Simpli Home brooklyn+max WyndenHall AXCKIT03-FOG User manual

Kitchener / Waterloo / Providence
End Table
Model # AXCKIT03-FOG
1

Great quality is a right.
Thank you for shopping with Simpli Home,
America's top brand for high-value furniture.
It's time to register your product warranty.
It's quick and easy. And you'll be happy you did.
üAcvate your 1-year warranty
üAutomac entry to win a $500 gi cerficate
üEarn instant rewards and save simpli-home.com/product-registraon
2

Thank you for your purchase! We hope you enjoy it. We’d love
your feedback. Please share a review and get instant rewards!
simpli-home.com/product-review
Review your product and collect rewards!
Send us images or share them on social and qualify for instant rewards.
You may even receive store credit on your enre purchase!
simpli-home.com/share-images
Share photos and get your cash back!
3

For Fastest Customer Service:
*If you’ve purchased from a retailer and you wish to return the product, please
contact the retailer directly.
Visit Us
Visit our site directly at
www.simpli-home.com
Call Us
1-866-518-0120
Monday to Friday
9am to 5pm EST
Email Us
customer[email protected]
Other ways to contact us…
1. Open your phone’s camera.
2. Point your phone’s camera at the QR code to scan.
3. Click on the pop up.
4. You’ll be taken to our customer service page.
5. Fill the form with your order informaon and issue.
6. Submit form.
7. A customer service associate will contact you.
4

We recommend that you assemble this unit on a carpeted floor to avoid scratches.
If using power tools, set the tool to low torque to avoid damage.
May require 2 people for ease of assembly.
Identify all the parts and hardware. Do not discard of the packaging until you have
checked that you have all the parts and hardware required. Hardware package may
have spare parts.
WARNING: This item contains small parts which can be swallowed by children and
pets. Keep children and pets away during assembly. To avoid danger of suffocation,
always keep plastic bags away from children and pets.
IMPORTANT: Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.
Safety Information
5

Care & Maintenance
This furniture is designed for indoor use.
Perhaps the greatest environmental damage to wood furniture comes from wide swings in
relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity
rises and falls, and in doing so it swells and shrinks. Making matters worse, it expands and
contracts unequally along different grain directions. As humidity changes, the components
of wooden objects are continually pushing and pulling against each other. This pressure
often results in parts of furniture no longer fitting together closely or becoming distorted
or breaking from their own internal stresses.
The response to relative humidity changes begins with determining the annual average RH
for your particular space. Then try to keep the RH in the space where your furniture is as
close to that average as possible, generally within about 10% up or down. De-humidify in
the summer and humidify in the winter.
Be aware that raising the temperature lowers the humidity and vice versa. Thus, modern
heating systems, which can drive down interior RH in the winter, almost invariably cause
problems for furniture. To counteract their effect, you can either modify the RH by keeping
furniture containing spaces cooler in the winter or most importantly, have a good working
humidifier for your home. A humidistat automatically works to balance the humidity in
your home so it is constant. Dry indoor air can suck enough moisture from its surroundings
to do permanent damage to wood, causing it to crack or split.
Remember, that not all woods are created equal. Two factors that help determine how
rapidly a wood will lose moisture are pore size and surface hardness. A piece made from a
dense and hard wood will dry less rapidly than pieces made from softer woods.
Furniture that is sealed and lacquered will lose moisture more slowly than an unfinished
piece while pieces with veneer finishes are not only stronger but lose moisture more
slowly than other finishes.
To help protect your wood furniture, take these steps:
• For soil build-up, wipe with damp cloth & dry
• Don't over-humidify; that can damage wood by causing it to expand and contract
• Dust with soft dry cloth
• Do not use liquid or aerosol products
• If you can avoid it, don't put furniture near heating vents; if you can’t, keep the item 3 to
4 inches away from the wall, giving the heat and air space to circulate
• Use a humidifier, preferably one with an automatic control system that can sense the
humidity level and adjust itself accordingly
• Do not use abrasive cleaners
• Keep furniture out of direct sunlight, which can cause it to dry out, crack and warp
• To avoid marking, do not place rubber on surface (foot pads, etc.)
6

