Simplex 2120 User manual

S@Simplex
2120 Multiplex
\
Jumper Placement and‘
Switch Settings
0 1994 Simplex Time Recorder Co.
MUX2-21-002
All specifications and other tnformation shown were current as of pubkat~on. and are subject to change without notse.
Ed 1194
firealarmresources.com

firealarmresources.com

TABLE OF CONTENTS
BMUX Boards
CPU Board, 562-055 ....................................................._........................................................................................ 3
24K PRAM Board, 562-049 .................................................................................................................................... 6
32K PRAM Board, 562-305 .................................................................................................................................... 8
96K PRAM Board, 562-51 1 .........................................................._....................................................................... 10
DC Transmission Board, 562-083 ........................................................................................................................ 12
RS232C Board, 562-047, Rev. A through D .._.............................._........................_............................................ 13
RS232C Board, 562-047, Rev. E or Higher ........................................................................................................ 15
RS232C Board, 562-513 ..............................................._...................................................................................... 18
Ceiestra Interface Board, 562-192 ....................................................................................................................... 21
Transponders
Local BT, 562-086 ............................................................_................................................................. :................. 22
FABTs (562-096, 562-312, and 562-531) and BTs (562-101 and 562-351) ...................................................... 23
Voltage Monitor Board, 562-348 ..................................._.._.................................. :................................................ 24
Expanded Transponder
ET CPU Board, 562-381 ................................................................................................................................ 25
Digital Monitor Board (562-448), Fire Alarm Digital Monitor Board (562-506)
and Fire Alarm Digital Monitor Board, Class A (562-465) ................................................_....................... 27
Digital Control Board with Supervision (562-445)
and Digital Control Board without Supervision (562-459) ................_........_..........................._._................. 30
Fire Alarm Digital Monitor I/O Board, Class A, 562-466 _.....................__.................................._....._.............. 31
Standard Relay I/O Board (562-447) and
Audio Relay I/O Board, Class A (562-450) ......................................_........................................................ 32
Simultaneous (Duai Channel) Audio Relay Board, 562-508 ....................._..........................._..._................... 33
Voltage Monitor I/O Board, 562-398 ..........................._..._............................._................................................ 34
Status Command Center (SCC)
SCC Controller Board, 562-184, Rev. A through K ...................._...._.._.._................................_........................... 35
SCC Controller Board, 562-184, Rev. L or Higher _...._................_...._._._................................__...._....................... 38
Graphic Drive Boards ........................................................................................................................................... 41
Relay Driver Board, 562-188 .......................................................................................................................... 43
Lamp Driver Board, 562-l 98 .................................__.........._._.._........_._............................................................ 43
Remote Control and Switch Board, 562-387 ........_......................_.............................................................. . 44
Remote Switch Board, 562-396 ..................................................................................................................... 44
Standard (120V) Relay Board, 562-219 ............................................................................................................... 45
Standard (120V) Relay Board, 562-322 ............................................................................................................... 47
240 Volt Relay Board, 562-324 ............................................................................................................................ 49
Audio Relay Board, 562-589 ................................................................................................................................ 50
DC COMM to RS232C (562-389) and RS232C to DC COMM (562-394) Converters ...................................... 51
DC Line Communications Repeater, 562-346 ..................................................................................................... 52
firealarmresources.com

-
CAUTION
ELECTRICAL HAZARD
Diinnect electrical power when making any internal
adjustments or repairs. Installation and servicing
should be performed by qualified Simplex Representa-
tives
CAUTION
POWERING REQUIREMENT
When rerncving power from this system, diinect
batteries FIRST and AC power last. When connecting
power by this system, connect AC power FIRST and
batteries last.
firealarmresources.com

CPU BOARD, 562-055
\ J’
The CPU board has a jumper package (Jl) and a switch package (S2). By setting these packages you select the
operating parameters for the system.
3
firealarmresources.com

