System Build 7445059COM User manual

7445059COM
WallCabinet
‐Unitcantipovercausingsevereinjuryordeath.
‐Anchorunittostudinwall(ifinstructedto).
‐DoNotallowchildrentoclimbonunit.
‐Putheavyitemsonlowershelvesordrawers.
B347445059COMT0
THISINSTRUCTIONBOOKLETCONTAINS IMPORTANT SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.
WARNING
ForthelatestinformationonSystemBuildproducts
followusatAmeriwoodHome
Tube
You
DateofPurchase___/___/___
LotNumber:
DoNotReturnThisProduct!
Contactourcustomerserviceteamforhelpfirst.
Call:1‐866‐452‐4081(tollfree)
Monday‐Friday9am‐5pmCST
Visit:www.systembuild.com
AssemblyDifficultyMeter
Easy Tough

ContactUs!
HelpfulHints
2
systembuild.com
DoNOTreturnthisproduct!
Contactourfriendlycustomerserviceteamfirstforhelp.
Callus!
1‐866‐452‐4081
Monday‐Friday
9am‐5pmCST
Visitsystembuild.comtoviewthe
limitedwarrantyvalidintheU.S.andCanada.
AssemblyTips
‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.

‐Identify,sortandcountthepartsbeforeattemptingassembly.

‐Compressiondowelsarelightlytappedinwithahammer.

‐Slidesarelabeledwitha
R (right)and L (left)forproperplacement.

‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe
outeredge.

‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.

‐Backpanelmustbeusedtomakesureyourunitissturdy.

‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.

‐Neverpush,pull,ordragyourfurniture.
Tube
You
PEOPLENEEDEDFORASSEMBLY:1‐2
ESTIMATEDASSEMBLYTIME:1HOUR

3
systembuild.com
BeforeYouStart

Quick
Tip
Assembly



CamLockFasteningSystem
ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.
1
3
2
4
Readthrougheachstepcarefullyandfollowtheproperorder

Separateandcountallyourpartsandhardware

Giveyourselfenoughroomfortheassemblyprocess

Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead
ScrewdriverandHammer
Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,
pleasebeawaretoslowdownandstopwhenscrewistight.
Failuretodosomayresultinstrippingthescrew.


4
systembuild.com
BoardIdentification
Notactualsize
Thispieceispaperboard
construction.Itisnotmade
fromwood,butisrequired
fortheassemblyofyourunit.
x2
SidePanel
37445315010
Top
37445315020
Bottom
37445315030
AdjustableShelf
37445316040
BackRail
37445000050
WallSupport
37445000060
LeftDoor
37445315070
RightDoor
37445315080
BottomRail
37445000090
BackPanel
K74455600
I
A
D
J
F
E
B
G
H
C

5
systembuild.com
BoardIdentification
Notactualsize
Thispieceispaperboard
construction.Itisnotmade
fromwood,butisrequired
fortheassemblyofyourunit.
A
A
B
C
D
E
F
G
H
I
J

6
systembuild.com
PartList
ActualSize
NotActualSize
(x12)
#A22570
cam lock
(x12)
#A22510
cam bolt
(x2)
#A11145
1/2" flat head screw
(x2)
#A11195
5/8" pan head screw
(x2)
#A11210
3/4" pan head screw
(x6)
#A13800
2-1/4" flat head
(x2)
#A89020
door stop
(x4)
#A23700
rubber cap
(x4)
#A80250
shelf support
(x4)
#A65615
hinge
(x1)
#A55410
latch
(x1)
#A55015
lock
(x2)
#A52995
handle
(x5)
#A21500
steel dowel

7
systembuild.com
STEP1
Proper orientation of CAM LOCK
Tip
Assembly
Quick
(x8)
#A22570
*rawedgesareshaded
Insertfourcamlocksandscrewtwocamboltsintobothsidepanels(A)asshown.Loosenscrew
inhingeandseparatehingeplatefromhinge.Mounttwohingeplatestobothsidepanels(A)as
shown.
(x4)
#A22510
(x4)
#A65615
Loosenscrewtoseparatehingeandhingeplate.
Ax2

8
systembuild.com
STEP2
*rawedgesareshaded
Attachfourcamboltstothetop(B)andbottom(C)asshown.Attachtwodoorstopstothetop
(B)withscrewsasshown.
(x8)
#A22510
(x2)
#A89020
(x2)
#A11195
B
C

9
systembuild.com
STEP3
Proper orientation of CAM LOCK
Tip
Assembly
Quick
(x4)
#A22570
Inserttwocamlocksintoboththebackrail(E)andbottomrail(I)asshown.Insertthesteel
dowelsintoeachpartasshown.
(x5)
#A21500
E
I

