Simpli Home AXWSH001-TB Operating instructions

WARM SHAKER / NORFOLK / LEXINGTON
COFFEE TABLE
MODEL # AXWSH001-TB
1/17
SI
M
P
I
I
H O M E
L I F E B Y D E S I G N

FOR REPLACEMENT PARTS OR HELP WITH
ASSEMBLY PLEASE CONTACT US AT:
simpli-home.com/customer-support
PLEASE ENSURE TO HAVE THE MODEL #
INSTRUCTION BOOKLETFROM THE PACKAGING OR
TO RETURN THE PRODUCT:
PLEASE CONTACT THE RETAILER
WHERE THE ITEM WAS PURCHASED FROM
2/17

Upload an image of our furniture
in your home with a short review
to our facebook page for a chance to
ENTER
TO WIN
Win up to $3000 of
Simpli Home furniture!!!
www.facebook.com/simplihomefurnishings
3/17
SI
M
P
I
I
H O M E
L I F E B Y D E S I G N

IMPORTANT : Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.
SAFETY INFORMATION
CARE and MAINTENANCE
Identify all the parts and hardware. Do not discard of the packaging until you
have checked that you have all of the parts and hardware required. Hardware
package may have spare parts.
WARNING: This item contains small parts which can be swallowed by
children and pets. Keep children and pets away during assembly. To avoid
danger of suffocation, always keep plastic bags away from children and pets.
We recommend that you assemble this unit on a carpeted floor to avoid
scratches. If using power tools, set the tool to low torque to avoid damage.
May require 2 people for ease of assembly.
To clean, use a soft or slightly damp cloth, then wipe with a clean, dry cloth.
Dust with soft dry cloth.
Do not use ammonia-based cleaning products, as they will damage the finish.
Do not leave liquids or damp cloths on this furniture.
To avoid dulling of the finish, do not place furniture in direct sunlight.
Please inspect and tighten all screws or bolts on a regular basis to ensure proper
performance and safety of your item.
4/17

NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST)
PRE-ASSEMBLY INFORMATION
MODEL # AXWSH001-TB
A
PARTS DESCRIPTION
5/17
TOP
QTY 1
SIDES
QTY 1 PAIR
TOP SHELF
QTY 1
BOTTOM SHELF
QTY 1
BACK
QTY 1
CENTRE DRAWER
QTY 1
BC
DEF
GHI
J
DRAWER FRONT
QTY 2
DRAWER BACK
QTY 2
DRAWER BOTTOM
QTY 2
DRAWER SIDE
QTY 2 PAIRS

PRE-ASSEMBLY INFORMATION
HARDWARE DESCRIPTION
NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST)
6/17
MODEL # AXWSH001-TB
123
4 5
Required -
Flathead screwdriver
Phillips screwdriver
Rubber mallet
Not Included
ALLEN KEY
QTY 1
WOOD DOWEL
Ø8 X 30 mm
QTY 6
CAM LOCK PIN
CAM LOCK
QTY 18 SETS
ALLEN KEY SCREW
M6 X 30 mm
QTY 26
HANDLE
M4X25 mm
QTY 4 SETS

COMPONENTS – KEY DIAGRAM
7/17
MODEL # AXWSH001-TB
A
E
B
B
C
F
D
I
H
H
J
G

ASSEMBLY
STEP 1
8/17
MODEL # AXWSH001-TB
1. Slide Drawer Bottom J firmly into slots on Drawer Sides H and Drawer Front G .
STEP 2
1. Attach 4 Cam Lock Pins 2 to back of Drawer Front G .
2. Align Cam Lock Pins with pre-drilled holes and attach Drawer Sides H .
3. Insert 2 Cam Lock 2 into pre-drilled holes on each Drawer Side H .
4. Use flathead screwdriver to secure Cam Locks.
G
2
H
H
G
H
H
J

ASSEMBLY
STEP 3
9/17
MODEL # AXWSH001-TB
STEP 4
1. Use Phillips Screwdriver to attach Handle 4 to Drawer Front G .
1. Align Drawer Back I with Drawer Bottom J and press firmly into slot .
2. Attach back using 2 Allen Key Screws 1 through pre-drilled holes on each side.
3. Use Allen key 3 to tighten. Do not over tighten.
NOTE: The screwdriver is not
included in the hardware pack.
G
J
H
H
I
1
3
4
G
Repeat Step 1-4 for the second drawer.

ASSEMBLY
STEP 5
10/17
MODEL # AXWSH001-TB
NOTE:
Holes are on the right side.
C
B
13
1. Attach Top Shelf C to one Side B using Allen Key Screws 1 through pre-drilled holes.

ASSEMBLY
STEP 6
11/17
MODEL # AXWSH001-TB
1. Attach 2 Cam Lock Pins 2 to one Side B using guide holes.
2. Align and insert Cam lock Pins on Side B into pre-drilled holes on Back E .
3. Using a flathead screwdriver tighten Cam Locks into Pins.
4. Use Phillips screwdriver to attach Handle 4 to Back E .
B
CE
4
2

ASSEMBLY
STEP 7
12/17
MODEL # AXWSH001-TB
1. To attach opposite Side B to Top Shelf C and Back E , repeat steps 5 - 6.
B
E
C
2
1
3

ASSEMBLY
STEP 8
13/17
MODEL # AXWSH001-TB
1. Attach Centre Drawer F to Top Shelf C
using Allen Key Screws 1 through pre-drilled holes.
F
C
1
3

ASSEMBLY
STEP 9
14/17
MODEL # AXWSH001-TB
1. Insert 2 Dowels 5 into pre-drilled holes on the Centre Drawer F .
2. Use rubber mallet to tap Dowels 5 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
3. Attach Bottom Shelf D to Sides B and Centre Drawer F
using Allen Key Screws 1 through pre-drilled holes.
D
B
B
F
3
1
5

ASSEMBLY
STEP 10
15/17
MODEL # AXWSH001-TB
1. Insert Dowels 5 into each corner of Side B .
2. Use rubber mallet to tap Dowels 5 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
3. Attach 6 Cam Lock Pins 2 to bottom of Top A .
4. Align and insert Cam Lock Pins on Top A into pre-drilled holes on Sides B .
5. Using a flathead screwdriver tighten Cam Locks into Pins.
STEP 11
A
B
B
5
2
1. Insert assembled drawer into glides on assembled table.
2. Drawers can be inserted into either side of table opening.

WARRANTY
Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max
product. These products have been made to demanding, high-quality
standards and are guaranteed for domestic use against manufacturing
faults for a period of 12 months from the date of purchase. This warranty
does not affect your statutory rights.
In case of any malfunction of your product (failure, missing parts, etc.)
please contact us at our toll free service line at 1-866-518-0120 ext. 262
from 9 am to 4 pm, Monday to Friday, Eastern Standard Time or by email at
simpli-home.com/customer-support.
We reserve the right to repair or replace the defective product, at its
discretion.
This product is guaranteed for 12 months if used for normal purposes.
Any warranty is invalid if the product has been overloaded or subject to
neglect, improper use or an attempted repair by other than an authorized
agent. Heavy-duty or daily professional/commercial usage are not
guaranteed.
Due to continuous product improvement, we reserve the right to change
the product specifications without prior notice.
