SIMPA RVH1SK User manual

香港煤氣適用
For Hong Kong Town Gas
煮食爐
Hotplate
型號 :
Model
使用說明書
Operating Instructions
RVH1SK
RVH2SK
RVH2SK RVH1SK

目錄
注意!
根據香港氣體安全條例，任何氣體裝置工程，包括爐具和接駁喉管的安裝，
必須由註冊氣體裝置技工執行，而該技工已於相關的氣體工程類別註冊及受
聘於註冊氣體工程承辦商。
重要安全指示 ················································································ 第1 頁
產品介紹 ························································································· 第3 頁
安裝指示 ························································································· 第4 頁
操作指示 ························································································· 第5 頁
保養 ·································································································第6 頁
故障處理方法 ················································································ 第7 頁
規格 ·································································································第8 頁

1
重要安全指示
感謝閣下選用簡柏產品！以下指示對氣體煮食爐的安全操作十分重要，請詳細閱讀，如有查詢和服務要求，
安裝
1. 使用認可印有機電工程署批准標記 (例如: 機電工程署批准 EMSD APPROVAL GTXXXX) 的氣體接駁喉管
連接爐具或使用機電工程署接納的其他恰當方法。
2. 爐具周圍和下方不可放置可燃物品，如紙張、塑膠等，與可燃物料距離須保留 150 毫米以上。
3. 爐具必須安裝在空氣流通之房間內。
使用
1. 當懷疑洩漏氣體時，將窗戶打開，以及關閉煤氣錶閥。切勿操作任何電器或電掣開關。切勿在現場使用任
何電話。在現場以外的地方，致電煤氣公司緊急事故熱線 2880 6999。
2. 請參照說明書內指引正確使用爐具。
3. 爐具只供家用，切勿用於商業用途。
4. 除煮食外，切勿使用爐具作其他用途，例如烘乾衣物。
5. 使用爐具前，請開啟窗戶及排氣系統。
6. 不可讓兒童使用爐具。
7. 切勿讓爐具在無人看管下運作。
8. 切勿在爐頭加上錫紙碟，這會引致燃燒問題。
9. 使用前，確保爐頭蓋、爐碟和爐架擺放正確，沒有傾斜。
10. 切勿放置超過 10 公斤的重量在爐架上。
11. 爐架很重，切勿掉下。
12. 請確保使用時火焰平均。
13. 注意爐面、爐頭及爐架的高溫。
14. 切勿使用直徑超過 300 毫米的平底煮食器皿，避免溫度過高而造成燙傷及影響爐具的使用壽命。
15. 使用細小器皿時，請將火力調低，避免火焰超出煮食器皿底部。
16. 請確保器皿穩定地放在爐架上，如器皿容易滑動，必須緊握它。
17. 燒開水或煮湯時，注入的水量連湯料不可超過器皿容量 3分之 2，溢出液體會影響燃燒和損壞爐具。
18. 請勿按下控制旋鈕超過 10 秒。如爐頂於 10 秒後仍未燃點，等待最少 1分鐘後，才再試燃點。
19. 烹調時，請儘量蓋上鍋具。而鍋具的手柄亦應轉向適當位置，避免受熱或碰撞。
20. 請勿在爐具附近使用噴霧產品。
21. 使用後，應將所有控制旋鈕設於關閉位置。
22. 經常清潔爐頭蓋以保持爐頭火孔暢通，如滾瀉食物及汁液，應在爐具冷卻後儘快作出妥善清潔。
23. 如爐具出現異常聲響，應先關火。在爐具冷卻後，檢查及放好爐頭蓋。若問題持續，聯絡煤氣公司進行
檢查。

