Simpli Home brooklyn+max WyndenHall INT-AXCACA-EB-ALB User manual

Acadian / Normandy / Brunswick
Entryway Storage Bench
Model # INT-AXCACA-EB-ALB
1

Great quality is a right.
Thank you for shopping with Simpli Home,
America's top brand for high-value furniture.
It's time to register your product warranty.
It's quick and easy. And you'll be happy you did.
üAcvate your 1-year warranty
üAutomac entry to win a $500 gi cerficate
üEarn instant rewards and save simpli-home.com/product-registraon
2

Thank you for your purchase! We hope you enjoy it. We’d love
your feedback. Please share a review and get instant rewards!
simpli-home.com/product-review
Review your product and collect rewards!
Send us images or share them on social and qualify for instant rewards.
You may even receive store credit on your enre purchase!
simpli-home.com/share-images
Share photos and get your cash back!
3

For Fastest Customer Service:
*If you’ve purchased from a retailer and you wish to return the product, please
contact the retailer directly.
Visit Us
Visit our site directly at
www.simpli-home.com
Call Us
1-866-518-0120
Monday to Friday
9am to 5pm EST
Email Us
customerser[email protected]
Other ways to contact us…
1. Open your phone’s camera.
2. Point your phone’s camera at the QR code to scan.
3. Click on the pop up.
4. You’ll be taken to our customer service page.
5. Fill the form with your order informaon and issue.
6. Submit form.
7. A customer service associate will contact you.
4

WARNING: This item contains small parts which can be swallowed by children and
pets. Keep children and pets away during assembly. To avoid danger of suffocation,
always keep plastic bags away from children and pets.
We recommend that you assemble this unit on a carpeted floor to avoid scratches.
If using power tools, set the tool to low torque to avoid damage.
May require 2 people for ease of assembly.
Identify all the parts and hardware. Do not discard of the packaging until you have
checked that you have all the parts and hardware required. Hardware package may
have spare parts.
IMPORTANT: Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.
Safety Information
5

• Use a humidifier, preferably one with an automatic control system that can sense the
humidity level and adjust itself accordingly
Perhaps the greatest environmental damage to wood furniture comes from wide swings in
relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity
rises and falls, and in doing so it swells and shrinks. Making matters worse, it expands and
contracts unequally along different grain directions. As humidity changes, the components
of wooden objects are continually pushing and pulling against each other. This pressure
often results in parts of furniture no longer fitting together closely or becoming distorted
or breaking from their own internal stresses.
The response to relative humidity changes begins with determining the annual average RH
for your particular space. Then try to keep the RH in the space where your furniture is as
close to that average as possible, generally within about 10% up or down. De-humidify in
the summer and humidify in the winter.
Be aware that raising the temperature lowers the humidity and vice versa. Thus, modern
heating systems, which can drive down interior RH in the winter, almost invariably cause
problems for furniture. To counteract their effect, you can either modify the RH by keeping
furniture containing spaces cooler in the winter or most importantly, have a good working
humidifier for your home. A humidistat automatically works to balance the humidity in
your home so it is constant. Dry indoor air can suck enough moisture from its surroundings
to do permanent damage to wood, causing it to crack or split.
Remember, that not all woods are created equal. Two factors that help determine how
rapidly a wood will lose moisture are pore size and surface hardness. A piece made from a
dense and hard wood will dry less rapidly than pieces made from softer woods.
Furniture that is sealed and lacquered will lose moisture more slowly than an unfinished
piece while pieces with veneer finishes are not only stronger but lose moisture more
slowly than other finishes.
This furniture is designed for indoor use.
To help protect your wood furniture, take these steps:
• Don't over-humidify; that can damage wood by causing it to expand and contract
• Keep furniture out of direct sunlight, which can cause it to dry out, crack and warp
• If you can avoid it, don't put furniture near heating vents; if you can’t, keep the item 3 to
4 inches away from the wall, giving the heat and air space to circulate
• Do not use liquid or aerosol products
• To avoid marking, do not place rubber on surface (foot pads, etc.)
• For soil build-up, wipe with damp cloth & dry
• Do not use abrasive cleaners
• Dust with soft dry cloth
Care & Maintenance
6

V16-AL
LEFT SIDE
QTY 1
RIGHT SIDE
QTY 1
SEAT
QTY 1
DIVIDER
QTY 1
FRONT
QTY 1
BACKREST
QTY 1
BACK PANEL
QTY 1
BOTTOM PANEL
QTY 1
BOTTOM SUPPORT LEG
QTY 1
Up Side /
V
ertical
V16-AR V16-B
V16-C V16-D V16-E
V16-F V16-G V16-H
Part Description
7
Pre-Assembly Information Model # INT-AXCACA-EB-ALB

