SIMPA U2 User manual

座枱式煮食爐
HOTPLATE
型號 :
Model
使用說明書
User Instructions
香港煤氣適用
For Hong Kong Town Gas
U2

目錄
注意!
根據香港氣體安全條例，任何氣體裝置工程，包括爐具和接駁喉管的安裝，
必須由註冊氣體裝置技工執行，而該技工已於相關的氣體工程類別註冊及受
聘於註冊氣體工程承辦商。
重要安全指示 ················································································ 第1 頁
安裝指示 ························································································· 第3 頁
操作指示 ························································································· 第5 頁
保養 ·································································································第6 頁
故障處理方法 ················································································ 第7 頁
規格 ·································································································第8 頁

1
重要安全指示
感謝閣下選用簡柏產品！以下指示對氣體煮食爐的安全操作十分重要，請詳細閱讀，如有查詢和服務要求，
安裝
1. 使用認可印有機電工程署批准標記 (例如: 機電工程署批准 EMSD APPROVAL GTXXXX) 的氣體接駁喉管
連接爐具或使用機電工程署接納的其他恰當方法。
2. 爐具周圍和下方不可放置可燃物品，如紙張、塑膠等，與可燃物料距離須保留 150 毫米以上。
3. 爐具必須安裝在空氣流通之房間內。
使用
1. 當懷疑洩漏氣體時，將窗戶打開，以及關閉煤氣錶閥。切勿操作任何電器或電掣開關。切勿在現場使用任
何電話。在現場以外的地方，致電煤氣公司緊急事故熱線 2880 6999。
2. 請參照說明書內指引正確使用爐具。
3. 爐具只供家用，切勿用於商業用途。
4. 除煮食外，切勿使用爐具作其他用途，例如烘乾衣物。
5. 使用爐具前，請開啟窗戶及排氣系統。
6. 不可讓兒童使用爐具。
7. 切勿讓爐具在無人看管下運作。
8. 切勿在爐頭加上錫紙碟，這會引致燃燒問題。
9. 使用前，確保爐頭蓋、爐碟和爐架擺放正確，沒有傾斜。
10. 切勿放置超過 10 公斤的重量在爐架上。
11. 爐架很重，切勿掉下。
12. 請確保使用時火焰平均。
13. 注意爐面、爐頭及爐架的高溫。
14. 切勿使用直徑過大的平底煮食鍋具，避免溫度過高而造成燙傷及影響爐具的使用壽命。 使用細小鍋具
時，請將火力調低，避免火焰超出鍋具底部。
15. 請確保器皿穩定地放在爐架上，如器皿容易滑動，必須緊握它。
爐頭 最大平底煮食鍋具直徑（毫米）
左爐頭 300
右爐頭 300

2
重要安全指示
16. 燒開水或煮湯時，注入的水量連湯料不可超過器皿容量 3分之 2，溢出液體會影響燃燒和損壞爐具。
17. 烹調時，請儘量蓋上鍋具。而鍋具的手柄亦應轉向適當位置，避免受熱或碰撞。
18. 請勿在爐具附近使用噴霧產品。
19. 使用後，應將所有開關按鈕設於關閉位置。
20. 經常清潔爐頭蓋以保持爐頭火孔暢通，如滾瀉食物及汁液，應在爐具冷卻後儘快作出妥善清潔。
21. 如爐具出現異常聲響，應先關火。在爐具冷卻後，檢查及放好爐頭蓋。若問題持續，聯絡煤氣公司進行
檢查。
保養
1. 定期檢查氣體喉管狀況，確保沒有紐結或裂縫，若發現損壞，請聯絡煤氣公司更換喉管。
2. 讓爐具完全冷卻後，才可進行清潔。
3. 清潔爐具時，應穿上保護手套，避免接觸爐具內部，防止割傷。
4. 清洗爐頭蓋後，用乾布將爐頭蓋完全抹乾，爐頭火孔不可留有水份，以免影響燃燒。
5. 使用前和使用後，注意爐頭的狀況和清潔。以下不正常狀況會產生燃燒不良，進而引致爐具損壞。請
確保採取相應措施，糾正有關問題。
不正常情況 處理措施
爐頭蓋變形 聯絡煤氣公司更換零件。
爐頭蓋傾斜 將爐頭蓋重新放好，不可傾斜。
爐頭火孔被水堵塞 用布將爐頭蓋抹乾後，重新放好。
爐頭火孔被污積堵塞 用溫和洗滌劑和刷子清潔爐頭蓋。用布將爐頭蓋抹乾後，重新放好。

