Simpli Home Wyndenhall Brooklyn + Max AXCBSACA07-WH User manual

ACADIAN / NORMANDY / BRUNSWICK
SPACE SAVER CABINET
MODEL # AXCBSACA07-WH
/241
TM
TM
SI
M P
HOME®
LIFE BY DESIG N

/242
TM
TM
SI
M P
HOME®
LIFE BY DESIG N
Questions, problems, assembly help, missing parts?
No need to return the product, we will gladly help and ship your
replacement parts free of charge
Please call Customer Service at 1-866-518-0120 ext. 262
Monday to Friday between 9 am –4 pm EST
or go to
www.simpli-home.com/parts request
In order to assist you in a timely manner, please have the following
information ready:
Model # _________________Part Number or Letter_____________________
Purchased at ____________Date of Purchase _________________________
If you wish to return the product, please contact the retailer where the
product was purchased.

/243
IMPORTANT : Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.
CAUTION: Injuries and damage can occur from furniture tip over if product is
not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint
provided with the product. Consult our assembly instructions for help.
If the Furniture Anti-Tipping Restraint kit is not in the box, please contact our
customer service department in order to obtain another kit before using the
furniture.
Identify all the parts and hardware. Do not discard of the packaging until you
have checked that you have all of the parts and hardware required.
Hardware package may have spare parts.
WARNING: This item contains small parts which can be swallowed by
children and pets. Keep children and pets away during assembly. To avoid
danger of suffocation, always keep plastic bags away from children and pets.
We recommend that you assemble this unit on a carpeted floor to avoid
scratches. If using power tools, set the tool to low torque to avoid damage.
May require 2 people for ease of assembly.
SAFETY INFORMATION

/244
Perhaps the greatest environmental damage to wood furniture comes from wide swings in
relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity
rises and falls, and in doing so it swells and shrinks. Making matters worse, it expands and
contracts unequally along different grain directions. As humidity changes, the components
of wooden objects are continually pushing and pulling against each other. This pressure
often results in parts of furniture no longer fitting together closely or becoming distorted
or breaking from their own internal stresses.
The response to relative humidity changes begins with determining the annual average RH
for your particular space. Then try to keep the RH in the space where your furniture is as
close to that average as possible, generally within about 10% up or down. De-humidify in
the summer and humidify in the winter.
Be aware that raising the temperature lowers the humidity and vice versa. Thus, modern
heating systems, which can drive down interior RH in the winter, almost invariably cause
problems for furniture. To counteract their effect, you can either modify the RH by keeping
furniture containing spaces cooler in the winter or most importantly, have a good working
humidifier for your home. A humidistat automatically works to balance the humidity in
your home so it is constant. Dry indoor air can suck enough moisture from its surroundings
to do permanent damage to wood, causing it to crack or split.
Remember, that not all woods are created equal. Two factors that help determine how
rapidly a wood will lose moisture are pore size and surface hardness. A piece made from a
dense and hard wood will dry less rapidly than pieces made from softer woods.
Furniture that is sealed and lacquered will lose moisture more slowly than an unfinished
piece while pieces with veneer finishes are not only stronger, but lose moisture more
slowly than other finishes.
To help protect your wood furniture, take these steps:
·Use a humidifier, preferably one with an automatic control system that can sense the
humidity level and adjust itself accordingly. Don't over-humidify; that can damage wood
by causing it to expand and contract.
·Keep furniture out of direct sunlight, which can cause it to dry out, crack and warp.
·If you can avoid it, don't put furniture near heating vents. If you must, keep the piece 3
to 4 inches away from the wall, giving the heat and air space to circulate.
·Dust with soft dry cloth.
·Do not use liquid or aerosol products.
·To avoid marking, do not place rubber on surface (foot pads, etc.)
·For soil build-up, wipe with damp cloth & dry.
·Do not use abrasive cleaners.
CARE and MAINTENANCE
IMPORTANT : Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.

PRE-ASSEMBLY INFORMATION MODEL # AXCBSACA07-WH
/245
.A.BL .BR
NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST)
PART DESCRIPTION
TOP
QTY 1 TOP LEFT SIDE
QTY 1 TOP RIGHT SIDE QTY 1
.CL .CR .D
.E.F.G
BOTTOM LEFT SIDE
QTY 1 BOTTOM RIGHT SIDE QTY 1 MIDDLE SHELF QTY 1
BOTTOM SHELF
QTY 1 TOP BAR QTY 1 BOTTOM BAR QTY 1
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant

PRE-ASSEMBLY INFORMATION MODEL # AXCBSACA07-WH
/246
.H.I.J
NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST)
PART DESCRIPTION
.JL .JR .K
DIVIDER
QTY 1
Front /
Avant
DOOR (L&R Same)
QTY 2 BOTTOM BACK PANEL
QTY 1
LEFT BACK PANEL
QTY 1 RIGHT BACK PANEL QTY 1
SHELF
QTY 2

/247
PRE-ASSEMBLY INFORMATION MODEL # AXCBSACA07-WH
.1
NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST)
HARDWARE DESCRIPTION
Required -
Flathead screwdriver
Phillips screwdriver
Rubber mallet
Not Included
CAM LOCK PIN
CAM LOCK
QTY 16 SETS
WOOD DOWEL
Ø8 X 30mm
QTY 13 HINGE
QTY 4 MAGNET AND PLATE
QTY 2 SETS
PHILLIPS SCREW
M4 X 50mm
QTY 6
PHILLIPS SCREW
M4 X 15mm
QTY 8
HANDLE
M4 X 25 mm
QTY 2 SETS
PHILLIPS SCREW
ROUND HEAD
M4 X 15mm
QTY 27
.12
FURNITURE TIP
OVER RESTRAINT
QTY 2 SETS
a.M4X25mm-QTY2
(1isextra)
b.M4X15mm-QTY1
c.M4X25mm-QTY1
.11 .10 .9
.8 .7 .6 .5
.4 .3 .2
BRACKET
QTY 2
SHELF SUPPORT
QTY 8
PHILLIPS SCREW
M3 X 15mm
QTY 24

