Simplex TYCO VLC-600 User manual

Features
Model VLC-600 addressable, analog output air
aspiration smoke sensor provides:
VESDA LaserCOMPACT operation communicating
with the established TrueAlarm analog sensing process
for area coverage up to 8000 ft2
Compact 8 ⅞” (225 mm) square size
Dual stage dust filter that is used on larger systems
Obscuration measurements communicated to the fire
alarm control panel for status determination
Panel selected sensitivity from 0.016%/ft to 4.08%/ft
Local computer port access for the VESDA Vconfig
Pro software program as used on larger systems
Single LED that indicates local status information
Capability of driving a remote LED (ordered
separately)
Trouble conditions are also communicated:
Mechanical problems are received as sensor troubles
Electrical problems are received as “no answer” troubles
Additional details are indicated by the sensor LED and
by accessing sensor diagnostics
Compatible with Simplex®4100ES, 4010ES,
4100U, or legacy 4100/4120 fire alarm control
panels:
Communications via 4100ES/4010ES/4100U IDNet
or 4100ES/4100U MAPNET II addressable formats
Connection is to the same SLC (signaling line circuit)
with other devices such as addressable manual
stations, TrueAlarm area smoke sensors, addressable
control modules, etc.
Communications are as a single device and connection is
direct to the SLC without requiring a dedicated interface
4100/4120 requires revision 8.01 or higher software
Three threshold levels are programmable from the
fire alarm control panel with typical selections as:
Stage 1 – Alert at 0.016 to 0.6218% obscuration/ft
Stage 2 – Pre-Alarm at 0.03 to 0.6234% obscuration/ft
Stage 3 – Alarm at 0.05 to 4.08% obscuration/ft
NOTE: UL listed evacuation alarm sensitivity is not
to be less sensitive than 0.625%/ft
Sampling pipe network:
Uses standard Vision Systems pipe and inlet in
accordance with Vision Systems Aspire design tool
UL listed to Standard 268 (URXG)
*This product has been approved by the California State Fire Marshal (CSFM) pursuant to
Section 13144.1 of the California Health and Safety Code. See CSFM Listing
7259-1728:0109 for allowable values and/or conditions concerning material presented in
this document. This product was not approved by FM as of document revision date.
Additional listings may be applicable; contact your local Simplex product supplier for the
latest status. Listings and approvals under Simplex Time Recorder Co. are the property of
Tyco Fire Protection Products.
Typical air inlet
VLC-600 TrueAlarm
LaserCOMPACT Air
Aspiration Smoke Sensor
Fire Alarm Control Panel requires 4100ES/4010ES/4100U
IDNet or 4100ES/4100U MAPNET II communications
(4100ES shown for reference)
4100ES/4010ES/4100U IDNet
or 4100ES/4100U MAPNET II
addressable communications
TrueAlarm
Laser
COMPACT
Addressable manual stations,
TrueAlert sensors and other devices
ALARMFIRE
PULL DOWN
24 VDC power
ALARM
Clean room cable tray
Remote LED indicator
CLEAN ROOM
SMOKE DETECTOR ALARM
TrueAlarm LaserCOMPACT System Connections
Description
Air aspiration technology smoke detection operates
by actively drawing in air for sampling in a high intensity,
stable detection chamber. The Model VLC-600
TrueAlarm LaserCOMPACT smoke detector uses the
latest in VESDA sampling technology including a highly
efficient laser light source and a dual stage dust filter.
TrueAlarm analog sensing occurs when the
TrueAlarm LaserCOMPACT sensor communicates
smoke chamber information to the connected fire alarm
control panel. The panel evaluates the smoke sensor
information against three programmed thresholds and
declares an alarm or pre-alarm condition depending on
smoke chamber activity.
Status communications. In addition to smoke
chamber information, the TrueAlarm LaserCOMPACT
also advises the fire alarm control panel of local trouble
conditions. Troubles may include dirty filter, airflow
restriction or failure, etc. Specific details are stored in
memory at the sensor location.
TrueAlarm Analog Sensing
UL, ULC, CSFM Listed* VLC-600 TrueAlarm LaserCOMPACT Smoke Sensor with
4100ES/4010ES/4100U IDNet and MAPNET II Communications
S4098-0036-7 7/2013

