Simpli Home BANTING AXCBAN-09-MSB User manual

BANTING / DEVLIN / ARGYLE
MID CENTURY DESK
MODEL # AXCBAN-09-MSB
/131
TM
TM
SI
M P
HOME®
LIFE BY DESIG N

/132
TM
TM
SI
M P
HOME®
LIFE BY DESIG N
Questions, problems, assembly help, missing parts?
No need to return the product, we will gladly help and ship your
replacement parts free of charge
Please call Customer Service at 1-866-518-0120 ext. 262
Monday to Friday between 9 am –4 pm EST
or go to
www.simpli-home.com/parts request
In order to assist you in a timely manner, please have the following
information ready:
Model # _________________Part Number or Letter_____________________
Purchased at ____________Date of Purchase _________________________
If you wish to return the product, please contact the retailer where the
product was purchased.

/133
IMPORTANT : Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.
SAFETY INFORMATION
Identify all the parts and hardware. Do not discard of the packaging until you
have checked that you have all of the parts and hardware required.
Hardware package may have spare parts.
WARNING: This item contains small parts which can be swallowed by
children and pets. Keep children and pets away during assembly. To avoid
danger of suffocation, always keep plastic bags away from children and pets.
We recommend that you assemble this unit on a carpeted floor to avoid
scratches. If using power tools, set the tool to low torque to avoid damage.
May require 2 people for ease of assembly.

/134
This furniture is designed for indoor use.
Damage to furniture can come from temperature changes in relative humidity (RH) in
our homes. Humid air oxidizes metal which results in rusting, corrosion, tarnishing
and roughness. Wood absorbs water as relative humidity rises and falls, and in doing
so it swells and shrinks.
To protect against the humidity effect, the metal is powder coated. The powder coat
layer protects the metal from oxidizing, corrosion, tarnishing and scratching and
keeps it looking good for years to come. The wood is sealed and lacquered to protect
against humidity.
To help protect your furniture, follow these steps:
·Use a humidifier, preferably one with an automatic control system that can
sense the humidity level and adjust itself accordingly.
·Dust with soft dry cloth.
·Wipe up spills promptly. Clean with a dry cloth.
·Do not use abrasive cleaners, chemical solvents, strong detergents, cleaners
with bleach, and furniture polish.
·Use soft felt base coasters, placemats to help prevent scratches.
·Keep furniture out of direct sunlight, which can cause cracking or roughness
on the protective layer.
·If it can be avoided, do not put furniture near heating vents. Keep the furniture
3 to 4 inches away from the wall, giving heat and air space to circulate.
IMPORTANT : Keep this manual for future reference.
CARE and MAINTENANCE

PART DESCRIPTION
NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST)
PRE-ASSEMBLY INFORMATION MODEL # AXCBAN-09-MSB
/135
.A
TOP
QTY 1
.BL .BR .C
.D.E.F
RIGHT LEG
QTY 1
LEFT LEG
QTY 1
LEG BACK CONNECTOR
QTY 1
LEG FRONT CONNECTOR
QTY 1 LEG LOWER CONNECTOR
QTY 1 LEG SUPPORTER QTY 2
Front /
Avant
UpSide/Vertical
UpSide/Vertical
UpSide/Vertical
Front /
Avant
Front /
Avant
Front /
Avant
UpSide/Vertical
UpSide/Vertical
UpSide/Vertical

PRE-ASSEMBLY INFORMATION MODEL # AXCBAN-09-MSB
/136
HARDWARE DESCRIPTION
NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST)
.1.2
Required -
Flathead screwdriver
Phillips screwdriver
Not Included
ALLEN KEY BOLT
M6 x 15 mm
QTY 20
LOCK WASHER
Ø10 / Ø6.5 x 1.5 mm
QTY 20
WASHER
Ø16 / Ø6.5 x 1.5 mm
QTY 24
PHILLIPS SCREW ROUND HEAD
M4 X 15mm
QTY 4
ALLEN KEY
QTY 1
.3.4
.5

COMPONENTS-KEY DIAGRAM MODEL # AXCBAN-09-MSB
/137
Front /
Avant
UpSide/Vertical
A
C
DBR
BL
F
F
E
Front /
Avant
UpSide/Vertical
UpSide/Vertical
UpSide/Vertical

ASSEMBLY MODEL # AXCBAN-09-MSB
/138
STEP-1
1. Align Parts C , D and E to Right Leg BR .
2. Use one Bolt 1 , one Lock Washer 2
and one Washer 3 to secure each part
C , D , E with BR .
3. Use Allen Key 5 to tighten Bolts.
Do not over-tighten.
E
D
C
BR
UpSide/Vertical
UpSide/Vertical
UpSide/Vertical
Front / Avant
Front /
Avant
UpSide/Vertical
5
1
2
3
UpSide/Vertical
UpSide/Vertical
UpSide/Vertical
Front / Avant
5123

ASSEMBLY MODEL # AXCBAN-09-MSB
/139
STEP-2
1. Repeat Step-1 for Left Leg BL .
BL
BR
D
C
E
UpSide/Vertical
UpSide/Vertical
UpSide/Vertical
Front / Avant
Front / Avant
UpSide/Vertical
3215
BR
D
C
E
BL
3215

ASSEMBLY MODEL # AXCBAN-09-MSB
/1310
STEP-3
STEP-4
1. Align Leg Supporters F to Legs BL , BR .
1. Use Allen Key 5 to tighten Bolts.
2. Use four Bolts 1 , four Lock Washers 2 and four Washers 3 to secure each part
F with BL , BR .
3. Use Allen Key 5 to tighten Bolts.
BL
BL
BL
BR
BR
BR
D
D
D
C
C
C
E
E
E
F
F
3
2
1
5
F
F
5

ASSEMBLY MODEL # AXCBAN-09-MSB
/1311
STEP-5
5
1
2
3
1. Attach the assembled metal frame to Top A .
2. Use six Bolts 1 , six Lock Washers 2
and six Washers 3 to secure metal frame
and Top A .
3. Use Allen Key 5 to tighten Bolts.
4.UsefourPhillipsScrewsRoundHead4andfour
Washers3tosecureTopAandmetalframe.
5.UsePhillipsscrewdrivertosnuglytightenScrews.
4
3
F
A
A
A

ASSEMBLY MODEL # AXCBAN-09-MSB
/1312
STEP-6
Note: Levelers on bottom of legs can be adjusted if floor is uneven.

/1313
TM
TM
SI
M P
HOME®
LIFE BY DESIG N
WARRANTY
Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max
product. These products have been made to demanding, high-quality
standards and are guaranteed for domestic use against manufacturing
faults for a period of 12 months from the date of purchase. This warranty
does not affect your statutory rights.
In case of any malfunction of your product (failure, missing parts, etc.)
please contact us at our toll free service line at 1-866-518-0120 ext. 262
from 9 am to 4 pm, Monday to Friday, Eastern Standard Time or by email at
[email protected].
We reserve the right to repair or replace the defective product, at its
discretion.
This product is guaranteed for 12 months if used for normal purposes.
Any warranty is invalid if the product has been overloaded or subject to
neglect, improper use or an attempted repair by other than an authorized
agent. Heavy-duty or daily professional/commercial usage are not
guaranteed.
Due to continuous product improvement, we reserve the right to change
the product specifications without prior notice.