A
TOP
QTY 1
LEFT SIDE
QTY 1
BL
RIGHT SIDE
QTY 1
BR
BACK PANEL
QTY 1
C
BOTTOM SHELF
QTY 1
D
FRONT BAR
QTY 1
E
DRAWER FRONT
QTY 1
F
LEFT DRAWER SIDE
QTY 1
GL
RIGHT DRAWER SIDE
QTY 1
GR
DRAWER BACK
QTY 1
H I
DRAWER BOTTOM
QTY 1
Front /
Avant
Front
/ Avant
Front /
Avant
Front / Avant
Front / Avant
7
Pre-Assembly Information Model # AXCKIT03-FOG
Part Description

123
4 5
ALLEN KEY
QTY 1
WOOD DOWEL
Ø8 X 30 mm
QTY 16
CAM LOCK PIN
CAM LOCK
QTY 10 SETS
ALLEN KEY SCREW
M6 X 30 mm
QTY 10
HANDLE
M4 X 25 mm
QTY 1 SET
Required -
Flathead screwdriver
Phillips screwdriver
Rubber mallet
Not Included
8
Pre-Assembly Information Model # AXCKIT03-FOG
Hardware Description

BL
A
C
E
D
I
H
GL
F
BR
GR
Fr
on
t
/ A
v
ant
Front
/
Avan
t
Fr
on
t
/
Av
an
t
9
Components - Key Diagram Model # AXCKIT03-FOG

1. Slide Drawer Bottom I firmly into slots on Drawer Sides GL , GR and
Drawer Front F .
Step 2
3. Insert 2 Cam Lock 2 into guide holes on each Drawer Side GL , GR .
1. Attach 4 Cam Lock Pins 2 to back of Drawer Front F .
2. Align Cam Lock Pins with guide holes and attach Drawer Sides GL , GR .
4. Use flathead screwdriver to secure Cam Locks.
2
GR
GL
F
F
GR
GL
I
Assembly Model # AXCKIT03-FOG
10
Step 1

Step 3
Step 4
1. Use Phillips Screwdriver to attach Handle 4 to Drawer Front F .
2. Attach back using 2 Allen Key Screws 1 through guide holes on each side.
1. Align Drawer Back H with Drawer Bottom I and press firmly into slot .
3. Use Allen Key 3 to tighten. Do not over tighten.
NOTE: The screwdriver is not
included in the hardware pack.
4
F
GR
GL
I
1
3
H
F
Assembly Model # AXCKIT03-FOG
11

Step 5
7. Use flathead screwdriver to secure Cam Locks.
6. Insert 6 Cam Locks 2 into guide holes on Bottom Shelf D .
1. Insert 4 Dowels 5 into of each Back Panel C , Front Bar E and Bottom Shelf D .
Dowels should be exposed.
2. Use rubber mallet to tap Dowels 5 into bottom of holes securely. 1/2 length of
4. Align Dowels 5 on C , E , D with guide holes of Side BL , BR .
3. Attach 3 Cam Lock Pins 2 to into each Side BL , BR .
5. Align Cam Lock Pins with guide holes and attach Bottom Shelf D .
C
D
E
BR
BL
5
5
2
Front /
Avant
Assembly Model # AXCKIT03-FOG
12

Step 6
1. Insert assembled drawer into slots on assembled table.
2. Drawer can be inserted into table’s opening.
Step 7
3. Align guide holes on bottom corners of Top A with Dowels 5 in Sides BL , BR .
4. Use Allen Key Screw 1 attach Top A to Sides BL , BR .
1. Insert 2 Dowels 5 into top corners of each Side BL , BR .
2. Use rubber mallet to tap Dowels 5 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
5. Use Allen key 3 to tighten Allenkey Screw. Do not over-tighten .
A
BL
BR
5
1
3
Fr
ont / A
vant
Fron
t
/
A
v
an
t
Assembly Model # AXCKIT03-FOG