Operation
Filtered air flow. A high efficiency aspirator
continually draws air through a simple pipe network to a
central detector. Air entering the sensor housing passes a
flow sensor before the sample is passed through a
dual-stage dust filter. The majority of air is exhausted
from the detector and where required, back vented to the
protected area. The first stage of the air filter removes
dust and dirt from the air sample before it enters the
smoke detection chamber. A second, ultra-fine filter stage
provides a clean air supply to be used inside the detection
chamber to form clean air barriers which protect the
optical surfaces from contamination.
Laser detection chamber. The detection chamber uses
a stable, highly efficient laser light source and unique
sensor configuration to achieve optimum response to a wide
range of smoke types. When smoke passes through the
detection chamber, it creates light scattering which is
detected by very sensitive sensor circuitry. The analog level
of the sensor is then communicated to the fire alarm control
panel for comparison to pre-selected alarm thresholds.
Operation (Continued)
Status logging. The sensor status history for all alarms,
service, and fault events, is monitored and logged with
time and date stamps within the electronics of the sensor,
accessible via the local computer port. General trouble
status indications are communicated to the panel as either
sensor troubles or “no answer” troubles.
Additional Information
Refer to Installation Instructions 19772 shipped with the
VLC-600 for additional information.
Model Description
VLC-600 TrueAlarm LaserCOMPACT Smoke Sensor (sampling pipe is ordered separately)
2098-9808 Remote Red LED Status Indicator on single gang stainless steel plate; mounting requires a single gang
box, 1 ½” minimum depth; connections are color coded wire leads
Sensor Voltage 18 to 30 VDC, supplied from fire alarm control panel
Sensor Current 205 mA @ 24 VDC; supervisory and alarm
Communications Compatibility 4100ES/4010ES/4100U IDNet or MAPNET II addressable
communications, automatically selected
Loading One address, one unit load per sensor
Electrical Terminations Terminal blocks for 18 to 12 AWG
Operating Conditions Sensor Ambient 14° F to 103° F (-10° C to 39° C) Sampled Air -4° F to 140° F (-20° C to 60° C)
Sensor Humidity 10-95% RH, non-condensing
Sampling Network Maximum area of coverage = 8000 ft2, maximum pipe length in
accordance with Vision Systems computer design tool (ASPIRE) and
NFPA standards
UL Listed Velocity Range 0 to 4000 ft/min (0 to 1200 m/min)
Alarm Sensitivity Range 0.016% to 4.08%/ft obscuration, selected at the fire alarm control panel;
NOTE: UL listed evacuation alarm sensitivity is not to be less sensitive
than 0.625%/ft
Recognized Sensitivity Levels Three levels, selectable and designated as required at the fire alarm
control panel
Sensor Service Access Internal DB-9, RS-232 connection for a service computer using VESDA
Vconfig Pro software program (authorized service access only)
Enclosure Rating NEMA 1 (IP 30)
Weight 4.2 lbs (1.9 kg)
2 S4098-0036-7 7/2013
Product Selection
Specifications

Indication Meaning
OFF Power off or active sensor is waiting for panel communications
ON for approximately 3 seconds Power up self-test due to sensor being in reset cycle
ON Steady Alarm condition as commanded from panel
1 pulse approximately every 4 seconds Normal operation, pulse indicates communications with panel
3 pulses (2 Hz rate every 2 seconds) Internal fault, not communicating with panel, sensor needs internal service
diagnostics or replacement
TrueAlarm
Laser
COMPACT
8-7/8"
(225 mm)
8-7/8" (225 mm) 3-3/8" (85 mm)
LED indicator
Air exhaust location
(rear assembly can be rotated 180º to reverse intake
and exhaust locations, and knockout locations)
Air intake location
Side knockouts (2)
Top knockout location
Rear knockout
location
Mounting
bracket
3 S4098-0036-7 7/2013
Mounting Information
LED Status Indications

Tyco Fire Protection Products • Westminster, MA • 01441-0001 • USA S4098-0036-7 7/2013
