Simpli Home 3AXCBED-04 User manual

Bedford / Freemont / Hampton
Sideboard Buffet and Wine Rack
Model # 3AXCBED-04
TM
TM
1

2
It's time to register your product warranty.
It's quick and easy. And you'll be happy you did.
simpli-home.com/product-registration
Great quality is a right.
Thank you for shopping with Simpli Home,
America's top brand for high-value furniture.
Activate your 1-year warranty
Automatic entry to win a $500 gift certificate
Earn instant rewards and save
ü
ü
ü

3
Review your product and collect rewards!
Thank you for your purchase! We hope you enjoy it. We’d love
your feedback. Please share a review and get instant rewards!
simpli-home.com/product-review
Share photos and get your cash back!
Send us images or share them on social and qualify for instant
rewards. You may even receive store credit on your entire purchase!
simpli-home.com/share-images

4
For Fastest Customer Service:
1. Open your phone’s camera.
2. Point your phone’s camera at the QR code to scan.
3. Click on the pop up.
4. You’ll be taken to our customer service page.
5. Fill the form with your order information and issue.
6. Submit form.
7. A customer service associate will contact you.
Other ways to contact us…
Visit Us
Visit our site directly at
www.simpli-home.com
Email Us
[email protected]
Call Us
1-866-518-0120
Monday to Friday
9am to 5pm EST
*If you’ve purchased from a retailer and you wish to return the product, please
contact the retailer directly.

CAUTION: Injuries and damage can occur from furniture tip over if product is
not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint
provided with the product. Consult our assembly instructions for help.
If the Furniture Anti-Tipping Restraint kit is not in the box, please contact our
customer service department in order to obtain another kit before using the
furniture.
Identify all the parts and hardware. Do not discard of the packaging until you
have checked that you have all of the parts and hardware required.
Hardware package may have spare parts.
WARNING: This item contains small parts which can be swallowed by
children and pets. Keep children and pets away during assembly. To avoid
danger of suffocation, always keep plastic bags away from children and pets.
We recommend that you assemble this unit on a carpeted floor to avoid
scratches. If using power tools, set the tool to low torque to avoid damage.
May require 2 people for ease of assembly.
Safety Information
IMPORTANT : Please read this manual carefully before beginning assembly
of this product. Keep this manual for future reference.
5

This furniture is designed for indoor use.
Perhaps the greatest environmental damage to wood furniture comes from wide swings in
relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity
rises and falls, and in doing so it swells and shrinks. Making matters worse, it expands and
contracts unequally along different grain directions. As humidity changes, the components
of wooden objects are continually pushing and pulling against each other. This pressure
often results in parts of furniture no longer fitting together closely or becoming distorted
or breaking from their own internal stresses.
The response to relative humidity changes begins with determining the annual average RH
for your particular space. Then try to keep the RH in the space where your furniture is as
close to that average as possible, generally within about 10% up or down. De-humidify in
the summer and humidify in the winter.
Be aware that raising the temperature lowers the humidity and vice versa. Thus, modern
heating systems, which can drive down interior RH in the winter, almost invariably cause
problems for furniture. To counteract their effect, you can either modify the RH by keeping
furniture containing spaces cooler in the winter or most importantly, have a good working
humidifier for your home. A humidistat automatically works to balance the humidity in
your home so it is constant. Dry indoor air can suck enough moisture from its surroundings
to do permanent damage to wood, causing it to crack or split.
Remember, that not all woods are created equal. Two factors that help determine how
rapidly a wood will lose moisture are pore size and surface hardness. A piece made from a
dense and hard wood will dry less rapidly than pieces made from softer woods.
Furniture that is sealed and lacquered will lose moisture more slowly than an unfinished
piece while pieces with veneer finishes are not only stronger but lose moisture more slowly
than other finishes.
To help protect your wood furniture, take these steps:
·Use a humidifier, preferably one with an automatic control system that can sense the
humidity level and adjust itself accordingly
·Don't over-humidify; that can damage wood by causing it to expand and contract
·Keep furniture out of direct sunlight, which can cause it to dry out, crack and warp
·If you can avoid it, don't put furniture near heating vents; if you can’t, keep the
item 3 to 4 inches away from the wall, giving the heat and air space to circulate
·Dust with soft dry cloth
·Do not use liquid or aerosol products
·To avoid marking, do not place rubber on surface (foot pads, etc.)
·For soil build-up, wipe with damp cloth & dry
·Do not use abrasive cleaners
Care & Maintenance
6