2
重要安全指示
保養
1. 定期檢查氣體喉管狀況，確保沒有紐結或裂縫，若發現損壞，請聯絡煤氣公司更換喉管。
2. 讓爐具完全冷卻後，才可進行清潔。
3. 清潔爐具時，應穿上保護手套，避免接觸爐具內部，防止割傷。
4. 清洗爐頭蓋後，用乾布將爐頭蓋完全抹乾，爐頭火孔不可留有水份，以免影響燃燒。
5. 使用前和使用後，注意爐頭的狀況和清潔。以下不正常狀況會產生燃燒不良，進而引致爐具損壞。請
確保採取相應措施，糾正有關問題。
不正常情況 處理措施
爐頭蓋變形 聯絡煤氣公司更換零件。
爐頭蓋傾斜 將爐頭蓋重新放好，不可傾斜。
爐頭火孔被水堵塞 用布將爐頭蓋抹乾後，重新放好。
爐頭火孔被污積堵塞 用溫和洗滌劑和刷子清潔爐頭蓋。用布將爐頭蓋抹乾後，重新放好。

3
這爐具是專為香港各式煮食需要而設計，配備壓電式點火裝置，旋鈕式火力控制，火力特強，兼備獨立芯
火，爐面採用優質不鏽鋼物料，清潔容易，美觀大方。
產品備有熄火安全裝置，如爐火意外熄滅或因爐頭阻塞而引致不正常燃燒，會自動關閉氣體，確保安全。
部件名稱
特點包括:
 強勁雙環爐頭、獨立芯火，滿足各式煮食需要
 壓電式點火系統，無需使用電池
 旋鈕式火力控制，操作簡單靈活
 銅合金製爐頭，表面加上耐高溫塗層，槽式火孔，堅固耐用，清理容易
 熄火安全裝置確保安全
產品介紹
產品介紹
膠腳
RVH2SK RVH1SK
外環爐頭座
雙環爐頭
爐面
爐架
控制旋鈕
熄火安全感應器
芯火爐頭座
移去爐頭蓋後

4
 爐具須放置在穩固之平面上。
 以批准的氣體軟喉接駁煮食爐。
 氣體接駁軟喉可置於爐底下，但必須平放貼灶台，避免翹起觸及爐頭底部。
 使用前確定正確擺放爐架、爐頭蓋和爐碟。
1. 爐架
爐架底定位針插入爐面通孔。
2. 爐頭蓋
不正確擺放會導致不良燃燒和爐頭蓋變形。
3. 爐碟
擺放爐碟時，不可傾斜。
安裝指示
爐碟
爐架
外環爐頭蓋
爐頭座
芯火爐頭蓋
正確
錯誤
緊貼爐面
不可傾斜
外環爐頭蓋
芯火爐頭蓋
傾斜
外環爐頭蓋
芯火爐頭蓋
傾斜

5
1. 點火
按下及向左轉動控制旋鈕，直至停在點火（ ）位置，爐頭便點著；否則，等待數秒後重新點火。
點著火後，保持按下控制旋鈕數秒。
若放開旋鈕後爐火熄滅，將旋鈕轉回關閉（●）位置，重新點火。
2. 火力調節
請慢慢調節火力。
要按照鍋子的大小調節火力。火力過大，會燒壞鍋子的把手，用手觸摸把手時，也會引致燙傷。
3. 熄火
將控制旋鈕轉回至關閉（●）的位置關閉爐火。
4. 爐火意外熄滅
如熄火意外熄滅，氣體將會自動關閉。轉動控制鈕至關閉（●）位置，確保爐頭是清潔後才重新點火。
如爐頭火孔被堵塞，待爐頭冷卻後，進行清理，抺乾後，重新點火。
操作指示
控制旋鈕位置
爐火狀況
芯火 小最大 最大 最小
外環火 小最大 熄滅 熄滅

6
保養
注意：待爐具完全冷卻後，才可進行任何保養及清潔。清潔時，亦應配戴手套保護雙手。
為妥善保養爐具，遵照以下指示定期清潔爐具：
 請勿使用蒸氣清潔爐具；
 使用適當非研磨及非腐蝕性的清潔劑清潔金屬及搪瓷部份，避免使用含氯清潔劑（如漂白劑）；
 避免酸性或鹼性物質（如醋、鹽水、檸檬汁）殘留在爐具；
 煮食時如有液體溢出，應待爐具冷卻後儘快清理；
 定期使用暖水及清潔劑清洗爐頭蓋，將污漬去除，並保持爐頭火孔暢通；
 清潔後須完全抹乾爐頭蓋，並確定爐頭火孔未被堵塞；
 將爐頭蓋正確放回爐頭座，不可傾斜或反轉；
 定期檢查熄火安全感應器，如有污物黏附，用軟刷將污物去除。

