1 D Class System Installation
How to install the basic HP 9000 D Class Enterprise server and its associated
components, such as the console and keyboard.

1-2
D Class System Installation
Overview of System Installation
Overview of System Installation
Installation of a basic system consists of the following procedures:
1. Install internal add-on options.
2. Connect the console or graphics monitor.
3. Connect the SCSI, network, and parallel cables.
4. Connect Remote Management (Access Port) card and the serial data cable for
the optional UPS.
5. Set the input voltage selector.
6. Connect system power cords.
7. Turn on power to the system.
8. Prepare for network connections.
9. Prepare for terminal connections.
The installation procedures start with “1. Install Internal Add-on Options”. Refer to
the picture on the next page when connecting cables to rear panel connectors.
WARNING The HP 9000 D Class Enterprise Server weighs about 49.5 kg (110 lbs). You
must use two people to lift the D Class server cabinet.

1-3
D Class System Installation
Overview of System Installation
CAUTION To avoid damage to the front panel of the server, DO NOT use any part of the front
panel as a handle to lift or move the D Class server cabinet. When moving or lifting
the server cabinet, be sure that the front panel peripheral door is locked.
REAR PANEL
CONNECTORS
1. Serial (D3xx servers) or
Serial 2/UPS (D2xx servers)
2. SCSI (Single-Ended)
3. Graphics Mouse
4. LAN 10 Base-T
5. Serial 1/Console
6. Parallel
7. Graphics Keyboard

1-4
D Class System Installation
1. Install Internal Add-on Options
1. Install Internal Add-on Options
D Class servers are configured at the factory to include most I/O cards and internal
peripherals.
If you have any internal add-on options, install them now according to the
instructions shipped with the option.
WARNING DO NOT CONNECT SYSTEM POWER CORD AT THIS TIME. If you open
the system cabinet when power is connected, you will be exposed to high-energy
(high-amperage) circuits and possible ejection of molten metal. Be sure to
remove all rings, watches, and other jewelry from fingers, wrists, and arms
before opening the system cabinet.
Electrostatic
Discharge
Precautions
If you are installing additional cards or peripherals, you must ensure that they are
not damaged due to electrostatic discharge (ESD). To prevent such damage from
occurring, observe the following ESD precautions when handling and installing
boards:
1. Use a grounding mat and an anti-static wrist strap. These items are included in
the ESD Field Service Kit (HP P/N A3024-80004).
2. Wear the anti-static wrist strap to ensure that any accumulated electrostatic
charge is discharged from your body to ground.
3. Keep uninstalled printed-circuit boards in their protective anti-static bags until
you are ready to install them.
4. Handle printed-circuit boards by their edges after you have removed them from
their protective anti-static bags.

1-5
D Class System Installation
2. Connect the Console or Graphics Monitor
2. Connect the Console or Graphics Monitor
1. Console/
Keyboard If you have an ASCII console (such as the HP 700/96) connect it to the server rear
panel connector labeled Serial 1/ Console. Connect the keyboard to the keyboard
connector at the rear of the console.
2. D3xx Graphics
Monitor,
Keyboard, Mouse
If you have a D3xx server with a graphics monitor, connect it to the graphics I/O
card at the rear of the system cabinet. Connect the keyboard and mouse to the
connectors labeled with keyboard and mouse symbols at the rear of the cabinet.
NOTE The interface card for the graphics monitor can be installed only in the slot marked
TURBO in the D3xx server (as shown in 2, below). The TURBO slot is not
available for model D310/320/330. Use any open HP-HSC slot..

1-6
D Class System Installation
3. Connect the SCSI, Network, and Parallel Cables
3. Connect the SCSI, Network, and Parallel
Cables
1. Connect your SCSI device cable to the connector labeled SCSI (Single-Ended)
on the server rear panel. If no SCSI cable is to be attached to the server, place or
leave the SCSI terminator (supplied with your server) on the SCSI (Single-
Ended) connector.
2. Connect your parallel device, such as a printer, to the rear panel connector
labeled Parallel.
3. Read and remove the sticker that covers the connector, then connect your LAN
cable to the LAN 10 Base-T connector at the rear of the D Class server.
NOTE An optional AUI adapter for the LAN 10 Base-T connector is available (if special
ordered).

