Simpli Home Brooklyn+Max WyndenHall AXCBSACA04-WH User manual

Acadian / Normandy / Brunswick
Double Door Wall Cabinet
Model # AXCBSACA04-WH
TM
TM
1

2
It's time to register your product warranty.
It's quick and easy. And you'll be happy you did.
simpli-home.com/product-registration
Great quality is a right.
Thank you for shopping with Simpli Home,
America's top brand for high-value furniture.
Activate your 1-year warranty
Automatic entry to win a $500 gift certificate
Earn instant rewards and save
ü
ü
ü

3
Review your product and collect rewards!
Thank you for your purchase! We hope you enjoy it. We’d love
your feedback. Please share a review and get instant rewards!
simpli-home.com/product-review
Share photos and get your cash back!
Send us images or share them on social and qualify for instant
rewards. You may even receive store credit on your entire purchase!
simpli-home.com/share-images

4
For Fastest Customer Service:
1. Open your phone’s camera.
2. Point your phone’s camera at the QR code to scan.
3. Click on the pop up.
4. You’ll be taken to our customer service page.
5. Fill the form with your order information and issue.
6. Submit form.
7. A customer service associate will contact you.
Other ways to contact us…
Visit Us
Visit our site directly at
www.simpli-home.com
Email Us
[email protected]
Call Us
1-866-518-0120
Monday to Friday
9am to 5pm EST
*If you’ve purchased from a retailer and you wish to return the product, please
contact the retailer directly.

This furniture is designed for indoor use.
Identify all the parts and hardware. Do not discard of the packaging until you
have checked that you have all of the parts and hardware required.
Hardware package may have spare parts.
WARNING: This item contains small parts which can be swallowed by
children and pets. Keep children and pets away during assembly. To avoid
danger of suffocation, always keep plastic bags away from children and pets.
We recommend that you assemble this unit on a carpeted floor to avoid
scratches. If using power tools, set the tool to low torque to avoid damage.
May require 2 people for ease of assembly.
Safety Information
Care & Maintenance
To clean, use a soft or slightly damp cloth, then wipe with a clean, dry cloth.
Dust with a soft dry cloth.
Do not use ammonia-based cleaning products, as they will damage the finish.
Do not leave liquids or damp cloths on this furniture.
To avoid dulling of the finish, do not place this furniture in direct sunlight.
Please inspect and tighten all screws or bolts on a regular basis to ensure
proper performance and safety of your item.
IMPORTANT : Please read this manual carefully before beginning assembly
of this product. Keep this manual for future reference.
5

.A.BL .BR
Part Description
TOP
QTY 1 LEFT SIDE
QTY 1 RIGHT SIDE QTY 1
BOTTOM SHELF
QTY 1 MIDDLE SHELF
QTY 1
DIVIDER
QTY 1
.C.D.E
.F.FL .FR
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
BOTTOM BACK PANEL
QTY 1 LEFT BACK PANEL
QTY 1
RIGHT BACK PANEL
QTY 1
Front /
Avant
6
Model # AXCBSACA04-WHPre-Assembly Information

.G.H.I
Part Description
.J
SHELF
QTY 2 DOOR (L&R Same)
QTY 2
WALL MOUNT BAR
QTY 1
BACK BAR
QTY 1
7
Model # AXCBSACA04-WHPre-Assembly Information

Hardware Description
.1.2.3
Required -
Flathead screwdriver
Phillips screwdriver
Rubber mallet
Not Included
.4.5.6
.7.8.9
CAM LOCK PIN
CAM LOCK
QTY 14 SETS
WOOD DOWEL
Ø8 X 30mm
QTY 15 HINGE
QTY 4
MAGNET AND PLATE
QTY 2 SETS
HANDLE
M4 X 25 mm
QTY 2 SETS
SHELF SUPPORT
QTY 8
WALL ANCHOR
QTY 4
.10
PHILLIPS SCREW
M4 X 50mm
QTY 7
PHILLIPS SCREW
M3 X 15mm
QTY 24
PHILLIPS SCREW ROUND HEAD
M4 X 15mm
QTY 7
8
Model # AXCBSACA04-WHPre-Assembly Information

Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
A
JI
FR
FL
F
H
H
E
C
D
G
G
BL
BR
9
Model # AXCBSACA04-WHComponents - Key Diagram

Step 1
P
X
Front /
Avant
Front /
Avant
Front /
Avant
A
BL BR
1. Attach Cam Lock Pins 1 into pre-drilled holes on parts A , BL , BR .
2. Use Phillips screwdriver to secure Cam Lock Pins. Do not over-tighten.
3. Insert one Dowel 2 into guide holes on each Side BL , BR .
4. Use rubber mallet to tap Dowels 2 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
1
1
1
1
11
2
2
2
10
Model # AXCBSACA04-WHAssembly

Step 2
1. Insert Dowels 2 into guide holes on each part C , D , E , I .
2. Use rubber mallet to tap Dowels 2 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
2
2
2
2
2
2
2
2
C
D
E
Front /
Avant
I
11
Model # AXCBSACA04-WHAssembly

