Simpact Freeway 1200 Manual

Simpact, Inc.
9210 Sky Park Court
San Diego, CA 92123
Freeway
®
1200/1300
Hardware Installation Guide
DC 900-1537B
November 1999

Simpact, Inc.
9210 Sky Park Court
San Diego, CA 92123
[phone]
Freeway 1200/1300 Hardware Installation Guide
© 1999 Simpact, Inc. All rights reserved
Printed in the United States of America
This document can change without notice. Simpact, Inc. accepts no liability for any errors this
document might contain.
Freeway is a registered trademark of Simpact, Inc.
All other trademarks and trade names are the properties of their respective holders.

DC 900-1537B 3
Contents
List of Figures 5
List of Tables 7
Preface 9
Safety Precautions 15
Freeway 1200 Certifications 21
Freeway 1300 Certifications 25
1 Getting Started 29
2 Hardware Installation 31
3 Configuring the Boot Parameters using the Initialization Disk 43
4 Configuring the Boot Parameters using the Local Console 51
A Electrical Interfaces 61
B Freeway 1300 LED Panel and Alarm Functions 63
C Replacing the Power Supply in a Freeway 1300 67
Index 71

4 DC 900-1537B
Freeway 1200/1300 Hardware Installation Guide

DC 900-1537B 5
List of Figures
Figure 2–1: Front View: Freeway 1200 (lockable door not shown) ........... 34
Figure 2–2: Front View: Freeway 1300 (lockable door not shown) ........... 35
Figure 2–3: Example Back View: Freeway 1200 ..................... 36
Figure 2–4: Example Back View: Freeway 1300 ..................... 37
Figure 2–5: ICP Numbering: Freeway 1200 ....................... 39
Figure 2–6: ICP Numbering: Freeway 1300 ....................... 40
Figure 3–1: Example of the Freeway System Boot Parameters ............. 45
Figure 3–2: Configured Freeway System Boot Parameters ............... 48
Figure 4–1: Freeway Boot System Main Menu ...................... 54
Figure 4–2: Example of the Freeway System Boot Parameters ............. 55
Figure 4–3: Configured Freeway Boot Parameters .................... 60
Figure B–1: Front Panel: Freeway 1300 (lockable door not shown)........... 63

6 DC 900-1537B
Freeway 1200/1300 Hardware Installation Guide

DC 900-1537B 7
List of Tables
Table 3–1: Freeway System Boot Parameters....................... 45
Table 3–2: Flags for Reset Action ............................. 47
Table 4–1: Freeway System Boot Parameters....................... 56
Table 4–2: Flags for Reset Action ............................. 58
Table A–1: Commonly Used Electrical Interfaces .................... 61

8 DC 900-1537B
Freeway 1200/1300 Hardware Installation Guide

DC 900-1537B 9
Preface
Purpose of Document
This document describes the hardware installation procedures for Simpact’s Freeway
1200/1300 communications server. It is used in conjunction with the Freeway User
Guide , which describes the software installation procedure.
Intended Audience
This document should be read by the computer technician who will be installing the
Freeway communications server. System administrators and system integrators may
also find it useful.
Organization of Document
The “Safety Precautions” section on page 15 describes important safety guidelines that
you should review before beginning the installation.
The “Freeway 1200 Certifications” section on page 21 shows the certifications for the
Freeway 1200.
The “Freeway 1300 Certifications” section on page 25 shows the certifications for the
Freeway 1300.
Chapter 1 is an overview of the Freeway installation procedure.
Chapter 2 describes the hardware installation.
Same:
3100/3150,
3200/7200,
1200/1300
The“Required
Equipment”
section was
intentionally
moved to
Chapter 2.
4/20/99: I
changed the
spac
i
ng above