TOP
QTY 1 BOTTOM FRAME
QTY 1 SHELF QTY 4
LEFT BACK PANEL
QTY 1
LEFT DOOR
QTY 1
LEFT DIVIDER
QTY 1
A B C
DLEL
FL
GL
RIGHT DOOR
QTY 1
FR
RIGHT DIVIDER
QTY 1
ER
DR
RIGHT SIDE
QTY 1
LEFT SIDE
QTY 1
GRG1
RIGHT BACK PANEL
QTY 1 TOP BACK PANEL QTY 1
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
Front / Avant
Warning Label
Part Description
7
Model # 3AXCBED-04Pre-Assembly Information

RIGHT DRAWER SIDE
QTY 2 DRAWER BACK
QTY 2
DRAWER BOTTOM
QTY 2
MRN
O
LEFT DRAWER SIDE
QTY 2
ML
MIDDLE SHELF
QTY 2
DIVIDER
QTY 9 DRAWER FRONT
QTY 2
J K L
BOTTOM SHELF
QTY 1 TOP SHELF
QTY 1
H I
G2
BOTTOM BACK PANEL
QTY 1
Front /
Avant
P
BOTTOM SUPPORT LEG
QTY 1
Part Description
8
Model # 3AXCBED-04Pre-Assembly Information

12 3 4
5678
9 10 11 12
13
ALLEN KEY SCREW
M6 X 30mm
QTY 30
CAM LOCK PIN
CAM LOCK
QTY 8 SETS
ALLEN KEY BOLT
M6 X 30mm
QTY 12
HANDLE
M4 X 15mm - QTY 2
M4 X 25mm - QTY 2
QTY 4 SETS
ALLEN KEY
QTY 1
PHILLIPS SCREW
ROUND HEAD
M4 X 15mm
QTY 26
WOODEN DOWEL
Ø8 X 30mm
QTY 36
MAGNET AND PLATE
QTY 2 SET
SHELF SUPPORT
QTY 24
PHILLIPS SCREW
M3 X 12mm
QTY 12
PHILLIPS SCREW
M3 X 15mm
QTY 8
PHILLIPS SCREW
M4 X 30mm
QTY 4
Required -
Flathead screwdriver
Phillips screwdriver
Rubber mallet
Not Included
a. M4 X 25mm - QTY 2
( 1 is extra )
b. M4 X 15mm - QTY 1
c. M4 X 25mm - QTY 1
FURNITURE TIP OVER RESTRAINT
QTY 1 SET
Hardware Description
9
Model # 3AXCBED-04Pre-Assembly Information

A
B
C
C
C
C
H
I
J
J
KKK
KKK
KKK
L
N
O
G1
L
DR
D
L
E
R
E
L
F
R
F
M L
M
R
R
G
L
G
G2
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
Front/
Avant
Front /
Avant
Front /
Avant
P
10
Model # 3AXCBED-04Components - Key Diagram

Step 1
1. Slide Drawer Bottom O firmly into slots on Drawer Sides ML , MRand
Drawer Front L .
Step 2
1. Attach 4 Cam Lock Pins 3 into pre-drilled holes on back of Drawer Front L .
2. Align Cam Lock Pins with guide holes and attach Drawer Sides ML , MR .
3. Insert 2 Cam Locks 3 into guided holes on each Drawer Side ML , MR .
4. Use flathead screwdriver to secure Cam Locks.
L
3
O
L
M
L
M
R
M
L
M
R
11
Model # 3AXCBED-04Assembly