7
故障處理方法
故障 原因 處理方法
1. 沒有火焰 仍未開啟煤氣錶閥及／或爐具供氣
閥。
完全開啟煤氣錶閥及／或爐具供氣閥。
錫紙阻塞爐頭。 拿去錫紙。
2. 不能保持爐火 未按盡而轉動控制旋鈕。 按盡控制旋鈕及反時針方向旋轉到點火
（）位置，維持按著 5秒後放開。
按著控制旋鈕的時間太短。
熄火安全感應器有污穢。 清理熄火安全感應器。
3. 使用中熄火 用小火時被風吹熄。 等待 1分鐘，重新點火。
煮食溢出物阻塞爐頭，引致熄火。 待爐頭冷卻後，清潔和抹乾爐頭，然後重
新點火。
4. 黃火 爐頭有污穢。 以暖水和清潔劑清洗爐頭蓋，將它抹乾和
放好後，重新點火 。
5. 火焰不穩定 爐頭蓋擺放不正確。 冷卻後，重新放好爐頭蓋，再點火。
6. 使用中出現異常 爐頭蓋擺放不正確。 將爐具熄火，待爐具冷卻後，重新放好爐
頭蓋，重新點火。
7. 關火時出現響聲 殘留在爐頭內氣體瞬間燃燒。 正常現象。
有些故障是可以由使用者處理，但如採取以下補救措施後仍然無效，請致電煤氣公司客户服務熱線
2880 6988。

8
規格
型號 RVH1SK RVH2SK
氣體種類 香港煤氣 香港煤氣
爐頭數目 1 2
額定熱負荷 (千瓦)
總5.5 10.9
左爐頭 - 5.5
右爐頭 - 5.5
供氣壓力 (千帕) 1.5 1.5
氣體接頭 1/2 吋 英制陽螺紋 1/2 吋 英制陽螺紋
機身尺寸 (毫米)
高
至爐面 138 138
至爐架 176 176
寬282 702
爐身 419 419
深
至氣體按頭 443 443
重量 (千克) 3.6 7.1
點火裝置 壓電式 壓電式
熄火安全裝置 熱電偶式 熱電偶式

9

Contents
Attention!
According to the Gas Safety Ordinance of Hong Kong, any gas
installation works including the installation of appliances and
connection tubing, must be undertaken by registered gas installers
who are registered for that appropriate classes and be employed by
registered gas contractors.
Important Safety Instructions.......................................... P. 11
Product Description ........................................................ P. 13
Installation Instructions................................................... P. 14
Operating Instructions .................................................... P. 15
Maintenance................................................................... P. 16
Troubleshooting.............................................................. P. 17
Specifications ................................................................. P. 18