10 DC 900-1537B
Freeway 1200/1300 Hardware Installation Guide
Chapter 3 describes how to configure the boot parameters using the boot parameter
initialization disk.
Chapter 4 describes how to configure the boot parameters using the local console.
Appendix A shows the commonly used electrical interfaces.
Appendix B describes the Freeway 1300 LED panel and alarm functions.
Appendix C describes how to replace a power supply in the Freeway 1300.
Simpact References
The following general product documentation list is to familiarize you with the avail-
able Simpact Freeway and embedded ICP products. The applicable product-specific
reference documents are mentioned throughout each document (also refer to the
“readme” file shipped with each product). Most documents are available on-line at
Simpact’s web site, www.simpact.com.
General Product Overviews
•
Freeway 1100 Technical Overview
25-000-0419
•
Freeway 2000/4000/8800 Technical Overview
25-000-0374
•
ICP2432 Technical Overview
25-000-0420
• ICP6000X Technical Overview
25-000-0522
Hardware Support
•
Freeway 1100/1150 Hardware Installation Guide
DC-900-1370
•
Freeway 1200/1300 Hardware Installation Guide
DC-900-1537
•
Freeway 2000/4000 Hardware Installation Guide
DC-900-1331
•
Freeway 8800 Hardware Installation Guide
DC-900-1553
•
Freeway ICP6000R/ICP6000X Hardware Description
DC-900-1020
•
ICP6000(X)/ICP9000(X) Hardware Description and Theory of
Operation
DC-900-0408
• ICP2424 Hardware Description and Theory of Operation
DC-900-1328
10/19/99
Leslie: Add
1566
Addendum to
1501, and add
“Freeway” to
title of 1533.

Preface
DC 900-1537B 11
•
ICP2432 Hardware Description and Theory of Operation
DC-900-1501
•
ICP2432 Electrical Interfaces (Addendum to DC-900-1501)
DC-900-1566
•
ICP2432 Hardware Installation Guide
DC-900-1502
Freeway Software Installation and Configuration Support
•
Freeway Message Switch User Guide
DC-900-1588
•
Freeway Release Addendum: Client Platforms
DC-900-1555
•
Freeway User Guide
DC-900-1333
•
Freeway Loopback Test Procedures
DC-900-1533
Embedded ICP Software Installation and Programming Support
•
ICP2432 User Guide for Digital UNIX
DC-900-1513
•
ICP2432 User Guide for OpenVMS Alpha
DC-900-1511
• ICP2432 User Guide for OpenVMS Alpha (DLITE Interface)
DC-900-1516
•
ICP2432 User Guide for Solaris STREAMS
DC-900-1512
•
ICP2432 User Guide for Windows NT
DC-900-1510
•
ICP2432 User Guide for Windows NT (DLITE Interface)
DC-900-1514
Application Program Interface (API) Programming Support
•
Freeway Data Link Interface Reference Guide
DC-900-1385
•
Freeway Transport Subsystem Interface Reference Guide
DC-900-1386
•
QIO/SQIO API Reference Guide
DC-900-1355
Socket Interface Programming Support
•
Freeway Client-Server Interface Control Document
DC-900-1303
Toolkit Programming Support
•
Freeway Server-Resident Application and Server Toolkit
Programmer Guide
DC-900-1325
•
OS/Impact Programmer Guide
DC-900-1030
•
Protocol Software Toolkit Programmer Guide
DC-900-1338
Protocol Support
•
ADCCP NRM Programmer Guide
DC-900-1317
•
Asynchronous Wire Service (AWS) Programmer Guide
DC-900-1324

12 DC 900-1537B
Freeway 1200/1300 Hardware Installation Guide
Document Conventions
The term “Freeway” refers to either of the Freeway models, 1200 or 1300.
Revision History
The revision history of the Freeway 1200/1300 Hardware Installation Guide , Simpact
document DC 900-1537B, is recorded below:
•
AUTODIN Programmer Guide
DC-908-1558
•
Bit-Stream Protocol Programmer Guide
DC-900-1574
•
BSC Programmer Guide
DC-900-1340
• BSCDEMO User Guide
DC-900-1349
•
BSCTRAN Programmer Guide
DC-900-1406
•
DDCMP Programmer Guide
DC-900-1343
•
FMP Programmer Guide
DC-900-1339
•
Military/Government Protocols Programmer Guide
DC-900-1602
• N/SP-STD-1200B Programmer Guide
DC-908-1359
•
SIO STD-1300 Programmer Guide
DC-908-1559
•
X.25 Call Service API Guide
DC-900-1392
•
X.25/HDLC Configuration Guide
DC-900-1345
•
X.25 Low-Level Interface
DC-900-1307
Document Revision Release Date Description
DC 900-1537A July 1999 Original release
DC 900-1537B November 1999 Added new flag, 0x2000
Added description of Freeway 1300
LED panel and alarm functions