Step 3
1. Align Drawer Back N with Drawer Bottom O and press firmly into slot .
2. Attach Drawer Back using 2 Allen Key Screws 2 through guided holes on
each Side ML , MR.
3. Use Allen Key 5 to tighten screws. Do not over-tighten.
1. Use Phillips screwdriver to attach Handle 4 to Drawer Front L .
Step 4
NOTE: The screwdriver is not
included in the hardware pack.
2
5
O
L
N
4
L
Repeat Step 1-4 for the second drawer.
M L
M
R
12
Model # 3AXCBED-04Assembly

Step 5
2
5
H
1. Attach Dividers EL , ER to Bottom Shelf H using 6 Allen Key Screws 2
(3 Screws on each Divider ).
2. Use Allen Key 5 to tighten screws. Do not over-tighten.
E
L
E
R
Front /
Avant
Front /
Avant
Front /
Avant
13
Model # 3AXCBED-04Assembly

Step 6
K
K
K
H
1. Insert 12 Dowels 7 into guided holes on 3 Dividers K (4 dowels on each Divider).
2. Use rubber mallet to tap Dowels 7 into bottom of holes securely. ½ length of
Dowels should be exposed.
3. Align Dowels 7 on Dividers K with guided holes on Bottom Shelf H .
7
K
7K
E
L
E
R
Front / Avant
Front /
Avant
Front /
Avant
14
Model # 3AXCBED-04Assembly

Step 7
K
K
K
H
1. Attach one Middle Shelf J to Dividers K with guided holes on the Middle Shelf J .
E
L
E
R
J
7
Front / Avant
Front / Avant
Front /
Avant
15
Model # 3AXCBED-04Assembly

Step 8
1. Repeat Step 6, 7 for the other Dividers K and Middle Shelves J .
H
E
L
E
R
K
K
K
K
K
K
J
7
K
Front / Avant
Front /
Avant
Front /
Avant
16
Model # 3AXCBED-04Assembly

Step 9
5
2
I
K
K
K
7
1. Align Dowels 7 on Dividers K with guided holes on Top Shelf I .
2. Attach Top Shelf I to Dividers EL , ER using 4 Allen Key Screws 2
(2 Screws on each Divider ).
3. Use Allen Key 5 to tighten screws. Do not over-tighten.
E
L
E
R
Front
Front /
Avant
Front /
Avant
Front /
Avant
17
Model # 3AXCBED-04Assembly

Step 10
1. Attach Dividers EL , ER to Bottom Shelf B using 6 Allen Key Screws 2
(3 Screws on each Divider ).
2. Use Allen Key 5 to tighten screws. Do not over-tighten.
3. Alway put the Front Side upward.
B
H
E
L
E
R
This Side Up
Front / Avant
Front / Avant
Front / Avant
Front /
Avant
5
2
18
Model # 3AXCBED-04Assembly

Step 11
1. Attach Bottom Shelf B to Sides DL , DR using 6 Allen Key Bolts 1
( 3 Bolts on each Side ).
2. Use Allen Key 5 to tighten screws. Do not over-tighten.
1
5
B
H
E
L
E
R
D
L
D
R
Front / Avant
Front / Avant
Front /
Avant
Front / Avant
Front / Avant
19
Model # 3AXCBED-04Assembly

Step 12
1. Attach Bottom Support Leg P to Bottom Shelf B using 4 Phillips Screws 12 .
2. Use Phillips screwdriver to tighten screws. Do not over-tighten.
B
H
E
L
E
R
D
L
D
R
Front / Avant
Front / Avant
Front / Avant
Front / Avant
Front / Avant
P
12
P
20
Model # 3AXCBED-04Assembly