3
產品介紹
安裝指示
安裝位置
爐具須安裝在空氣流通之房間內，但切勿置於強風直接吹入的位置。附近不可放置易燃物料 ( 如紙張、油
類)、噴霧及壓縮容器。爐具與周圍可燃物料應保持 150 毫米以上的距離。爐具上方須保留最少 650 毫米
空間 。若上方裝有抽油煙機，並要求不同安裝距離，應採用較大者。
安裝爐具
放置爐具於工作平面，確保所放之處穩固平坦。
氣體接駁
根據現行指定的標準，將氣體爐具連接供氣設施上，接駁前確保爐具符合所供應之氣體類型。並檢查供氣
壓力為1.5千帕。
注意：煤氣型號的氣體接頭為½吋英制陽螺紋。使用獲批准的氣體喉管接駁爐具。氣體軟喉長度不可超過
2000毫米。確保喉管沒有接觸任何活動部件、被扭曲或被擠壓。接駁完成後，檢查喉管的氣密性。切勿
使用明火作檢查。
完成安裝
使用前，確定所有部件正確放置。
爐頭部件
點火電極
熄火安全感應器
開關按鈕 火力控制桿
爐架
爐面
爐碟
爐頭蓋
芯火爐頭
爐具介紹
電池盒在爐底左前方。
注意電池的電極方向，若電池擺放錯誤，爐具便不能操作。

4
安裝指示
 爐具須放置在穩固之平面上。
 以批准的氣體軟喉接駁爐具。
 氣體接駁軟喉可置於爐底下，但必須平放貼灶台，避免翹起觸及爐頭底部。
 使用前正確擺放爐架和爐頭蓋。
1. 爐架
• 爐架底定位針插入爐面通定位孔。
• 爐架必須平放，不可傾斜。
2. 爐頭
• 爐頭由外環爐頭蓋、芯火爐頭蓋和爐頭座組成。
• 爐頭蓋必須平放，不可傾斜。
• 若爐頭蓋未放置正確，有機會導致以下情況：
- 無法點火
- 火焰不均和回火會導致不完全燃燒、 一化碳中
毒和爐頭變形。
- 火焰進入爐具內，會導致損毀。
3. 爐碟
擺放爐碟時，必須平放，不可傾斜。
平放
不可傾側
正確
錯誤
定位針
爐碟
爐面定位孔
爐架
空隙 空隙
爐頭座
外環爐頭蓋
芯火爐頭蓋

5
操作指示
最大 中火 最小
火力控制桿位置
1. 點火
完全按下按鈕，火花點著爐頭後鬆開按鈕，爐火會維持。
若爐火不能維持，按一下按鈕返回熄火位置，等待 1分鐘，
讓氣體散走，然後重新點火。
2. 火力調節
爐頭點燃後，可按烹調所需推動火力控制桿調節火力。
請慢慢推火力控制桿。火力可用火力控制桿加以調節。
在調較最大火力至接近中火時，若發現外環火焰不穩定(微弱或熄滅)，請立即調大火力，直至外環火
焰穩定，才繼續使用；或調小火力，使用芯火。
3. 熄火
按一下按鈕，按鈕會回到關的位置。
注意：熄火時有機會因殘留在爐頭內的氣體瞬間燃燒而出現響聲，此屬正常現象。

6
保養
注意：待爐具完全冷卻後，才可進行任何保養及清潔。清潔時，亦應配戴手套保護雙手。
為妥善保養爐具，遵照以下指示定期清潔爐具：
• 請勿使用蒸氣清潔爐具；
• 使用適當非研磨及非腐蝕性的清潔劑清潔金屬及搪瓷部份，避免使用含氯清潔劑（如漂白劑）；
• 避免酸性或鹼性物質（如醋、鹽水、檸檬汁）殘留在爐具；
• 煮食時如有液體溢出，應待爐具冷卻後儘快清理；
• 定期使用暖水及清潔劑清洗爐頭蓋，將污漬去除，並保持爐頭火孔暢通；
• 清潔後須完全抹乾爐頭蓋，並確定爐頭火孔未被堵塞；
• 將爐頭蓋正確放回爐頭座，不可傾斜或反轉；
• 定期檢查熄火安全感應器和點火電極，如有污物黏附，用軟刷將污物去除。

