Sauder Radial 426023 User manual

sauder.com
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
sauder.com
CONTACT US FIRST
BEFORE MAKING ANY RETURNS TO THE STORE.
sauder.com
CONTACT US FIRST
BEFORE MAKING ANY RETURNS TO THE RETAILER.
Visit sauder.com/service to order replacement parts, view video assembly tips, or chat with a live rep.
Prefer the phone? Give us a ring at 1-800-445-1527.
Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays)
Sauder.com
Share your journey!
English pg 1-19
Français pg 20-22
Español pg 23-25
Lot # 548124 06/08/20
Purchased: __________________
Lift-top Coee Table
Radial Collection | Model 426023
It's addicting.

Part Identification
Hardware Identification
Hardware Usage Guide
Assembly Steps
Français
Español
Safety
Warranty
Table of Contents Assembly Tools Required
No. 2 Phillips Screwdriver
Tip Shown Actual Size
3
4
5
6-19
20-22
23-25
26
27
Page 2 www.sauder.com/service 426023
Adjustable Wrench

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
Now you know
our ABCs.
A TOP (1)
B SHELF (1)
C BOTTOM (1)
D FRONT/BACK (2)
E RIGHT END (1)
F LEFT END (1)
G UPRIGHT FRAME (2)
H END FRAME (2)
A
B
C
D
D
E
F
G
G
H
H
Page 3www.sauder.com/service426023

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
1/2" PAN HEAD SCREW - 24
16
1-1/8" HEX HEAD SCREW - 16
13 13/16" PAN HEAD SCREW - 2
14
1-3/8" FLAT HEAD SCREW - 10
12
1-3/8" HEX HEAD SCREW - 6
11
NUT - 8
5BUSHING - 2 6SUPPORT BRACKET - 2 7APPLIQUE CARD - 2 8
9LIFT TABLE MECHANISM SET - 1 BRACE - 1
10
1/2" HEX HEAD SCREW - 4
15
Page 4 www.sauder.com/service 426023
CAM SCREW - 8
2
HIDDEN CAM - 8
1WOOD DOWEL - 2 3L-WRENCH - 1
4

Hardware Usage Guide
HOW TO USE A HIDDEN CAM & CAM SCREW OR CAM DOWEL
NOTE: Various CAM SCREWS or a CAM DOWEL may be used.
Cam Screws Cam Dowel
Turn the CAM SCREW or
gently tap the CAM DOWEL
until the shoulder is against
the surface of the part.
1.
Hidden CamHidden Cam
Arrow
Push a HIDDEN CAM into
the part. The arrow in the
HIDDEN CAM must point
toward the hole in the
edge of the board.
Hole
2.
3.
1
2
Insert the CAM SCREW or CAM DOWEL into the
HIDDEN CAM. Tighten the HIDDEN CAM.
Page 5www.sauder.com/service426023

Step 1
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å Turn eight CAM SCREWS (2) into the FRONT/BACKS (D).
Look for this icon. It means a video assembly tip is
available at www.sauder.com/service/tips
Find the numbered video or scan the QR code.
D
D
1
2(8 used)
Page 6 www.sauder.com/service 426023

Step 2
E
F
1
Arrow
1
å Push eight HIDDEN CAMS (1) into the ENDS (E and F).
1
Arrow
Page 7www.sauder.com/service426023

Step 3
D
D
E
F
å Fasten the FRONT/BACKS (D) to the ENDS (E and F).
Tighten eight HIDDEN CAMS.
1
These set of holes
must be here.
Surface with
HIDDEN CAMS
Surface without
HIDDEN CAMS
Finished edge
Finished edge
Page 8 www.sauder.com/service 426023

å Fasten the SHELF (B) to the UPRIGHT FRAMES (G). Tighten
four 1-1/8" HEX HEAD SCREWS (13) using the L-WRENCH (4).
å NOTE: You should start each SCREW a few turns before
completely tightening any of them.
å NOTE: Be sure the ARROWS on the stickers are pointing
the direction as shown.
Step 4
B
G
G
INWARD
INWARD
A sticker will be on the top of
the UPRIGHT FRAMES (G).
The arrows must be pointing
the direction as shown.
1-1/8" HEX HEAD SCREW
(4 used in this step)
13
Page 9www.sauder.com/service426023
4

å Fasten the BOTTOM (C) to the UPRIGHT FRAMES (G).
Tighten four 1-1/8" HEX HEAD SCREWS (13) using the
L-WRENCH (4).
å NOTE: You should start each SCREW a few turns before
completely tightening any of them.
Step 5
C
1-1/8" HEX HEAD SCREW
(4 used in this step)
13
G
G
Page 10 www.sauder.com/service 426023
4
