3 3AS
Install the post in line with the manufac-
turers guidelines, taking into account the
type of soil, location and windage of the
equipment being tted.
Figure A
6
49 -
SMA
RT Puls
a
8
5
0
- GPRS
Pu
lsa
685 - GPRS Pulsa
550 - SMART Pulsa