BAUD RATE SELECTION
Jumper package Jl (Figure 1) is used to select three baud rates. Once the baud rate is selected, it will be
available for use by any controller or device in the system. Unless specified at order entry, the standard system
configuration will be:
COMMUNICATIONS = 4800 Baud (Jumper from Pin 1to Pin 16)
LOCAL PRINTER = 1200 Baud (Jumper from Pin 5 to Pin 13)
REMOTE PORT = 300 Baud (Jumper from Pin 7 to Pin 11)
Jl
- BAUD 3 1
I BAUD 2
- BAUD 1
FIGURE 1 FIGURE 2
This jumper package will be factory-preset. The only time you need be concerned with it is when replacing a
defective CPU board. In this case, remove the pluggable jumper package from the defective board and install it
on your replacement board.
Switch package S2 (Figure 2) is used to notify the system of specific operating conditions. Switch settings and
their functions are given in Table A.
4
firealarmresources.com

TABLE A
Channel 1BaudRateSelection
Channel2 Baud Rate Selection
OPEN Channel 1Communication Option(Note 1)
CLOSED
OPEN
POSITION 7
CLOSED
OPEN
POSITION 8
CLOSED
OPEN
Single Line
McCulloch Loop
No remote device
Remote device in
system
Normal executive
program
Is Not Used
Channel2Communication Option(Note2)
Remote Device Option
-
Note 1: To determine if Channel 1 uses Single Line or McCulloch Loop operation, look at the AC Input Board.
If Terminals 20 through 24 are used, then Channel 1 uses McCulloch Loop operation. If only terminals
20 through 22 are used, Channel 1 uses Single Line operation.
Note 2: To determine if Channel 2 uses Single Line or McCulloch Loop operation, look at the AC Input Board.
If Terminals 15 through 19 are used, then Channel 2 uses McCulloch Loop operation. If only Terminals
15through 17 are used, Channel 2 uses Single Line operation.
5
firealarmresources.com

24K PRAM BOARD, 5621049
53
PROM MEMORY
SELECT
J2 Ji
PROM MEMORY RAM MEMORY
SELECT SELECT 54
A memory board containing PROM and RAM memory chips is referred to as a PRAM board. On each PRAM
board there are three blocks containing 8K of memory each (one block of RAM and two blocks of PROM). A
starting address must be selected for each block of memory.
Before setting the switches, let’s look at a PROM label. PROMS are located in IC sockets 1 through 8. The first
line of information on the label is the program number. The second line tells what card this is and what IC socket
this chip goes into. The third line is the date the chip was programmed. For example,
H901102C
cl
PROGRAM NUMBER
CARD2lC3 PRAM BOARD 2 AND THIS CHIP GOES IN IC SOCKET 3
7-8-82 THIS CHIP WAS PROGRAMMED JULY 8TH 1982
Since the memory mix between PROM and RAM is customer-sensitive, there is no standard way to set the switch
packages. However, if you perform the following procedure, the switches will be set correctly.
First, remove the PRAM boards and lay them on a static-free surface. Open all switches on switch packages Jl ,
J2, and J3. Then perform the following procedures.
6
firealarmresources.com