7
故障處理方法
注意：於重新點火前，請將開關按鈕按回關閉位置。
確保爐具完全冷卻後，才進行任何故障處理。如採取以下補救措施後仍然無效，請致電煤氣公司安排維修，
電話：2880 6988。
故障 原因 處理方法
1. 沒有點火
點火電極濕了。 以乾布抹乾點火電極。
點火電極有污垢。 清理點火電極。
電池已耗盡。 更換電池。
電池電極擺放錯誤。 重新放好電池。
2. 沒有火焰
仍未開啟煤氣錶閥及／或爐具供
氣閥。 完全開啟煤氣錶閥及／或爐具供氣閥。
錫紙碟阻塞爐頭。 拿去錫紙碟。
3. 不能保持爐火
開關按鈕未按盡。 按盡開關按鈕，並保持數秒。
熄火安全感應器有污垢。 清理熄火安全感應器。
4. 使用中熄火
煮食溢出物阻塞爐頭。 待爐具冷卻後，清理爐頭蓋，重新點火。
用小火時被風吹熄。 等待 1分鐘，重新點火。
防高溫保護裝置啟動 。 按鈕轉至關閉位置。等待 1分鐘，重新點火。
5. 黃火 爐頭有污垢。 以暖水和清潔劑清洗爐頭蓋，將它抹乾和放好
後，重新點火 。
6. 火焰不穩定
爐頭蓋變形。 聯繫煤氣公司更換零件。
爐頭蓋擺放不正確。 將爐具熄火，待爐具冷卻後，重新放好爐頭
蓋，重新點火。
7. 使用中出現異常聲音 爐頭蓋擺放不正確。 將爐具熄火，待爐具冷卻後，重新放好爐頭
蓋，重新點火。
電池電壓低。 更換電池。
8. 出現蜂鳴提示聲音
防高溫保護裝置啟動 。 按鈕轉至關閉位置。等待 1分鐘，重新點火。
9. 關火時出現響聲 殘留在爐頭內氣體瞬間燃燒。 正常現象。

8
規格
型號 U2
基本規格
爐具類別 氣體煮食爐
安裝方式 座枱式
氣體種類 香港煤氣
供氣壓力（千帕） 1.5
氣體接駁 1/2 吋 英制陽螺紋
點火裝置 快易電子點火
爐頭數目 2
額定熱負荷
（千瓦）
左爐頭 6.0
右爐頭 6.0
總11.8
爐具尺寸
（毫米）
高
至爐面 123
至爐架 160
闊 713
深
至爐身 380
至氣體接頭 417
重量（千克） 9.0
電源供應 1.5 伏特 D型鹼性電池(2 枚)
耗電量 （瓦） /
安全裝置
熄火安全裝置 熱電偶式
防高溫保護裝置 熱敏電阻
連續煮食自動熄火安全裝置 /

Contents
Attention!
According to the Gas Safety Ordinance of Hong Kong, any gas
installation works including the installation of appliances and
connection tubing, must be undertaken by registered gas installers
who are registered for that appropriate classes and be employed by
registered gas contractors.
Important Safety Instructions.......................................... P. 1
Installation Instructions................................................... P. 3
Operating Instructions .................................................... P. 5
Maintenance................................................................... P. 6
Troubleshooting.............................................................. P. 7
Specifications ................................................................. P. 8

1
Important Safety Instructions
Thank you for choosing SIMPA products! The following instructions are very important to safety operation
of gas hotplate. Please read through them carefully. Please contact Towngas 24-hour Customer Service
Hotline on 2880 6988 for enquiry and services.
Installation
1. Use approved gas tubing bearing EMSD approval marking (such as: 機電工程署批准 EMSD APPROVAL
GTXXXX) for connection to appliance or other appropriate methods accepted by EMSD.
2. Do not put any combustible materials, e.g. paper and plastic near or under appliance. The appliance
should be installed with a distance more than 150mm distance away from combustible materials.
3. Install the appliance in a well-ventilated room.
Operation
1. In case of suspected gas leak, open windows and shut off gas meter valve. Do not operate any electric
appliances or switches. Do not use any phones on site. Contact Towngas Emergency Hotline on
2880 6999 with a phone outside the premises.
2. Please use the appliance properly according to the operating instructions.
3. This appliance is designed for domestic use only. Do not use it for commercial purposes.
4. Do not use the appliance for any purposes other than cooking, e.g. drying clothes.
5. Open windows and turn on ventilation system before operating the appliance.
6. Do not allow kids to use appliance.
7. Do not leave operating appliance unattended.
8. Do not add aluminum discs to burners. This will incur combustion problem.
9. Before use, ensure the burner caps, drip pans and pan supports are in correct position and are not
tilted.
10. Do not put weight exceeding 10kg on pan support.
11. Pan support is heavy. Do not drop it.
12. Make sure that flame condition is uniform during operation.
13. Heed high temperature of top plate, burner and pan support.
14. Do not use flat bottom utensil with too large diameter to avoid the risk of scald by high temperature and
reduce the service life of the appliance. When using small utensil, reduce flame power that flame does
not escape from utensil bottom.
15. Ensure stability of utensil resting on pan support. Hold utensil firmly if it slips easily.
Burner
Maximum Diameter of
Flat Bottom Utensil (mm)
Left Burner 300
Right Burner 300