Preface
DC 900-1537B 13
Customer Support
If you are having trouble with any Simpact product, call us at 1-800-275-3889 Monday
through Friday between 8 a.m. and 5 p.m. Pacific time.
You can also fax your questions to us at [phone] or [phone] any time.
Please include a cover sheet addressed to “Customer Service.”
We are always interested in suggestions for improving our products. You can use the
report form in the back of this manual to send us your recommendations.

14 DC 900-1537B
Freeway 1200/1300 Hardware Installation Guide

DC 900-1537B 15
Safety Precautions
English
Be sure to take the following safety precautions during installation and maintenance of
the Freeway communications server:
•Observe the warnings and directions printed on the Freeway server and its asso-
ciated equipment.
•Check the electrical rating label on the Freeway chassis. Be sure that the voltage
and frequency of your power source match this rating.
•The Freeway server must be plugged into a grounded, three-wire power outlet.
Do not use an adapter that permits a three-wire electrical cord to be plugged into
a two-wire power outlet.
•Use appropriately rated extension cords or power strips only.
•To ensure proper cooling, always operate the Freeway server with its covers in
place. Do not cover or block any of the openings on the Freeway chassis. Do not
place the unit near a heater.
•Do not insert objects through openings in the Freeway chassis. Doing so could
result in a short circuit that might cause a fire or an electric shock.
•Do not modify the Freeway equipment in any way. Simpact, Inc. is not responsi-
ble for regulatory compliance of any Freeway communications server that has
been modified. Altering the Freeway enclosure in any way other than the installa-
tion of Simpact-provided options may invalidate Freeway’s safety certifications.

16 DC 900-1537B
Freeway 1200/1300 Hardware Installation Guide
•Always unplug the Freeway AC power cord before removing the top or bottom
covers for servicing.
Français
Précautions d’emploi
Nous vous prions de suivre les précautions d’emploi suivantes au cours de l’installation
ou de tout entretien de votre serveur de communication Freeway:
•Respecter les avertissements et les instructions imprimées sur le serveur Freeway
et les appareils qui y sont associés.
•Vérifier les normes électriques indiquées sur une étiquette se trouvant sur le châs-
sis Freeway. Prière de s’assurer que le voltage et la fréquence de la source d’alimen-
tation sont compatibles avec ces normes.
•Le serveur Freeway doit être branché dans une prise de terre à trois broches. Ne
pas utiliser d’adaptateur permettant de brancher une prise mâle à trois broches
dans une prise de courant à deux broches.
•N’utiliser des rallonges, fils électriques ou parasurtenseurs qu’aux normes appro-
priées.
•Afin de refroidir correctement le serveur Freeway, utiliser seulement celui-ci avec
la housse en place. Ne pas couvrir ou bloquer les ouvertures du châssis Freeway.
Ne pas placer l’appareil Freeway près d’une source de chaleur.
•Ne pas insérer d’objets par les ouvertures du châssis Freeway. Ceci risquerait de
provoquer un court-circuit résultant en une décharge ou un incendie.
•Ne pas modifier l’appareil Freeway de quelque manière que ce soit. Simpact, Inc.
ne pourra être tenu responsable de toute infraction aux normes d’un serveur de
communication Freeway ayant été modifié. Toute altération de l’enveloppe Free-
way d’une manière autre que pour l’installation d’options fournies par Simpact
risque de rendre les normes de sécurité de Freeway invalides.