1 2 3
4 5
ALLEN KEY BOLT
M6 X 40 mm
QTY 8
ALLEN KEY BOLT
M6 X 30 mm
QTY 4
PHILLIPS SCREW
M3 X 12 mm
QTY 9
PHILLIPS SCREW ROUND HEAD
M4 X 15 mm
QTY 4
ALLEN KEY SCREW
M6 x 30 mm
QTY 2
6
7 8 9
ALLEN KEY
QTY 1
LID SUPPORT
QTY 1
WOOD DOWEL
8 X 30 mm
QTY 10
PHILLIPS SCREW
M4 X 25 mm
QTY 6
Required -
Phillips screwdriver
Rubber mallet
Not Included
Hardware Description
8
Pre-Assembly Information Model # INT-AXCACA-EB-ALB

Up
Side
/
Vertical
Up Side / Vertical
V16-E
V16-B V16-AR
V16-AL
V16-C
V16-G
V16-F
V16-H
V16-D
9
Components - Key Diagram Model # INT-AXCACA-EB-ALB

Step 1
1. Insert Dowel 6 into Divider V16-C .
2. Use rubber mallet to tap Dowels 6 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
3. Align pre-drilled holes on bottom of Back V16-F with Dowel 6 on Divider V16-C .
( Note: please pay close attention to the location of the 2 small guide holes which
accommodate the lid support. They need to be on the same side as the hinges .)
4. Use 2 Allen Key Screws 3 to attach Back V16-F to Divider V16-C .
Hinge
Up
Side
/
Vertical
3
Small pre-drilled holes
53
6
V16-C
V16-F
10
Assembly Model # INT-AXCACA-EB-ALB

Step 2
1. Attach Bottom Panel V16-G to Divider V16-C & Back V16-F by sliding on the gap
between Divider V16-C & the long rail on Back V16-F .
Up Side
/
V
ertical
Up
Side / V
ertical
V16-G
V16-C
V16-F
V16-F
V16-C
V16-G
11
Assembly Model # INT-AXCACA-EB-ALB

Step 3
3. Align pre-drilled holes on bottom of Front V16-D with Dowel 6 on Divider V16-C .
4. Use 2 Phillips Screws 8 to attach Divider V16-C to the middle bar on Front V16-D .
1. Insert Dowel 6 into Divider V16-C .
2. Use rubber mallet to tap Dowels 6 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
NOTE: The screwdriver is not
included in the hardware pack.
Up
Side /
V
ertical
6
8
8
V16-D
V16-C
12
Assembly Model # INT-AXCACA-EB-ALB

Step 4
1. Insert 4 Dowels 6 into each Side V16-AL , V16-AR at specified location.
each Side V16-AL , V16-AR .
3. Align pre-drilled holes on side bars of Front V16-D & Back V16-F with Dowel 6 on
each Side V16-AL , V16-AR .
2. Use rubber mallet to tap Dowels 6 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
4. Use 4 Allen Key Bolts 1 (40mm length ) to attach Front V16-D & Back V16-F to
6
6
6
1
1
5
66
6
V16-F
V16-D
V16-AL
V16-AR
V16-D
V16-F
13
13
Assembly Model # INT-AXCACA-EB-ALB

Step 5
2. Use Phillips screwdriver to tighten Screws. Do not over-tighten.
1. Attach Bottom Support Leg V16-H into pre-drilled holes of Bottom Panel V16-G
using 4 Phillips Screws 8 .
NOTE: The screwdriver is not
included in the hardware pack.
8
V16-G
V16-H
V16-H
14
14
Assembly Model # INT-AXCACA-EB-ALB

2. Use phillips screwdriver to tighten Screws. Do not over-tighten.
1. Attach Lid Support 4 into pre-drilled holes of Seat V16-B and Divider V16-C
using Phillips Screws Round Head 9 .
Step 6
1. Attach Seat V16-B to 3 Hinges on Back V16-F using Phillips Screws 7
( using guide holes underneath of Seat ).
2. Use phillips screwdriver to tighten Screws. Do not over-tighten.
Step 7
NOTE: The screwdriver is not
included in the hardware pack.
7
4
9
V16-B
V16-F
V16-C
V16-B
15
Assembly Model # INT-AXCACA-EB-ALB

Step 8
1. Attach Backrest V16-E to back of Sides V16-AL , V16-AR using Allen Key Bolt 2
into pre-drilled holes.
2. Use Allen Key 5 to tighten Bolts. Do not over-tighten.
2
2
2
5
V16-E
V16-AR
V16-AL
16
Assembly Model # INT-AXCACA-EB-ALB