COMPONENTS-KEY DIAGRAM MODEL # AXCBSACA07-WH
/248
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
A
F
BL
BR
CL
CR
D
E
G
H
I
I
J
JR
JL
K
K

/249
STEP-1
ASSEMBLY MODEL # AXCBSACA07-WH
P
X
1
1. Attach Cam Lock Pins 1 into pre-drilled holes on each part A , BL , BR .
2. Use Phillips screwdriver to secure Cam Lock Pins. Do not over-tighten.
3. Insert Dowels 2 into guide holes on parts F , H .
4. Use rubber mallet to tap Dowels 2 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
2
22H
F
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
1
1
1
1
1
A
BR
BL

/2410
STEP-2
ASSEMBLY MODEL # AXCBSACA07-WH
1. Align Wood Dowels with guide holes and attach Divder H to Middle Shelf D .
2. Use two Phillips Screws 8 to attach Middle Shelf D through guide holes from
Middle Shelf D to pre-drilled holes of Divider H .
3. Use Phillips screwdriver to secure Screws. Do not over-tighten.
8
8
Front / Avant
Front / Avant
H
D
D
H
4
10
10
4.AttachMagnets4usingPhillipsScrews10intopre-drilledholesDividerH.
5. Use Phillips screwdriver to secure screws.Do not over-tighten.

/2411
STEP-3
ASSEMBLY MODEL # AXCBSACA07-WH
3. Insert two Cam Locks 1 into guide holes on part D .
4. Use Phillips screwdriver to secure Cam Locks.
1. Align Wood Dowels with guide holes on part BL and attach part F to Left Side BL .
2. Align Cam Lock Pins with guide holes on part D and attach part D to Left Side BL .
Front / Avant
Front / Avant
BL
H
F
D
Front / Avant
H
F
D
BL
Front / Avant
1
1

/2412
STEP-4
ASSEMBLY MODEL # AXCBSACA07-WH
1. Repeat Step-3 for the Right Side BR .
Front / Avant
Front / Avant
F
H
D
BL
BR
Front / Avant
F
H
D
BL
Front / Avant
BR
1
1

/2413
STEP-5
ASSEMBLY MODEL # AXCBSACA07-WH
Front / Avant
Front / Avant
Front / Avant
A
BL
H
BR
Front / Avant
Front / Avant
1. Align Cam Lock Pins with guide holes
and attach part A to Sides BL , BR , H .
Front / Avant
Front / Avant
BL
H
BR
Front / Avant
A
1
2. Insert two Cam Locks 1 into guide holes on each part BL , BR , H .
3. Use Phillips screwdriver to secure Cam Locks.

/2414
STEP-6
ASSEMBLY MODEL # AXCBSACA07-WH
P
X
1. Attach three Cam Lock Pins 1 into pre-drilled holes on each part CL , CR .
2. Use Phillips screwdriver to secure Cam Lock Pins. Do not over-tighten.
3. Insert Dowels 2 into guide holes on parts G , CL , CR .
4. Use rubber mallet to tap Dowels 2 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
1
2
2
G
CL
CR
1
1
1
1
2
2
2
Front /
Avant
Front /
Avant

/2415
STEP-7
ASSEMBLY MODEL # AXCBSACA07-WH
Front / Avant
1. Align Wood Dowels and Cam Lock Pins with
guide holes and attach parts E , G to part CL .
2. Insert Cam Locks 1 into guide holes on parts E , G .
3. Use Phillips screwdriver to secure Cam Locks.
Front / Avant
ECL
G
CL
E
G
11

/2416
STEP-8
ASSEMBLY MODEL # AXCBSACA07-WH
1. Repeat Step-7 for the Bottom Right Side CR .
Front / Avant
Front / Avant
CL
CL
CR
CR
E
E
G
G
1
1

/2417
STEP-9
ASSEMBLY MODEL # AXCBSACA07-WH
1. Align Wood Dowels with guide holes on top fame and attach top frame to
bottom frame.
2. Use four Phillips Screws 8 into guide holes on bottom fame .
3.AttachBracket5usingPhillipsScrews9intopre-drilledholesontopframe
andbottomframe.
4. Use Phillips screwdriver to secure Screws. Do not over-tighten.
Front /
Avant
Front /
Avant
Front /
Avant
9
5
8

/2418
STEP-10
ASSEMBLY MODEL # AXCBSACA07-WH
Front /
Avant
Note:
Thebackofthecabinetframedoesnothave
pre-drilledholestoattachthebackpanels.
11
1. Attach the Back Panels J , JL , JR to back frame using Phillips Screws Round
Head 11 through guide holes from Back Panels.
2. Use Phillips Screwdriver to tighten screws. Do not over-tighten.
Warning Label
JR
JL
J

/2419
STEP-11
ASSEMBLY MODEL # AXCBSACA07-WH
1. Use four Shelf Supports 7 for each Shelf K in desired location .
KK
7
7

/2420
STEP-12
ASSEMBLY MODEL # AXCBSACA07-WH
II
3
10
10
4
6
6
1.AttachHinges3toDoorsIusingPhillipsScrews10intopre-drilledholesonDoorsI.
2.AttachMagnetPlates4totopcornerofDoorsIusingPhillipsScrews10into
pre-drilledholesonDoorsI.
3. UsePhillipsscrewdrivertoattachHandle6toDoorsI.