Safety Precautions
DC 900-1537B 17
•Toujours débrancher le fil d’alimentation en courant alternatif de Freeway avant
d’enlever la housse supérieure ou inférieure à des fins d’entretien.
Deutsch
Sicherheitsvorkehrungen
Vergewissern Sie sich, daß die folgenden Sicherheitsmaßnahmen bei der Installation
und Wartung des Freeway Kommunikations-Servers eingehalten werden:
•Lesen Sie die Anleitung und Sicherheitsregeln auf dem Freeway Server und auf
dem Zubehör.
•Die Voltspannung und Frequenz der von Ihnen verwendeten Stromquelle muß
mit den elektrischen Werten, die auf dem Freeway Chassis angegeben sind, übere-
instimmen.
•Der Freeway Server muß an eine geerdete, dreiadrige Stromquelle angeschlossen
werden. Bitte verwenden Sie keine Adapter, die den Anshluß dreiadriger Kabel an
zweiadrige Stromquellen ermöglichen.
•Benutzen Sie nur den Angaben entsprechende Verlängerungskabel oder Steck-
dosenleisten.
•Benutzen Sie den Freeway Server nur, wenn alle Abdeckungen intakt sind und die
vordere Scharniertür geschlossen ist. Blockieren Sie in keiner Weise irgendwelche
Öffnungen des Freeway Chassis, und positionieren Sie den Apparat nicht in der
Nähe einer Heizung.
•Stecken Sie keine Gegenstände durch die Öffnungen des Gehäuses; dies könnte
einen Kurzschluß hervorrufen, der einen Brand oder einen elektrischen Schlag
verursachen kann.
•Verändern Sie in keiner Weise das Freeway Zubehör. Simpact, Inc. ist nicht für
abgeänderte Freeway Kommunikations-Server verantwortlich, die demzufolge
den vorgeschriebenen Regeln nicht entsprechen. Jegliche Abänderungen der

18 DC 900-1537B
Freeway 1200/1300 Hardware Installation Guide
Freeway Anlage, mit Ausnahme der Installation von Simpact-Sonderausstattun-
gen, können die Sicherheitsbescheinigung der Anlage ungültig werden lassen.
•Entfernen Sie immer das Freeway Stromkabel von der Stromquelle, bevor Sie die
oberen oder unteren Deckel zur Wartung abnehmen.
Italiano
Norme di sicurezza
Durante l’installazione e la manutenzione del server per le comunicazioni Freeway
seguire le seguenti norme di sicurezza:
•Seguire le avvertenze e le istruzioni stampate sul server Freeway e sulle altre unità
ad esso collegate;
•Controllare l’etichetta con l’indicazione del voltaggio elettrico sul telaio ed assi-
curarsi che voltaggio e frequenza della presa di corrente vi corrispondano;
•Il server Freeway deve essere collegato ad una spina con messa a terra, e con tre
fili. Non usare un adattatore che consente di collegare un filo a tre fili in una presa
a due;
•Usare solo fili e prese multiple con taratura appropriata;
•Per assicurare un raffreddamento adeguato usare sempre il server Freeway con il
suo relativo coperchio. Non coprire o bloccare nessuna delle aperture del telaio di
Freeway. Non collocare l’unità vicino a fonti di calore;
•Non inserire oggetti nelle aperture situate sul telaio di Freeway, perchè così
facendo si rischia di provocare un corto circuito, che può generare un incendio o
una scossa elettrica;
•Non modificare in nessun modo l’unità Freeway. La Simpact, Inc. non è respons-
abile della conformità alle norme di nessun server Freeway per le comunicazioni
che sia stato modificato. L’alterazione in qualsiasi maniera del telaio di Freeway,

Safety Precautions
DC 900-1537B 19
che differisca dalle opzioni di installazione fornite dalla Simpact, può invalidare le
garanzie di sicurezza;
•Prima di togliere il coperchio o la base per effettuare qualsiasi manutenzione,
togliere sempre la spina di Freeway.

20 DC 900-1537B
Freeway 1200/1300 Hardware Installation Guide