Note: If your system does not use the PRAM card specified in B through D below, proceed to RAM MEMORY
SELECTION. If AT ANY TIME you have closed a total of 8 switches (regardless of what step you are on),
proceed to SYSTEMS WITH MEMORY EXPANSION.
A. PRAM CARD 1
1. There is ALWAYS a PROM chip in IC8 of PRAM card 1,so close switch 7 on switch package J3.
2. If there is a PROM chip on ICl , close switch 8 on switch package J2. Otherwise, open all switches on J2
and go to RAM MEMORY SELECTION.
B. PRAM CARD 2
3. If there is a PROM chip in IC8, close switch 6 on switch package J3. Otherwise, open all switches on J3
and go to RAM MEMORY SELECTION.
4. If there is a PROM chip in ICl, close switch 5 on switch package J2. Otherwise, open all switches on J2
and go to RAM MEMORY SELECTION.
C. PRAM CARD 3
5. If there is a PROM chip in IC8, close switch 4 on switch package J3. Otherwise, open all switches on J3
and go to RAM MEMORY SELECTION.
6. If there is a PROM chip in ICl, close switch 3 on switch package 52. Otherwise, open all switches on J2
and go to RAM MEMORY SELECTION.
D. PRAM CARD 4
7. If there is a PROM chip in IC8, close switch 2 on switch package J3. Otherwise, open all switches on J3
and go to RAM MEMORY SELECTION.
E. RAM MEMORY SELECTION
Note: You have now set switches to address all of your PROM memory in the system. You are now prepared
to set switches for addressing all RAM memory which will be used. Proceed to Step 8. If your system
does not use the specified PRAM card, or if your count of closed switches reaches 8, go to SYSTEMS
WITH MEMORY EXPANSION.
8. On PRAM card 1, close switch 1 on switch package Jl .
9. On PRAM card 2, close switch 2 on switch package Jl .
10. On PRAM card 3, close switch 3 on switch package Jl .
11. On PRAM card 4, close switch 4 on switch package Jl .
12. On PRAM card 5, close switch 5 on switch package Jl.
13. On PRAM card 6, close switch 6 on switch package Jl .
14. On PRAM card 7, close switch 8 on switch package Jl .
Note: At this point all your RAM and PROM memory has been addressed. Switch package J4 is used for
systems with memory expansion. it will NOT be used with this PRAM board (562-049) so set all J4
switch packages as follows:
CLOSE switches 1,3, and 5
OPEN switches 2,4,6, 7, and 8
IMPORTANT NOTE!
ENSURE THAT ONLY ONE ROLL SWITCH ON EACH SWITCH PACKAGE (Jl, J2, AND J3) IS CLOSED.
7
firealarmresources.com

32K PRAM BOARD, 562-305
The 32K PRAM memory board has three switch packages. Switch package Sl is used to set the board number
and address range. Switch packages S2 and S3 are used to select RAM or PROM memory chips.
Before setting the switches, let’s look at a PROM label. PROMS are located in IC sockets 9 through 24. The first
‘line of information on the label is the program number. The second line tells what card this is and what IC socket
this chip goes into. The third line is the date the chip was programmed. For example,
H901102C
cl
PROGRAM NUMBER
CARD2lC9 PRAM BOARD 2 AND THIS CHIP GOES INTO IC SOCKET 9
3-l 5-83 THIS CHIP WAS PROGRAMMED ON MARCH 15,1983
To set the switches on switch package Sl , use the illustration above and Table B.
To set the switches on switch packages S2 and S3 you must first determine the status of IC sockets 9 through
24. Each of these will either be occupied by a RAM or PROM chip, or will be empty. Use the illustration above
and Table C to set the switches.
firealarmresources.com

TABLE B
C = closed
0 = open
Example: On PRAM Board (Card 1):
Close Sl switches 1,2,3,4,6 and8
Open Sl switches 5and 7
TABLE C
I I
If PROM Chip(s)
lf RAM Chip(s) or if both empty I
IC Sockets
I
Close S2
I
Open S3
Switch Switch
I
Open S2
Switch
I
Close S3
Switch
I
9 and/or 10
11and/or 12
13and/or 14
15and/or 16
17and/or 18
19and/or 20
21 and/or 22
23 and/or 24
1 1 1 1
2 2 2 2
3 3 3 3
4 4 4 4
5 5 5 5
6 6 6 6
7 7 7 7
1 8 1 8 1 8 1 8 1
Example: Inthe case of sockets IC9 and ICl 0, if either or both contain RAM chips:
Close S2 switch 1
Open S3 switch 1
firealarmresources.com