1-7
D Class System Installation
4. Connect Remote Management Card and Serial Data Cable for the
Optional UPS
4. Connect Remote Management Card and Serial
Data Cable for the Optional UPS
The Remote Management card (also called the Access Port or AP card) is optional
on Model D2xx servers, and standard on Model D3xx servers. The Remote
Management card is located in different slots depending on which model of D Class
server you have. Also, on Model D2xx servers, the UPS data cable connection will
vary depending on whether the optional Remote Management card is present.
Model D2xx 1. If you have a Remote Management card, connect your Line Access Module
(LAM) for connecting to the phone line, to the Modem/LAM connector on the
Remote Management card.
2. If you also have a UPS, connect the data cable from the UPS Port on the UPS to
the UPS connector on the Remote Management card.
3. If you do not have a Remote Management card, connect the UPS data cable from
the UPS Port on the UPS to the connector on the server labeled Serial 2/UPS.

1-8
D Class System Installation
4. Connect Remote Management Card and Serial Data Cable for the
Optional UPS
Model D3xx 1. Connect your Line Access Module (LAM), for connecting to the phone line, to
the Modem/LAM connector on the Remote Management (Access Port) card.
2. If you have a UPS, connect the UPS data cable from the UPS Port on the UPS
to the UPS connector on the Remote Management card.
1
2

1-9
D Class System Installation
5. Set the Input Voltage Selector
5. Set the Input Voltage Selector
CAUTION To avoid damage to your server, be sure to set the input voltage selector switch to a
setting within the voltage range of the power source you intend to use. Always
check the switch setting before connecting the power cord.
1. If your input voltage is in the range of 100 V to 127 V, set the voltage selector to
the 115 setting.
2. If your input voltage is in the range of 200 V to 240 V, set the voltage selector to
the 230 setting.
NOTE System models Dx70, Dx80, and D390 have a power supply that automatically
switches to match the input voltage level. There is no voltage selector switch on
these models.

1-10
D Class System Installation
6. Connect the System Power Cords
6. Connect the System Power Cords
How you connect the system power cords depends on whether your server
configuration includes the optional Uninterruptible Power System (UPS). Be sure to
connect power correctly for your system, as shown below.
WARNING Be sure the server cabinet is closed and secured before connecting power cord.
Refer to the WARNING on page 4.
The D Class servers can be connected to any UPS in the PowerTrust UPS family,
except as noted below.
NOTE The A2941A PowerTrust UPS (600VA) can only be used on the HP D200 and HP
D210 Deskside Enterprise Servers. All other D Class Enterprise Servers require an
A2994A PowerTrust UPS (1300VA), or larger. Contact your nearest HP Sales
Representative for more information.
The UPS shown in the following diagram is only representative. Contact your
nearest HP Sales Representative for more information.
1. If you do not have a UPS, connect both the D Class server and the console (or
optional graphics monitor) directly to your AC power source.
2. If you have a UPS, connect the D Class server to the upper-left socket at the top-
rear of the UPS (using the cord supplied with the UPS), then connect the system
console (or optional graphics monitor) to one of the other AC Outlet sockets
along the top of the UPS rear panel. Finally, connect your AC power source to
the input socket of the UPS.

1-11
D Class System Installation
6. Connect the System Power Cords

1-12
D Class System Installation
7. Turn On Power to the System
7. Turn On Power to the System
1. If you have the optional UPS, set the Power switch on the front panel of the UPS
to the ON position. The green AC Output light should be on. If any of the other
UPS front panel lights are on, refer to the UPS manual for appropriate action.
2. Turn on the system console (or graphics monitor).
3. Set the Power switch on thefrontpanel of the D Class server to the ON position.
The green light inside the switch should come on.

1-13
D Class System Installation
8. Prepare for Network Connections
8. Prepare for Network Connections
To use your D Class server on a network, you will need the following information:
• LAN station address (see system label)
• System name (or hostname)
• Internet Protocol (IP) address.
The LAN station address is provided on the server’s system label located on the
inside of the front panel peripheral door. Write the number down and give it to your
system administrator.
The hostname and IP address must be obtained from your system administrator.

1-14
D Class System Installation
9. Prepare for Terminal Connections
9. Prepare for Terminal Connections
Configure your D Class server for terminal connections using the System
Administration Manager (SAM) program. To use SAM, refer to the following
manuals that were shipped with your system:
• System Administration Tasks
• Configuring HP-UX for Peripherals.
For EISA MUX card installation, refer to the manuals that came with the EISA
MUX card:
• HP EISA MUX Quick Installation Card
• HP EISA MUX Cabling, Diagnostics and Troubleshooting Guide.
Also refer to the I/O Card Installation guide that came with the system.