2
Important Safety Instructions
16. Do not fill water including soup ingredients over two-thirds of utensil volume when boiling water or
soup. Spilled liquid of boiling will affect combustion and damage the appliance.
17. Always use pots with covers and make sure that the handles of the pots are correctly positioned to
avoid heating and collision of handles.
18. Do not use sprays near the appliance.
19. ON / OFF buttons should be pressed to off position after use.
20. Clean burner caps regularly to ensure smooth passage of burner flame holes. In case of spillage of
food or liquid, clean appliance properly once it cools down.
21. If abnormal noise is observed, turn off flame. Check and place burner caps correctly after appliance
cools down. Contact Towngas Company for inspection if problem persists.
Maintenance
1. Check condition of gas hose regularly. Ensure that it is free from kink or crack. Contact Towngas
Company to replace it if damage is found.
2. Allow the appliance to cool down completely before cleaning.
3. Wear gloves to protect the hands when cleaning the appliance. Avoid to touch interior of appliance to
prevent cut injury.
4. Dry burner caps completely with dry cloth after washing. Burner flame holes must be free from water
lest combustion is affected.
5. Before and after use, notice the condition and cleanliness of burner. The following abnormal
conditions will incur abnormal combustion and thus damage of the appliance. Ensure undertaking
measures to rectify the problem accordingly.
Abnormal Condition Handling Measure
Burner caps are deformed. Contact Towngas Company to replace the parts.
Burner caps are tilted. Place burner caps properly. Burner caps must not
be tilted.
Burner flame holes are blocked by
water.
Dry burner caps with cloth and place them
properly.
Burner flame holes are blocked by dirt.
Clean burner caps with mild detergent and brush.
Dry burner caps with cloth and place them
properly.

3
Installation Instructions
Installation Position
Install the appliance in a well-ventilated room but not at the position of strong wind. Keep it away from
any combustible materials (such as paper, oil), sprays or pressurized containers. It should keep a
distance of more than 150mm from surrounding combustible materials. Allow 650mm or more clearance
above appliance. If range hood is installed above the appliance and requires different distance, adopt
the larger value.
Appliance Installation
Position the appliance onto the bench-top. Ensure the bench-top is stable and flat.
Gas Connection
Connect the gas appliance to the gas supply according to the prescribed standards in force, and ensure
that the appliance matches with the type of gas supply. Furthermore, check the supply pressure is 1.5
kPa.
Attentions: The gas connection of town gas model is ½” B.S.P male thread. Use approved gas
tubing for connecting to appliance. Flexible tubing must not be longer than 2000 mm. Tubing
shall not touch any moving parts, be kinked or compressed. After connection , check gas
soundness of piping. Never use naked flame for checking.
Completing Installation
Make sure that all the parts are fitted properly before use.
Spark ElectrodeFlame Failure Safety Sensor
Burner Parts
Flame Control Lever
ON /OFF Button
Pan Support
Top Plate
Drip Pan
Burner Cap
Simmer Burner Cap
Component Description
Battery box located at left-front corner of bottom position.
Be careful the battery orientation, appliance does not operate if batteries are placed wrongly.

4
Installation Instructions
• Place the appliance on a stable and level surface.
• Connect the appliance with approved flexible gas hose.
• Gas hose can be placed under appliance. However, it must be placed horizontally on bench and avoid
tilting up to touch burner bottom.
• Place pan supports and burner caps correctly before use.
1. Pan Support
Fit pan support bottom guide pins into top plate guide
holes.
Place the pan support horizontally and never tilt it.
2. Burner
• Burner consists of outer ring burner cap, simmer burner
cap
and burner base.
• Place burner caps horizontally and never tilt them.
• If burner caps are not placed properly, it may cause
the following problems:
- No ignition.
- It may cause incomplete combustion, risk of carbon
monoxide poisoning and burner deformation.
- Flame may get into appliance and damage it.
3. Drip Pan
Place drip pan horizontally and never tilt it.
Wrong No tilt
Correct
Horizontally placed
Gap Gap
Outer Ring Burner Cap
Burner Base
Simmer Burner Cap
Guide Pin
Top Plate
Guide hole
Drip Pan
Pan Support