96K PRAM BOARD, 562411
A m
B m
r
c m
m
“B
PA
PN
FiK 4321
C
s4
WI
AAAA
4321
B
The 96K PRAM board was designed primarily to increase the 2120 memory capacity and decrease the number
of BMUX slots required for memory boards. Each bank of memory is still 32K, but there are now three 32K banks
on each 96K PRAM board. In terms of 32K PRAM boards,
ONE 96K PRAM Board = THREE 32K PRAM Boards
As shown in the illustration above, the three banks on each 96K PRAM board are referred to as bank A, bank
8, and bank C.
The upper bank, also called the common bank, hotds the system’s main (executive) operating program. In all
2120 systems using 96K PRAM boards, bank A on the first PRAM board is designated as common.
The 96K PRAM board has five switch packages. Switch packages Sl and S2 are used to select system common
memory and “standard” banks. Switch packages S3, S4, and S5 are used to set each bank’s address range.
Although the 96K PRAM board contains both PROMS and RAMS, its design eliminates the need to identify
whether a slot contains a PROM or RAM chip.
Before setting the switches, let’s look at a PROM label. The first line of information on the label is the program
number. The second line tells what card this is and what IC socket this PROM goes into. The third line is the date
the chip was programmed. For example,
PROGRAM NUMBER
PRAM BOARD 1AND THIS PROM GOES INTO IC SOCKET 16
THIS CHIP WAS PROGRAMMED ON MARCH 23,1984
Set the switches on switch packages Sl through S5 usingTable D and the 96K PRAM board illustration above.
10
firealarmresources.com

Note:
TABLE D
PRAM Board 1
1 3 and 4 CLOSED
Bank C (7) Switch 3 Switch 3 S3: Switches 1,2, and
LEFT LEFT OPEN; 4 CLOSED
PRAM Board 4 Switch 1 Switch 1 S5: Switch 4 OPEN;
Bank A (8) LEFT LEFT 1,2,.and 3 CLOSED
Bank B (9) Switch 2 Switch 2 S4: Switches 1 and 4
LEFT LEFT OPEN; 2 and 3 CLOSEC
Bank C (10) Switch 3 Switch 3 S3: Switches 2 and 4
LEFT LEFT OPEN; 1 and 3 CLOSEC
Switch packages Sl and S2 are slide switches. Hold the board as shown in the illustration on page 10 to
set Sl and S2.
On both Sl and S2, position 4 is UNUSED.
11
firealarmresources.com

DC TRANSMISSION BOARD, 5621063
BAUD RATE 3
BAUD RATE 2
BAUD RATE 1
’ UNUSED
UNUSED
UNUSED
CHANNEL 2
CHANNEL 1
A DC transmission board is required for each communication channel used in the system (up to 2). Each board
has a switch package (Jl) which is used to select the baud rate and the associated channel address. Except for
the setting of switch package Jl ,the transmission boardfor Channel 1 is identical to that for Channel 2.
When the transmission board is used for Channel 1, switch 8 of Jl will be CLOSED. When it is used for Channel
2, switch 7 of Jl will be CLOSED.
To determine the selected baud rate for your communication channel(s), refer to the 2120 CPU board, jumper
package Jl (see Figure 1). Close the corresponding switch on switch package Jl on the transmission board.
CAUTIqN: If you close more than two switches on Jl ,you will destroy the CPU board’s baud rate generator!
12
firealarmresources.com

PORT 1 PORT 2
RS232C BOARD, 562-047
REV. A THROUGH D
Jl /
This RS232C board provides two ports. Looking at the board from the front of the card rack, the top port is referred
to as Port 1 (the LOCAL port). Port 1 interfaces with the local printer (if equipped). The bottom connector is
referred to as Port 2 (the REMOTE port). Port 2 interfaces with remote peripheral equipment using RS232C or
20-mA current loop signals.
Switch package Jl (Figure 3) is used to select the baud rate for each port. There are three baud rates available
to the system. See the CPU board, jumper package Jl (Figure l), to determine the baud rates for the LOCAL
and REMOTE ports.
Jl
Set the switches on switch package Jl as follows:
LOCAL PRINTER
Baud Rate 1 = CLOSE switch 7
REMOTE PRINTER
Baud Rate 1 = CLOSE switch 8
Baud Rate 2 = CLOSE switch 6
Baud Rate 3 = CLOSE switch 4
’ o-/-o UNUSED
ti+ UNUSED
o-/a
e-0
Baud Rate 2 = CLOSE switch 5
Baud Rate 3 = CLOSE switch 3
3
BAUD 3 LOCAL
BAUD 3 REMOTE
C++ BAUD 2 LOCAL
e-0 BAUD 2 REMOTE
o-/-o BAUD 1 LOCAL
o-/--o BAUD 1 REMOTE
FIGURE 3
Caution: If you close more than two switches on Jl , you will destroy the CPU board’s baud rate generator!
13
firealarmresources.com