11
Important Safety Instructions
Thank you for choosing SIMPA products! The following instructions are very important to safety operation
of gas hotplate. Please read through them carefully. Please contact Towngas 24-hour Customer Service
Hotline on 2880 6988 for enquiry and services.
Installation
1. Use approved gas tubing bearing EMSD approval marking (such as: 機電工程署批准 EMSD APPROVAL
GTXXXX) for connection to appliance or other appropriate methods accepted by EMSD.
2. Do not put any combustible materials, e.g. paper and plastic near or under appliance. The appliance
should be installed with a distance more than 150mm distance away from combustible materials.
3. Install the appliance in a well-ventilated room.
Operation
1. In case of suspected gas leak, open windows and shut off gas meter valve. Do not operate any electric
appliances or switches. Do not use any phones on site. Contact Towngas Emergency Hotline on
2880 6999 with a phone outside the premises.
2. Please use the appliance properly according to the operating instructions.
3. This appliance is designed for domestic use only. Do not use it for commercial purposes.
4. Do not use the appliance for any purposes other than cooking, e.g. drying clothes.
5. Open windows and turn on ventilation system before operating the appliance.
6. Do not allow kids to use appliance.
7. Do not leave operating appliance unattended.
8. Do not add aluminum discs to burners. This will incur combustion problem.
9. Before use, ensure the burner caps, drip pans and pan supports are in correct position and are not
tilted.
10. Do not put weight exceeding 10kg on pan support.
11. Pan support is heavy. Do not drop it.
12. Make sure that flame condition is uniform during operation.
13. Heed high temperature of top plate, burner and pan support.
14. Do not use flat bottom pot of diameter larger than 300mm to avoid the risk of scald by high temperature
and reduction of service life of appliance.
15. When using small utensil, reduce flame power that flame does not escape from utensil bottom.
16. Ensure stability of utensil resting on pan support. Hold utensil firmly if it slips easily.
17. Do not fill water including soup ingredients over two-thirds of utensil volume when boiling water or
soup. Spilled liquid of boiling will affect combustion and damage the appliance.
18. Do not press the control knob more than 10 seconds. If the burner is not ignited after 10 seconds,
wait at least 1 minute before making further attempt.
19. Always use pots with covers and make sure that the handles of the pots are correctly positioned to
avoid heating and collision of handles.
20. Do not use sprays near the appliance.
21. Control knobs should be turned to off position after use.
22. Clean burner caps regularly to ensure smooth passage of burner flame holes. In case of spillage of
food or liquid, clean appliance properly once it cools down.
23. If abnormal noise is observed, turn off flame. Check and place burner caps correctly after appliance
cools down. Contact Towngas Company for inspection if problem persists.

12
Important Safety Instructions
Maintenance
1. Check condition of gas hose regularly. Ensure that it is free from kink or crack. Contact Towngas
Company to replace it if damage is found.
2. Allow the appliance to cool down completely before cleaning.
3. Wear gloves to protect the hands when cleaning the appliance. Avoid to touch interior of appliance to
prevent cut injury.
4. Dry burner caps completely with dry cloth after washing. Burner flame holes must be free from water
lest combustion is affected.
5. Before and after use, notice the condition and cleanliness of burner. The following abnormal
conditions will incur abnormal combustion and thus damage of the appliance. Ensure undertaking
measures to rectify the problem accordingly.
Abnormal Condition Handling Measure
Burner caps are deformed. Contact Towngas Company to replace the parts.
Burner caps are tilted. Place burner caps properly. Burner caps must not
be tilted.
Burner flame holes are blocked by
water.
Dry burner caps with cloth and place them
properly.
Burner flame holes are blocked by dirt.
Clean burner caps with mild detergent and brush.
Dry burner caps with cloth and place them
properly.

13
This appliance is designed to meet versatile cooking needs in Hong Kong. It is equipped with piezoelectric
ignition device, rotary control knob and powerful flame with independent simmer. The top plate is made of
quality stainless steel which is easy to clean and has appealing appearance.
It is equipped with flame failure safety device. In cases of unexpected flame extinguishment, gas is shut off
automatically to ensure safety.
Component Name
Features include:
 Powerful double ring burner with independent simmer for versatile cooking needs
 Piezo-electric ignition device which does not require battery
 Rotary flame control knob for simple and flexible operation
 Brass burner caps with thermal resistant coating and slot type flame holes for durability and easy cleaning
 Flame failure safety device for safety
Product Description
RVH2SK RVH1SK
Double Ring
Burner
Rubber Leg
Top Plate
Control Knob
Pan Support
Outer Ring Burner Base
Flame Failure Safety Sensor
Simmer Burner Base
After Removal of Burner Caps