Step 3
Front / Avant
Front / Avant
E
E
D
D
7
1. Align Wood Dowels with guide holes and attach Divder E to Middle Shelf D .
2. Use two Phillips Screws 7 to attach Middle Shelf D through guide holes from
Middle Shelf D to pre-drilled holes of Divider E .
3. Use Phillips screwdriver to secure Screws. Do not over-tighten.
Step 4
7
Front / Avant
E
D
9
4
9
1. Attach Magnets 4 using Phillips Screws 9 into pre-drilled holes Divider E .
2. Use Phillips screwdriver to secure screws.Do not over-tighten.
12
Model # AXCBSACA04-WHAssembly

Step 5
Front / Avant
Front / Avant
Front / Avant
Front /
Avant
E
DI
BL
BL E
DI
11
1
1. Align Wood Dowels and Cam Lock Pins with guide holes and attach parts D , I
to Left Side BL .
2. Insert two Cam Locks 1 into guide holes on Middle Shelf D .
3. Use Phillips screwdriver to secure Cam Locks.
Step 6
Front / Avant
Front / Avant
Front / Avant
Front / Avant
Front / Avant
Front /
Avant
BL BL
CC
1
1
1. Align Wood Dowels and Cam Lock Pins with guide holes and attach part C to Left Side BL .
2. Insert two Cam Locks 1 into guide holes on Bottom Shelf C .
3. Use Phillips screwdriver to secure Cam Locks.
13
Model # AXCBSACA04-WHAssembly

Step 7
1
1. Repeat Step-5 and Step-6 for the Right Side BR .
Front / Avant
Front /
Avant
Front /
Avant
Front / Avant
Front /
Avant
Front /
Avant
C
C
D
D
BR
BR
I
BL
BL
14
Model # AXCBSACA04-WHAssembly

Step 8
FL
FR
F
Front /
Avant
BR BL
C
Warning Label
1. Slide Back Panels F , FL , FR firmly into slots on Sides BL , BR and Bottom Shelf C .
Step 9
Front / Avant
Front / Avant
Front / Avant
Front / Avant
Front / Avant
Front / Avant
Front /
Avant
Front / Avant
C
BL
BR
EA
A
C
BL
E
BR
1
1. Align Wood Dowels and Cam Lock Pins with guide holes and attach Top A to parts
BL , BR , E .
2. Insert two Cam Locks 1 into guide holes on each parts BL , BR , E .
3. Use Phillips screwdriver to secure Cam Locks.
15
Model # AXCBSACA04-WHAssembly

Step 10
Front /
Avant
Warning Label
FR
FL
F
8
1. Use Phillips Screws Round Head 8 to attach Back Panels F , FL , FR through guide holes.
2. Use Phillips screwdriver to secure Screws. Do not over-tighten.
A
Step 11
6
1. Use four Shelf Supports 6 for each Cabinet Shelf G in desired location .
Front /
Avant
G
G
16
Model # AXCBSACA04-WHAssembly

Step 12 4
9
5
39
1. Attach Hinge 3 to Doors H using Phillips Screws 9 into pre-drilled holes on Doors H .
2. Attach Magnet Plates 4 to top corner of Doors H using Phillips Screws 9 into
pre-drilled holes on Doors H .
3. Use Phillips screwdriver to attach Handle 5 to Doors H .
Step 13
9
1. Attach Hinge on Doors H to Sides BL , BR using Phillips Screws 9 into pre-drilled
holes on Sides BL , BR .
2. Use Phillips screwdriver to secure screws. Do not over-tighten.
BL
H
H
BR
H
17
Model # AXCBSACA04-WHAssembly

e
d
c
b
a
1. Determine the location for the unit on the wall. The Top A should be
approximately 1 ¼” above the top of the Wall Mount Bar J when mounted.
2. Place the Wall Mount Bar J at the predetermined height. Use a level to ensure
that it is straight. The flat side of Wall Mount Bar J should face outward away
from the wall. Hole (c) should align with your studs. Carefully mark the position of
each hole using the tip of the Phillips Screw 7 .
3. Install four Wall Anchors 10 to positions (a),(b),(d),(e) using a Phillips screwdriver.
Anchors are self-tapping and do not need pre-drilled holes.
4. Use your drill to create 1 hole 0.15” diameter x 2” deep at position (c) .
Step 14 - Positioning
Step 15 - Attach Wall Mount Bar to Wall
1. Screw one Phillip Screw 7 through the
raised side of the Wall Mount Bar J at position (c).
2. Screw four Phillip Screws 7 through the
raised side of the Wall Mount Bar J at positions
(a),(b),(d),(e) where Wall Anchors 10 were placed.
3. Tighten all screws. Do not over tighten.
ab
cde
10
J
7
7
7
J
18
Model # AXCBSACA04-WHAssembly

Step 16
1. Align the top of the Wall Mount Bar J with the bottom of the angled bracket
on the back of the Cabinet.
2. Gently slide the Cabinet down on to the Wall Mount Bar J .
J
JJ
19