Port 1 is dedicated to the local printer. Therefore, the following switches on switch packages J2 and J3 should
ALWAYS be CLOSED:
J2 -- switches 1 and 3
J3 -- switch 2
The selection of switches for Port 2 depends on the peripheral device being used. If Port 2 is being used for any
of the following devices, the switches should be set as shown in Figure 4:
- Model 43 Teletype - G.E. Terminette - ADDS CRT
OR
- Any peripheral device requiring the Data Terminal Ready signal to be normally HIGH, and LOW when
busy. OR
- Any peripheral device NOT using the Data Terminal Ready signal.
52
l Switch package J2
CLOSE switches 5 and 8
l Switch package J3
CLOSE switch 7
FIGURE 4
8
53
If Port 2 is being used for a Centronics 150 terminal, or for any peripheral device requiring the Data Terminal
Ready signal to be normally LOW, and HIGH when busy, set the switches as shown in Figure 5.
l Switch package J2
CLOSE switch 7
l Switch package J3
CLOSE switches 7 and 8
J2 53
FIGURE 5
If Port 2 is being used for 20-mA current loop operation, set the switches as shown in Figure 6.
l Switch package J2
ALL switches OPEN
l Switch package J3
ALL switches OPEN
52
FIGURE 6
14
firealarmresources.com

RS232C BOARD, 562-047
REV. E OR HIGHER
PORTlOR3 r PORT 2 OR 4
The newer revisions of the RS232C board contain two ports, each of which is capable of providing an RS232C
or 20-mA current loop signal. Each system may have up to two RS232C boards. Looking at the board from the
front of the card rack, the top connector is referred to as the LOCAL port. The bottom connector is referred to as
the REMOTE port. When a system has two RS232C boards, the ports will be labeled as shown in Table E.
TABLE E
BOARD #
1st BOARD
2nd BOARD
PORT # PORT DESCRIPTION
1 LOCAL
2 REMOTE PORT 2
3 REMOTE PORT 3
4 REMOTE PORT 4
15
firealarmresources.com

Switch package Jl (Figur-,;7) is used to select the baud rate for each port. There are three baud rates available
to the system. See the CPU board, jumper package Jl (Figure l), to determine the baud rates for the LOCAL
and REMOTE ports.
Set the switches on switch package Jl as follows:
PORT 1 OR 3
Baud Rate 1 = CLOSE switch 7
Baud Rate 2 = CLOSE switch 5
Baud Rate 3 = CLOSE switch 3
PORT 2 OR 4
Baud Rate 1 = CLOSE switch 8
Baud Rate 2 = CLOSE switch 6
Baud Rate 3 = CLOSE switch 4
&, UNUSED
BAUD 3 PORT 1 OR 3
BAUD 3 PORT 2 OR 4
BAUD 2 PORT 1 OR 3
BAUD 2 PORT 2 OR 4
BAUD 1 PORT 2 OR 4
FIGURE 7
CAUTION: If you close more than two switches on Jl , you will destroy the CPU board’s baud rate generator!
Switch package 52 (Figure 8) selects either RS232C or 20-mA current loop operation FOR BOTH PORTS ON
THE RS232C BOARD. Set the switches as shown in Figure 8.
52
CLOSE OPEN
CLOSE if port 1 or 3 is RS232C C
1 OPEN if port 1 or 3 is 20 MA. cunent loop
CLOSE if port 2 or 4 is RS232C C
1 OPEN if port 2 or 4 is 20 MA. current loop
FIGURE 8
Switch package J3 (Figure 9) is used to select the status of the Data Terminal Ready (DTR) signal. Set the
switches as indicated below for the peripheral device being used.
MODEL 43 TELETYPE, G.E. TERMINETTE, ADDS CRT, Port 1 or 3, CLOSE switches
LOCAL PRINTER, CASSETTE TAPE UNIT
Any device requiring Data Terminal Ready to be normally HIGH
1
1,3, and 4 and OPEN switch 2
(LOW when busy) Port 2 or 4, CLOSE switches
Any peripheral device NOT using Data Terminal Ready signal 5,6, and 8 and OPEN switch 7
Port 1 or 3, CLOSE switches
CENTRONICS 150
1 1,2,4 and OPEN switch 3
Any device requiring Data Terminal Ready to be normally LOW
(HIGH when buffer isfull) Port 2 or 4, CLOSE switches
6,7, and 8 and OPEN switch 5.
18
firealarmresources.com