10
systembuild.com
STEP4
*rawedgesareshaded
Pressthesidepanels(A)ontothebackrail(E)andbottomrail(I)asshownandturnthecam
locksclockwisetolockinplace.
UNLOCKLOCK
E
I
A
A
angled edge

11
systembuild.com
STEP5
Withthefrontfinishededgesfacingup,attachthetop(B)andbottom(C)asshown.Turnthe
camlocksclockwisetolockinplace.
UNLOCKLOCK
A
A
E
B
C

12
systembuild.com
STEP6
(x2)
#A13800
Locatethewallstudsanddeterminetheplacementforthecabinet.Markthestudlocationsonthe
wallforthewallsupport(F).
Drilltwo3/16"(5mm)diameterholesinthecenterofthewallsupport(F)asshown.
Locatethewallstudsandattachthewallsupporttothewallintothestudsusingtwoscrews,
makingsurethewallsupportislevel.Hangcabinetontowallsupportasshown.
Thedistancefromthebottomedgeofthewall
support(F)tothetopsurfaceofthetop(B).
stud
wallboard
6‐9/16"
16.7cm
F
F
B

13
systembuild.com
STEP7
(x4)
#A13800
Afterthecabinetismountedtothewall,drilltwo3/16"(5mm)diameterholesintothebackrail
(E)andbottomrail(I).Usingscrews,fastenthecabinettothewallbyscrewingthroughtheback
andbottomrails(E&I).Usethesamescrewlocationthatyouusedattachingthewallsupport(F)
sothescrewsfastentoastud.
Drill and fasten screws here.
E
F
I

14
systembuild.com
STEP8
Unfoldthebackpanel.Positionthebackpanelintothecabinetopeningwiththefoldlinesofthe
backpanelrunningupanddown.Insertthebottomedgeintothegrooveinthebottom(C).Foldthe
upperendofthebackpaneluntilitinsertsintothegrooveinthetop(B).

backpanel
finishedsurface
B
J
C

15
systembuild.com
STEP9
(x4)
#A65615
Attachtwohingestoeachdoor(G&H)asshown.Attachthelatchtotheleftdoor(G)withthe
longerscrewsandthelocktotherightdoorwiththeshorterscrewsasshown.Afterthelockis
attached,pressthelockringoverthebarrelofthelockandpressuntilseated.
(x1)
#A55015
(x1)
#A55410
(x2)
#A11145
(x2)
#A11210
G
H

16
systembuild.com
STEP10
(x2)
#A52995
Attachahandletoeachdoorasshown.Pressarubbercapontoeachhandleboltasshown.
(x4)
#A23700

17
systembuild.com
STEP11
Tomountthedoors,havethehingesintheopenposition.Slidethehingesontothehingeplates
andtightenscrew"C".
Loosen screw C
Adjust door.
Tighten screw C
*side view
Loosen screw C
Turn screw B to
move door.
Tighten screw C
Loosen screw A
Adjust door.
Tighten screw A
A
B
C
G
H

18
systembuild.com
STEP12
(x4)
#A80250
Inserttheshelfsupportsatthedesiredlevelandplacetheadjustableshelf(D)ontotheshelf
supports.
D

19
systembuild.com
STEP13
Tolockdoors:

Closetheleftdoor(G)firstandpressthelatchdownsothestoppininsertsintotheholeinthe
bottom(C).

Closetherightdoor(H).Usingthekey,turnthelocksothelockingbarextendsbehindtheleft
door.
G
H
GH
C

20
systembuild.com
MaximumLoads

Warning:Riskofinjurytopersons‐donotplaceatelevisiononthisfurniture.Thisfurnitureis
notapprovedforusewithatelevision.


CertificateofConformity
1.ThiscertificateappliestotheDorelHomeFurnishings,Inc.productidentifiedbythisinstructionmanual.
2.ThiscertificateappliestocomplianceofthisproductwiththeCPSCBanonLead‐ContainingPaint(16CFR1303).
3.Thisproductisdistributedby:DorelHomeFurnishings,Inc.
410EastFirstStreetSouth
WrightCity,MO63390
636‐745‐3351
4.SiteofManufacture:TiffinOH
5.Seefrontpageofinstructionmanualfordateofmanufacture.
25lbs
11.3kg
Thisunithasbeendesignedtosupportthemaximumloadsshown.Exceedingtheseloadlimits
couldcausesagging,instability,productcollapse,and/orseriousinjury.
25lbs
11.3kg
0lbs
0kg