5
Operating Instructions
1. Ignition
Fully press ON/OFF button. Release button after spark ignites
burner. Flame will persist.
If flame does not persist, press button once to turn off. Wait
for 1 minute to allow gas dispersion. Then repeat ignition
procedure.
2. Flame Adjustment
After ignition, move the flame control to adjust flame power according to cooking needs.
Please move flame control lever slowly. Flame can be adjusted by moving flame control lever.
When adjust flame power from maximum close to medium, if flame of outer ring burner is found
unstable (weak or extinguished), please adjust the flame power to maximum until flame of out-
er ring burner is stable, or reduce flame power and use flame of simmer burner.
3. Turn Off
Press ON/OFF button once. Button returns to OFF position.
Attentions: Pop sound might be generated when turning off flame due to the instant combustion of
gas remained in burner. This is a normal phenomenon.
Maximum Medium Minimum
Flame Control
Lever Position

6
Maintenance
Attention: Allow the appliance to cool down before performing any maintenance and cleaning.
Wear gloves to protect the hands while cleaning.
To maintain the appliance properly, follow the following instructions to clean it regularly:
• Do not use steam cleaners for cleaning;
• The metal and enameled parts must be cleaned with suitable non-abrasive and non-corrosive
detergents. Avoid using chlorine-based detergents (e.g. bleach);
• Avoid leaving acidic or alkaline substances on the appliance (e.g. vinegar, brine, lemon juice);
• Clean and tidy up the appliance after spillage of liquid once it cools down;
• The burner caps must be washed regularly with warm water and detergent. Remove any grime and
keep the flame holes of burners away from blockage;
• Dry the burner caps completely after wash and ensure that all flame holes of burner are not
clogged;
• Replace burner caps on burner bases correctly. Ensure that they are not tilted or reversed;
• Regularly check the flame failure safety sensors and spark electrodes. In case of sticking with
stains, clean them with soft brush.

7
Troubleshooting
Fault Cause Remedy
1. No ignition or
flame
Spark electrode is wet. Dry the spark electrode with dry cloth.
Spark electrode has dirt. Clean the spark electrode.
Battery is consumed. Change battery.
Battery polarity is in wrong direction. Replace battery correctly.
2. No flame
Gas meter valve and / or appliance
gas supply valve is turned off.
Open gas meter valve and / or appliance
gas supply valve completely.
Burner is blocked by aluminium disc. Remove aluminium disc.
3. Flame cannot be
held
ON/OFF button is not fully pressed. Fully press ON/OFF button and hold it for a
few seconds.
Flame failure safety sensor has dirt. Clean flame failure safety sensor.
4. Flame off when
using
Cooking spillage blocks burner Turn off flame. Clean burner caps after
appliance cools down. Restart ignition.
Small flame is blown off by wind. Wait for 1 minute and restart ignition.
Overheat protection device is
activated.
Press the button to off position. Wait for 1
minute and restart ignition.
5. Yellow flame Burner caps have dirt.
Wash burner caps in warm water with
detergent. Dry and replace them at correct
position. Restart ignition .
6. Unstable flame
Deformation of burner caps. Contact Towngas Company to replace the
parts.
Incorrect placement of burner caps.
Turn off flame. Replace burner caps
correctly after appliance cools down.
Restart ignition.
7. Abnormal noise
when using Incorrect placement of burner caps.
Turn off flame. Replace burner caps
correctly after appliance cools down.
Restart ignition.
Battery low voltage. Change battery.
8. Buzzer
notification
sound emitted
Overheat protection device is
activated.
Press the button to off position. Wait for 1
minute and restart ignition.
9. Pop sound
when flame off
Instant combustion of gas remained
in burner. Normal phenomenon.
Attention: Before restarting ignition, return the ON/OFF button to off position.
Some malfunctions can be handled by user. But if the following remedial actions are not effective, please
call Towngas Customer Service Hotline at 2880 6988.

8
Specifications
Model U2
Basic
Specifications
Appliance Type Gas Cooking Hob
Installation Type Hotplate
Gas Type Hong Kong Town Gas
Gas Supply Pressure (kPa) 1.5
Gas Connection ½” BSP Male Thread
Ignition Device Fast-easy Electronic Ignition
Number of Burner 2
Rated
Heat Input
(kW)
Left Burner 6.0
Right Burner 6.0
Total 11.8
Appliance
Dimensions
(mm)
Height
To top plate 123
To pan support 160
Width 713
Depth
Body 380
Including gas
connection
417
Weight (kg) 9.0
Power Supply 1.5V D-size Alkaline Battery (2 pcs)
Power Consumption (W) /
Safety
Device
Flame Failure Safety Device Thermocouple Type
Overheat Protection Device Thermistor Type
Continuous Cooking Automatic
Flame Off Safety Device /

202306