If a port is to be used for 20-mA current loop operation, the J3 switch setting for that port will be ignored by the
system (J2 switch settings OVERRIDE J3 settings).
CLOSED
ALWAYS CLOSED
Close when DTR signal LOW (HIGH when busy)
Close when DTR signal HIGH (LOWwhen busy)
ALWAYS CLOSED
Close when DTR signal HIGH (LOW when busy)
ALWAYS CLOSED
Close when DTR signal LOW (HIGH when busy)
ALWAYS CLOSED
53
PORT 1 OR 3
M1
o-/-o2
ti*3
-4
e*”
-6
ti-07
-6
PORT 2 OR 4
OPEN
ALWAYS CLOSED
Open when DTR signal HIGH (LOW when busy)
Open when DTR signal LOW (HIGH when busy)
ALWAYS CLOSED
Open when DTR signal LOW (HIGH when busy)
ALWAYS CLOSED
Open when DTR signal HIGH (LOW when busy)
ALWAYS CLOSED
Note: DTR = DataTerminal Ready
FIGURE 9
Switch package J4 (Figure 10) is used to address the RS232C ports. On the first board, CLOSE switches 1, 3,
and 4; OPEN switches 2 and 5. The local printer is ALWAYS connected to Port 1 of the first RS232C board.
If a second RS232C board is equipped, CLOSE switches 2 and 5; OPEN switches 1,3, and 4.
CLOSED
on 1st board
on2nd board
on 1st board
on 1st board
on2nd board
notused
OPEN
on2nd board
on1st board
on2nd board
on2nd board
on1st board
notused
FIGURE 10
17
firealarmresources.com

RS232C BOARD, 562-513
PORT 1,3, PORT 2,4, OR 6
The new RS232C board contains two ports, each of which is capable of providing an RS232C or 20-mA current
loop signal. Each system can have up to three 562-513 RS232C boards. Looking at the board from the front of
the card rack, the top connector is referred to as the LOCAL port. The bottom connector is referred to as the
REMOTE port. When a system has three RS232C boards, the ports will be labeled as shown in Table F.
BOARD #
1st BOARD
2nd BOARD
3rd BOARD
TABLE F I
PORT # PORT DESCRIPTION
1 LOCAL
2 REMOTE PORT 1
3 REMOTE PORT 2
4 REMOTE PORT 3
5 REMOTE PORT 4
6 REMOTE PORT 5
Switch package SW1 (Figure 11) is used to select the baud rate for each port. There are three baud rates
available to the system. See the CPU board jumper package Jl (Figure 1) to determine the baud rates for the
LOCAL and REMOTE ports.
Set the switches on SW1 as follows:
PORTS 1,3, AND 5
Baud Rate 1 = Close switch 7
Baud Rate 2 = Close switch 5
Baud Rate 3 = Close switch 3
PORTS 2,4, AND 6
BAUD 3 PORT 1.3, OR 5
BAUD 3 PORT 2,4, OR 6
BAUD 2 PORT 1,3, OR 5
BAUD 2 PORT 2,4, OR 6
BAUD 1 PORT 1,3, OR 5
BAUD 1 PORT 2,4, OR 6
Baud Rate 1 = Close switch 8
Baud Rate 2 = Close switch 6 FIGURE 11
Baud Rate 3 = Close switch 4
18
firealarmresources.com