14
 Place the hotplate on a stable and level surface.
 Connect the hotplate with approved flexible gas hose.
 Flexible gas hose can be placed under appliance, however it must be placed horizontally and close to
cooking bench in order to avoid touching burner base part.
 Place pan supports, burner caps and drip pans correctly before use.
1. Pan Support
Fit pan support bottom guide pins into top plate holes.
2. Burner Cap
Improper placement will cause poor combustion and burner cap deformation.
3. Drip Pan
Place drip pan so that it does not tilt.
Installation Instructions
Simmer Burner Cap
Pan Support
Drip Pan
Burner Base
Outer Burner Cap
Simmer Burner Cap
Outer Burner Cap
Inclined
Simmer Burner Cap
Outer Burner Cap
Inclined
No tilt
Align with top plate
Correct
Wrong

15
1. Ignition
Press and turn control knob to the left until it is stopped at ignition ( ) position. Burner is ignited. If
not, wait for several seconds and ignite again.
When the flame is ignited, hold it for a few seconds.
If the flame goes out when the knob is released, turn it back to off (●) position and repeat ignition.
2. Flame Adjustment
Please adjust flame slowly.
Please adjust flame according to pot size. If flame is too large, it may damage the utensil handle and
may incur burn injury when the handle is touched.
3. Turn Off
Turn control knob backwards to off (●) position to turn off flame.
4. Accidental Flame Off
If the flame is off unexpectedly, gas will be shut off automatically. Turn control knob to off (●) position,
ensure cleanliness of burner before ignition again.
If flame holes of burner are blocked, allow burner to cool down and clean it. Wipe it dry before ignition
again.
Operating Instructions
Position Control
Knob
Flame Condition
Simmer Flame Small Max. Max. Min.
Outer Ring Flame Small Max. Off Off

16
Maintenance
Attention: Allow the appliance to cool down before performing any maintenance and cleaning.
Wear gloves to protect the hands while cleaning.
To maintain the appliance properly, follow the following instructions to clean it regularly:
 Do not use steam cleaners for cleaning;
 The metal and enameled parts must be cleaned with suitable non-abrasive and non-corrosive
detergents. Avoid using chlorine-based detergents (e.g. bleach);
 Avoid leaving acidic or alkaline substances on the appliance (e.g. vinegar, brine, lemon juice);
 Clean and tidy up the appliance after spillage of liquid once it cools down;
 The burner caps must be washed regularly with warm water and detergent. Remove any grime and
keep the flame holes of burners away from blockage;
 Dry the burner caps completely after wash and ensure that all flame holes of burner are not
clogged;
 Replace burner caps on burner bases correctly. Ensure that they are not tilted or reversed;
 Regularly check the flame failure safety sensors. In case of sticking with stains, clean them with soft
brush.

17
Troubleshooting
Some malfunctions can be handled by user. But if the following remedial actions are not effective, please
call Towngas Customer Service Hotline at 2880 6988.
Fault Cause Remedy
1. No flame Gas meter valve and / or
appliance gas supply valve is
turned off.
Open gas meter valve and/or appliance
gas supply valve completely.
Burner is blocked by aluminum
foil.
Remove aluminum foil.
2. Flame cannot be held Control knob is not fully pressed
during turning.
Fully press and turn the control knob
anti-clockwise to ignition ( ) position.
Hold it for 5 seconds before releasing it.
Holding time of control knob is too
short.
Flame failure safety sensor has
dirt.
Clean flame failure safety sensor.
3. Flame off when using Small flame is blown off by wind. Wait for 1 minute, restart ignition.
Cooking spillage blocks burner and
incurs flame off.
Allow burner to cool down, clean and
dry it, restart ignition.
4. Yellow flame Burner has dirt. Wash burner caps in warm water with
detergent. Wipe them dry and replace
them properly. Restart ignition .
5. Unstable flame Incorrect placement of burner
caps.
After cooling, replace burner caps
properly, then restart ignition.
6. Abnormal noise when
using
Incorrect placement of burner
caps.
Turn off flame. Replace burner caps
correctly after appliance cools down and
restart ignition.
7. Pop sound when
turning off flame
Instant combustion of gas
remained in burner.
Normal phenomenon.
